Transistors
Publication date : May 2007 SJC00384AED 1
This product complies with the RoHS Directive (EU 2002/95/EC).
2SA2162G
Silicon PNP epitaxial planar type
For general amplification
Complementary to 2SC6036G
Features
Low collector-emitter saturation voltage VCE(sat)
SSS-Mini type package, allowing downsizing of the equipment and automatic
insertion through the tape packing
Absolute Maximum Ratings Ta= 25°C
Parameter Symbol Rating Unit
Collector-base voltage (Emitter open) VCBO –15 V
Collector-emitter voltage (Base open) VCEO –12 V
Emitter-base voltage (Collector open) VEBO –5 V
Collector current IC–500 mA
Peak collector current ICP –1 A
Collector power dissipation PC100 mW
Junction temperature Tj125 °C
Storage temperature Tstg –55 to +125 °C
Electrical Characteristics Ta= 25°C±3°C
Parameter Symbol Conditions Min Typ Max Unit
Collector-base voltage (Emitter open) VCBO IC= –10 mA, IE= 0 –15 V
Collector-emitter voltage (Base open) VCEO IC= –1 mA, IB= 0 –12 V
Emitter-base voltage (Collector open) VEBO IE= –10 mA, IC= 0 –5 V
Collector-base cutoff current (Emitter open) ICBO VCB = –10 V, IE= 0 – 0.1 mA
Forward current transfer ratio hFE VCE = –2 V, IC= –10 mA 270 680 
Collector-emitter saturation voltage VCE(sat) IC= –200 mA, IB= –10 mA –250 mV
Transition frequency fTVCB = –2 V, IE= 10 mA, f = 200 MHz 200 MHz
Collector output capacitance
(Common base, input open circuited) Cob VCB = –10 V, f = 1 MHz 4.5 pF
Note) Measuring methods are based on JAPANESE INDUSTRIAL STANDARD JIS C 7030 measuring methods for transistors.
Package
Code
SSSMini3-F2
Marking Symbol: 2U
Pin Name
1. Base
2. Emitter
3. Collector

2SA2162G
2SJC00384AED
This product complies with the RoHS Directive (EU 2002/95/EC).
PCTaICVCE ICVBE
VCE(sat) IChFE ICCob VCB
020 40 60 80 100 120 140
0
20
40
60
80
100
120
2SA2162_ PC-Ta
Collector power dissipation PC(mW)
Ambient temperature Ta(°C)
0− 0.5 −1.0 −1.5 −2.0 −2.5 −3.0
0
−10
−20
−30
−40
−50
−60
−70
2SA2162_ IC-VCE
Collector current IC(mA)
Collector-emitter voltage VCE (V)
−140 µA
−120 µA
−100 µA
−80 µA
−60 µA
−40 µA
−20 µA
IB=−160 µA
Ta =25°C
0− 0.2 − 0.4 − 0.6 − 0.8 −1.0 −1.2 −1.4
0
−10
−20
−30
−40
−50
−60
−100
−70
−80
−90
2SA2162_ IC-VBE
Collector current IC(mA)
Base-emitter voltage VBE (V)
VCE =−2 V
Ta =85°C
25°C
−25°C
− 0.1 −1 −10 −100 −1 000
− 0.01
− 0.1
−1
2SA2162_ VCE(sat)-IC
Collector-emitter saturation voltage VCE(sat) (V)
Collector current IC(mA)
IC / IB =20
Ta =85°C
25°C
−25°C
−1 −10 −100 −1 000
0
100
200
300
400
500
600
2SA2162_ hFE-IC
Forward current transfer ratio hFE
Collector current IC(mA)
VCE =−2V
Ta =85°C
25°C
−25°C
0 5 10
1
10
100
2SA2162_ Cob-VCB
Collector output capacitance (Common base, input open circuited) Cob (pF)
Collector-base voltage VCB (V)
f = 1 MHz
Ta= 25°C

This product complies with the RoHS Directive (EU 2002/95/EC).
SSSMini3-F2 Unit: mm
0.30 +0.05 −0.02
0.20 +0.05 −0.02 0.13 +0.05
−0.02
(0.4)
(0.4)
0.80 ±0.05
0.80 ±0.05
0.51 ±0.04
1.20 ±0.05
1.20 ±0.05
0.20 ±0.05
3
12
(0.27)
5°
0 to 0.05 (0.5)
5°
