Transistors
Publication date : October 2008 SJC00420AED 1
This product complies with the RoHS Directive (EU 2002/95/EC).
2SC1318
Silicon NPN epitaxial planar type
For low-frequency power amplification and driver amplification
Complementary to 2SA0720
Features
Low collector-emitter saturation voltage VCE(sat)
Complementary pair with 2SA0720
Absolute Maximum Ratings Ta= 25°C
Parameter Symbol Rating Unit
Collector-base voltage (Emitter open) VCBO 60 V
Collector-emitter voltage (Base open) VCEO 50 V
Emitter-base voltage (Collector open) VEBO 7 V
Collector current IC0.5 A
Peak collector current ICP 1 A
Collector power dissipation PC625 mW
Junction temperature Tj150 °C
Storage temperature Tstg –55 to +150 °C
Electrical Characteristics Ta= 25°C±3°C
Parameter Symbol Conditions Min Typ Max Unit
Collector-base voltage (Emitter open) VCBO IC= 10 mA, IE= 0 60 V
Collector-emitter voltage (Base open) VCEO IC= 10 mA, IB= 0 50 V
Emitter-base voltage (Collector open) VEBO IE= 10 mA, IC= 0 7 V
Collector-base cutoff current (Emitter open) ICBO VCB = 20 V, IE= 0 0.1 mA
Forward current transfer ratio hFE1 *VCE = 10 V, IC= 150 mA 85 340

hFE2 VCE = 10 V, IC= 500 mA 40
Collector-emitter saturation voltage VCE(sat) IC= 300 mA, IB= 30 mA 0.35 0.60 V
Base-emitter saturation voltage VBE(sat) IC= 300 mA, IB= 30 mA 1.1 1.5 V
Transition frequency fTVCB = 10 V, IE= –50 mA, f = 200 MHz 200 MHz
Collector output capacitance
(Common base, input open circuited)
Cre VCB = 10 V, IE= 0, f = 1 MHz 6 15 pF
Note) 1. Measuring methods are based on JAPANESE INDUSTRIAL STANDARD JIS C 7030 measuring methods for transistors.
2. *: Rank classification
Rank Q R S
hFE1 85 to 170 120 to 240 170 to 340
Package
Code
TO-92B-B1
Pin Name
1. Emitter
2. Collector
3. Base

2SC1318
2SJC00420AED
This product complies with the RoHS Directive (EU 2002/95/EC).
PCTaICVCE ICIB
VCE(sat) ICVBE(sat) IC hFE IC
0 16040 12080
0
800
600
200
400
Collector power dissipation PC(mW)
Ambient temperature Ta(°C)
2SC1318_PC-Ta
0 20164 128
0
0.8
0.6
0.2
0.5
0.7
0.4
0.1
0.3
Ta=25°C
IB=10 mA
9 mA
8 mA
7 mA
6 mA
5 mA
4 mA
3 mA
2 mA
1 mA
Collector current IC(A)
Collector-emitter voltage VCE (V)
2SC1318_IC-VCE
0.01 0.1 1 10
0.01
0.1
1
10
100 IC/ IB=10
Ta=75°C
25°C
−25°C
Collector-emitter saturation voltage VCE(sat) (V)
Collector current IC(A)
2SC1318_VCE(sat)-IC
0.01 0.1 1 10
0.01
0.1
1
10
100 IC/ IB=10
Ta=75°C
−25°C
25°C
Base-emitter saturation voltage VBE(sat) (V)
Collector current IC(A)
2SC1318_VBE(sat)-IC
0.01 0.1 1 10
0
300
250
200
150
100
50
VCE =10 V
Ta=75°C
25°C
−25°C
Forward current transfer ratio hFE
Collector current IC(A)
2SC1318_hFE-IC
−1−10 −100
0
240
200
160
120
80
40
VCB =10 V
Ta=25°C
Transition frequency fT(MHz)
Emitter current IE(mA)
2SC1318_fT-IE
1 10 100
0
12
10
8
6
4
2
IE=0
f =1 MHz
Ta=25°C
Collector-base voltage VCB (V)
2SC1318_Cob-VCB
Collector output capacitance (Common base, input open circuited) Cob (pF)
1 10 100 1000
0
120
100
80
60
40
20
IC=2 mA
Ta=25°C
Base-emitter resistance RBE (kΩ)
2SC1318_VCER-RBE
Collector-emitter voltage (Resistor between B and E) VCER (V)
0 1082 64
0
0.8
0.6
0.2
0.5
0.7
0.4
0.1
0.3
VCE =10 V
Ta=25°C
Base current IB(mA)
Collector current IC(A)
2SC1318_IC-IB
fTIECob VCB VCER RBE

2SC1318
SJC00420AED 3
This product complies with the RoHS Directive (EU 2002/95/EC).
ICEO TaSafe operation area
0 20016040 12080
1
10
102
103
104
VCE =10 V
Ambient temperature Ta(°C)
ICEO (Ta)
ICEO (Ta=25°C)
2SC1317_ICEO-Ta
0.1 1 10 100
0.001
0.01
0.1
1
10 Single pulse
Ta=25ºC
t =10 ms
t =1 s
DC
ICP
IC
Collector current IC(A)
Collector-emitter voltage VCE (V)
2SC1318_ASO

2SC1318
4SJC00420AED
This product complies with the RoHS Directive (EU 2002/95/EC).
TO-92-B1 Unit: mm
5.0 ±0.2
5.1 ±0.212.9 ±0.5
0.7 ±0.2
0.7 ±0.1
0.45
4.0 ±0.2
0.45
2.3 ±0.2
123
2.5
2.5
+0.15
−0.1
+0.6
−0.2
+0.15
−0.1
+0.6
−0.2
