Panasonic Zener Diodes MAZQxxx Series User manual

Zener Diodes
Publication date: January 2009 SKE00030CED 1
This product complies with the RoHS Directive (EU 2002/95/EC).
MAZQxxx Series
Silicon planar type
For constant voltage, constant current, waveform clipper and surge
absorption circuit
Features
Optimum for high-density mounting
Low noise type
Absolute Maximum Ratings Ta= 25°C
Parameter Symbol Rating Unit
Repetitive peak forward current IFRM 200 mA
Total power dissipation *PT120 mW
Junction temperature Tj150 °C
Storage temperature Tstg -55 to +150 °C
Note) *: PT= 120 mW achieved with a printed circuit board.
Electrical Characteristics Ta= 25°C±3°C
Parameter Symbol Conditions Min Typ Max Unit
Forward current VFIF= 10 mA 0.9 1.0 V
Zener voltage *VZIZSpecified value Refer to the list of the
electrical characteristics
within part numbers
V
Zene operating resistance RZIZSpecified value W
Reverse current IRVRSpecified value mA
Note) 1. Measuring methods are based on JAPANESE INDUSTRIAL STANDARD JIS C 7031 measuring methods for diodes.
2. Absolute frequency of input and output is 5 MHz.
3. The temperature must be controlled 25°C for VZmesurement. VZvalue measured at other temperature must be adjusted to VZ(25°C)
4. *: VZguaranted 20 ms after current flow.
Electrical Characteristics within Part Numbers Ta= 25°C±3°C
Part number
Zener voltage
VZ(V)
Zener
operating
resistance
RZ(W)
Reverse current
IR( mA) Marking symbol
Min Typ Max IZ
(mA) Max IZ (mA) Max VR (V)
MAZQ062 5.8 6.2 6.6 5 30 5 0.2 4.0 E
MAZQ068 6.4 6.8 7.2 5 20 5 0.1 4.0 F
MAZQ100 9.40 10.00 10.60 5 30 5 0.05 7 L
MAZQ200 18.80 20.00 21.20 5 80 5 0.05 15.0 V
MAZQ300 28.00 30.00 32.00 2 160 2 0.05 23.0 Y
Package
Code
USSMini2-F1
Pin Name
1: Anode
2: Cathode
Marking Symbol
Refer to the list of the electrical characteristics
within part numbers

MAZQxxx Series
2SKE00030CED
This product complies with the RoHS Directive (EU 2002/95/EC).
IZVZ IFVF IRVR
46 8 10
10−3
10−1
10−2
1
10
102
103
MAZQxxx_ IZ - VZ
Zener current IZ(mA)
Zener voltage VZ(V)
Ta =25°C
MAZQ062 MAZQ068
10−11 10 102
10−1
1
10
102
103
MAZQxxx_ RZ - IZ
Zener operating resistance RZ(Ω)
Zener current IZ(mA)
Ta =25°C
MAZQ062
MAZQ068
02 4 6
0
10
20
30
40
50
MAZQxxx_ Ct - VR
Terminal capacitance Ct(pF)
Reverse voltage VR(V)
Ta =25°C
MAZQ062
MAZQ068
RZIZCtVR
00.4 0.8 1.2
10−3
10−1
10−2
1
10
102
103
MAZQxxx_ IF - VF
Forward current IF(mA)
Forward voltage VF(V)
Ta =25°C
02 4 6
MAZQxxx_ IR - VR
Reverse current IR(nA)
Reverse voltage VR(V)
Ta =25°C
MAZQ062
MAZQ068
10−4
10−1
10−2
10−3
1
10
102
103
Characteristics charts of MAZQ100
79 11 13
10−3
10−1
10−2
1
10
102
103
MAZQxxx_ IZ - VZ
Zener current IZ(mA)
Zener voltage VZ(V)
Ta =25°C
00.4 0.8 1.2
10−3
10−1
10−2
1
10
102
103
MAZQxxx_ IF - VF
Forward current IF(mA)
Forward voltage VF(V)
Ta =25°C
04 128
MAZQxxx_ IR - VR
Reverse current IR(nA)
Reverse voltage VR(V)
Ta =25°C
10−1
10−2
10−3
1
10
102
IZVZ IFVF IRVR
Characteristics charts of MAZQ062, MAZQ068

MAZQxxx Series
SKE00030CED 3
This product complies with the RoHS Directive (EU 2002/95/EC).
RZIZCtVR
10−11 10 102
10−1
1
10
102
103
MAZQxxx_ RZ - IZ
Zener operating resistance RZ(Ω)
Zener current IZ(mA)
Ta =25°C
16 2018 22 24 26
10−1
10−2
1
10
102
MAZQxxx_ IZ - VZ
Zener current IZ(mA)
Zener voltage VZ(V)
Ta =25°C
00.4 0.8 1.2
10−3
10−1
10−2
1
10
102
103
MAZQxxx_ IF - VF
Forward current IF(mA)
Forward voltage VF(V)
Ta =25°C
510 2015
MAZQxxx_ IR - VR
Reverse current IR(nA)
Reverse voltage VR(V)
Ta =25°C
10−2
10−1
10−3
10−4
1
IZVZ IFVF IRVR
04 8 12
0
5
10
15
20
25
30
MAZQxxx_ Ct - VR
Terminal capacitance Ct(pF)
Reverse voltage VR(V)
Ta =25°C
10−11 10 102
10−1
1
10
102
103
MAZQxxx_ RZ - IZ
Zener operating resistance RZ(Ω)
Zener current IZ(mA)
Ta =25°C
05 1510 20
0
5
10
15
20
25
30
MAZQxxx_ Ct - VR
Terminal capacitance Ct(pF)
Reverse voltage VR(V)
Ta =25°C
RZIZCtVR
Characteristics charts of MAZQ200

MAZQxxx Series
4SKE00030CED
This product complies with the RoHS Directive (EU 2002/95/EC).
20 25 3530 40 45 50
10−1
10−2
1
10
102
MAZQxxx_ IZ - VZ
Zener current IZ(mA)
Zener voltage VZ(V)
Ta =25°C
010 3020
MAZQxxx_ IR - VR
Reverse current IR(nA)
Reverse voltage VR(V)
Ta =25°C
10−5
10−4
10−6
10−7
10−3
10−11 10 102
10−1
1
10
102
103
MAZQxxx_ RZ - IZ
Zener operating resistance RZ(Ω)
Zener current IZ(mA)
Ta =25°C
IZVZ IRVR RZIZ
010 3020 40
0
1
2
3
7
6
5
4
8
9
10
MAZQxxx_ Ct - VR
Terminal capacitance Ct(pF)
Reverse voltage VR(V)
Ta =25°C
CtVR
Characteristics charts of MAZQ300

MAZQxxx Series
SKE00030CED 5
This product complies with the RoHS Directive (EU 2002/95/EC).
USSMini2-F1 Unit: mm
0.60 ±0.05
2
1
0.85 ±0.05 0.075 ±0.050
0.075 ±0.050
1.00 ±0.05
0.20 +0.05 −0.02
0.13 +0.05 −0.02
0.38 +0.02
−0.03
5°
5°
0.15 max.
