KX-P1150 Dot Matrix Printer
Print Method
Printhead and Life
Print Direction
Print Speed
(charactersper sec)
Near Letter Quality
Fonts
Character Matrix(HxV)
Printing Sizes
Characters Per Line
Lines Per Inch
Character Sets
Bit Image (matrix)
Line Feed Time
Setup Disk
Tractor Feed
Paper Feed
Paper Specifications
Emulations*
Interface
Buffer
Noise Level
Environment
Reliability
Ribbon
Warranty
Dimensions & Weight
Power Consumption
Options
Features:
• 240 cps maximum draft print speed for high productivity
• Flat-belt push tractor simplifies loading continuous paper and
provides for greater application versatility
• 11.7" max. paper width enables landscape orientation of
8.5" x 11" paper for greater printing flexibility
• Easy-to-use setup disk provides on-screen prompts for modifying
the printer's parameters
• Windows 3.1* printer driver enables full accessibility of the
printer's features in this popular environment
• Energy Star compliancy verifies Panasonic's commitment to
helping preserve the environment
Panasonic Computer Peripheral Company
Division of Panasonic Communications & Systems Company
Unit of Matsushita Electric Corporation of America
Imaging Products Group
Headquarters: 2 Panasonic Way, Secaucus, NJ 07094
O n l i n e S p e c S h e e t
w w w . p a n a s o n i c . c o m / a l i v e
All product/brand names are trademarks or registered trademarks of their respective holders.
Specifications subject to change without notice.
Product may be subject to export control regulations.
Copyright ©1997 Matsushita Electric Corporation of America. All rights reserved.
Impact Serial Dot Matrix
9-pin (0.3 mm wire diameter), 200 mil
strokes; 100 mil chr (draft)
Text: Bidirectional (user selectable unidirec-
tional) logic seeking; Graphics; Unidirectional
Draft NLQ
Micron 240 cps 32 cps
Elite 192 cps 38 cps
Pica 160 cps 32 cps
Courier, Bold PS, Roman, Sans Serif
Draft 9 x 9; NLQ 18 x 18
5,6,7.5, 8.5,10,12,15,17,20 cpi & PS
40,48,60,68,80,96,120, 137, & 160 cpl
6,8, 7/72, n/72, n/216 & programmable Ipi
96 ASCII characters, 96 italic ASCII characters,
38 International characters -14 language sets
& legal, 158 IBM special characters
240 x 216 dots per inch
Approx 100 msec (with 1/6 inch line feeding)
3 1/2" disk controls all printer functions.
Includes a command reference program and
a Windows* version 3.1 driver.
Push
Path: Method:
Top Friction (single sheets)
Cut Sheet Feeder (optional)
Rear Push Tractor (adjustable)
Continuous: 4.0 to 10.0 inches, 16 to 24 lbs.
Single Sheet: 4.0 to 11.7 inches, 14 to 24 lbs.
Envelopes: #6 & #10 Copies: Up to original
+3 non carbon copies Thickness: Maximum
thickness less than 0.013 in.
Epson FX-850, IBM Proprinter Ill
Centronics parallel
4K (standard), additional 32K (optional)
55 dBA
Operating: 50°F to 95°F; 20 to 80% humidity
Storage: -4°F to 140°F; 10 to 90% humidity
4000 hrs MTBF @ 25% duty cycle
Black seamless ribbon; 4 mil chr
draft/rolling ASCII (KX-P115)
Limited 2 years - parts & labor
See your dealer for details.
17.1(W) x 12.4(D) x 5.3 (H) inches; 10.6 lbs.
Standby 5.66W; maximum 150W
Automatic Single Bin Cut Sheet Feeder
(KX-PT12) 32K Expansion Buffer Chip (KX-P44)
KX-P1150 Specifications
