Panasonic PT-DW5000 System manual

•High image quality
-Native WXGA (1,280 x 768) panel
-Ultra bright 4,500 lumens
-High 1,600:1 contrast ratio*1
- High uniformity of brightness and color
- Progressive cinema scan (3/2 pulldown)
- Dynamic sharpness control
•High reliability and easy maintenance
- Liquid cooling system
- Dustproof design with sealed optical block
-Dual lamp system and lamp relay function
- Optional long-life lamp
-Easy replacement of dust filter and lamp
•Flexible system applications
- Lens-centered design
- Horizontal/vertical lens shift
- Optional lenses for various venues
-Easy lens replacement
-Multiple terminals including DVI-D
- Control panel and wireless remote control
-Quiet operation: 29 dB*2
• Networking
- Wired LAN system
-Web browser control/monitoring
-E-mail message alert
- Compliant with PJLink™
•Other valuable features
- Direct power off
- Anti-theft features with chain opening
- Customizable top panel
-Flexibble angle setting
- Mechanical shutter
*1In high contrast mode
*2In low lamp power mode
-1 -
SPEC FILE
PRODUCT NO.: PT-DW5000/DW5000L
PRODUCT NAME: DLP™-Based Projectors
MAJOR FEATURES
The PT-DW5000L is not equipped with a lens.
TENTATIVE

2
PT-DW5000/DW5000L
DLP™-Based Projectors
SPEC FILE
Specifications
Main Unit
Power supply: North America: 120 V AC, 50/60 Hz
Europe: 220–240 V AC, 50/60 Hz
Power consumption: North America: 770 W (770 VA) (10 W during standby mode with fan stopped)
Europe: 750 W (790 VA) (15 W during standby mode with fan stopped)
DMD™ device: Panel size: 0.65˝ diagonal (15:9 aspect ratio)
Display method: DMD™ x 1, DLP™ system
Pixels: 983,040 (1,280 x 768) x 1, total of 983,040 pixels
Lens: PT-DW5000: Powered zoom/focus lenses (1:1.8–1:2.5), F 1.7–2.0, f 25.6–33.8 mm
PT-DW5000L: Optional poweredzoom/focus lenses
Lamp: 300 W UHM™ lamps (x 2) (dual lamp system)
Screen size: 50–600 inches
Brightness: 4,500 lumens (dual lamp, high power mode)
Center-to-corner uniformity: 90%
Contrast: 1,600:1 (full on/full off, contrast mode: high)
800:1 (full on/full off, contrast mode: normal)
Resolution: RGB: 1,280 x 768 pixels
(1,600 x 1,200 pixels compatible, compression mode)
Video: 560 TV lines
Scanning frequency: RGB: Horizontal: 15–91 kHz, Vertical: 50–85 Hz,
Dot clock: 108 MHz or lower
YPBPR(YCBCR): 480i: fH15.75 kHz; fV60 Hz, 576i: fH15.63 kHz; fV50 Hz,
480p: fH31.5 kHz; fV60 Hz, 576p: fH31.25 kHz; fV50 Hz,
720/60p: fH45 kHz; fV60 Hz, 720/50p: fH37.5 kHz; fV50 Hz,
1035/60i: fH33.75 kHz; fV60 Hz, 1080/60i: fH33.75 kHz; fV60 Hz,
1080/50i: fH28.13 kHz; fV50 Hz
S-Video/Video: Horizontal: 15.75/15.63 kHz, Vertical: 50/60 Hz,
(NTSC, NTSC4.43, PAL, PAL60, PAL-N, PAL-M, SECAM)
Optical axis shift: Horizontal (manual) and vertical (powered),
horizontal: ±10% (6:4– 4:6), vertical: 0–50% (0:10 –10:10)
Keystone correction range: Vertical: ±30° (with standard lens)
Installation: Ceiling/floor, front/rear
Terminals: DVI-D IN: DVI-D 24-pin x 1, DVI 1.0 compliant, HDCP compatible, for single link only
EDID 1 480p, 576p, 720/60p, 720/50p, 1080/60i, 1080/50i
EDID 2 For non-interlaced signals only,
Display mode: From VGA (640 x 480) to SXGA (1,280 x 1,024) ,
Dot clock: 25 MHz–108 MHz
RGB 1 IN: BNC x 5
R, G, B: G: 0.7 Vp-p (G: 1.0 Vp-p for sync on G), 75Ω,
B, R: 0.7 Vp-p, 75Ω
HD/VD, SYNC: 1.4 Vp-p–5.0 Vp-p, 75Ω(positive/negative)
Y, PB, PR:Y: 1.0 p-p, 75Ω, PB,/PR:0.7 Vp-p, 75Ω
RGB 2 IN: D-sub HD 15-pin x 1
R, G, B: G: 0.7 Vp-p (G: 1.0 Vp-p for sync on G), 75Ω,
B, R: 0.7 Vp-p, 75Ω
HD/VD, SYNC: 1.4 Vp-p–5.0 Vp-p, 75Ω(positive/negative)
Y, PB, PR:Y: 1.0 p-p, 75Ω, PB,/PR:0.7 Vp-p, 75Ω
VIDEO IN: BNC pin x 1, 1.0 Vp-p, 75Ω
S-VIDEO IN: Mini DIN 4-pin x 1, Y: 1.0 Vp-p, C: 0.286 Vp-p, 75Ω
SERIAL IN: D-sub 9-pin x 1 (RS-232C compliant) for external controller
SERIAL OUT: D-sub 9-pin x 1 (RS-232C compliant) for external controller
REMOTE 1 IN: M3 jack x 1 for wired remote control or link control
REMOTE 1 OUT: M3 jack x 1 for link control
REMOTE 2 IN: D-sub 9-pin x 1 for external control (parallel)
LAN: RJ-45 x 1, compliant with PJLink™, 10Base-T/100Base-TX
On-screen menu: 9languages: English, French, German, Spanish, Italian, Russian, Korean,
Chinese, and Japanese
Noise: 35 dB (high lamp power mode), 29 dB (low lamp power mode)
As of March 2006
TENTATIVE

3
PT-DW5000/DW5000L
DLP™-Based Projectors
SPEC FILE
Power cord length: 3.0 m (9.9´)
Dimensions (W x H x D): 530 x 167 x 429 mm (20-7/8˝ x 6-9/16˝ x 16-7/8˝) (without lens)
Weight: PT-DW5000 14.5 kg (32.0 lbs) (with supplied lens)
PT-DW5000L 13.7 kg (30.2 lbs) (without lens)
Operating temperature: 0°–45°C (32°–113°F)
Operating humidity: 20%–80% (no condensation)
Remote Control Unit
Power supply: 3 V DC (AAA battery x 2)
Operation range*: Wireless: Approx. 7 m when operated from directly in front of the signal receptor
Wired: Approx. 15 m
Dimensions (W x H x D): 45 x145 x 24.5 mm (1-3/4˝ x 5-11/16˝ x 15/16˝)
Weight: Approx. 115 g (4.9 oz.) (including batteries)
Supplied Accessories Power cord, Wireless/wired remote control unit, Batteries for remote
control (x 2)
Optional Accessories
Replacement lamp unit: ET-LAD55 (1 unit)
ET-LAD55W (set of two lamps)
Replacement long-life lamp unit: ET-LAD55L (1 unit)
ET-LAD55WL (set of two lamps)
Ceiling mount bracket: ET-PKD55 (for high ceilings)
ET-PKD55S (for low ceilings)
Zoom lens (1.3-1.8:1) ET-DLE100
Zoom lens (2.5 -4.0:1) ET-DLE200
Zoom lens (3.4 - 4.5:1) ET-DLE310
Zoom lens (4.5- 8.2:1) ET-DLE410
Fixed-focus lens (0.8:1) ET-DLE050
Wireless mouse receiver ET-RMRC2
*Operation range differs depending on the environment.
As of March 2006
TENTATIVE
POWER
LAMP2
LAMP1
TEMP
TM
ATEXASINSTRUMENTS TECHNOLOGY
DLP
429 [16-7/8]
425 [16-3/4]
530.4 [20-7/8]
529 [20-13/16]
167 [6-9/16]
81 [3-3/16]
146.9 [5-13/16]
Dimensions
unit: mm [inch]
Note: This illustration is not drawn to scale.
The illustration shows the PT-DW5000L.
Weights and dimensions shown are approximate. Specifications subject to change without notice.

4
PT-DW5000/DW5000L
DLP™-Based Projectors
SPEC FILE
As of March 2006
TENTATIVE
Terminals
RGB IN connector pin assignment
1 Video input
2 S-Video input
3 RGB 1 input
4 RGB 2 Input
5 DVI-D input
6 LAN connector
7 Remote 1 input and output
8 Remote 2 input
9 Serial input
10 Serial output
no. signal
6 GND
7 GND
8 GND
9NC
10 GND
no. signal
11 GND
12 NC
13 HD/SYNC
14 VD
15 NC
no. signal
1 R/PR
2 G/Y
3 B/PB
4NC
5GND
123 456
78910
DVI-D output connector pin assignment
no. signal
1T, M, D, S data 2-
2T, M, D, S data 2+
3T, M, D, S data 2 shield
4NC
5NC
6DDC clock
7DDC clock
8NC
no. signal
9T, M, D, S data 1-
10 T, M, D, S data 1+
11 T, M, D, S data 1 shield
12 NC
13 NC
14 +5 V
15 GND
16 Hot plug detection
no. signal
17 T, M, D, S data 0-
18 T, M, D, S data 0+
19 T, M, D, S data 0 shield
20 NC
21 NC
22 T, M, D, S clock shield
23 T, M, D, S clock +
24 T, M, D, S clock -

5
PT-DW5000/DW5000L
DLP™-Based Projectors
SPEC FILE
As of March 2006
TENTATIVE
Standard setting-up positions
Projection distance (screen aspect ratio 15:9)
Upper edge of projected image
Projected image
Projected image
L
L
L
HH
340–465*
2
76.5
13-3/8˝–18-5/16˝)(3˝)
157
(6-3/16˝)
169*
1
260
(6-21/32˝) (10-1/4˝)
87.5
(3-7/16˝)
Lower edge of projected image
unit: mm (inch)
*1 When the lens protrudes to the maximum.
172 mm (6-25/32˝) with the ET-DLE050
204 mm (8-1/32˝) with the ET-DLE100
203 mm (8˝) with the ET-DLE200
191 mm (7-17/32˝) with the ET-DLE310
191 mm (7-17/32˝) with the ET-DLE410
*2 Adjustable in 40 mm (1-9/16˝) steps.
NOTE:
Illustrations show the projector installed using
optional celing bracket.
unit: m/ft
50
60
70
80
90
100
120
150
200
250
300
350
400
500
600
1.45
1.75
2.05
2.35
2.65
2.95
3.55
4.45
5.95
7.45
8.95
10.45
11.95
14.94
17.94
1.97
2.38
2.78
3.18
3.59
3.99
4.80
6.01
8.03
10.05
12.07
14.09
16.11
20.15
24.20
1.94
2.35
2.75
3.15
3.55
3.95
4.76
5.96
7.97
9.98
11.99
14.00
16.01
20.03
24.05
2.59
3.12
3.65
4.18
4.71
5.24
6.30
7.89
10.54
13.19
15.84
18.49
21.14
26.44
31.74
2.67
3.22
3.77
4.31
4.86
5.41
6.50
8.15
10.88
13.62
16.36
19.09
21.83
27.31
32.78
4.40
5.29
6.19
7.08
7.98
8.87
10.66
13.35
17.82
22.30
26.77
31.25
35.72
44.67
53.62
min. max. min. max. min. max.
Screen
size
(inch,
diagonal)
ET-DLE100
Zoom lens
(1.33 –1.78:1)
Supplied lens
(1.8–2.5:1)
ET-DLE200
Zoom lens
(2.5–4.0:1)
15:9 (WXGA)
3.82
4.61
5.40
6.18
6.97
7.75
9.33
11.68
15.61
19.54
23.47
27.40
31.33
39.19
47.05
5.02
6.05
7.08
8.10
9.13
10.15
12.21
15.28
20.41
25.54
30.67
35.80
40.93
51.19
61.45
5.08
6.13
7.17
8.21
9.26
10.30
12.39
15.52
20.74
25.96
31.18
36.40
41.62
52.06
62.50
9.62
11.57
13.52
15.47
17.42
19.37
23.28
29.13
38.88
48.64
58.39
68.15
77.90
97.41
116.92
min. max. min. max.
ET-DLE310
Zoom lens
(3.4–4.5:1)
ET-DLE410
Zoom lens
(4.5–8.4:1)
0.87
1.05
1.23
1.41
1.59
1.77
2.13
2.67
3.57
-
-
-
-
-
-
ET-DLE050
Fixed-focus
lens
(0.8:1)
4.8
5.7
6.7
7.7
8.7
9.7
11.6
14.6
19.5
24.4
29.4
34.3
39.2
49.0
58.9
6.5
7.8
9.1
10.4
11.8
13.1
15.7
19.7
26.3
33.0
39.6
46.2
52.9
66.1
79.3
6.4
7.7
9.0
10.3
11.6
13.0
15.6
19.6
26.1
32.7
39.3
45.9
52.5
65.7
78.9
8.5
10.2
12.0
13.7
15.5
17.2
20.7
25.9
34.6
43.3
52.0
60.7
69.4
86.7
104.1
8.8
10.6
12.4
14.1
15.9
17.7
21.3
26.7
35.7
44.7
53.7
62.6
71.6
89.6
107.5
14.4
17.4
20.3
23.2
26.2
29.1
35.0
43.8
58.5
73.2
87.8
102.5
117.2
146.6
176.0
12.5
15.1
17.7
20.3
22.9
25.4
30.6
38.3
51.2
64.1
77.0
89.9
102.8
128.6
154.4
16.5
19.8
23.2
26.6
30.0
33.3
40.1
50.1
60.0
83.8
100.6
117.5
134.3
167.9
201.6
16.7
20.1
23.5
26.9
30.4
33.8
40.6
50.9
68.0
85.2
102.3
119.4
136.5
170.8
205.1
31.6
38.0
44.4
50.8
57.2
63.5
76.4
95.6
127.6
159.6
191.6
223.6
255.6
319.6
383.6
2.9
3.4
4.0
4.6
5.2
5.8
7.0
8.6
11.7
-
-
-
-
-
-
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

6
PT-DW5000/DW5000L
DLP™-Based Projectors
SPEC FILE
As of March 2006
TENTATIVE
Calculation of the projection distance:
For a screen size, use the equation below to calculate the projection distance. (unit: mm)
ET-DLE100
Supplied lens
ET-DLE200
ET-DLE310
ET-DLE410
ET-DLE050
15 : 9 minimum L(m) = (diagonal screen size in inches) x 0.0300 - 0.0452
maximum L(m) = (diagonal screen size in inches) x 0.0404 - 0.0478
15 : 9 minimum L(m) = (diagonal screen size in inches) x 0.0402 - 0.0650
maximum L(m) = (diagonal screen size in inches) x 0.0530 - 0.0638
15 : 9 minimum L(m) = (diagonal screen size in inches) x 0.0547 - 0.0657
maximum L(m) = (diagonal screen size in inches) x 0.0895 - 0.0758
15 : 9 minimum L(m) = (diagonal screen size in inches) x 0.0786 - 0.1062
maximum L(m) = (diagonal screen size in inches) x 0.1026 - 0.1056
15 : 9 minimum L(m) = (diagonal screen size in inches) x 0.1044 - 0.1374
maximum L(m) = (diagonal screen size in inches) x 0.1951 - 0.1352
15 : 9 (fixed focus) L(m) = (diagonal screen size in inches) x 0.0180 - 0.0361

7
PT-DW5000/DW5000L
DLP™-Based Projectors
SPEC FILE
As of March 2006
TENTATIVE
Notes on Projector Placement and Operation:
The projector uses a high-wattage lamp that becomes very hot during operation. Please observe the following precautions.
1. Never place objects on top of the projector while it is operating.
2. Make sure there is an unobstructed space of 500 mm or more around the projector’s exhaust openings.
3. Do not stack projector units directly on top of one another for the purpose of multiple (stacked) projection. When
stacking projector units, be sure to provide the amount of space indicated below between them. These space
requirements also apply to installations where only one projector unit is operating at one time and the other unit is
used as a backup.
4. If the projector is placed in a box or enclosure, ensure the temperature of the air surrounding the projector is between
0°Cand 35°C. Also make sure the projector’s intake and exhaust openings are not blocked. Take particular care to
ensure that hot air from the exhaust openings is not sucked into the intake openings.
Operating the Projector Continuously:
1. If the projector is to be operated continuously 24 hours a day, use the dual-lamp optical system’s alternating lamp
operation (lamp changer) function. The projector cannot be operated continuously 24 hours a day in dual-lamp mode.
Allow a minimum of two hours per day of non-operation time.
2. The lamp replacement cycle duration becomes shorter if the projector is operated repeatedly for short periods.
