PT-D5500U/UL
DLPTM-Based Projector
Advanced Design Teams with
Flexible, Reliable Operation

Liquid-Cooling System
DMD chip
Dual Lamp System
Radiator
Reserver tank
Cooling directly
DMD chip
Ecology-Conscious Design
Panasonc works from every angle to minimize
environmental impact in the product design,
production and delivery processes, and in the
performance of the product during its life cycle.
The PT-D5500U/UL reflects the following
ecological considerations.
・ Lead-free solder is used to mount
 components to the printed circuit boards.
・ The non-coated cabinet enables
 easy recycling.
・ Lamp power switching further reduces
 power consumption.
・ Auto Power Save activates standby mode
 when no signal is input.
・ The packing case and operating manual are
 made from recycled paper.
The PT-D5500U/UL brings together three
advancement DLPTM technology, dual lamp
system, and liquid cooling to deliver bright,
high-quality images and quiet,
reliable operation.
Panasonic's acclaimed dual lamp system
generates 5,000-lumen brightness,
so the vivid, high-resolution images made
possible by DLPTM technology are easy to see
in any installation environment.
In the Dual Lamp system, the lamp relay
function in single lamp mode automatically
switches the bulb when one of the lamps burns
out, allowing continuous, non-stop operation.
Panasonic's newly developed liquid-cooling
system directly cools the DMD chip, giving
the PT-D5500U/UL the reliability needed
for 24/7 operation. The cooling system also
reduces the number of cooling fans needed,
so operating noise is greatly reduced.
You'll find the PT-D5500U/UL quiet enough to
use almost anywhere.
A Synergy of
Technologies Achieves
Superior Quality,
High Reliability and
Low Operating Costs
LampLamp

Superior Brightness,
Image Quality and Reliability
DLPTM technology combines with Panasonic's dual
lamp system and new liquid-cooling system
in a projector that stands out for image quality,
brightness and reliability.
The PT-D5500U/UL packs a host of leading
technologies into a compact body with a lens-
centered symmetrical design.
Thanks to DLPTM technology, the PT-D5500U/UL
projects images with a sharpness and resolution
suitable for the highest-level applications.
The dual lamp system delivers 5,000-lumen
brightness, ensuring that the images are bright
and easy to see in any environment.
And thanks to Panasonic's newly developed liquid-
cooling system, the PT-D5500U/UL can provide
reliable, whisper-quiet operation 24 hours a day,
7 days a week for extended periods.
The lens, lamp, and dust filter are easy to replace,
making maintenance easy.
You can connect the PT-D5500U/UL to a LAN and
control or monitor it via a Web browser.
A wide range of lenses are available as options
to meet all your projecting needs.
With its high reliability, low operating costs and
long-term durability, the PT-D5500U/UL is a high-
cost-to-performance projector that brings DLPTM
technology into reach of even limited budgets.
Conference rooms Classrooms
Churches Control rooms
The high-performance PT-D5500U/UL is ideal
in applications from conference rooms, classrooms
and church halls to control rooms and public facilities
that operate on a non-stop 24/7 basis.
Its sleek, compact styling makes this projector
a good match with virtually any decor.
And the PT-D5500U/UL can be mounted at any angle
with the lens pointing upward, downward, or anywhere
in between for easy installation.
With all this plus an array of optional lenses,
the versatile PT-D5500U/UL is a solution for any application
calling for high-quality projection.
The DLPTM logo and DLPTM medallion are trademarks of Texas Instruments.

1,600:1
ContrastContrast Mode
800:1
High
Low 2,500lm
5,000lm 1,250lm 2,500lm
Brightness
Normal Lamp Long Life Lamp
Under Dual lamp condition
Dual High
Lamp modeNumber of Lamp
Single
2,500lm
1,250lm
Low
High
Low
5,000lm
4,000lm
2,500lm
2,000lm
Brightness
Normal Lamp Long Life Lamp
Lens removal bottom
Horizontal lens shift bottom
(Vertical : powered)
High Image Quality
Flexible System Applications
High Reliability and Easy Maintenance
Ultra Bright 5,000 Lumens
Lens-Centered Design
Liquid Cooling System
Dustproof Design with Sealed Optical Block
Dual Lamp System and Lamp Relay Function
Optional Long-Life Lamp
Easy Replacement of Dust Filter and Lamp
High 1,600:1 Contrast Ratio
High Uniformity of Brightness and Color
A single-chip DLPTM design, liquid-cooling system and dual-lamp optical
system team up to achieve a brightness of 5,000 lumens.
This enables bright, large-screen projection even in well-lit condition.
Dynamic Sharpness Control
The Dynamic Sharpness Control circuit adjusts the video signal waveforms based
on the difference in brightness of adjacent pixels for a sharp, clear picture that is
relatively unaffected by signal noise.
A lens-centered, symmetrical design provides flexible system layout, eliminating
the need for any special considerations when planning the installation site.
Panasonic's newly developed liquid-cooling system directly cools the DMD chip,
whichextends thePT-D5500U/UL's performanceand attainsa highlevel ofreliability.
The effect of dust has been minimized by completely sealing the optical block.
The dust-free design helps ensure that this DLPTM projector will continue to deliver
crisp, sharp, high-resolution images over an extended service life.
The use of two lamp systems increases brightness and eliminates the need to
interrupt a presentation if a lamp burns out (in dual lamp operation mode).
In single lamp operation mode, the lamp relay function greatly extends continuous
operating time.
A long-life lamp that stretches lamp life to 4,000 hours is available as an option.
In single lamp operation mode, the lamp relay function allows non-stop operation
24 hours a day for up to 47 weeks without replacing the lamps.
The use of UHM lamps dramatically cuts operating costs.
Dust filter is replaced from the side
and lamps are replaced from the back
panel.
Both of them are replaced very easily
even if PT-D5500U/UL is installed.
This high-contrast combines with an outstanding brightness for crisp,
high-resolution images in virtually any viewing environment. Contrast can
be switched between High and Normal as conditions require.
The PT-D5500U/UL's outstanding brightness and contrast ratio assures high
uniformity of brightness and color, resulting in vivid and natural image.
Progressive Cinema Scan (3/2 Pulldown)
This interlace/progressive conversion technology automatically detects when
the input signal is derived from filmed material and selects the optimum
progressive processing method to assure faithful reproduction of the original image.
Horizontal/Vertical Lens Shift
A wide adjustment range of
the horizontal/vertical lens shift
assures distortion free images and
adds convenience and versatility.
(Horizontal : manual, Vertical : powered)
Lens-centered design
V50%
0
Screen center
H
+10%
0Screen center
-10%

Other Valuable Features
Five optional lenses with different throw distances are available in addition
to the supplied lens. These powered zoom/focus lenses enable the projectors
to perform superbly in an array of projection environments.
ET-DLE050
100 inc. screen
5.2'(1.6m)
Optional Lenses For Various Venues
Wired LAN System
Web Browser Control/Monitoring
E-Mail Message Alert
Direct Power Off
Anti-Theft Features With Chain Opening
Customizable Top Panel
The PT-D5500U/UL comes standard-equipped with a LAN connector
for 10Base-T/100Base-TX connection.
Simply hook it up to your existing LAN network for easy remote control
and/or monitoring. System administrators will appreciate this feature
when using the PT-D5500U/UL as a fixed-installation projector.
Anybody can operate the PT-D5500U/UL by remote control
or monitor its status over a LAN network, because it is all done using
the computer's familiar Web browser.
The PT-D5500U/UL automatically sends an E-mail message to notify
theoperator whenan errorhas occurred, or a lamp needs to be replaced.
Built-in capacitor provides power to cool the internal parts.
This means that you can switch off the room's main power as soon as
the presentation ends. It doesn't make you wait around and helps minimize
lamp damage.
Anti-theftfeatures help protect the PT-D5500U/UL form unauthorized use,
including a password protection function and an operation key lock
function that disables the control buttons on the main unit. It also features
a Kensington lock and an additional security chain opening.
Thetoppanelcanbecustomizedbyadding
yourcompany'slogoorchangingtheclolor
ifdesired.Pleaseaskyourdealerfordetails.
Easy Lens Replacement
Multiple Terminals Including DVI-D
The PT-D5500U/UL uses the bayonet
system, so lenses attach and detach
with one-touch ease.
ET-DLE100
8.9'(2.7m)~12.1'(3.7m)
supplied lens
11.8'(3.6m)~15.8'(4.8m) ET-DLE200
16.4'(5.0m)~26.9'(8.2m)
ET-DLE300
25.6'(7.8m)~40.0'(12.2m)
ET-DLE400
38.7'(11.8m)~54.1'(16.5m)
*Projection Range Example
Flexible Angle Setting
ThePT-5500U/UL can be rotated vertically.
Thismeans you can install it at any up-and-down
angle
youwish to accommodate different installation
conditions.
Others
ThePT-D5500UL delivers the same performance
asthe PT-D5500U, but comes without lens.
Combineit with an optional lens to get the
exactperformance you need according to
usageand operating conditions.
・6colors-matching function (red, green, blue, cyan,
magenta,yellow)
・IDassignment for up to 65 units
・Coordinatedgroup control for up to 26 groups (A-Z)
・Digitalvertical keystone correction
・3xdigital zoom
・Built-intest pattern
・Selectable9-language on-screen menu
(English,German,French, Spanish,Italian, Russian,Japanese, Chinese,Korean)
The PT-D5500U/UL has an array of terminals-two RGB inputs including
a 5-BNC connector, serial in/out one S-video inputs, two remote in,
one remote out, DVI-D and control capability-to support a broad range of
projection needs.
Networking
Control Panel And Wireless Remote Control
Quiet Operation, 29dB*
The rear control panel allows for easy
operation when the PT-D5500U/UL is
set on a desk or floor. A Multi-function
wirelessremote control withmouse control
also comes supplied with each projector.
* Requires the optional ET-RMRC2 wireless mouse receiver
The unique Panasonic silent design ensures that the audience is
not disturbed by projector noise.
* with lamp mode:low

Panasonic Broadcast & Television Systems Company
Presentation Systems Group
1 888 843 9788
www/panasonic.com/projectors
Headquarters
1 Panasonic Way, 4E-7
Secaucus, NJ 07094
201 348 5300
Panasonic Canada Inc.
5770 Ambler Drive
Mississauga, Ontario
Canada L4W 2T3
905 624 5010
Weights and dimensions shown are approximate. Specifications are subjemt to cahange without notice. This product
may be subject to export regulations. UHM is trademark of Matsushita Electric Indusutrial Co., Ltd. VGA and
XGA are trademarks of International Business Machines Corporation. All other trademarks are the property of their
respective trademark owners. Projection Images simulated.
PT-D5500U1-04Aug30K Printed in Japan.
Please contact Panasonic or your dealer for a demonstration.
JQA-1617
+
-
Normal Lamp
Replacement unit
ET-LAD55
ET-LAD55W (twin pack)
Long Life Lamp
Replacement unit
ET-LAD55L
ET-LAD55LW (twin pack)
Ceiling mount bracket
ET-PKD55
・The projector uses a high-voltage mercury lamp that contains high internal pressure.
This lamp may break, emitting a large sound, or fail to illuminate, due to impact or
extended use. The length of time that it takes for the lamp to break or fail to illuminate
varies greatly depending on individual lamp characteristics and usage conditions.
・The brightness of the lamp will gradually decrease with use.
・The replacement cycle of the lamp will be shortened if the power is frequently turned
on and off or the projector is subjected to daily continuous use for 10 or more hours.
Low-Ceiling mount bracket
ET-PKD55S
Wireless Mouse Receiver
ET-RMRC2
Zoom lens (1.3-1.8:1):ET-DLE100
Zoom lens (2.5-4.0:1):ET-DLE200
Zoom lens (3.7-5.7:1):ET-DLE300
Zoom lens (5.7-8.0:1):ET-DLE400
Fixed focus lens (0.8:1):ET-DLE050
Dimensions Optional accessories
NOTES ON USE
Projection distance
Specifications
R
System
Device
Pixels
Lamp
Brightness (normal lamp)
Brightness (long life lamp)
Contrast ratio
Resolution
RGB
Video
Lens
PT-D5500U
PT-D5500UL
Screen size
Lens shift
RGB input scanning
frequency
Component signal
Video signal
DLPTM system
0.7" (diagonal) DMDTM(x 1), 4:3
786,432 (1,024 x 768) x 1
300 W UHMTM lamp x 2 (BrightOpticTM Dual Lamp System)
5,000 lumens (dual lamp)
2,500 lumens (dual lamp)
1,600:1 (full white/full black, with contrast mode:high)
1,024 x 768 pixels
560 TV lines
Powered zoom/focus lens (1:1.8-1:2.5)
F 1.7-2.0, f 25.6-33.8 mm
Optional
50 - 600"diagonal
Vertical, horizontal
fH15-91 kHz, fV50-85 Hz
Dot clock 24-108 MHz
480i, 480p, 576i, 576p, 720/60p, 1035/60i, 1080/60i, 1080/50i
NTSC, PAL, SECAM, M-NTSC, PAL60, PAL-M, PAL-N
Terminals
VIDEO IN
S-VIDEO IN
RGB1/YPBPRIN
RGB2 IN
DVI-D IN
RS-232C IN
RS-232C OUT
REMOTE 1 IN
REMOTE 1 OUT
REMOTE 2 IN
LAN
Keystone correction range
Installation
Power code length
Power supply
Power consumption
Dimensions(W x H x D)
Weight
PT-D5500U
PT-D5500UL
Operating temperature
Operating humidity
Supplied accessories
BNC
Mini DIN 4-pin
BNC x 5
D-sub HD 15-pin
24 pin
D-sub 9-pin female
D-sub 9-pin male
M3 jack
M3 jack
D-sub 9-pin female (parallel)
RJ-45(10 Base-T/100 Base-TX)
30 (with supplied lens)
Front/rear, ceiling/floor (menu selection)
8.2'(2.5m)
120 V AC, 60Hz
770 W (770 VA) (10 W during standby mode with fan stopped)
20-7/8" x 6-37/64" x 16-47/64" (530 x 167 x 425 mm)
30.2 lbs (13.7 kg) with supplied lens
28.4 lbs (12.9 kg) without lens
32 -104 F (0 -40 C)
10-80% (no condensation)
・Wireless remote control unit
・Batteries for remote control
・Remote control cable
Throw distanceScreen size
(4:3)
With ET-DLE050
50"(4.2')
1.3 m
80"(6.7')
2.0 m
100"(8.3')
2.5 m
150"(12.5')
3.8 m
200"(16.7')
5.1 m
300"(25.0')
7.6 m
400"(33.3')
1.3 m
500"(41.7')
12.7 m
2.7'
0.8 m
4.2'
1.3 m
5.3'
1.6 m
8.0'
2.5 m
10.9'
3.3 m
-
-
-
-
-
-
-
-
600"(50.0')
15.2 m
With ET -DLE400With ET -DLE100
min.
4.4'
1.3 m
7.1'
2.2 m
8.1'
2.7 m
13.5'
4.1 m
17.1'
5.5 m
27.0'
8.3 m
36.1'
11.0 m
45.2'
13.8 m
54.3'
16.6 m
min.
5.1'
1.8 m
9.7'
2.9 m
12.0'
3.7 m
18.2'
5.5 m
24.3'
7.4 m
36.5'
11.1 m
48.8'
14.8 m
60.1'
18.6 m
73.1'
22.3 m
With supplied lens
min.
5.9'
1.8 m
9.5'
2.9 m
11.8'
3.6 m
18.0'
5.5 m
24.0'
7.3 m
36.4'
11.1 m
48.6'
14.8 m
60.7'
18.5 m
72.8'
22.2 m
min.
7.9'
2.4 m
12.5'
3.8 m
15.8'
4.8 m
24.0'
7.3 m
31.8'
9.7 m
47.9'
14.6 m
64.0'
19.5 m
80.1'
24.4 m
95.8'
29.2 m
With
ET -DLE200
min.
8.0'
2.5 m
13.0'
4.0 m
16.4'
5.0 m
24.7'
7.5 m
32.1'
10.0 m
49.4'
15.1 m
65.1'
20.1 m
82.6'
25.2 m
99.0'
30.2 m
min.
13.3'
4.1 m
21.4'
6.5 m
26.9'
8.2 m
40.3'
12.3 m
53.1'
16.4 m
80.1'
24.7 m
107.1'
32.9 m
134.1'
41.1 m
162.0'
49.4 m
With
ET -DLE300
0.8:1 5.7-8.0:11.3-1.8:1 1.8-2.5:1 2.5-4.0:1 3.7-5.7:1
min.
12.7'
3.8 m
20.4'
6.2 m
25.7'
7.8 m
38.8'
11.8 m
51.8'
15.8 m
77.9'
23.7 m
103.1'
31.7 m
129.1'
39.6 m
156.0'
47.6 m
min.
19.9'
6.0 m
31.1'
9.7 m
39.1'
12.2 m
60.2'
18.4 m
80.4'
24.5 m
120.1'
36.8 m
161.3'
49.2 m
201.8'
61.5 m
242.1'
73.8 m
min.
19.5'
5.9 m
31.0'
9.5 m
38.8'
11.8 m
57.1'
17.7 m
77.1'
23.5 m
115.8'
35.3 m
154.3'
47.0 m
193.0'
58.9 m
231.1'
70.7 m
min.
27.3'
8.3 m
43.5'
13.2 m
54.2'
16.5 m
81.2'
24.8 m
108.2'
33.0 m
162.2'
49.4 m
216.2'
65.9 m
270.3'
82.4 m
324.4'
98.9 m
478 [18 27/32]
530 [20 7/8]
157 [6 3/16]
425 [16 47/64]
167 [6 37/64]
