Panasonic PTLB51NTU - LCD PROJECTOR - MULTI LANGUAGE User manual

1 Specifications 2
2 Points of difference between LB50NT**/LB50**/LB50S** and
LB51NT**/LB51**/LB51S** 3
©2007 Matsushita Electric Industrial Co., Ltd. All
rights reserved. Unauthorized copying and
distribution is a violation of law.
PT-LB51NTU
PT-LB51NTE
PT-LB51NTEA
PT-LB51U
PT-LB51E
PT-LB51EA
PT-LB51SU
PT-LB51SEA
2.1. Replacement Parts List 3
LCD Projector
Please file and use this manual together with the service manual for Model No. PT-LB50NTU/E/EA, PT-
LB50U/E/EA, PT-LB50SU/E/EA Order No. VED0603369C0.
CONTENTS
Page Page
VED0707380A0
D10

1 Specifications
2
PT-LB51NTU / PT-LB51NTE / PT-LB51NTEA / PT-LB51U / PT-LB51E / PT-LB51EA / PT-LB51SU / PT-LB51SEA

2 Points of difference between LB50NT**/LB50**/LB50S**
and LB51NT**/LB51**/LB51S**
2.1. Replacement Parts List
2.1.1. PT-LB51NTU
Ref. No. Part Name & Description PT-LB50NTU (Base Model) PT-LB51NTU Remarks
Part No. Pcs Part No. Pcs
[MECHANICAL PARTS]
FERRITE CORE -J0KG00000046 1
12 REMOTE CONTROLLER N2QAYA000001 1N2QAYB000169 1
13 LAN MODULE N5HZZ0000042 1 -
18 LOGO BADGE TBMA191 1TBMA241 1NT
MODEL NAME PLATE TBMG174-1 1TBMG679 1
MODEL NO. LABEL TBMG183 1 -
19 CONTROLL BUTTON A TBXA48901 1TBXA48902 1
33 REMOTE RECEIVER PLATE TKKC5243 1TKKC5253 1
SHIELD SHEET TMKY028 1 -
PCB-A SHIELD -TMKY350 1
61 CARTON TPCB94302 1TPCC26902A 1
67 PASSWORD SHEET TQBH7017 1TQBH7032 1
66 INSTRUCTION BOOK TQBJ0192-2 1TQBJ0228-1 1
HIGH GROUND SHEET -TQBJ7008 1
GUARANTEE CARD (USA) TQDJ18028 1TQDJ18028-1 1
68 INSTALL GUIDE TQDJ19029-1 1 - UK/SPAIN
69 CD-ROM TXFQH01VKB9D 1TXFQB02QEXZF 1
2-1 POWER CORD K2CG3DR00006 1 -
POWER CORD & FERRITE CORE -TXFSX02QHRZ 1
POLY BAG XZBT6532 1XZBT6506 1
57 UPPER COVER TXFKF99QCBZ 1TXFKF99QHRZ 1
58 BOTTOM COVER TXFKF98QCBZ 1TXFKF98QHRZ 1
[INTEGRATED CIRCUIT]
IC1011 I.C TVRP607-1 1TVRP671 1
IC1802 I.C TVRN743-3 1TVRP608 1
[COILS]
L1043 EMI FILTER J0JJC0000022 1 -
L1046 EMI FILTER J0JJC0000022 1J0JCC0000168 1
FL1001 FILTER J0HABB000014 1J0HAYY000046 1
FL1002 FILTER J0HABB000014 1J0HAYY000046 1
FL1010 FILTER -J0HAAB000036 1
FL1011 FILTER -J0HAAB000036 1
3
PT-LB51NTU / PT-LB51NTE / PT-LB51NTEA / PT-LB51U / PT-LB51E / PT-LB51EA / PT-LB51SU / PT-LB51SEA

Ref. No. Part Name & Description PT-LB50NTU (Base Model) PT-LB51NTU Remarks
Part No. Pcs Part No. Pcs
FL1012 FILTER -J0HAAB000036 1
FL1013 FILTER -J0HAAB000036 1
FL1014 FILTER -J0HAAB000036 1
FL1015 FILTER -J0HAAB000036 1
FL1016 FILTER -J0JYD0000020 1
FL1017 FILTER -F1J1E1040022 1
FL1018 FILTER -J0JYD0000020 1
[RESISTORS]
R1042 M 56 OHM,J,1/16W ERJ3GEYJ560 1 -
R1042 M 10 OHM,J,1/16W -ERJ3GEYJ100 1
R1043 M 56 OHM,J,1/16W ERJ3GEYJ560 1 -
R1043 M 10 OHM,J,1/16W -ERJ3GEYJ100 1
R1272 M 1K OHM, 0.063W ERJ2GEJ102 1 -
R1340 M 100 OHM, 0.063W ERJ2GEJ101X 1 -
R1357 M 10 OHM,J,1/10W ERJ6GEYJ100 1 -
R1360 M 10 OHM,J,1/10W ERJ6GEYJ100 1 -
R1390 M 100 OHM, 0.063W ERJ2GEJ101X 1 -
R1391 M 100 OHM, 0.063W ERJ2GEJ101X 1 -
R1392 M 100 OHM, 0.063W ERJ2GEJ101X 1 -
R1402 M 100 OHM, 0.063W ERJ2GEJ101X 1 -
R1403 M 100 OHM, 0.063W ERJ2GEJ101X 1 -
R1404 M 100 OHM, 0.063W ERJ2GEJ101X 1 -
R1405 M 100 OHM, 0.063W ERJ2GEJ101X 1 -
R1578 M 56 OHM, 0.063W ERJ2GEJ560 1 -
R1578 M 75 OHM, 0.063W -ERJ2GEJ750 1
R1667 M 100 OHM, 0.063W ERJ2GEJ101X 1 -
R1674 M 10 OHM,J,1/10W ERJ6GEYJ100 1 -
R1712 RESISTOR EXB2HV220JV 1 -
R1713 RESISTOR EXB2HV220JV 1 -
R1714 RESISTOR ARRAY EXB28V220J 1 -
R1715 RESISTOR EXB2HV220JV 1 -
R1716 RESISTOR ARRAY EXB28V220J 1 -
R1717 RESISTOR EXB2HV220JV 1 -
R1718 M 22 OHM, 0.063W ERJ2GEJ220 1 -
R1719 RESISTOR ARRAY EXB28V220J 1 -
R1720 RESISTOR EXB2HV220JV 1 -
[CAPACITORS]
C1169 C 1000PF, 50V -ECJ0EB1H102K 1
C1174 C 1000PF, 50V -ECJ0EB1H102K 1
C1180 C 1000PF, 50V -ECJ0EB1H102K 1
C1181 C 1000PF, 50V -ECJ0EB1H102K 1
[OTHERS]
RTL CIRCUIT BOARD WL TNPA4323AB 1TNPA4323 1
RTL CIRCUIT BOARD G TNPA4329 1TNPA4329AB 1
RTL CIRCUIT BOARD A TXANP01QCCZ 1TXANP01QHRZ 1
BALLAST UNIT ASSY TXANP04VKB9 1TXANPBQQHRZ 1
2.1.2. PT-LB51NTE
Ref. No. Part Name & Description PT-LB50NTE (Base Model) PT-LB51NTE Remarks
Part No. Pcs Part No. Pcs
[MECHANICAL PARTS]
FERRITE CORE -J0KG00000046 1
12 REMOTE CONTROLLER N2QAYA000001 1N2QAYB000169 1
18 LOGO BADGE TBMA191 1TBMA241 1NT
MODEL NAME PLATE TBMG175-1 1TBMG680 1
MODEL NO. LABEL TBMG184 1 -
19 CONTROL BUTTON A TBXA48901 1TBXA48902 1
33 REMOTE RECEIVER PLATE TKKC5243 1TKKC5253 1
SHIELD SHEET TMKY028 1 -
PCB-A SHIELD -TMKY350 1
61 CARTON TPCB94303B 1TPCC26903A 1
67 PASSWORD SHEET TQBH7017 1TQBH7032 1
66 INSTRUCTION BOOK TQBJ0194 1TQBJ0229-1 1
4
PT-LB51NTU / PT-LB51NTE / PT-LB51NTEA / PT-LB51U / PT-LB51E / PT-LB51EA / PT-LB51SU / PT-LB51SEA

Ref. No. Part Name & Description PT-LB50NTE (Base Model) PT-LB51NTE Remarks
Part No. Pcs Part No. Pcs
VISTA SHEET TQDH19025 1 - JAPAN/ENGLISH
68 INSTALL GUIDE TQDJ19030-1 1 - GERMAN/ITALIAN
INSTALL GUIDE TQDJ19031-1 1 - FRENCH/SPANISH
INSTALL GUIDE TQDJ19032-1 1 - ENGLISH/KOREA
VISTA SHEET TQDJ19056 1 - FRENCH/SPANISH
VISTA SHEET TQDJ19057 1 - GERMAN/ITALIAN
R+TTE SHEET TQDJ19067 1 -
SHEET TQDJ19069 1 -
NEW EMC SHEET TQDJ19072 1 -
QUICK GUIDE (WIN) -TQDJ19079 1ENG/KOREA
QUICK GUIDE (WIN) -TQDJ19080 1GER/ITA
QUICK GUIDE (WIN) -TQDJ19081 1FRA/SPA
QUICK GUIDE (MAC) -TQDJ19083 1ENG/KOREA
QUICK GUIDE (MAC) -TQDJ19084 1GER/ITA
QUICK GUIDE (MAC) -TQDJ19085 1FRA/SPA
69 CD-ROM ASSY TXFQH01VKB9D 1TXFQB02QEXZF 1
2-2 POWER CORD K2CM3DR00002 1 -
POWER CORD & FERRITE CORE -TXFSX02QHUZ 1
POLY BAG XZBT6532 1XZBT6506 1
57 UPPER COVER TXFKF99QCCZ 1TXFKF99QHRZ 1
58 BOTTOM COVER TXFKF98QCCZ 1TXFKF99QHUZ 1
[INTEGRATED CIRCUIT]
IC1011 I.C TVRP607-1 1TVRP671 1
IC1802 I.C TVRN743-3 1TVRP608 1
[OTHERS]
RTL CIRCUIT BOARD WL TNPA4323AB 1TNPA4323 1
RTL CIRCUIT BOARD A TXANP01VKB9A 1TXANP01QHRZ 1
BALLAST UNIT ASSY TXANP04VKB9 1TXANPBQQHRZ 1
2.1.3. PT-LB51NTEA
Ref. No. Part Name & Description PT-LB50NTEA (Base Model) PT-LB51NTEA Remarks
Part No. Pcs Part No. Pcs
[MECHANICAL PARTS]
FERRITE CORE -J0KG00000046 2
12 REMOTE CONTROLLER N2QAYA000001 1N2QAYB000169 1
18 LOGO BADGE TBMA191 1TBMA241 1NT
MODEL NAME PLATE TBMG176-3 1TBMG681 1
MODEL NO. LABEL TBMG185 1 -
19 CONTROL BUTTON A TBXA48901 1TBXA48902 1
33 REMOTE RECEIVER PLATE TKKC5243 1TKKC5253 1
SHIELD SHEET TMKY028 1 -
PCB-A SHIELD -TMKY350 1
61 CARTON TPCB94304A 1TPCC26904A 1
67 PASSWORD SHEET TQBH7017 1TQBH7032 1
66 INSTRUCTION BOOK TQBJ0196 1TQBJ0230 1
VISTA SHEET TQDH19025 1 - JAPAN/ENGLISH
POWER CORE SHEET -TQDH19039 1
68 INSTALL GUIDE TQDJ19032-1 1 - ENGLISH/KOREA
VISTA SHEET TQDJ19058 1 - KOREAN/CHINESE
VISTA SHEET TQDJ19057 1 - GERMAN/ITALIAN
R+TTE SHEET TQDJ19067 1 -
SHEET TQDJ19069 1 -
NEW EMC SHEET TQDJ19072 1 -
QUICK GUIDE (WIN) -TQDJ19079 1ENG/KOREA
QUICK GUIDE (MAC) -TQDJ19083 1ENG/KOREA
69 CD-ROM ASSY TXFQH01VKB9D 1TXFQB02QEXZF 1
2-2 POWER CORD(EUROPE) K2CM3DR00002 1 -
2-3 POWER CORD(UK) K2CT3DR00005 1 -
POWER CORD & FERRITE CORE -TXFSX02QHUZ 1EUROPE
POWER CORD & FERRITE CORE -TXFSX02QHXZ 1UK
POLY BAG XZBT6532 1XZBT6506 1
57 UPPER COVER TXFKF99QCDZ 1TXFKF99QHRZ 1
58 BOTTOM COVER TXFKF98QCDZ 1TXFKF99QHXZ 1
[INTEGRATED CIRCUIT]
5
PT-LB51NTU / PT-LB51NTE / PT-LB51NTEA / PT-LB51U / PT-LB51E / PT-LB51EA / PT-LB51SU / PT-LB51SEA

Ref. No. Part Name & Description PT-LB50NTEA (Base Model) PT-LB51NTEA Remarks
Part No. Pcs Part No. Pcs
IC1011 I.C TVRP607-1 1TVRP671 1
IC1802 I.C TVRN743-3 1TVRP608 1
[OTHERS]
RTL CIRCUIT BOARD WL TNPA4323AB 1TNPA4323 1
RTL CIRCUIT BOARD A TXANP01VKB9A 1TXANP01QHRZ 1
BALLAST UNIT ASSY TXANP04VKB9 1TXANPBQQHRZ 1
2.1.4. PT-LB51U
Ref. No. Part Name & Description PT-LB50U (Base Model) PT-LB51U Remarks
Part No. Pcs Part No. Pcs
[MECHANICAL PARTS]
FERRITE CORE -J0KG00000046 1
12 REMOTE CONTROLLER N2QAYA000002 1N2QAYB000172 1
18 LOGO BADGE TBMA192 1TBMA242 1XGA
MODEL NAME PLATE TBMG177 1TBMG682 1
MODEL NO. LABEL TBMG186 1 -
19 CONTROLL BUTTON A TBXA48901 1TBXA48902 1
33 REMOTE RECEIVER PLATE TKKC5243 1TKKC5253 1
SHIELD SHEET TMKY028 1 -
PCB-A SHIELD -TMKY350 1
61 CARTON TPCB94305 1TPCC26905A 1
67 PASSWORD SHEET TQBH7017 1TQBH7032 1
66 INSTRUCTION BOOK TQBJ0192-2 1TQBJ0228-1 1
HIGH GROUND SHEET -TQBJ7008 1
POWER CORE SHEET -TQDH19039 1
GUARANTEE CARD (USA) TQDJ18028 1TQDJ18028-1 1
2-1 POWER CORD K2CG3DR00006 1 -
POWER CORD & FERRITE CORE -TXFSX02QHRZ 1
POLY BAG XZBT6532 1XZBT6506 1
57 UPPER COVER TXFKF99QCEZ 1TXFKF99QNGZ 1
58 BOTTOM COVER TXFKF98QCEZ 1TXFKF98QNGZ 1
[INTEGRATED CIRCUIT]
IC1011 I.C TVRP607-1 1TVRP671 1
[COILS]
L1043 EMI FILTER J0JJC0000022 1 -
L1046 EMI FILTER J0JJC0000022 1J0JCC0000168 1
FL1001 FILTER J0HABB000014 1J0HAYY000046 1
FL1002 FILTER J0HABB000014 1J0HAYY000046 1
FL1010 FILTER -J0HAAB000036 1
FL1011 FILTER -J0HAAB000036 1
FL1012 FILTER -J0HAAB000036 1
FL1013 FILTER -J0HAAB000036 1
FL1014 FILTER -J0HAAB000036 1
FL1015 FILTER -J0HAAB000036 1
FL1016 FILTER -J0JYD0000020 1
FL1017 FILTER -F1J1E1040022 1
FL1018 FILTER -J0JYD0000020 1
[RESISTORS]
R1042 M 56 OHM,J,1/16W ERJ3GEYJ560 1 -
R1042 M 10 OHM,J,1/16W -ERJ3GEYJ100 1
R1043 M 56 OHM,J,1/16W ERJ3GEYJ560 1 -
R1043 M 10 OHM,J,1/16W -ERJ3GEYJ100 1
R1272 M 1K OHM, 0.063W ERJ2GEJ102 1 -
R1340 M 100 OHM, 0.063W ERJ2GEJ101X 1 -
R1357 M 10 OHM,J,1/10W ERJ6GEYJ100 1 -
R1360 M 10 OHM,J,1/10W ERJ6GEYJ100 1 -
R1390 M 100 OHM, 0.063W ERJ2GEJ101X 1 -
R1391 M 100 OHM, 0.063W ERJ2GEJ101X 1 -
R1392 M 100 OHM, 0.063W ERJ2GEJ101X 1 -
R1402 M 100 OHM, 0.063W ERJ2GEJ101X 1 -
6
PT-LB51NTU / PT-LB51NTE / PT-LB51NTEA / PT-LB51U / PT-LB51E / PT-LB51EA / PT-LB51SU / PT-LB51SEA

Ref. No. Part Name & Description PT-LB50U (Base Model) PT-LB51U Remarks
Part No. Pcs Part No. Pcs
R1403 M 100 OHM, 0.063W ERJ2GEJ101X 1 -
R1404 M 100 OHM, 0.063W ERJ2GEJ101X 1 -
R1405 M 100 OHM, 0.063W ERJ2GEJ101X 1 -
R1578 M 56 OHM, 0.063W ERJ2GEJ560 1 -
R1578 M 75 OHM, 0.063W -ERJ2GEJ750 1
R1667 M 100 OHM, 0.063W ERJ2GEJ101X 1 -
R1674 M 10 OHM,J,1/10W ERJ6GEYJ100 1 -
R1712 RESISTOR EXB2HV220JV 1 -
R1713 RESISTOR EXB2HV220JV 1 -
R1714 RESISTOR ARRAY EXB28V220J 1 -
R1715 RESISTOR EXB2HV220JV 1 -
R1716 RESISTOR ARRAY EXB28V220J 1 -
R1717 RESISTOR EXB2HV220JV 1 -
R1718 M 22 OHM, 0.063W ERJ2GEJ220 1 -
R1719 RESISTOR ARRAY EXB28V220J 1 -
R1720 RESISTOR EXB2HV220JV 1 -
[CAPACITORS]
C1169 C 1000PF, 50V -ECJ0EB1H102K 1
C1174 C 1000PF, 50V -ECJ0EB1H102K 1
C1180 C 1000PF, 50V -ECJ0EB1H102K 1
C1181 C 1000PF, 50V -ECJ0EB1H102K 1
[OTHERS]
RTL CIRCUIT BOARD G TNPA4329 1 -
RTL CIRCUIT BOARD G -TNPA4329AB 1
RTL CIRCUIT BOARD A TXANP01QCFZ 1TXANP01QNGZ 1
BALLAST UNIT ASSY TXANP04VKB9 1TXANPBQQHRZ 1
2.1.5. PT-LB51E
Ref. No. Part Name & Description PT-LB50E (Base Model) PT-LB51E Remarks
Part No. Pcs Part No. Pcs
[MECHANICAL PARTS]
FERRITE CORE -J0KG00000046 1
12 REMOTE CONTROLLER N2QAYA000002 1N2QAYB000172 1
18 LOGO BADGE TBMA192 1TBMA242 1XGA
MODEL NAME PLATE TBMG178-1 1TBMG807 1
MODEL NO. LABEL TBMG187 1 -
19 CONTROL BUTTON A TBXA48901 1TBXA48902 1
33 REMOTE RECEIVER PLATE TKKC5243 1TKKC5253 1
SHIELD SHEET TMKY028 1 -
PCB-A SHIELD -TMKY350 1
61 CARTON TPCB94306A 1TPCC26911 1
67 PASSWORD SHEET TQBH7017 1TQBH7032 1
66 INSTRUCTION BOOK TQBJ0194 1TQBJ0229-1 1
NEW EMC SHEET TQDJ19072 1 -
2-2 POWER CORD K2CM3DR00002 1 -
POWER CORD & FERRITE CORE -TXFSX02QHUZ 1
POLY BAG XZBT6532 1XZBT6506 1
57 UPPER COVER TXFKF99QCFZ 1TXFKF99QNGZ 1
58 BOTTOM COVER TXFKF98QCFZ 1TXFKF99QHVZ 1
[INTEGRATED CIRCUIT]
IC1011 I.C TVRP607-1 1TVRP671 1
[OTHERS]
RTL CIRCUIT BOARD A TXANP01QCEZA 1TXANP01QNGZ 1
BALLAST UNIT ASSY TXANP04VKB9 1TXANPBQQHRZ 1
7
PT-LB51NTU / PT-LB51NTE / PT-LB51NTEA / PT-LB51U / PT-LB51E / PT-LB51EA / PT-LB51SU / PT-LB51SEA

2.1.6. PT-LB51EA
Ref. No. Part Name & Description PT-LB50EA (Base Model) PT-LB51EA Remarks
Part No. Pcs Part No. Pcs
[MECHANICAL PARTS]
FERRITE CORE -J0KG00000046 2
12 REMOTE CONTROLLER N2QAYA000002 1N2QAYB000172 1
18 LOGO BAFGE TBMA192 1TBMA242 1XGA
MODEL NAME PLATE TBMG179-1 1TBMG683 1
MODEL NO. LABEL TBMG188 1 -
19 CONTROL BUTTON A TBXA48901 1TBXA48902 1
33 REMOTE RECEIVER PLATE TKKC5243 1TKKC5253 1
SHIELD SHEET TMKY028 1 -
PCB-A SHIELD -TMKY350 1
61 CARTON TPCB94307 1TPCC26906 1
67 PASSWORD SHEET TQBH7017 1TQBH7032 1
66 INSTRUCTION BOOK TQBJ0196 1TQBJ0230 1
POWER CORE SHEET -TQDH19039 1
NEW EMC SHEET TQDJ19072 1 -
2-2 POWER CORD(EUROPE) K2CM3DR00002 1 -
2-3 POWER CORD(UK) K2CT3DR00005 1 -
POWER CORD & FERRITE CORE -TXFSX02QHUZ 1EUROPE
POWER CORD & FERRITE CORE -TXFSX02QHXZ 1UK
POLY BAG XZBT6532 1XZBT6506 1
57 UPPER COVER TXFKF99QCGZ 1TXFKF99QNGZ 1
58 BOTTOM COVER TXFKF98QCGZ 1TXFKF99QHYZ 1
[INTEGRATED CIRCUIT]
IC1011 I.C TVRP607-1 1TVRP671 1
[OTHERS]
RTL CIRCUIT BOARD A TXANP01QCEZA 1TXANP01QNGZ 1
BALLAST UNIT ASSY TXANP04VKB9 1TXANPBQQHRZ 1
2.1.7. PT-LB51SU
Ref. No. Part Name & Description PT-LB50SU (Base Model) PT-LB51SU Remarks
Part No. Pcs Part No. Pcs
[MECHANICAL PARTS]
FERRITE CORE -J0KG00000046 1
12 REMOTE CONTROLLER N2QAYA000002 1N2QAYB000172 1
18 LOGO BADGE TBMA193 1TBMA243 1SVGA
MODEL NAME PLATE TBMG180 1TBMG684 1
MODEL NO. LABEL TBMG189 1 -
19 CONTROLL BUTTON A TBXA48901 1TBXA48902 1
33 REMOTE RECEIVER PLATE TKKC5243 1TKKC5253 1
SHIELD SHEET TMKY028 1 -
PCB-A SHIELD -TMKY350 1
61 CARTON TPCB94308 1TPCC26907A 1
67 PASSWORD SHEET TQBH7017 1TQBH7032 1
66 INSTRUCTION BOOK TQBJ0192-2 1TQBJ0228-1 1
HIGH GROUND SHEET -TQBJ7008 1
POWER CORE SHEET -TQDH19039 1
GUARANTEE CARD (USA) TQDJ18028 1TQDJ18028-1 1
2-1 POWER CORD K2CG3DR00006 1 -
POWER CORD & FERRITE CORE -TXFSX02QHRZ 1
POLY BAG XZBT6532 1XZBT6506 1
57 UPPER COVER TXFKF99QCHZ 1TXFKF99QHTZ 1
58 BOTTOM COVER TXFKF98QCHZ 1TXFKF98QHTZ 1
[INTEGRATED CIRCUIT]
IC1011 I.C TVRP609-1 1TVRP672 1
[COILS]
L1043 EMI FILTER J0JJC0000022 1 -
8
PT-LB51NTU / PT-LB51NTE / PT-LB51NTEA / PT-LB51U / PT-LB51E / PT-LB51EA / PT-LB51SU / PT-LB51SEA

Ref. No. Part Name & Description PT-LB50SU (Base Model) PT-LB51SU Remarks
Part No. Pcs Part No. Pcs
L1046 EMI FILTER J0JJC0000022 1J0JCC0000168 1
FL1001 FILTER J0HABB000014 1J0HAYY000046 1
FL1002 FILTER J0HABB000014 1J0HAYY000046 1
FL1010 FILTER -J0HAAB000036 1
FL1011 FILTER -J0HAAB000036 1
FL1012 FILTER -J0HAAB000036 1
FL1013 FILTER -J0HAAB000036 1
FL1014 FILTER -J0HAAB000036 1
FL1015 FILTER -J0HAAB000036 1
FL1016 FILTER -J0JYD0000020 1
FL1017 FILTER -F1J1E1040022 1
FL1018 FILTER -J0JYD0000020 1
[RESISTORS]
R1042 M 56 OHM,J,1/16W ERJ3GEYJ560 1 -
R1042 M 10 OHM,J,1/16W -ERJ3GEYJ100 1
R1043 M 56 OHM,J,1/16W ERJ3GEYJ560 1 -
R1043 M 10 OHM,J,1/16W -ERJ3GEYJ100 1
R1272 M 1K OHM, 0.063W ERJ2GEJ102 1 -
R1340 M 100 OHM, 0.063W ERJ2GEJ101X 1 -
R1357 M 10 OHM,J,1/10W ERJ6GEYJ100 1 -
R1360 M 10 OHM,J,1/10W ERJ6GEYJ100 1 -
R1390 M 100 OHM, 0.063W ERJ2GEJ101X 1 -
R1391 M 100 OHM, 0.063W ERJ2GEJ101X 1 -
R1392 M 100 OHM, 0.063W ERJ2GEJ101X 1 -
R1402 M 100 OHM, 0.063W ERJ2GEJ101X 1 -
R1403 M 100 OHM, 0.063W ERJ2GEJ101X 1 -
R1404 M 100 OHM, 0.063W ERJ2GEJ101X 1 -
R1405 M 100 OHM, 0.063W ERJ2GEJ101X 1 -
R1578 M 56 OHM, 0.063W ERJ2GEJ560 1 -
R1578 M 75 OHM, 0.063W -ERJ2GEJ750 1
R1667 M 100 OHM, 0.063W ERJ2GEJ101X 1 -
R1674 M 10 OHM,J,1/10W ERJ6GEYJ100 1 -
R1712 RESISTOR EXB2HV220JV 1 -
R1713 RESISTOR EXB2HV220JV 1 -
R1714 RESISTOR ARRAY EXB28V220J 1 -
R1715 RESISTOR EXB2HV220JV 1 -
R1716 RESISTOR ARRAY EXB28V220J 1 -
R1717 RESISTOR EXB2HV220JV 1 -
R1718 M 22 OHM, 0.063W ERJ2GEJ220 1 -
R1719 RESISTOR ARRAY EXB28V220J 1 -
R1720 RESISTOR EXB2HV220JV 1 -
[CAPACITORS]
C1169 C 1000PF, 50V -ECJ0EB1H102K 1
C1174 C 1000PF, 50V -ECJ0EB1H102K 1
C1180 C 1000PF, 50V -ECJ0EB1H102K 1
C1181 C 1000PF, 50V -ECJ0EB1H102K 1
[OTHERS]
RTL CIRCUIT BOARD G TNPA4329 1 -
RTL CIRCUIT BOARD G -TNPA4329AB 1
RTL CIRCUIT BOARD A TXANP01QCJZ 1TXANP01QHTZ 1
BALLAST UNIT ASSY TXANP04VKB9 1TXANPBQQHRZ 1
9
PT-LB51NTU / PT-LB51NTE / PT-LB51NTEA / PT-LB51U / PT-LB51E / PT-LB51EA / PT-LB51SU / PT-LB51SEA

2.1.8. PT-LB51SEA
Ref. No. Part Name & Description PT-LB50SEA (Base Model) PT-LB51SEA Remarks
Part No. Pcs Part No. Pcs
[MECHANICAL PARTS]
FERRITE CORE -J0KG00000046 2
12 REMOTE CONTROLLER N2QAYA000002 1N2QAYB000172 1
18 LOGO BADGE TBMA193 1TBMA242 1SVGA
MODEL NAME PLATE TBMG182-1 1TBMG685 1
MODEL NO. LABEL TBMG191 1 -
19 CONTROL BUTTON A TBXA48901 1TBXA48902 1
33 REMOTE RECEIVER PLATE TKKC5243 1TKKC5253 1
SHIELD SHEET TMKY028 1 -
PCB-A SHIELD -TMKY350 1
61 CARTON TPCB94310 1TPCC26908 1
67 PASSWORD SHEET TQBH7017 1TQBH7032 1
66 INSTRUCTION BOOK TQBJ0196 1TQBJ0230 1
POWER CORE SHEET -TQDH19039 1
NEW EMC SHEET TQDJ19072 1 -
2-2 POWER CORD(EUROPE) K2CM3DR00002 1 -
2-3 POWER CORD(UK) K2CT3DR00005 1 -
POWER CORD & FERRITE CORE -TXFSX02QHUZ 1EUROPE
POWER CORD & FERRITE CORE -TXFSX02QHXZ 1UK
POLY BAG XZBT6532 1XZBT6506 1
57 UPPER COVER TXFKF99QCKZ 1TXFKF99QHTZ 1
58 BOTTOM COVER TXFKF98QCKZ 1TXFKF99QHZZ 1
[INTEGRATED CIRCUIT]
IC1011 I.C TVRP609-1 1TVRP672 1
[OTHERS]
RTL CIRCUIT BOARD A TXANP01QCHZA 1TXANP01QHTZ 1
BALLAST UNIT ASSY TXANP04VKB9 1TXANPBQQHRZ 1
10
PT-LB51NTU / PT-LB51NTE / PT-LB51NTEA / PT-LB51U / PT-LB51E / PT-LB51EA / PT-LB51SU / PT-LB51SEA
