Panasonic WX-SE200P User manual

Operating Instructions
Included Installation Instructions
Extension Receiver
Model No. WX-SE200P
ENGLISHFRANÇAIS
Before attempting to connect or operate this product, please read these instructions
carefully and save this manual for future use.
The model number is abbreviated in some descriptions in this manual.
PUQX1022YA
PUQX1022YAV6_WX-SE200P_OI_en-fr.indb 1 2022/03/23 10:21:36

2
Safety precautions
The lightning flash with
arrowhead symbol, within an
equilateral triangle, is intended
to alert the user to the presence
of uninsulated "dangerous
voltage" within the product's
enclosure that may be of
sufficient magnitude to
constitute a risk of electric shock
to persons.
The exclamation point within an
equilateral triangle is intended to
alert the user to the presence of
important operating and
maintenance (servicing)
instructions in the literature
accompanying the appliance.
Power disconnection. Unit with or without
ON-OFF switches have power supplied to
the unit whenever the power cord is
inserted into the power source; however,
the unit is operational only when the
ON-OFF switch is in the ON position.
Unplug the power cord to disconnect the
main power for all units.
WARNING:
⿠To prevent fire or electric shock hazard,
do not expose this apparatus to rain or
moisture.
⿠The apparatus should not be exposed
to dripping or splashing and no objects
filled with liquids, such as vases, should
be placed on the apparatus.
⿠The mains plug or an appliance coupler
shall remain readily operable.
⿠This device complies with Part 15 of the
FCC Rules and Innovation, Science
and Economic Development Canada’s
licence-exempt RSS(s). Operation is
subject to the following two conditions:
(1) This device may not cause harmful
interference, and (2) this device must
accept any interference received,
including interference that may cause
undesired operation.
CAN ICES-3(A)/NMB-3(A)
For Canada.
FCC Caution:
Changes or modifications not expressly
approved by the party responsible for
compliance could void the user's authority
to operate the equipment.
For U.S.A.
Supplier’s Declaration of
conformity
Trade Name: Panasonic
Model No.: WX-SE200P
Responsible Party:
Panasonic Corporation of North America
Two Riverfront Plaza, Newark, NJ
07102-5490
Support Contact: 1-800-491-9986
[email protected]
For U.S.A.
PUQX1022YAV6_WX-SE200P_OI_en-fr.indb 2 2022/03/23 10:21:37

3
ENGLISH
NOTE: This equipment has been tested
and found to comply with the limits for a
Class A digital device, pursuant to part 15
of the FCC Rules. These limits are
designed to provide reasonable protection
against harmful interference when the
equipment is operated in a commercial
environment. This equipment generates,
uses, and can radiate radio frequency
energy and, if not installed and used in
accordance with the instruction manual,
may cause harmful interference to radio
communications. Operation of this
equipment in a residential area is likely to
cause harmful interference in which case
the user will be required to correct the
interference at his own expense.
For U.S.A.
The model number and serial number of
this product may be found on the surface
of the unit.
You should note the model number and
serial number of this unit in the space
provided and retain this book as a
permanent record of your purchase to aid
identification in the event of theft.
Model No. ________________________
Serial No. ________________________
For U.S.A.
Descriptions of graphic symbols
This symbol indicates
alternating current (AC).
This symbol indicates a c-UL
certification mark in the United
States.
This symbol indicates double
insulation.
PUQX1022YAV6_WX-SE200P_OI_en-fr.indb 3 2022/03/23 10:21:37

4
Safety precautions
IMPORTANT SAFETY INSTRUCTIONS
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
8) Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
9) Only use attachments/accessories specified by the manufacturer.
10) Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use
caution when moving the cart/apparatus combination to avoid injury from
tip-over.
11) Unplug this apparatus during lightning storms or when unused for long periods of time.
12) Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.
PUQX1022YAV6_WX-SE200P_OI_en-fr.indb 4 2022/03/23 10:21:37

5
ENGLISH
Product overview
This product is an extension receiver for 1.9 GHz digital wireless microphone systems.
Connecting it to a wireless receiver (WX-SR204P: sold separately) enables receiving audio
from wireless microphones (WX-ST200P and WX-ST400P, both sold separately) via a
wireless antenna (WX-SA250P: sold separately) and the wireless receiver and adjusting
the audio output volume.
⿟Connecting this product enables up to 8 wireless microphones to be used with a
WX-SR204P system.
⿟Depending on the connected devices, either channel isolated output or mix output is
selectable for the audio output.
Limitation of liability
THIS PUBLICATION IS PROVIDED "AS IS" WITHOUT WARRANTY OF ANY KIND,
EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY, FITNESS FOR ANY PARTICULAR PURPOSE,
OR NON-INFRINGEMENT OF THE THIRD PARTY’S RIGHT. THIS PUBLICATION COULD
INCLUDE TECHNICAL INACCURACIES OR TYPOGRAPHICAL ERRORS. CHANGES
ARE ADDED TO THE INFORMATION HEREIN, AT ANY TIME, FOR THE
IMPROVEMENTS OF THIS PUBLICATION AND/OR THE CORRESPONDING
PRODUCT(S).
PUQX1022YAV6_WX-SE200P_OI_en-fr.indb 5 2022/03/23 10:21:37

6
Safety precautions
Disclaimer of Warranty
IN NO EVENT SHALL Panasonic Connect Co., Ltd. BE LIABLE TO ANY PARTY OR ANY
PERSON, EXCEPT FOR REPLACEMENT OR REASONABLE MAINTENANCE OF THE
PRODUCT, FOR THE CASES, INCLUDING BUT NOT LIMITED TO BELOW:
A
ANY LOSS OR DAMAGE, INCLUDING WITHOUT LIMITATION, DIRECT OR
INDIRECT, SPECIAL, CONSEQUENTIAL OR EXEMPLARY, ARISING OUT OF OR
RELATING TO THE PRODUCT;
B
ANY INCONVENIENCE, LOSS, OR DAMAGE CAUSED BY INAPPROPRIATE USE OR
NEGLIGENT OPERATION OF THE USER;
C
ALL MALFUNCTIONS OR TROUBLES FROM UNAUTHORIZED DISASSEMBLY,
REPAIR OR MODIFICATION OF THE PRODUCT BY THE USER, REGARDLESS OF
THE CAUSE OF THE MALFUNCTION OR TROUBLE;
D
ANY PROBLEM CAUSING FAILED SIGNAL TRANSMISSION RESULTING IN
CONSEQUENTIAL INCONVENIENCE, LOSS OR DAMAGE, ARISING OUT OF
CAUSES SUCH AS SYSTEM MALFUNCTION, FAULT, SET UP OR INSTALLATION.
E
ANY PROBLEM, CONSEQUENTIAL INCONVENIENCE, OR LOSS OR DAMAGE,
ARISING OUT OF THE SYSTEM COMBINED BY THE DEVICES OF THIRD PARTY.
Copyright
Distributing, copying, disassembling, reverse compiling and reverse engineering of the
software provided with this product are all expressly prohibited. In addition, exporting any
software provided with this product violating export laws is prohibited.
Abbreviations
This manual uses the following abbreviations.
⿟“Extension Receiver (WX-SE200P)” is referred to as “this product” or “extension
receiver”.
⿟“Wireless Receiver (WX-SR204P: sold separately)” is referred to as “receiver”.
⿟“Wireless Microphone (WX-ST200P/WX-ST400P: both sold separately)” is referred to as
“microphone”.
⿟“Wireless Antenna (WX-SA250P: sold separately)” is referred to as “antenna”.
All information on separately-sold products contained in this manual is up-to-date as of
May 2021. Refer to a retailer for the latest information.
PUQX1022YAV6_WX-SE200P_OI_en-fr.indb 6 2022/03/23 10:21:37

7
ENGLISH
Table of contents
Safety precautions……………………… 2
Product overview ………………………… 5
Limitation of liability ……………………… 5
Disclaimer of Warranty ………………… 6
Copyright ………………………………… 6
Abbreviations …………………………… 6
Precautions ……………………………… 8
Usage precautions……………………… 10
Parts and their names ………………… 12
Installation ……………………………… 15
Installation precautions ………………… 15
Installing in a rack………………………… 18
Connections …………………………… 20
Connecting the Euroblock connectors … 20
Connecting audio output ………………… 21
Connecting with a receiver ……………… 22
Pairing …………………………………… 24
Wireless pairing ………………………… 24
Wired pairing……………………………… 26
How to use ……………………………… 28
Operating microphones ………………… 28
Confirm the signal reception level ……… 29
Confirm the remaining battery level of the
microphone …………………………… 30
Confirm the paired microphones ……… 31
Dimensions ……………………………… 33
Troubleshooting ………………………… 34
Specifications …………………………… 35
Standard accessories …………………… 36
PUQX1022YAV6_WX-SE200P_OI_en-fr.indb 7 2022/03/23 10:21:37

8
Precautions
Entrust building operations to a retailer
The building operations needed to install this product require skill and experience. There is
a risk of fires, electric shocks, injuries, and damage to property.
⿟Always ask a retailer to do this.
Tighten screws and bolts with the specified tools
Failing to do so may cause parts to fall leading to accidents and injuries.
Plug the power plug all the way in
An improperly plugged power plug may lead to electric shocks, overheating, and fires.
⿟Do not use damaged power plugs or loose power sockets.
Directly grab the plug to remove the power cable from the socket
Failing to do so may damage the cord and lead to fire or electric shocks.
Use the specified fuses
Failing to do so may lead to fires or electric shocks.
Turn the product OFF before performing maintenance
Failing to do so may cause electric shocks.
Regularly remove dust from the electric plug
The insulation on a dusty plug may fail when it is subject to elements such as humidity,
thus leading to fire or electric shocks.
⿟Remove the power cord and clean it with a dry cloth.
If the product shows any abnormality, immediately stop using it
If the product shows abnormalities such as smoke or an unusual smell, continuing to use it
may pose a fire hazard.
⿟Immediately remove the power cord and contact the retailer.
Do not attempt to repair or wire the product while it is turned ON
It may lead to fire or electric shock.
Do not pull on cables and other components
It may lead to fire or electric shock.
Do not damage the cables
Placing heavy objects on the cables or squeezing them in tight places will damage them,
which could cause fires or electric shocks.
Do not use near flammable gases
Doing so may lead to explosions and accidents or injuries.
Do not install the product where there is a risk of damage from seawater or
corrosive gases
This may cause the mounting unit to deteriorate, leading to accidents and injuries.
Do not install at places exposed to large amount of humidity and/or dust.
It may lead to fire or electric shock.
PUQX1022YAV6_WX-SE200P_OI_en-fr.indb 8 2022/03/23 10:21:37

9
ENGLISH
Do not place on unstable surfaces
Failing to do so may cause the product to fall leading to accidents and injuries.
Do not use where there is a risk of exceeding the maximum recommended
wattage for the socket or the wiring, and only use 120 V current
Overloading multi-outlet extension cords could result in overheating and fires.
Do not let foreign substances into the product
Water or metals entering the antenna may lead to fires or electric shocks.
⿟Immediately remove the power cord and contact the retailer.
Avoid damaging the power cord and power plug
(by breaking them, tampering with them, bringing them near heat sources,
bending them excessively, twisting them, pulling on them, placing heavy
objects on them, tying them, etc.)
Using a damaged power cord or power plug may cause electric shocks, short circuits, or
fires.
⿟Entrust the repair of the power cord and power plug to a retailer.
Do not insert or pull the power plug with wet hands
Failing to do so may cause electric shocks.
Do not attempt to disassemble or remodel the product
It may lead to fire or electric shock.
Do not wet
It may lead to fire or electric shock.
⿟Immediately remove the batteries and contact the retailer.
Do not place containers full of water or other liquids on or near the product
If wet, the product may lead to fire or electric shocks.
⿟Immediately remove the power cord and contact the retailer.
Do not perform the installation and wiring work during a thunderstorm
It may lead to fire or electric shock.
PUQX1022YAV6_WX-SE200P_OI_en-fr.indb 9 2022/03/23 10:21:37

10
Other than the aforementioned “Precautions”, make sure to follow the points below.
This product is intended for indoor use only
⿟It cannot be used outdoors.
Avoid exposing the product to direct sunlight for extended periods of time, and do not
install it near air conditioners or heaters. Failing to do so may lead to damage to the
shape and color of the product, and may cause it to malfunction. Also avoid exposure to
water droplets and bubbles.
Use this product with care
⿟This product contains delicate components which may be damaged by improper use or
storage.
⿟Repair or replace any damaged components.
The operating temperature range is
⿟Between 0 °C (32 °F) and 45 °C (113 °F). Using the product outside of this range may
cause it to malfunction or to be damaged.
The power switch
⿟Turning the [POWER] switch to the OFF position will turn the extension receiver OFF,
but it will not interrupt the flow of current. (The [POWER] indicator being off does not
necessarily mean that there is no power going through the extension receiver.) Remove
the power cord from the power outlet to completely break off the flow of current to the
extension receiver.
Power
⿟The extension receiver uses AC 120 V (60 Hz) power. Connect the extension receiver to
an enough capacity power source.
⿟Connect the power cord to the power source in one of the following ways.
⿠Install the extension receiver near the electric outlet, allowing for easy access to the
power plug.
⿠Connect it to a breaker panel with at least 3.0 mm (1/8 inches) of space between
contacts. Use a breaker which can cut off power from all poles except the protective
ground connection.
Microphone remaining battery level indication
⿟When the distance between the microphone and the antenna is too far, the signal
reception becomes unstable so that microphone remaining battery level may not be
obtained. Keep the proper distance to ensure a stable wireless connection when using
the remaining battery level indication function. Refer to the receiver manual for
information about the distance (wireless reach) from the microphones to the antenna.
Usage precautions
PUQX1022YAV6_WX-SE200P_OI_en-fr.indb 10 2022/03/23 10:21:37

11
ENGLISH
When turning the power switch to ON or OFF
⿟All connected peripheral devices and power amplifiers have to be turned OFF before the
power switch operation. Failing to do so may cause a clicking noise which could
potentially damage the speakers or other peripheral devices.
When not using for an extended period of time
⿟Turn the power switch to OFF and remove the power plug from the electric outlet.
Condensation
⿟Be careful of condensation, as it may cause malfunctions.
Condensation is likely to happen in the following scenarios:
⿠High humidity
⿠Moving from a cold place to a hot or humid one
⿟If condensation does happen, wait for one to two hours and make sure that all
condensation is gone before turning ON the equipment.
Maintenance
⿟Perform it after having turned OFF the product. It may lead to injury.
⿟Clean the product with a dry, soft cloth.
⿟Do not use volatile chemicals such as paint thinner or benzine.
⿟When using chemically treated cloths, carefully read the included instructions.
⿟When the product is particularly dusty, use a vacuum cleaner etc. to clean it.
PUQX1022YAV6_WX-SE200P_OI_en-fr.indb 11 2022/03/23 10:21:37

12
Parts and their names
A B C D E
F
G
IH
APower switch [POWER]
Turns the power ON/OFF.
BPower indicator (green)
Lights when the power is turned ON. Goes off when the power is turned OFF.
CStatus indicator [STATUS]
Indicates the status of communication with the extension receiver.
On (green): Normal
Blinking (green): Error (no receiver or unable to communicate with the extension receiver)
Off: Power is OFF.
DReception level indicator [RF LEVEL]
Shows the reception level of the microphone RE signal on each channel in five
increments. Installing the wireless antenna and selecting the antenna field in such a way
that the microphone always shows at least three green lines (level 3) within its usage
area will ensure stable operation.
On (5 green lines): Level 5 (Max.)
On (4 green lines): Level 4
On (3 green lines): Level 3
On (2 green lines): Level 2
On (1 green line): Level 1 (Min.)
On (1 to 5 red lines): Reception error
All off: No paired microphone, or no signal from the paired microphone
EAudio level indicator / mute status indicator [AUDIO/MUTE]
Shows the audio level of the signal from the microphones on each channel.
On (red): Peak
On (orange): Close to peak
On (green): Audio is being received
Slow blinking (red): Muted (when this device is being controlled remotely)
Quick blinking (red): Volume adjustment knob cannot be operated (when this device
is being controlled remotely)
Off: No audio
If the volume adjustment knob is operated in the external remote state, the volume
level indicator blinks quickly (red) and volume adjustment is not possible.
Front
PUQX1022YAV6_WX-SE200P_OI_en-fr.indb 12 2022/03/23 10:21:37

13
ENGLISH
FVolume adjustment knob [VOL 0, 10]
Adjusts the volume of the microphone on the respective channel.
GMicrophone battery indicator [MIC BATT]
Changes color (green/orange/red) depending on the residual battery level of the
microphones on each channel. See “Confirm the remaining battery level of the
microphone” (page 30) for details.
HPairing button
This button controls the pairing between microphones and each channel on the
extension receiver.
⿟Pairing: Keep the [REG] button pressed for more than two seconds to enter pairing
mode. (page 24)
Exit pairing mode by shortly pressing the [REG] button once while in pairing
mode.
A channel cannot enter pairing mode when the microphones paired to that
channel are currently active.
⿟Pairing confirmation:
Shortly press the [REG] button to enter pairing confirmation mode.
(page 31)
Exit pairing confirmation mode by shortly pressing the [REG] button once
more.
IPairing indicator [REG]
Shows the current operation mode (pairing, pairing confirmation) of the channel.
Off: Standard mode
Blinking (orange): Pairing mode
On (green) (1 second): Pairing successful
Alternately blinking (orange/green):
Pairing confirmation
PUQX1022YAV6_WX-SE200P_OI_en-fr.indb 13 2022/03/23 10:21:37

14
Parts and their names
J K L M N O
JExtension receiver connector [RCVR IN]
Connect the receiver (EXT OUT) and the extension receiver (RCVR IN) with a LAN
cable (page 17).
KChanneloutputconnectors[CHOUT-10dBV600Ω1/2/3/4]
Individually outputs the audio from each channel.
LExternalinputconnector[AUDIOIN-10dBV600Ω]
Takes external audio input to be mixed and sent to the mix output connector.
MMixoutputconnector[MIXOUT-10dBV600Ω]
Outputs audio obtained by mixing the audio from each channel with the audio input from
the [AUDIO IN] connector.
NSIGNAL GND connector [SIGNAL GND]
Gathers the SIGNAL GND from external devices to eliminate electrical potential
difference.
OPower cord
Connect the power cord to an AC 120 V 60 Hz power source.
Rear
PUQX1022YAV6_WX-SE200P_OI_en-fr.indb 14 2022/03/23 10:21:37

15
ENGLISH
J K L M N O
JExtension receiver connector [RCVR IN]
Connect the receiver (EXT OUT) and the extension receiver (RCVR IN) with a LAN
cable (page 17).
KChanneloutputconnectors[CHOUT-10dBV600Ω1/2/3/4]
Individually outputs the audio from each channel.
LExternalinputconnector[AUDIOIN-10dBV600Ω]
Takes external audio input to be mixed and sent to the mix output connector.
MMixoutputconnector[MIXOUT-10dBV600Ω]
Outputs audio obtained by mixing the audio from each channel with the audio input from
the [AUDIO IN] connector.
NSIGNAL GND connector [SIGNAL GND]
Gathers the SIGNAL GND from external devices to eliminate electrical potential
difference.
OPower cord
Connect the power cord to an AC 120 V 60 Hz power source.
Rear
Installation
■Installation precautions
Warning
⿟Always ask a retailer to perform these operations.
⿟Before installation, set the power switch on the devices
you want to connect to OFF.
⿟Carefully read the “Precautions” section and follow all of
its instructions. Also refer to the manual of the devices
you are connecting.
⿟If this product is used in a residential environment, it
may cause wireless interference.
When installing this product, follow all official ordinances on electrical equipment
technical standards.
This product is intended for indoor use only
⿟It cannot be used outdoors.
Avoid exposing the product to direct sunlight for extended periods of time, and do not
install it near air conditioners or heaters. Failing to do so may lead to damage to the
shape and color of the product, and may cause it to malfunction. Also avoid exposure to
water droplets and bubbles.
Turn the product OFF to install it
⿟Remove the power cord from the power socket before performing these operations. Also
turn OFF all mixers, amplifiers, and other devices connected to the extension receiver.
Failing to do so will result in a loud noise coming out of the speakers and possibly
damaging the system.
Installation place
⿟This product produces a large amount of heat.
When installing product near a wall or ceiling, make sure it has at least 10 cm (3-15/16
inches) of clearance on all sides (see figure below).
At least
10 cm
(3-15/16 inches)
At least 10 cm
(3-15/16 inches)
At least
10 cm
(3-15/16 inches)
Wall
Front
side
⿟Place the product on a flat surface. Do not place it upright with the rear surface facing
downward.
PUQX1022YAV6_WX-SE200P_OI_en-fr.indb 15 2022/03/23 10:21:38

16
Installation
Do not install the product in the following places
⿟Places exposed to direct sunlight or hot air currents
⿟Places exposed to large amounts of humidity and/or dust
⿟Places with a lot of condensation, subject to extreme temperature variation, or with very
high humidity
⿟Places with large amounts of steam or grease, such as kitchens
⿟Near speakers, TVs, magnets, and other strong magnetic sources
⿟Inclined surfaces
⿟Where there is a risk of damage from seawater or corrosive gases
When installing in a rack
⿟When installing the extension receiver in a rack, use one of those listed on “Installing in
a rack” (page 18).
⿟Make sure that the temperature of the rack does not exceed +45 °C (113 °F). Not doing
so damages the inner components of the extension receiver and causes it to
malfunction.
⿟Place the extension receiver as far down on the rack as possible.
Power specifications
⿟The product uses AC 120 V (60 Hz) power. Connect the product to an enough capacity
power source.
Power
⿟Turning the power switch to OFF will turn the product OFF but it will not interrupt the flow
of current. Connect the power cord through a power breaking device in one of the
following ways in order to be able to easily switch it OFF.
⿠Install the product near the electric outlet or breaker, and connect by the power plug.
⿠Connect the product to a breaker panel with at least 3.0 mm (1/8 inches) of space
between contacts. Use a breaker which can cut off power from all poles except the
protective ground connection.
Static electricity
⿟Before installing the product, discharge yourself by touching a grounded metal object in
order to avoid damage caused by static electricity buildup.
Tightening screws
⿟Tighten screws straight up. After tightening the screws, make visual confirmation that
they are straight and well-tightened.
⿟Do not use impact screwdrivers or electric screwdrivers, as even the ones with clutches
make it difficult to control the torque, and risk damaging the mounting unit.
PUQX1022YAV6_WX-SE200P_OI_en-fr.indb 16 2022/03/23 10:21:38

17
ENGLISH
Avoid subjecting the product to shocks
⿟Protect the product from strong hits or shocks. These may cause damage to the product.
LAN cable
⿟LAN cable not included with the antenna.
Use a Cat 5 (or Cat 5e or Cat 6) straight network LAN cable. There is a maximum cable
length depending on the connection method. See “Connecting with a receiver” (page
22) for details.
PUQX1022YAV6_WX-SE200P_OI_en-fr.indb 17 2022/03/23 10:21:38

18
Installation
■Installing in a rack
The extension receiver can be installed within a rack.
Use one of the following racks (sold separately) for installation.
EIA-standard product: EIA 19-inch rack, at least 450 mm (17-5/8 inches) long
1 Remove the rubber feet (x4) on the bottom of the extension receiver
Rubber feet
2 Use the included rack-bracket screws (x4) to attach the rackmount
brackets to both sides of the extension receiver
⿟Rack-bracket screws torque: 0.88 N•m to 1.08 N•m (9.0 kgf•cm to 11.0 kgf•cm)
Rackmount bracket
(Both sides)
Rack-bracket
screws
x4
PUQX1022YAV6_WX-SE200P_OI_en-fr.indb 18 2022/03/23 10:21:38

19
ENGLISH
3 Install the extension receiver in the rack
Use rack-installation screws (x4) to securely fix the extension receiver.
⿟Rack-installation torque: 2.0 N•m to 2.4 N•m {20.5 kgf•cm to 24.5 kgf•cm}
Rack-installation screws
x4 (locally procured)
memo
Important
⿟Make sure that the temperature inside the rack does not exceed +45 °C
(113 °F).
⿟Do not place the extension receiver near devices which diffuse large
amounts of heat (eg: power amplifiers).
If it is absolutely necessary to do so, leave at least 1 U (44 mm (1-3/4
inches)) of free space between the extension receiver and the heat-
diffusing device.
⿟When installing heat-sensitive devices in the same rack as the extension
receiver, place them lower than the extension receiver itself.
⿟Install the rack at well-ventilated location. Ventilate the rack so that
accumulated heat does not bring the internal temperature over +45 °C
(113 °F).
PUQX1022YAV6_WX-SE200P_OI_en-fr.indb 19 2022/03/23 10:21:39

20
■Connecting the Euroblock connectors
The audio input and output connectors of the extension receiver use removable Euroblock
connectors.
1 Connecting wires to the included Euroblock connectors
Use a flat-head screwdriver to loosen the screws on the Euroblock connector. Remove
a piece of coating from the wire to expose the conductor. Twist the conductor and
insert it into the Euroblock connector. Finally, tighten the screws on the Euroblock
connector.
7 mm±1 mm
(1/4 inches ± 1/16 inches)
memo
Important
Cable specifics
⿟Recommended cable: AWG 16 to 28 (do not use soldered cables)
⿟Length of the coating to be removed: 7 mm ± 1 mm (1/4 inches ± 1/16
inches)
⿟Screw diameter: 2 mm (1/16 inches)
⿟Make sure that the wires are securely connected.
Connections
PUQX1022YAV6_WX-SE200P_OI_en-fr.indb 20 2022/03/23 10:21:39
