Panasonic WJHD100 - DIGITAL DISC RECORDE User manual

Digital Disk Recorder
WJ-HD100
R
Equipped with a 30GB hard disk drive, this digital
surveillance recorder combines high image quality with
outstanding cost performance.
• High quality picture by DIGITAL recording.
• Built-in 30GB HDD.
• Max. 960 hours (approx.) recording capability.
• Four(4) way compression modes (Super Fine / Fine / Normal / Extended)
and manual settings.
• Built-in *CF (CompactFlash) Card slot for browsing the recorded pictures to PC.
• Built-in Motion Detector function.
• Built-in Time & Date generator.
• Easy access Time/Date & Alarm search function for speedy checking.
• Up to 16 units WJ-HD100 as series connection for extended length recording.
• Remote control by PC with RS232C devices, and RS485 chain by
PS-Data link.
• Various alarm mode setting.
• Easy installation and operation.
• 1H (height) compact design.
*Trademarks : SanDisk and CompactFlash are trademarks of SanDisk Corporation.
Panasonic proudly introduces the WJ-HD100 surveillance hard
disk recorder equipped with a 30GB disk drive for image storage.
The WJ-HD100 takes surveillance systems to a new level. The
benefits that come with a hard disk drive include, ultra-fast retrieval,
high durability, and elimination of image degradation due to
repeated recording and reproduction. And with no need to change or
file cassettes.
Additional features include motion detection, time & date display,
remote control from a PC, and alarm-driven image capture.
The *CompactFlash card slot makes it easy
to transfer images to other digital devices.
All these features are combined into a
single, compact unit. A digital surveillance
recorder whose cost performance is
extraordinary.
Key Features
REC MODE (H) 18 24 48 72 96 120 170 180 240 480 960
Extended FPS 15 10 6.0 4.2 3.3 2.7 1.8 1.7 1.3 0.6 0.3
QUALITY 55555555555
REC MODE (H) 18 24 48 72 96 120 170 180 240 480 960
Normal FPS 15 10 5.0 3.7 2.7 2.3 1.5 1.5 1.1 0.5 0.2
QUALITY 77777777777
REC MODE (H) 12 18 24 48 72 96 120 170 180 240 480 960
Fine FPS 15 10 10 5.0 3.3 2.5 2.0 1.4 1.3 1.0 0.5 0.2
QUALITY 888888888888
REC MODE (H) 12 18 24 48 72 96 120 170 180 240 480 960
Super Fine FPS 15 10 7.5 3.7 2.7 2.0 1.5 1.1 1.0 0.8 0.4 0.2
QUALITY 10 10 10 10 10 10 10 10 10 10 10 10
M
O
D
E
Time-Lapse Mode Recording Time
640H x 240V, NTSC Color Signal, Audio Signal ; Off FPS ( Field Per Second ) Time-Lapse Mode Recording Time 640H x 240V, NTSC Color Signal, Audio Signal ; Off
Capture Rate 0.5 sec 1.0 sec 2.0 sec
FPS 2 1 0.5
Extended 166 333 667
Normal 139 277 556
Fine 125 250 500
Super Fine 99 199 399
( Hours )
Hard Disk Drive
In Case of 30GB HDD

• Weights and dimensions are approximate. • Specifications are subject to change without notice. • These products may be subject to export control regulations.
Printed in Japan
WJ-JHHD100T(2P-480)
DISTRIBUTED BY:
PANASONIC CANADA INC.
5770 Ambler Drive, Mississauga, Ontario, L4W 2T3 Canada [phone]
PANASONIC SALES COMPANY
DIVISION OF MATSUSHITA ELECTRIC OF PUERTO RICO, INC.
San Gabriel Industrial Park 65th Infantry Ave. KM. 9.5 Carolina, P.R. 00985 [phone]
Zone Office
Eastern : One Panasonic Way, Suite 3E-7, Secaucus, NJ 07094 [phone]
Western : 6550 Katella Ave., Cypress, CA 90630 [phone]
http://cctv.panasonic.com
Panasonic Security & Digital Imaging Company
A Division of Matsushita Electric Corporation of America
Security Systems Group
Executive Office : One Panasonic Way 3E7, Secaucus, New Jersey 07094
Operate LED
Daylight Savings Button
Lock LED
*
CF (CompactFlash) Card slot
LCD Display
1
2
3
4
5
LCD Contrast VR
Alarm Search Button
(PLAY MODE SELECT)
Step Button
(PLAY MODE SELECT)
/ Button
6
7
8
REW/FF Button
(PLAY MODE SELECT)
/ Button
JOG Shuttle
Alarm Suspend LED
Timer LED
9
10
11
12
HDD LED
FULL LED
Display Select Button
Stop Button/SETUP, ESC Button
Play Button
Rec Button
13
14
15
16
17
18
Power Coad
Power SW
Fan
Terminal Connector
MODE SW
DATA Connector
19
20
21
22
23
24
RS-232C Connector
Monitor Out Connector
Video In / Out Connector
Camera SW Out Connector
Audio In / Out Connector
25
26
27
28
29
1 13
1 2
11 12 16 18 25 24 23 14 15 17
29 28 27 26 22 21 20 19
4 5 6 7 8 9 10
3
SYSTEM EXAMPLES
MAJOR OPERATING CONTROLS
DIMENSIONS
SPECIFICATIONS
Color Monitor Color Monitor
Color Monitor
(up to 16 units)
WJ-MP204
SystemController
SystemController
WV-CU360
WV-CU360
PS-Data Link
Color Camera WV-CS854 x 4
WJ-MP204
WV-CS554 x 4
Color Cameras
x 8
Digital Disk Recorder WJ-HD100
Digital Disk Recorder WJ-HD100
Digital Disk Recorder WJ-HD100
Video Multiplexer
Spot
Color Monitor
Multi
screen
Color Monitor
WV-CU161
Color Quad Unit WJ-MS424
Alarm / Sensor
WV-CS854
Color Cameras
*
*
Panasonic
480(18-7/8")
465(18-5/16")(Mounting Pitch)
420(16-9/16")
320(12-5/8")
270(10-5/8")
40
(1-9/16")
350(13-3/4")
44(1-3/4")
10
(3/8")
32 (1-1/4")
Digital Disk Recorder WJ-HD100
Mounting Pitch
1
2
3
General
Required Power AC 120V 50/60Hz
Power Consumption 24W
Operating Temperature +5˚C - +45˚C (41˚F - 113˚F)
Dimensions
420mm(W) x 44mm(H) x 350mm(D)[16-9/16” x 1-3/4” x 13-3/4”], rubber feet exclusive
Weight 5.2 kg (2.4 lbs)
Input
Video Input Composite video signal, 1V [p-p], 75 Ωauto-termination, BNC
Audio Input -10 dBV, 10 kΩ, unbalanced, RCA pinjack
Alarm Input Dry contact, 100ms or longer, terminal
Alarm Reset Input Dry contact, 100ms or longer, terminal
Clock Calibration Input Dry contact, 100ms or longer, terminal
Series Recording Input Dry contact, 100ms or longer, terminal
Alarm Recall Input Dry contact, 100ms or longer
Output
Video Output Looped through, composite video signal, 1V[p-p], 75 Ωauto-termination, BNC
Audio Output -10 dBV, 600 Ω, unbalanced, RCA pinjack
Camera Switching Output Open-collector, Max. DC 12V 100mA, terminal
Alarm Output Low-active (open-collector, Max. DC 24V 100mA) /hi-active (DC 12V, 220 Ω)
switchable, terminal
Alarm Recovery Output Low-active (open-collector, Max. DC 24V 100mA) /hi-active (DC 5V, 220 Ω)
switchable, terminal
Recording Status Output Open-collector, Max. DC 24V 100mA, terminal
Playback Status Output Open-collector, Max. DC 24V 100mA, terminal
Clock Calibration Output Open-collector, Max. DC 24V 100mA, terminal
Disk End Status Output Open-collector, Max. DC 24V 100mA, terminal
Auto Off Output Open-collector, Max. DC 24V 100mA, terminal
Series Recording Output Open-collector, Max. DC 24V 100mA, terminal
Serial Interface
RS-232C 9-pin D-sub
RS-485 PS-Data protocol, RJ-11
Remote Control In
REC, PLAY, STOP (SET), FF/REW, STEP, ALM SEARCH, JOG-RIGHT, JOG-LEFT, JOG-CLICK :
Non-voltage make contact, 100ms or longer, terminal
Alarm Function
Alarm Buzzer On/Off
Alarm Reset Auto reset/manual reset
Alarm Suspension On/Off
Button Lock Buzzer On/Off
Unit : mm(inches)
