Panasonic AK-HRP1005G User manual

DVQP2898ZAW1122AM0 -PS
ENGLISH
For details of operating Remote Operation Panel AK-HRP1005G, please visit
the Panasonic website (https://pro-av.panasonic.net/manual/en/index.html),
and refer to the Operating Instructions (HTML or PDF).
Read this document when using the AK-HRP1005G Remote Operation Panel in
conjunction with AW-UE80/AW-UE50/AW-UE40 4K Integrated Camera.
Operating Guide
Remote Operation Panel
Model No. AK-HRP1005G

Connecting the Unit to AW-UE80/AW-UE50/AW-
UE40 Cameras 3
Connection Example 3
Connections 4
Compatible Functions List 5
ROP Menu (during AW-UE80/AW-UE50/AW-UE40
connection) 8
ROP Menu List 8
01 SCENE 14
02 SHUTTER SPEED 15
03 FILTER 16
04 PEDESTAL 17
05 CHROMA 18
06 GAIN 19
07 WHITE BALANCE 20
08 GAMMA 21
09 KNEE 22
10 WHITE CLIP 23
11 DRS 24
12 DETAIL 25
13 MATRIX 26
14 COLOR CORRECTION 27
15 DNR 30
16 BRIGHTNESS 31
17 LENS CONTROL 32
18 IRIS RELATIVE 33
19 SYSTEM CAM 34
20 CAMERA MENU CONTROL 36
21 ROP SETTING 37
22 CONNECT SETTING 38
23 ROP IP SETTING 39
24 CAMERA IP SETTING 39
25 AUTO IRIS SETTING 40
26 SWITCHER LINK 41
27 AW CONTROLLER LINK 41
- 2 -
Table of Contents

Connecting the Unit to AW-UE80/AW-UE50/AW-UE40
Cameras
Connection Example
IP connection with AW-UE80
Switching hub
with PoE support
LAN cable (straight cable)
Supplied
AC adapter
LAN cable
(straight cable)
<LAN LINK/ACT> connector
4K Integrated Camera
AW-UE80
IP connection with AW-UE50/AW-UE40
The figure shows a connection example with the AW-UE40 model.
RS-422
SERVICE
AUDIO IN
LAN
LINK ACT
DC IN
12V
4K Integrated Camera
AW-UE50/AW-UE40
<LAN LINK/ACT> connector
Switching hub
with PoE support
LAN cable (straight cable)
LAN cable (straight cable)
Supplied AC adapter
- 3 -
Connecting the Unit to AW-UE80/AW-UE50/AW-UE40 Cameras

Connections
Set the connection settings to “LAN (AW6)” in the [CONNECT SETTING] menu.
ヒチバチヒヘ
ヤヰワワユヤヵチヴユヵヵリワヨロモワ⾷モヸプ⾸ワヰワワヰワワヰワワヰワワヰワヤモヮヒヤモヮピヤモヮプヤモヮフヤモヮブヤモヮビヤヰワワユヤヵチヮヰュユドㄑㄖㄔㄉナヤヰワワユヤヵチヮヰュユドㄑㄖㄔㄉナ
When connecting, observe the following points.
Connect the <LAN> connector on this unit to the <LAN LINK/ACT> connector on the AW-UE80/AW-UE50/AW-UE40
using a LAN cable (sold separately).
Configure the camera IP address and port number settings of the connection destinations in [CAMERA IP SETTING] as
well.
This unit can be powered using PoE. Use a switching hub with PoE support.
Use a straight cable (category 5e or higher; up to 100 m (328.0 ft) in length) for the LAN cable (STP).
For details on switching hubs and PoE injectors that have been verified to support PoE, consult with your dealer.
- 4 -
Connecting the Unit to AW-UE80/AW-UE50/AW-UE40 Cameras

Compatible Functions List
When the unit is used in conjunction with an AW-UE80/AW-UE50/AW-UE40 4K Integrated Camera, there will be functions that are limited
or disabled for some of the unit's buttons, dials, and other controls. Be sure to refer to the following table.
Front panel 1
Front panel 2
Front panel 3
Front panel 4
Front panel 5
Front panel 6
Number Part name
✓: Enabled
×: Disabled
Remarks
Front panel 1
[PANEL LOCK] button ✓
[AUTO] button ✓If auto setup has been assigned, this will not
operate.
[BARS] button ✓Only the ON/OFF for the color bar signal output
will function.
[TALLY/CALL] lamp/button ✓Only the [TALLY] lamp is lit.
[REF. RECALL] button ×
[FILES] button ✓This is always lit.
[SETUP] button ✓
[AUTO IRIS] button ✓
Front panel 2
Function buttons ✓
LCD panel ✓
Menu operation dials ✓
- 5 -
Connecting the Unit to AW-UE80/AW-UE50/AW-UE40 Cameras

Number Part name
✓: Enabled
×: Disabled
Remarks
Front panel 3
[GAIN] button ✓When this button is pressed, the gain menu
appears on the LCD panel. The button is lit dur-
ing menu display.
[SHT] button ✓When this button is pressed, the shutter menu
appears on the LCD panel. The button is lit dur-
ing menu display.
[COLOR] button ✓The menus will switch with each press of the but-
ton. The button is lit during menu display.
[WHITE BALANCE] > [CHROMA] > [MATRIX] >
[COLOR CORRECTION] > Menu off (status
screen)
[FILTER] button ✓When the button is pressed, the filter menu
appears on the LCD panel. The button lit during
menu display, and the ND filter can be con-
figured.
Functional only when connected to the AW-
UE80.
[GAMMA] button ✓When the button is pressed, the gamma menu
appears on the LCD panel. The button lit during
menu display.
[FLARE] button ×
[KNEE] button ✓The menus will switch with each press of the but-
ton. The button is lit during menu display.
[KNEE] > [WHITE CLIP] > Menu off (status
screen)
[DTL] button ✓The menus will switch with each press of the but-
ton. The button is lit during menu display.
[DTL] > [DNR] > Menu off (status screen)
Front panel 4
[GAIN], [TEMP], [GAMMA], [SKIN] adjust-
ment block
✓When [GAIN] is lit:
Adjust [GAIN R] with the red (R) adjust-
ment dial.
Adjust [GAIN B] with the blue (B) adjust-
ment dial.
When [TEMP] is lit:
Adjust the balance of [WHITE BALANCE]
> [COLOR TEMP] with the green (G)
adjustment dial.
When [GAMMA] is lit:
Adjust [MASTER GAMMA] with the green
(G) adjustment dial.
When [SKIN] is lit:
[SKIN] cannot be controlled.
[PED], [FLARE], [B.GAM] adjustment block ✓When [PED] is lit:
Adjust [M.PED] with the green (G) adjust-
ment dial.
When [FLARE] is lit:
[FLARE] cannot be controlled.
When [B.GAM] is lit:
[B.GAM] cannot be controlled.
- 6 -
Connecting the Unit to AW-UE80/AW-UE50/AW-UE40 Cameras

Number Part name
✓: Enabled
×: Disabled
Remarks
Front panel 5
[ALM] indicator ✓
[OPT] indicator ×
[EXT] indicator ×
[D.EXT] indicator ✓
Adjustment value display ✓The adjustment value of the CC filter is not dis-
played.
[ND] indicator ✓
[CC] indicator ×
[IRIS] indicator ✓
[GAIN] indicator ✓
[PED] indicator ✓
[SHT] indicator ✓
[SYNC] indicator ✓
[DISP] button ✓
[UP (FREE)] button ✓
[DOWN (CHARA)] button ✓
[LOCK] indicator ✓
[SEL] dial ✓Corresponds to the setting value of the function
selected with the [DISP] button.
Front panel 6
Memory card slot ✓
Memory card access indicator ✓
Camera number/tally display ✓
[IRIS RELATIVE] button ✓
Torque adjustment screw ✓
IRIS lever ✓
Master pedestal dial ✓
[PREVIEW] button ✓
- 7 -
Connecting the Unit to AW-UE80/AW-UE50/AW-UE40 Cameras

ROP Menu (during AW-UE80/AW-UE50/AW-UE40 con-
nection)
ROP Menu List
When an AW-UE80/AW-UE50/AW-UE40 4K Integrated Camera is connected, the ROP menu will be as follows.
Setting values differ according to the model to be connected. Functions not supported depending on the model are indicated with [-].
NOTE
To use the menu features of AW-UE80, AW-UE50 and AW-UE40, upgrade their unit system versions to the following:
AW-UE80: System version 5.12-00-0.00 or later
AW-UE50/AW-UE40: System version 5.13-00-0.00 or later
For details on menu operations, refer to the following sections in the Operating Instructions.
“Displaying menus”
“Basic menu operations”
01 SCENE
SCENE1(push) “SCENE1(push)” (see page 14)
SCENE2(push) “SCENE2(push)” (see page 14)
SCENE3(push) “SCENE3(push)” (see page 14)
SCENE4(push) “SCENE4(push)” (see page 14)
02 SHUTTER SPEED
MODE “MODE” (see page 15)
SPEED “SPEED” (see page 15)
ELC “ELC” (see page 15)
03 FILTER ND “ND” (see page 16)
04 PEDESTAL M.PED “M.PED” (see page 17)
05 CHROMA
LEVEL “LEVEL” (see page 18)
PHASE “PHASE” (see page 18)
06 GAIN
SUPER GAIN “SUPER GAIN” (see page 19)
GAIN “GAIN” (see page 19)
AGC MAX GAIN “AGC MAX GAIN” (see page 19)
07 WHITE BALANCE
MODE “MODE” (see page 20)
COLOR TEMP “COLOR TEMP” (see page 20)
GAIN OFFSET “GAIN OFFSET” (see page 20)
GAIN R “GAIN R” (see page 20)
GAIN B “GAIN B” (see page 20)
ATW SPEED “ATW SPEED” (see page 20)
ATW TRGT R “ATW TRGT R” (see page 20)
ATW TRGT B “ATW TRGT B” (see page 20)
08 GAMMA
MODE “MODE” (see page 21)
GAMMA “GAMMA” (see page 21)
09 KNEE MODE “MODE” (see page 22)
10 WHITE CLIP
WHITE CLIP “WHITE CLIP” (see page 23)
WHITE CLP LV “WHITE CLP LV” (see page 23)
11 DRS DRS “DRS” (see page 24)
- 8 -
ROP Menu (during AW-UE80/AW-UE50/AW-UE40 connection)

12 DETAIL
MASTER DTL “MASTER DTL” (see page 25)
CORING “CORING” (see page 25)
V DTL LEVEL “V DTL LEVEL” (see page 25)
SKIN DTL “SKIN DTL” (see page 25)
SKIN DTL EFFECT “SKIN DTL EFFECT” (see page 25)
DTL SW “DTL SW” (see page 25)
13 MATRIX
TYPE “TYPE” (see page 26)
ADAPTIVE MATRIX “ADAPTIVE MATRIX” (see page 26)
R-G “R-G” (see page 26)
R-B “R-B” (see page 26)
G-R “G-R” (see page 26)
G-B “G-B” (see page 26)
B-R “B-R” (see page 26)
B-G “B-G” (see page 26)
- 9 -
ROP Menu (during AW-UE80/AW-UE50/AW-UE40 connection)

14 COLOR CORRECTION
TYPE “TYPE” (see page 28)
ADAPTIVE MATRIX “ADAPTIVE MATRIX” (see page 28)
COLOR CORRECT “COLOR CORRECT” (see page 28)
SAT “SAT” (see page 28)
PHASE “PHASE” (see page 28)
SAT B_Mg “SAT B_Mg” (see page 28)
PHASE B_Mg “PHASE B_Mg” (see page 28)
SAT Mg “SAT Mg” (see page 28)
PHASE Mg “PHASE Mg” (see page 28)
SAT Mg_R “SAT Mg_R” (see page 28)
PHASE Mg_R “PHASE Mg_R” (see page 28)
SAT Mg_R_R “SAT Mg_R_R” (see page 28)
PHASE Mg_R_R “PHASE Mg_R_R” (see page 29)
SAT R “SAT R” (see page 29)
PHASE R “PHASE R” (see page 29)
SAT R_R_YL “SAT R_R_YL” (see page 29)
PHASE R_R_YL “PHASE R_R_YL” (see page 29)
SAT R_YL “SAT R_YL” (see page 29)
PHASE R_YL “PHASE R_YL” (see page 29)
SAT R_YL_YL “SAT R_YL_YL” (see page 29)
PHASE R_YL_YL “PHASE R_YL_YL” (see page 29)
SAT YL “SAT YL” (see page 29)
PHASE YL “PHASE YL” (see page 29)
SAT YL_YL_G “SAT YL_YL_G” (see page 29)
PHASE YL_YL_G “PHASE YL_YL_G” (see page 29)
SAT YL_G “SAT YL_G” (see page 29)
PHASE YL_G “PHASE YL_G” (see page 29)
SAT G “SAT G” (see page 29)
PHASE G “PHASE G” (see page 29)
SAT G_CY “SAT G_CY” (see page 29)
PHASE G_CY “PHASE G_CY” (see page 29)
SAT CY “SAT CY” (see page 29)
PHASE CY “PHASE CY” (see page 29)
SAT CY_B “SAT CY_B” (see page 29)
PHASE CY_B “PHASE CY_B” (see page 29)
SAT B “SAT B” (see page 29)
PHASE B “PHASE B” (see page 29)
15 DNR DNR “DNR” (see page 30)
16 BRIGHTNESS
PICTURE LEVEL “PICTURE LEVEL” (see page 31)
FRAME MIX “FRAME MIX” (see page 31)
DAY/NIGHT “DAY/NIGHT” (see page 31)
A.F.MIX GAIN “A.F.MIX GAIN” (see page 31)
BACKLIGHT “BACKLIGHT” (see page 31)
SPOTLIGHT “SPOTLIGHT” (see page 31)
FLICKER “FLICKER” (see page 31)
- 10 -
ROP Menu (during AW-UE80/AW-UE50/AW-UE40 connection)

17 LENS CONTROL
FOCUS MODE “FOCUS MODE” (see page 32)
FOCUS SPEED “FOCUS SPEED” (see page 32)
FOCUS “FOCUS” (see page 32)
ZOOM TELE “ZOOM TELE” (see page 32)
ZOOM SPEED “ZOOM SPEED” (see page 32)
ZOOM WIDE “ZOOM WIDE” (see page 32)
AF MODE “AF MODE” (see page 32)
DIGITAL ZOOM SW “DIGITAL ZOOM SW” (see page 32)
DIGITAL ZOOM MAX “DIGITAL ZOOM MAX” (see page 32)
DIGITAL ZOOM D.EXT “DIGITAL ZOOM D.EXT” (see page 32)
18 IRIS RELATIVE
SENSE “SENSE” (see page 33)
COARSE “COARSE” (see page 33)
RELATIVE “RELATIVE” (see page 33)
19 SYSTEM CAM
FORMAT “FORMAT” (see page 34)
FREQUENCY “FREQUENCY” (see page 34)
3G SDI OUT “3G SDI OUT” (see page 34)
I.S. “I.S.” (see page 34)
OSD 12G “OSD 12G” (see page 34)
OSD 3G “OSD 3G” (see page 34)
OSD NDI “OSD NDI” (see page 34)
OSD HDMI “OSD HDMI” (see page 34)
OSD IP “OSD IP” (see page 35)
OSD STATUS “OSD STATUS” (see page 35)
AUDIO “AUDIO” (see page 35)
GENLOCK PHASE “GENLOCK PHASE” (see page 35)
TALLY CONTROL “TALLY CONTROL” (see page 35)
TALLY INPUT “TALLY INPUT” (see page 35)
TALLY SIGNAL “TALLY SIGNAL” (see page 35)
TALLY CONT MD “TALLY CONT MD” (see page 35)
20 CAMERA MENU CONTROL
MENU ON/OFF “MENU ON/OFF” (see page 36)
CURSOR/PARAMETER “CURSOR/PARAMETER” (see page 36)
EXECUTE “EXECUTE” (see page 36)
- 11 -
ROP Menu (during AW-UE80/AW-UE50/AW-UE40 connection)

21 ROP SETTING
IRIS LEV MODE Refer to the following section in the Operating Instructions.
“37 ROP SETTING”
M.PED CONT
LOCK SELECT
AUTO BUTTON
G/M PED VOL
FREE+LOCK
CAM SEL
DTL BUTTON
SKIN VOL
LCD BRIGHT
PANEL BRIGHT
B.GAMMA VOL
BUZZER
PERIOD
CYCLE
STD POSITION M.GAIN
STD POSITION VAR
STD POSITION ND
STD POSITION CC
IRIS PRIORITY
ROP DATA SAVE
ROP DATA LOAD
SD CARD FORMAT
INITIAL with NW
INITIAL
UPGRADE
IRIS CALIBRATION TOP
IRIS CALIBRATION BOTTOM
SYSTEM VERSION
SOFT VERSION
FPGA VERSION
22 CONNECT SETTING
CONNECT MODE(push) CAM1 “CONNECT MODE(push) CAM1” (see page 38)
CONNECT MODE(push) CAM2
to CAM99 “CONNECT MODE(push) CAM2 to CAM99” (see page 38)
- 12 -
ROP Menu (during AW-UE80/AW-UE50/AW-UE40 connection)

23 ROP IP SETTING
IP ADDRESS 1 Refer to the following section in the Operating Instructions.
“39 ROP IP SETTING”
IP ADDRESS 2
IP ADDRESS 3
IP ADDRESS 4
IP ADDRESS PORT
IP ADDRESS UPLOAD
SUBNET MASK 1
SUBNET MASK 2
SUBNET MASK 3
SUBNET MASK 4
SUBNET MASK UPLOAD
DEFAULT GATEWAY
DEFAULT GATEWAY
UPLOAD
MAC ADDRESS
24 CAMERA IP SETTING
CAM1 to CAM99 IP ADDRESS Refer to the following section in the Operating Instructions.
“40 CAMERA IP SETTING”
CAM1 to CAM99 PORT
CAM1 to CAM99 INF UPLOAD
25 AUTO IRIS SETTING
IRIS SPEED “IRIS SPEED” (see page 40)
IRIS WINDOW “IRIS WINDOW” (see page 40)
26 SWITCHER LINK
SW' IP Refer to the following sections in “Functions Added by Version
Updates”.
“Functions linking with AV-HS6000”
RECEIVE UDP PORT
UPLOAD
SWITCHER LINK
TALLY RECEIVE
PREVIEW
TALLY ACTION MATERIAL
TALLY ACTION CAM No.
27 AW CONTROLLER LINK
RECEIVE PORT Refer to the following sections in “Functions Added by Version
Updates”.
“Function linking with AW-RP150”
INFO UPLOAD
AW CONT LINK
- 13 -
ROP Menu (during AW-UE80/AW-UE50/AW-UE40 connection)

01 SCENE
ヒチバチヒ
ヴヤユワユヰワヰョョヰョョヰョョヴヤユワユヒドㄑㄖㄔㄉナヴヤユワユピドㄑㄖㄔㄉナヴヤユワユフドㄑㄖㄔㄉナヴヤユワユビドㄑㄖㄔㄉナ
Item Setting details
SCENE1(push) Switches the scene file.
Switches to the scene set to ON.
SCENE2(push)
SCENE3(push)
SCENE4(push)
- 14 -
ROP Menu (during AW-UE80/AW-UE50/AW-UE40 connection)

02 SHUTTER SPEED
ヒチバチヒ
ヴラヶヵヵユンチヴヱユユュユロヤ
ノ
ヮヰュユユロヤヴヱユユュヒバビパパパ
Item Setting details
MODE Selects the operation mode of the shutter.
SPEED Sets the shutter speed.
ELC Sets the maximum shutter value for ELC operation.
- 15 -
ROP Menu (during AW-UE80/AW-UE50/AW-UE40 connection)

03 FILTER
ヒチバチヒ
ョリロヵユンヒワュ
Item Setting details
ND Sets the transmittance of the lens’ built-in ND (neutral density) filter. Functional only when connected to the
AW-UE80.
- 16 -
ROP Menu (during AW-UE80/AW-UE50/AW-UE40 connection)

04 PEDESTAL
ヒチバチヒ
ヱユュユヴヵモロパヮハヱユュ
Item Setting details
M.PED Adjusts the black level of the master pedestal.
- 17 -
ROP Menu (during AW-UE80/AW-UE50/AW-UE40 connection)

05 CHROMA
ヒチバチヒ
ヤランヰヮモパパロユヷユロヱラモヴユ
Item Setting details
LEVEL Sets the color intensity of images.
PHASE Finely adjusts the color phase of images.
- 18 -
ROP Menu (during AW-UE80/AW-UE50/AW-UE40 connection)

06 GAIN
ヒチバチヒ
ヨモリワヰョョモヶヵヰビフヴヶヱユンヨモリワモヨヤヮモヹチヨモリワヨモリワ
Item Setting details
SUPER GAIN Sets the super gain (increased sensitivity) to ON/OFF.
GAIN Adjusts the gain of images.
AGC MAX GAIN When “AUTO” is selected as the [GAIN] setting, the maximum gain-up amount can be set.
- 19 -
ROP Menu (during AW-UE80/AW-UE50/AW-UE40 connection)

07 WHITE BALANCE
ヒチバチビ
ヸラリヵユチャモロモワヤユモヵヸピビパパレヰョョヮヰュユヨモリワヰョョヴユヵヤヰロヰンヵユヮヱンャ
ノノ
ヨモリワ
ビチバチビ
ヸラリヵユチャモロモワヤユワヰンヮモロパパヴヱユユュヵンヨヵチャヵンヨヵチンモヵヸ
Item Setting details
MODE Sets the white balance mode.
COLOR TEMP Sets color temperature settings.
GAIN OFFSET Sets the [GAIN R] and [GAIN B] values when the [MODE] is set to “AWB A” or “AWB B”.
GAIN R Adjusts the R gain.
GAIN B Adjusts the B gain.
ATW SPEED Sets the control speed of the ATW function.
ATW TRGT R Finely adjusts the [GAIN R] output when converged in the auto tracking white balance operation.
ATW TRGT B Finely adjusts the [GAIN B] output when converged in the auto tracking white balance operation.
- 20 -
ROP Menu (during AW-UE80/AW-UE50/AW-UE40 connection)
