Panasonic KV-S1045C User manual

Model No. KV-S1045C
Installation Manual
These instructions contain information on installing the scanner. Please read this manual before installing the
unit.
For information on operating the scanner, please read the Operating Manual on the CD-ROM enclosed with this
unit.
Please carefully read this manual, and keep this documentation in a safe place for future reference.
High Speed Color Scanner

Introduction
Thank you for purchasing a Panasonic High Speed Color Scanner.
About the documentation
The scanner documentation consists of 2 manuals: the Installation Manual and the Operating Manual. In
addition, 3 software reference manuals are included.
Installation Manual
(this manual)
The Installation Manual explains the installation method and
procedures.
Operating Manual
(electronic documentation)
The Operating Manual explains the part names, operations, features
and maintenance of the unit.
Software Reference Manuals
(electronic documentation)
•PIE Reference Manual
Explains the settings of the PIE (Panasonic Image Enhancement
Technology) features using the ISIS and TWAIN drivers.
•RTIV Reference Manual
Explains the features and settings for RTIV (Reliable Throughput
Imaging Viewer). (You can view this manual by clicking the help
button on RTIV.)
•User Utility Reference Manual
Explains how to use the User Utility, which is used for scanner
maintenance. (You can view this manual by clicking the help
button on User Utility.)
•The electronic documentation is located on the included CD-ROM. For details on viewing the
documentation, see "Viewing Manuals From the CD-ROM" (page 18).
Abbreviations
•Windows® refers to the Microsoft® Windows® operating system (hereafter Windows).
•Windows® 2000 refers to the Microsoft® Windows® 2000 operating system (hereafter Windows 2000).
•Windows® XP refers to the Microsoft® Windows® XP operating system (hereafter Windows XP).
•Windows Vista® refers to the Microsoft® Windows Vista® operating system (hereafter Windows Vista).
2 Installation Manual
Introduction

Trademarks
•Microsoft, Windows, and Windows Vista are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
•ISIS and QuickScan are registered trademarks or trademarks of EMC Corporation in the United States
and other countries.
•IBM and AT are trademarks of International Business Machines Corporation in the United States, other
countries, or both.
•Pentium is a trademark of Intel Corporation in the U.S. and other countries.
•Adobe and Reader are either registered trademarks or trademarks of Adobe Systems Incorporated in the
United States and/or other countries.
•All other trademarks identified herein are the property of their respective owners.
International ENERGY STAR Program
As an ENERGY STAR®Partner, Panasonic has determined that this product meets
the ENERGY STAR guidelines for energy efficiency.
Installation Manual 3
Introduction

Federal Communications Commission Requirements (For United States
only)
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
•The user may find the booklet "Something About Interference" available from FCC local regional offices
helpful.
FCC Warning: To assure continued FCC emission limit compliance, the user must use the recommended
shielded interfacing cable when connecting to a host computer. Also, any unauthorized changes or
modifications to this equipment would void the user's authority to operate this device.
FCC Declaration of Conformity
Trade Name: Panasonic
Model Number: KV-S1045C
Responsible Party: Panasonic Corporation of North America
One Panasonic Way
Secaucus, NJ 07094 U.S.A.
Telephone No.: 1-800-726-2797
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation.
For FRG Users (For Germany Only)
•Machine noise information regulation - 3.GPSGV, the maximum sound pressure level is 70 dB(A) or less,
in conformity with EN ISO 7779.
•This device is not intended for use in the direct field of view at visual display workplaces. To avoid
incommoding reflexions at visual display workplaces this device must not be placed in the direct field of
view.
4 Installation Manual
Introduction

Table of Contents
Before You Start .......................................................................................6
For Your Safety .................................................................................................................6
Safety Information (For United Kingdom only) ..............................................................8
Precautions ........................................................................................................................9
Installation ..............................................................................................11
Installing the Unit ............................................................................................................11
Installing Software ..........................................................................................................15
System Requirements ....................................................................................................15
CD-ROM Contents .........................................................................................................15
Software Installation .......................................................................................................16
Uninstalling Software ......................................................................................................17
Viewing Electronic Documentation ...............................................................................18
Viewing Manuals From the CD-ROM .............................................................................18
Viewing Manuals Installed On Your Computer ...............................................................18
Uninstalling Manuals ......................................................................................................18
Appendix .................................................................................................19
Troubleshooting ..............................................................................................................19
Installation Manual 5
Table of Contents

For Your Safety
To prevent severe injury and loss of life, read this
section carefully before using the unit to ensure proper
and safe operation of your unit.
•This section explains the graphic symbols used
in this manual.
WARNING
Denotes a potential
hazard that could
result in serious
injury or death.
CAUTION
Denotes hazards
that could result in
minor injury or
damage to the unit.
This symbol is used to alert
operators to a specific operating
procedure that must be
performed carefully.
These symbols are used to alert
operators to a specific operating
procedure that must not be
performed.
These symbols are used to alert
operators to a specific operating
procedure that must be
emphasized in order to operate
the unit safely.
For Users
WARNING
Power
The power source voltage of this unit is
listed on the nameplate.
Only plug the unit into an AC outlet with
the proper voltage.
If you use a cord with an unspecified
current rating, the unit or plug may emit
smoke or become hot to the touch.
When you operate this product, the power
outlet should be near the product and
easily accessible.
Connect the AC adaptor firmly to the
power cord, and plug the power cord
firmly into an AC outlet. Otherwise, it can
cause fire or electric shock.
Do not pull, bend, rest objects on, or chafe
the power cord, plug, and AC adaptor.
Damage to the power cord or plug can
cause fire or electric shock.
Do not attempt to repair the power cord,
plug, or AC adaptor. If the power cord or
plug is damaged or frayed, contact an
authorized service representative for a
replacement.
Ensure that the plug connection is free of
dust. In a damp environment, a
contaminated connector can draw a
significant amount of current that can
generate heat, and eventually cause fire
if left unattended over an extended period
of time.
Never touch the plug or AC adaptor with
wet hands.
Danger of electric shock exists.
6 Installation Manual
Before You Start
Before You Start

Stop operation immediately if the unit
emits smoke, excessive heat, abnormal
smell, or unusual noise. These conditions
can cause fire or electric shock.
Immediately turn the unit off, and unplug
the power cord, and contact your dealer
for service.
When disconnecting the unit, grasp the
plug instead of the cord. Pulling on a cord
forcibly can damage it, and cause fire or
electric shock.
Operating Safeguards
If metal fragments or water gets into the
unit, turn the unit off, and unplug the unit
immediately. Contact your dealer for
service. Operating the contaminated unit
can cause fire or electric shock.
Do not open covers, and do not attempt to
repair the unit yourself. Contact your
dealer for service.
Do not alter the unit or modify any parts.
Alteration or modification can cause fire or
electric shock.
During thunderstorms, do not touch the
unit, plug and AC adaptor. It may cause
an electric shock.
Roller Cleaning Paper
Do not drink or inhale the roller cleaning
paper fluid including isopropyl alcohol.
The roller cleaning paper may be harmful
to sensitive skin. Please use protective
gloves.
Do not use the roller cleaning paper near
a heater or open flame.
CAUTION
Power
The unit should be used only with the
power cord and AC adaptor enclosed with
the unit.
When the unit is not used over an
extended period of time, switch it off, and
unplug it. If an unused unit is left
connected to a power source for a long
period, degraded insulation may cause
electric shock, current leakage, or fire.
Installation and Relocation
Do not position the unit in a location where
it is unstable.
To prevent fire or shock hazard, do not
expose this unit to rain or any type of
moisture.
Do not place the unit in a hot humid or
dusty environment.
Prolonged exposure to these adverse
conditions may cause fire or electric
shock.
When moving the unit, be sure to unplug
the power cord from the AC outlet. If the
unit is moved with the power cord
attached, it can cause damage to the cord
which could result in fire or electric shock.
Do not use the exit tray hanging out of a
table.
When carrying the unit, do not use the
trays as handles.
Installation Manual 7
Before You Start

Operating Safeguards
If the unit falls down or gets damaged, turn
the unit off, and unplug the power cord.
Otherwise, it may cause fire or electric
shock.
Do not place any liquids or heavy items on
the unit.
Accidental spillage of liquid into the unit
may cause severe damage. If this occurs,
turn the unit off, unplug the power cord,
and contact your dealer for service.
Do not touch the scanning glass or their
surroundings immediately after
continuous scanning.
This area is very hot and can cause burns.
Safety Information (For
United Kingdom only)
This appliance is supplied with a moulded three pin
mains plug for your safety and convenience.
A 5 amp fuse is fitted in this plug. Should the fuse need
to be replaced, please ensure that the replacement fuse
has a rating of 5 amps and that it is approved by ASTA
or BSI to BS1362. Check for the ASTA mark
ASA
or the
BSI mark on the body of the fuse. And you must refit
the fuse cover when the fuse is replaced. If you lose the
fuse cover, the plug must not be used.
How to replace the fuse:
Open the fuse compartment with a screwdriver and
replace the fuse and fuse cover.
8 Installation Manual
Before You Start

Precautions
Installation
•Do not place the unit in direct sunlight, in a cold
draft, or near heating apparatus.
•Do not place the unit near apparatus which
generate electronic or magnetic noise.
•Protect the unit from static electricity.
•Do not move the unit immediately from a cold place
to a warm place. It may cause dew.
CD-ROM
•Do not write or stick paper on the front and/or back
of CD-ROM.
•Do not touch the data side of the CD-ROM. When
handling the CD-ROM, be careful not to leave
fingerprints or otherwise damage the CD-ROM.
•Do not leave the CD-ROM where it is directly
exposed to sunlight or near a heater for extended
periods.
•Do not throw or bend the CD-ROM.
Roller Cleaning Paper
•Keep the roller cleaning paper out of reach of small
children.
•Do not store the roller cleaning paper in direct
sunlight or in a place with a temperature over
40
°C
(104 °F).
•Only use the roller cleaning paper to clean the
rollers and scanning glass.
•For details about the roller cleaning paper, please
refer to the Material Safety Data Sheet (MSDS).
Please ask your Panasonic sales company about
obtaining the Material Safety Data Sheet.
KEEP AWAY FROM FIRE.
Others
•Make sure to remove paper clips and staples from
documents before scanning. Failing to do so can
damage the unit, document, or both.
•Do not use thinner, benzine, or cleaners containing
abrasives or surfactants, for cleaning the outside of
scanner.
•Plug the power cord into an outlet from which you
can easily unplug it.
Installation Manual 9
Before You Start

Illegal Duplication
It is unlawful to make duplication of certain
documents.
Duplicating certain documents may be illegal in
your country/area.
Penalties of fines and/or imprisonment may be
imposed on those found guilty. The following are
examples of items that may be illegal to duplicate
in your country/area.
•Currency
•Bank notes and checks
•Bank and government bonds, and securities
•Passports, licenses, official or private
documents, identification cards, and the like
•Copyright materials, or trademarks without
the consent of the owner
•Postage stamps, and other negotiable
instruments
This list is not inclusive, and no liability is
assumed for either its completeness or accuracy.
In case of doubt, contact your legal counsel.
Notice
Install your machine near a supervised area
to prevent illegal duplication from being
made.
Security Notice
The management of documents and scanned data is
the responsibility of the user. In particular, pay attention
to the following points.
•Make sure you have the same number of pages for
important documents both before and after
scanning, and take care not to leave any pages in
the scanner.
•Periodically back up important data.
•When having your computer or hard disk serviced,
or when disposing of your computer or hard disk,
completely erase any stored image data.
Caution Labels
HOT SURFACE
DO NOT TOUCH.
The glass in the scanning area becomes very hot.
Exercise care not to touch heated areas, or you may get
burned.
CAUTION
10 Installation Manual
Before You Start

Installing the Unit
About the installation location
•In order to ensure proper operation, install the unit
maintaining the proper distances from surrounding
objects, as shown in the following illustration.
100 mm
(4 in.)
100 mm
(4 in.)
380 mm
(15 in.)
[ Top View ]
250 mm *
(9.8 in.)
1
*1 Clearance required to set the feed tray.
Notice
•Do not move the unit immediately from a cold
place to a warm place. It may cause dew.
1. Check the accessories.
•Check that all accessories are included before
installing the scanner.
In the event that an item is missing, please
contact your dealer.
Power cord
USB cable
AC adaptor
Feed tray
Mixed batch card guide
Drivers & Utilities /
Manuals CD-ROM
Roller cleaning paper
Installation Manual
(this manual)
Safety Guide*1
(for French, German,
Spanish, Italian and
Russian only)
*1 Safety Guide may be included depending on country/area.
Installation Manual 11
Installation
Installation

Note
•It is highly recommended to keep the
original carton and all packing materials.
They are necessary when repacking.
•[For United States only]
Applicable limited warranty information is
included on the Drivers & Utilities / Manuals
CD-ROM.
•Two power cords may be included. Use the
power cord appropriate for where you use
the unit.
2. Remove all packing tape.
3. Uninstall the mixed batch card guide (A).
•With the mixed batch card guide, you do not
have to adjust the document guides to fit the
width of the card. It also prevents a card from
skewing when scanning paper documents and
a card simultaneously.
•It is pre-installed and fixed to the scanner with
adhesive tape.
•When not using the mixed batch card guide,
uninstall it as shown in the illustration below,
and keep it on the back side of the feed tray
(B) for future use.
A
B
•When using the mixed batch card guide, install
it in the reverse order of uninstallation.
For details on the mixed batch card guide, refer
to the Operating Manual.
4. Set the feed tray.
Before using the scanner, follow the steps below to
set the feed tray.
a. Insert the feed tray (A) into the scanner as
shown in the illustration below.
A
b. Push the right (A) and left (B) sides of the feed
tray in that order until the feed tray locks in
place.
A
B
c. Pull out the feed extension tray in the direction
of the arrow shown in the illustration below.
12 Installation Manual
Installation

5. Set the exit tray.
The exit tray prevents documents from dropping
after they are scanned. Follow the steps below to
set the exit tray.
a. Raise the exit stopper (A).
A
b. Pull out the exit tray (A) and the exit extension
tray (B).
2
1
6. Connect cables.
•Connect the power cord to the AC adaptor.
•Connect the AC adaptor to the scanner.
•Plug into the AC outlet.
•Connect the USB cable to the scanner and to
your computer.
Note
•Use only with the power cord and the AC
adaptor enclosed with the unit.
•Use the USB cable enclosed with the unit.
•When the unit is not used over an extended
period of time, switch it off, and unplug it.
The power consumption is approximately
0.3 W when the unit is turned off, and the
AC adaptor is connected to the AC outlet.
CD
E
F
AB
AC adaptor
Power cord
To AC outlet
To computer
USB cable
Power switch
Installation Manual 13
Installation

About LED
The status of the scanner can be established by the
condition of the two LED indicators shown in the table
below:
Ready
Error
Start / Stop
A
B
A LED
(Green)
B LED
(Red) Status
ON OFF Ready
ON Blink (Slow) Caution
Blink (Fast) OFF Warming up*1
Blink (Slow) OFF Sleep
Blink (Slow) Blink (Slow) Caution / Sleep
OFF ON Error
*1 It will take about 30 seconds to initialize the scanner under the
following conditions:
–Just after turning the power on
–After about 2 hours on sleep mode
–Over about 5 seconds with the ADF door open
14 Installation Manual
Installation

Installing Software
System Requirements
Computer IBM® PC/AT® or compatible
machine with a CD-ROM drive
CPU Pentium® III, 1 GHz or higher
Operating
System
Windows 2000 / Windows XP /
Windows Vista
Interface USB 2.0
Memory 256 MB or higher
Hard Disk 5 GB or more free space is
required.
Note
•The above system requirements may not satisfy
the requirements of all operating systems.
•The scanning speed differs depending on the
host computer's operating environment or the
application used.
•Due to the slower speed of USB 1.1, it is
recommended to use a USB 2.0 interface.
•If you connect the scanner to a USB hub, it is
not guaranteed to work.
CD-ROM Contents
Drivers
Device Driver
TWAIN*2
ISIS
Applications
RTIV*3
QuickScan Pro Demo*4
Utilities
MCD*5
User Utility
Manuals*1
Installation Manual
Operating Manual
PIE Reference Manual*6
RTIV Reference Manual
User Utility Reference Manual
Others
Control Sheet*7
Warranty Information (U.S.A. only)
*1 All manuals are in PDF format. To view manuals, Adobe®
Reader® must be installed.
*2 There is no TWAIN application on this CD-ROM.
*3 RTIV (Reliable Throughput Imaging Viewer) is our original
application software, and does not require either TWAIN driver
or ISIS driver.
*4 There are some restrictions for QuickScan Pro due to being a
trial version. In addition, when using QuickScan Pro, the ISIS
driver is required.
QuickScan Pro does not work with the 64-bit version of Windows.
*5 For details on how to use MCD, refer to PIE Reference Manual
and RTIV Reference Manual.
*6 PIE is an acronym for Panasonic Image Enhancement
Technology.
*7 The control sheets are stored as PDF files. For use them, print
the control sheets in the same size as the document pages to be
scanned. For details, refer to "Using Control Sheets" in the
Operating Manual.
Installation Manual 15
Installation

Software Installation
The software on the enclosed CD-ROM can be installed
on your computer.
You can select from the 4 installation methods below,
depending on your needs.
a. Complete: Install all of the CD-ROM components.
b. All Drivers & Utilities: Install all of the CD-ROM
components except for applications.
c. Custom: Install one of the drivers, utilities or
manuals.
d. Application: Select and install RTIV or the
QuickScan Pro Demo.
Notice
•Make sure to log on as an administrator to install
the software.
1. Turn OFF the scanner power.
2. Insert the included CD-ROM into the CD/DVD drive
on your computer.
•If you have a feature called "Autorun" activated,
the installation process will start automatically.
•The setup window will appear.
Note
•If the AutoPlay dialog box is displayed in
Windows Vista, select "CDRun.exe".
•If the program does not start automatically,
from [My Computer] ([Computer] in
Windows Vista), select the CD/DVD drive,
and then double-click "CDRun.exe".
3. Select your scanner model.
4. Select the desired installation methods from the
"Installation" list on the left side of the screen.
•If you selected [Complete] or [All Drivers &
Utilities], continue to step 6.
•If you selected [Custom], continue to step 5.
•If you selected [RTIV] or [QuickScan Pro Demo]
in "Application", continue to step 6.
16 Installation Manual
Installation

5. If you selected [Custom] for the installation type in
step 4, select the item that you want to install.
6. Follow the instructions on the screen.
•In Windows Vista, if a window appears with the
message "Windows can’t verify the publisher of
this driver software", continue with the
installation by selecting "Install this driver
software anyway".
7. Turn ON the scanner power.
•If you installed a device driver, it is necessary to
continue with the next step.
8. Follow the instructions of the hardware wizard to
complete the installation.
•The installation process is performed
automatically in Windows Vista.
Note
Continue with the installation even if a window
appears with the message "Digital Signature
Not Found" or "has not passed Windows Logo
testing...".
Uninstalling Software
If you want to remove the software that is installed on
your computer, follow the procedure below to uninstall
them.
1. In Control Panel, open [Add or Remove Programs].
•In Windows 2000, select [Add/Remove
Programs], and in Windows Vista, select
[Uninstall a program].
2. Select the item that you want to uninstall.
•The software is displayed with the program
names below:
Software Program Name
Device driver Panasonic High Speed
Scanner Device Driver
X.XX*1
TWAIN KV-S1045C
TWAIN Driver
ISIS KV-S1045C KV-S1025C
KV-S1020C ISIS Driver
RTIV RTIV
QuickScan Pro
Demo
QuickScan 4.6*1
User Utility Panasonic Scanner User
Utility
MCD (Multi-color
Dropout) Utility
MCD
*1 "X.XX" and the number that follows a program name are the
software version. When you upgrade the software, the
numbers above may be different from the actual software
version.
3. Follow the instructions on the screen.
Installation Manual 17
Installation

Viewing Electronic
Documentation
Viewing Manuals From the
CD-ROM
All manuals on the CD-ROM can be viewed using
Adobe Reader.
1. Insert the included CD-ROM into the CD/DVD drive
on your computer.
•If you have a feature called "Autorun" activated,
the installation process will start automatically.
•The setup window will appear.
Note
•If the AutoPlay dialog box is displayed in
Windows Vista, select "CDRun.exe".
•If the program does not start automatically,
from [My Computer] ([Computer] in
Windows Vista), select the CD/DVD drive,
and then double-click "CDRun.exe".
2. Select your scanner model.
3. Select a manual from the "Manuals" list on the right
side of the screen.
•The selected manual will open.
Note
•To view the electronic documentation,
Adobe Reader must be installed on your
computer. If your computer is connected to
the Internet, you can download Adobe
Reader by clicking the URL below
"Download Adobe® Reader®".
The URL is displayed in the "Manuals" list
on the setup screen.
Viewing Manuals Installed On
Your Computer
All manuals installed on your computer can be viewed
as follows.
Note
•To install manuals on your computer, see
page 16.
•You can view the RTIV Reference Manual and
the User Utility Reference Manual by clicking
the help button on the software's operation
screen.
1. On the [Start] menu, point to [All Programs], then
[Panasonic], and select [Scanner Manuals].
•If you are using Windows 2000, point to
[Program] instead of [All Programs].
2. Select the desired manual.
•The selected manual will open.
Uninstalling Manuals
If you want to remove manuals that are installed on your
computer, follow the procedure below to uninstall them.
1. In Control Panel, open [Add or Remove Programs].
•In Windows 2000, select [Add/Remove
Programs], and in Windows Vista, select
[Uninstall a program].
2. Select "Panasonic Scanner Manuals".
3. Follow the instructions on the screen.
18 Installation Manual
Installation

Troubleshooting
If a problem occurs while the unit is being used, check the following items and check the unit status with the
User Utility. For other problems, refer to "Troubleshooting" in the Operating Manual.
If the unit still malfunctions, turn it OFF, unplug the power cord from the AC outlet, and call for service.
Symptom Possible Cause Remedy
The ready indicator does not
light when the power switch is
turned ON.
The power cord is not plugged in. Insert the power plug firmly.
Problem with the AC adaptor. Unplug the power cord from the AC
outlet, and call for service.
The computer does not
recognize the unit.
The scanner is not functioning
correctly.
The unit is not connected to the
computer correctly. Connect the USB cable correctly.
The software is not installed correctly.
Uninstall the software from the
computer (page 17), and then install
the software again (page 16).
The USB interface of the computer is
not installed correctly.
Check the computer whether the USB
interface of your computer is installed
correctly using the device manager’s
property.
The unit is connected to the computer
via a USB hub, and the USB hub is not
functioning well.
Do not connect via the USB hub.
Connect the unit to the computer
directly.
There is a problem with the USB
cable.
Use the included USB cable or a
certified Hi-speed USB 2.0 cable.
If you still experience problems after following these suggestions, please contact our Technical Support
Department at 1-800-726-2797 for further assistance. (U.S.A. only)
Installation Manual 19
A
p
p
e
n
d
i
x
Appendix

PNQX5670ZA-CD DD0512NU0
© Panasonic System Networks Co., Ltd. 2009
Things you should keep a record of:
For your future reference
Date of purchase
Model number
Serial number
Dealer’s name and address
Dealer’s telephone number
Notice [For United States only]
This product has a fluorescent lamp that contains mercury. Disposal may be regulated in your community due to
environmental considerations. For disposal or recycling information, please visit Panasonic website:
http://www.panasonic.com/environmental or call 1-888-769-0149.
