Fire alarm system
Plate for wire installation 6363
•A kit for wire installation with all the necessary pieces for all kinds of detectors.
General
6363 is a kit that consists of the following:
•A metal plate with pre-drilled screw
holes for all kinds of detectors / bases.
•A clamp (to fix the plate to a wire)
•Two screws 3.5x10 mm
•Two screws 3.5x12 mm
•Two screws 4x15 mm
•Two screws 4x27 mm
•Two screws 4x40 mm
•Two spacers 6.4 mm Ø 9.5 / 4.5
•Two spacers 25.4 mm Ø 6.4 / 4.5
Product applications
The kit is used with any of the Panasonic
heat or smoke detectors plugged in a base,
allowing the user to make a wire installation
of the detector.

All technical features and data are subject to changes without notice, resulting from continuous development and improvement.
Product Leaflet Date of issue Revision / Date of revision
MEW00350 2003-03-04 2 / 2006-08-31
Type number
6363 Plate for wire installation. (Detector and base are not included.)
Dimensions:
Technical data
Weight (g) ~160
Material Aluzink ®
