Main unit SA-BX500EB/EE/EG
O
OO
OGENERAL
Power supply: AC 220V to 240V, 50 Hz
Power consumption: This unit 150 W
Power consumption in standby mode:
approx. 0.8 W
Power consumption in HDMI off mode:
approx. 0.4 W
Dimensions (W×H×D): 430 mm×158.5 mm×339 mm
Mass: This unit 5 kg
Operating temperature range: +0 °C to +40 °C
Operating humidity range: 20% to 80% RH
(no condensation)
O
OO
OAMPLIFIER SECTION
Power output (at AC220 to 240 V)
1 kHz (T.D.H. 1%) each channel driven
Front (L/R):
150 W per channel (6 Ω)
Center:
150 W per channel (6 Ω)
Surround (L/R):
150 W per channel (6 Ω)
© 2008 Matsushita Electric Industrial Co. Ltd.. All
rights reserved. Unauthorized copying and
distribution is a violation of law.
SA-BX500EB
SA-BX500EE
SA-BX500EG
Colour
(K).......................Black Type
Surround Back (L/R):
150 W per channel (6 Ω)
Total Harmonic distortion at 1 kHz power:
0.3% W
Load impedance
Front (L/R)
A
or B:
4to16Ω
A
and B:
6to16Ω
BI-WIRE:
4to16Ω
Center:
6to16Ω
Surround (L/R):
6to16Ω
Surround Back (L/R):
6to16Ω
Frequency Response
CD, AUX, TV, GAME, CABLE/SAT, VCR, DVD RECORDER,
BD/DVD PLAYER/ ANALOG 8CH IN, OPTION
4Hzto40kHz,±2dB
AV Control Receiver
Specifications
ORDER NO. MD0807009CE

Subwoofer frequency response (-6 dB)
7 Hz to 200 Hz
Input sensitivity and impedance
CD, AUX, TV, GAME, CABLE/SAT, VCR, DVD RECORDER,
BD/DVD PLAYER/ ANALOG 8CH IN, OPTION
200 mV/22 kΩ
S/N at rated power (6 Ω
ΩΩ
Ω)
CD, TV, BD/DVD PLAYER, DVD RECORDER (Digital Input)
97 dB
Tone controls
BASS: 50 Hz, +10 to -10 dB
TREBLE: 20 kHz, +10 to -10 dB
Output Voltage
DVD RECORDER: 200 mV
Channel balance (250 Hz to 6.3 kHz)
±1 dB
Channel separation
55dB
Digital input (OPTICAL):
3
Digital input (COAXIAL):
1
HDMI Input (Corresponding Deep Colour)
3
HDMI Output (Corresponding Deep Colour)
1
O
OO
OFM TUNER, TERMINALS SECTION
Frequency Modulation (FM)
Frequency range:
87.50-108.00 MHz (50-kHz step)
Sensitivity
S/N 30 dB 1.5 µV / 75 Ω
S/N 26 dB 1.3 µV / 75 Ω
S/N 20 dB 1.2 µV / 75 Ω
Total harmonic distortion
MONO 0.2%
STEREO 0.3%
S/N
MONO 60 dB
STEREO 58 dB
Frequency response
20 Hz to 15 kHz, +1 dB, -2 dB
Antenna terminal
75 Ω(unbalanced)
O
OO
OAM TUNER SECTION
Frequency range:
522 to 1629 kHz (9 kHz steps)
520 to 1630 kHz (10 kHz steps)
O
OO
OD-Port SECTION
An exclusive terminal for SH-PD10 (option)
1
O
OO
OVIDEO SECTION
Output voltage at 1 V input (unbalanced)
1±0.1Vp-p
Maximum input voltage
1.5 Vp-p
Input/output impedance
75 Ω(unbalanced)
Composite Video (Input)
BD/DVD PLAYER, DVD
RECORDER, VCR,
CABLE/SAT, GAME, AUX
Composite Video (Output)
DVD RECORDER, TV
MONITOR
S-Video (Input)
BD/DVD PLAYER, DVD
RECORDER, VCR,
CABLE/SAT, GAME, AUX
S-Video (Output)
DVD RECORDER, TV
MONITOR
Component Video (Input)
BD/DVD PLAYER, DVD
RECORDER, CABLE/SAT
Component Video (Output)
TV MONITOR
Note:
1. Specifications are subject to change without notice.
Mass and dimensions are approximate.
2. Total harmonic distortion is measured by the digital spectrum
analyzer.
Solder:
This model uses lead free solder (PbF).
2
SA-BX500EB / SA-BX500EE / SA-BX500EG

1 Safety Precautions 5
1.1. GENERAL GUIDELINES 5
1.2. Before Repair and Adjustment 5
1.3. Protection Circuitry 5
1.4. Safety Parts Information 6
1.5. Caution for AC Cord 7
2 Prevention of Electrostatic Discharge (ESD) to
Electrostatically Sensitive (ES) Devices 8
3 About Lead Free Solder (PbF) 9
3.1. Service caution based on legal restrictions 9
4 Accessories 10
5 Operation Procedures 11
5.1. Remote Control Key Buttons Operations 11
5.2. Main Unit Key Buttons Operations 12
5.3. Using the VIERA Link “HDAVI Control™” 13
5.4. Main Unit Connections 14
6 Self-Diagnosis and Display Function 22
6.1. Automatically Displayed Error Codes 22
6.2. Display Details 22
6.3. Overload/Shutdown Detection internal Condition 23
6.4. Overload/Thermal Detection Display 23
6.5. Activating Self Diagnosis Function (Service Mode) 23
6.6. Returning to Normal Display 24
6.7. Activating Self Diagnosis Function (Doctor Mode) 24
6.8. Wireless Link 25
7 Assembling and Disassembling 27
7.1. Disassembly Flow Chart 28
7.2. Main Components and P.C.B. Locations 29
7.3. Disassembly of Top Cabinet 30
7.4. Disassembly and checking of DSP (Side A/B) P.C.B. 30
7.5. Disassembly and checking of Speaker P.C.B. 31
7.6. Disassembly and checking of D-Amp B (3CH) & Fan
P.C.B. 31
7.7. Replacement of Digital Amp IC (IC5000) of D-Amp B
(3CH) P.C.B. 33
7.8. Disassembly and checking of SMPS & AC Inlet P.C.B.
34
7.9. Replacement of Switch Regulator IC (IC5701) 35
7.10. Replacement of Switch Regulator Diode (D5702) 36
7.11. Replacement of Regulator Diode (D5801) 38
7.12. Replacement of Regulator Diode (D5802) 38
7.13. Replacement of Regulator Diode (D5803) 39
7.14. Disassembly and checking of D-Amp A (4CH) P.C.B. 40
7.15. Replacement of Digital Amp IC (IC5000) of D-Amp A
(4CH) P.C.B. 41
7.16. Disassembly and checking of HDMI side (A) and side (B)
42
7.17. Disassembly and Checking of S-Video & Video P.C.B. 43
7.18. Disassembly and checking of Wireless Adapter, Digital &
D-Port P.C.B. 43
7.19. Disassembly and Checking of Main (Side A/B) P.C.B. 45
7.20. Disassembly of Front Panel 46
7.21. Disassembly and checking of Panel, Headphone, Volume
P.C.B. 47
8 Voltage and Waveform Chart 49
8.1. HDMI P.C.B. 49
8.2. DSP P.C.B. 51
8.3. D-Amp A (4CH) P.C.B. 54
8.4. D-Amp B (3CH) P.C.B. 55
8.5. Main P.C.B. 56
8.6. Panel P.C.B. 59
8.7. Digital, Speaker & Fan P.C.B. 59
8.8. Video P.C.B. 60
8.9. S-Video P.C.B. 60
8.10. SMPS P.C.B. 60
8.11. Waveform Chart 61
9 Illustration of IC’s, Transistors and Diodes 63
10 Wiring Connection Diagram 65
11 Block Diagram 67
11.1. System Control 67
11.2. HDMI 68
11.3. IC Terminal (HDMI) Chart 69
11.4. DSP 70
11.5. IC Terminal (DSP) Chart 72
11.6. Audio 74
11.7. Digital Audio Amp (4CH) 76
11.8. Digital Audio Amp (3CH) 77
11.9. Speaker Channel 78
11.10. Video (component & composite video) 79
11.11. Video (S-video) 80
11.12. Power 81
12 Schematic Diagram Notes 83
13 Schematic Diagram 85
13.1. HDMI Circuit 85
13.2. DSP Circuit 89
13.3. Main Circuit 95
13.4. Panel Circuit 103
13.5. S-Video Circuit 105
13.6. Speaker Circuit 106
13.7. Video Circuit 107
CONTENTS
Page Page
3
SA-BX500EB / SA-BX500EE / SA-BX500EG

13.8. D-Port, Headphone, Digital, Volume, Wireless Adapter,
Fan Circuit 108
13.9. D-Amp A (4CH) Circuit 109
13.10. D-Amp B (3CH) Circuit 111
13.11. SMPS Circuit 113
13.12. AC Inlet Circuit 115
14 Printed Circuit Board 117
14.1. HDMI P.C.B. 117
14.2. DSP P.C.B. 118
14.3. Main P.C.B. 119
14.4. D-Port, Panel, S-Video P.C.B. 120
14.5. Headphone, Speaker, Digital, Video, Volume P.C.B. 121
14.6. Wireless, Fan, AC Inlet P.C.B. 122
14.7. D-Amp A (4CH) P.C.B. 123
14.8. D-Amp B (3CH) P.C.B. 124
14.9. SMPS P.C.B. 125
15 Basic Troubleshooting Guide 127
15.1. Troubleshooting Guide for F61 and/or F76 127
16 Overall Simplified Block for BX500 135
17 Terminal Function of IC’s 137
17.1. IC8001 (RFXWBX500EBK): Micro-processor 137
17.2. IC501 (C0HBB0000057): IC FL Driver 137
18 Exploded Views 139
18.1. Cabinet Parts Location 139
18.2. Packaging 142
19 Replacement Parts List 145
19.1. Component Parts List 146
20 Schematic Diagram for printing with letter size 169
4
SA-BX500EB / SA-BX500EE / SA-BX500EG

1 Safety Precautions
1.1. GENERAL GUIDELINES
1.When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or
damaged by the short circuit.
2.After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly
installed.
3.After servicing, carry out the following leakage current checks to prevent the customer from being exposed to shock hazards.
1.1.1. LEAKAGE CURRENT COLD CHECK
1.Unplug the AC cord and connect a jumper between the two prongs on the plug.
2.Measure the resistance value, with an ohmmeter, between the jumpered AC plug and each exposed metallic cabinet part on
the equipment such as screwheads, connectors, control shafts, etc. When the exposed metallic part has a return path to the
chassis, the reading should be between 1MΩand 5.2MΩ.
When the exposed metal does not have a return path to the chassis, the reading must be
1.1.2. LEAKAGE CURRENT HOT CHECK
1.Plug the AC cord directly into the AC outlet. Do not use an isolation transformer for this check.
2.Connect a 1.5kΩ, 10 watts resistor, in parallel with a 0.15µF capacitors, between each exposed metallic part on the set and a
good earth ground such as a water pipe, as shown in Figure 1.
3.Use an AC voltmeter, with 1000 ohms/volt or more sensitivity, to measure the potential across the resistor.
4.Check each exposed metallic part, and measure the voltage at each point.
5.Reverse the AC plug in the AC outlet and repeat each of the above measurements.
6.The potential at any point should not exceed 0.75 volts RMS. A leakage current tester (Simpson Model 229 or equivalent) may
be used to make the hot checks, leakage current must not exceed 1/2 milliamp. In case a measurement is outside of the limits
specified, there is a possibility of a shock hazard, and the equipment should be repaired and rechecked before it is returned to
the customer.
Figure 1
1.2. Before Repair and Adjustment
Disconnect AC power to discharge unit AC Capacitors as such (C5700, C5701, C5702, C5703, C5704) through a 10 Ω,10W
resistor to ground.
Caution:
DO NOT SHORT-CIRCUIT DIRECTLY (with a screwdriver blade, for instance), as this may destroy solid state devices.
After repairs are completed, restore power gradually using a variac, to avoid overcurrent.
Current consumption at AC 230 V~240 V, 50 Hz in NO SIGNAL mode volume minimal should be ~ 600 mA.
1.3. Protection Circuitry
The protection circuitry may have operated if either of the following conditions are noticed:
• • •
• No sound is heard when the power is turned on.
• • •
• Sound stops during a performance.
The function of this circuitry is to prevent circuitry damage if, for example, the positive and negative speaker connection wires are
5
SA-BX500EB / SA-BX500EE / SA-BX500EG

“shorted”, or if speaker systems with an impedance less than the indicated rated impedance of the amplifier are used.
If this occurs, follow the procedure outlines below:
1.Turn off the power.
2.Determine the cause of the problem and correct it.
3.Turn on the power once again after one minute.
Note:
When the protection circuitry functions, the unit will not operate unless the power is first turned off and then on again.
1.4. Safety Parts Information
Safety Parts List:
There are special components used in this equipment which are important for safety.
These parts are marked by in the Schematic Diagrams & Replacement Parts List. It is essential that these critical parts
should be replaced with manufacturer’s specified parts to prevent shock, fire or other hazards. Do not modify the original design
without permission of manufacturer.
Table 1
Ref. No. Part No. Part Name & Description Remarks
14 REXX0640-J BLACK WIRE (SMPS-AC) [M]
15 REXX0641-J RED WIRE (SMPS-AC) [M]
19 RGR0385A-A REAR PANEL [M]EB/EG
19 RGR0385A-B REAR PANEL [M] EE
30 RKM0603-K TOP CABINET [M]
A2 K2CQ2CA00007 AC CORD [M] EG/EE
A2 K2CT3CA00004 AC CORD [M] EB
PCB18 REPX0622R SMPS P.C.B [M] (RTL)
PCB19 REPX0622R AC INLET P.C.B. [M] (RTL)
DZ5701 ERZV10V511CS ZNR [M]
L5701 ELF15N035AN LINE FILTER [M]
L5702 ELF22V020E LINE FILTER [M]
L5703 ELF21N024E LINE FILTER [M]
T5701 ETS42BM1B6AC TRANSFORMER [M]
T5751 ETS19AB281AG BACKUP TRANSFORMER [M]
T7001 G4D1A0000094 SWITCHING TRANSFORMER [M]
PC5701 B3PBA0000402 PHOTO COUPLER [M]
PC5702 B3PBA0000402 PHOTO COUPLER [M]
PC5720 B3PBA0000402 PHOTO COUPLER [M]
PC5799 B3PBA0000402 PHOTO COUPLER [M]
F1 K5D402BK0007 FUSE [M]
IP7001 K5H7512A0010 IC PROTECTOR [M]
TH5701 D4CAA5R10001 THERMISTOR [M]
TH5860 D4CC11040013 THERMISTOR [M]
P5701 K2AA2B000017 AC INLET [M]
C5700 F1BAF1020020 1000pF [M]
C5701 ECQU2A104MLC 0.1uF [M]
C5702 ECQU2A104MLC 0.1uF [M]
C5703 ECQU2A104MLC 0.1uF [M]
C5704 F1BAF1020020 1000pF [M]
6
SA-BX500EB / SA-BX500EE / SA-BX500EG

1.5. Caution for AC Cord
(For the United Kingdom and Republic of Ireland)
( EB area code model only)
For your safety, please read the following text
carefully.
This appliance is supplied with a moulded three pin
mains plug for your safety and convenience.
A 5-ampere fuse is fitted in this plug.
Should the fuse need to be replaced please ensure
that the replacement fuse has a rating of 5-ampere
and that it is approved by ASTA or BSI to BS1362.
Check for the ASTA mark or the BSI mark
on the body of the fuse.
If the plug contains a removable fuse cover you
must ensure that it is refitted when the fuse is
replaced.
If you lose the fuse cover the plug must not be used
until a replacement cover is obtained.
A replacement fuse cover can be purchased from
your local dealer.
CAUTION!
IF THE FITTED MOULDED PLUG IS
UNSUITABLE FOR THE SOCKET OUTLET IN
YOUR HOME THEN THE FUSE SHOULD BE
REMOVED AND THE PLUG CUT OFF AND
DISPOSED OF SAFELY.
THERE IS A DANGER OF SEVERE
ELECTRICAL SHOCK IF THE CUT OFF PLUG IS
INSERTED INTO ANY 13-AMPERE SOCKET.
If a new plug is to be fitted please observe the
wiring code as stated below.
If in any doubt please consult a qualified electrician.
WARNING: DO NOT CONNECT EITHER WIRE
TO THE EARTH TERMINAL WHICH IS MARKED
WITH THE LETTER E, BY THE EARTH SYMBOL
OR COLOURED GREEN OR GREEN/
YELLOW.
THIS PLUG IS NOT WATERPROOF KEEP DR Y.
Before use
Remove the connector cover.
How to replace the fuse
The location of the fuse differ according to the type
of AC mains plug (figures A and B). Confirm the AC
mains plug fitted and follow the instructions below.
Illustrations may differ from actual AC mains plug.
1. Open the fuse cover with a screwdriver.
2. Replace the fuse and close or attach the fuse cover.
IMPORTANT
The wires in this mains lead are coloured in
accordance with the following code:
Blue: Neutral, Brown: Live.
As these colours may not correspond with the
coloured markings identifying the terminals in your
plug, proceed as follows:
The wire which is coloured Blue must be connected
to the terminal which is marked with the letter N or
coloured Black or Blue.
The wire which is coloured Brown must be
connected to the terminal which is marked with the
letter L or coloured Brown or Red.
Figure A
Figure B
Figure A
Figure B
Fuse
(5 ampere)
Fuse
(5 ampere)
Fuse cover
7
SA-BX500EB / SA-BX500EE / SA-BX500EG

2 Prevention of Electrostatic Discharge (ESD) to
Electrostatically Sensitive (ES) Devices
Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called
Electrostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors and
semiconductor “chip” components. The following techniques should be used to help reduce the incidence of component damage
caused by electrostatic discharge (ESD).
1.Immediately before handling any semiconductor component or semiconductor-equipped assembly, drain off any ESD on your
body by touching a known earth ground. Alternatively, obtain and wear a commercially available discharging ESD wrist strap,
which should be removed for potential shock reasons prior to applying power to the unit under test.
2.After removing an electrical assembly equipped with ES devices, place the assembly on a conductive surface such as
aluminum foil, to prevent electrostatic charge buildup or exposure of the assembly.
3.Use only a grounded-tip soldering iron to solder or unsolder ES devices.
4.Use only an anti-static solder removal device. Some solder removal devices not classified as “anti-static (ESD protected)” can
generate electrical charge sufficient to damage ES devices.
5.Do not use freon-propelled chemicals. These can generate electrical charges sufficient to damage ES devices.
6.Do not remove a replacement ES device from its protective package until immediately before you are ready to install it. (Most
replacement ES devices are packaged with leads electrically shorted together by conductive foam, aluminum foil or comparable
conductive material).
7.Immediately before removing the protective material from the leads of a replacement ES device, touch the protective material
to the chassis or circuit assembly into which the device will be installed.
Caution:
Be sure no power is applied to the chassis or circuit, and observe all other safety precautions.
8.Minimize bodily motions when handling unpackaged replacement ES devices. (Otherwise harmless motion such as the
brushing together of your clothes fabric or the lifting of your foot from a carpeted floor can generate static electricity (ESD)
sufficient to damage an ES device).
8
SA-BX500EB / SA-BX500EE / SA-BX500EG

3 About Lead Free Solder (PbF)
3.1. Service caution based on legal restrictions
3.1.1. General description about Lead Free Solder (PbF)
The lead free solder has been used in the mounting process of all electrical components on the printed circuit boards used for this
equipment in considering the globally environmental conservation.
The normal solder is the alloy of tin (Sn) and lead (Pb). On the other hand, the lead free solder is the alloy mainly consists of tin
(Sn), silver (Ag) and Copper (Cu), and the melting point of the lead free solder is higher approx.30 degrees C (86°F) more than that
of the normal solder.
Definition of PCB Lead Free Solder being used
The letter of “PbF” is printed either foil side or components side on the PCB using the lead free solder.
(See right figure)
Service caution for repair work using Lead Free Solder (PbF)
• • •
• The lead free solder has to be used when repairing the equipment for which the lead free solder is used.
(Definition: The letter of “PbF” is printed on the PCB using the lead free solder.)
• • •
• To put lead free solder, it should be well molten and mixed with the original lead free solder.
• • •
• Remove the remaining lead free solder on the PCB cleanly for soldering of the new IC.
• • •
• Since the melting point of the lead free solder is higher than that of the normal lead solder, it takes the longer time to melt
the lead free solder.
• • •
• Use the soldering iron (more than 70W) equipped with the temperature control after setting the temperature at 350±30
degrees C (662±86°F).
Recommended Lead Free Solder (Service Parts Route.)
• • •
• The following 3 types of lead free solder are available through the service parts route.
RFKZ03D01K-----------(0.3mm 100g Reel)
RFKZ06D01K-----------(0.6mm 100g Reel)
RFKZ10D01K-----------(1.0mm 100g Reel)
Note
* Ingredient: tin (Sn), 96.5%, silver (Ag) 3.0%, Copper (Cu) 0.5%, Cobalt (Co) / Germanium (Ge) 0.1 to 0.3%
9
SA-BX500EB / SA-BX500EE / SA-BX500EG

Remote control
AC cord
(EE/EG only)
AC cord
(EB only)
FM indoor antenna
AM loop antenna
Setup microphone
Antenna plug
adapter
(EB only)
4 Accessories
• • •
• Note: Refer to “Replacement Parts List” (Section 25) for the part number.
10
SA-BX500EB / SA-BX500EE / SA-BX500EG

5 Operation Procedures
5.1. Remote Control Key Buttons Operations
Remote control
O
N
E
T
O
T
T
U
C
H
P
L
A
L
L
Y
Y
Y
A
O
N
E
T
O
U
C
H
P
L
A
Y
D
I
R
E
C
T
N
A
V
I
G
A
T
O
R
T
O
P
M
E
N
U
F
U
N
C
T
I
O
N
S
0
AV
SYSTEM
TV
RECORDER
DVD
BD/DVD
PLAYER
CABLE
ANALOG 8CH
SAT
OPTION
PORT
FM/AM
CH
VOL
SKIP
SEARCH/SLOW
STOP PAUSE PLAY
DRIVE
SELECT MUTING
OK
OPTION RETURN
OFF
SURROUND SOUND
TV
VOL
NEO : 6
SFC
MUSIC MOVIE
TV/AV
MENU
DISPLAY
-/--
DISC
DIRECT
TUNING
TEST
AUTO
SETUP
INPUT
SELECTOR
Power button
For selecting input
sources
For inputting channels
TV, cab le box and satellite
receiver
DVD recorder
Radio
For selecting a track or
chapter
DVD recor der
Blu-ray Disc /DVD player
For inputting frequencies
For confirming speaker
output/For auto speaker
setup/For adjusting
speaker level
For listening to surround
sounds
For switching an input
source on and off/
Source switching/
Switching remote
control modes
For playing 8 channels
sources
For selecting a channel
TV, cable box and satellite
receiver
DVD recorder
Radio
For adjusting volumes
For silencing speakers
temporarily
For operating other
equipment
For operating SOUND
MENU/SETUP
For operating a TV
For selecting SOUND
MENU
For c
display
hanging the
For playing an iPod
/For entering
SETUP menu items
Batteries
Press on the tab to open.
(R6/LR6, AA)
Place this side in before the other side
when you close.
Insert so the poles ( and ) match those in the
remote control.
Do not use rechargeable type batteries.
Do not heat or expose to.
Do not leave the batteries in an automobile
exposed to direct sunlight for a long period of
time with doors and windows closed.
Use
WIRELESSREADY
SURROUND M.ROOM
INPUT SELECTOR
VOLUME
+
_
DTS-HD
MULTICH
LPCM BI-AMP
AUX
TUNE
RETURN
AUTO SPEAKER SETUP
- SETUP OK
SPEAKERS A SPEAKERS B
S VIDEO VIDEO L - AUDIO - R
About 7 meters or less when you
sit directly in front of the signal
sensor (Exact distance depends
on angles).
Remote control signal sensor
Transmission window
Caution
Do not place an object between the signal
sensor and the remote control.
Do not place the signal sensor under direct
sunlight or the strong light of an in
fluorescent lamp.
verter
Keep the transmission window and the unit s
sensor free from dust.
When you set the unit in a cabinet
The remote controlling range may decrease
depending on the thickness or colours of
glass cabinet doors.
For switching FM or AM
11
SA-BX500EB / SA-BX500EE / SA-BX500EG

5.2. Main Unit Key Buttons Operations
This unit
WIRELESS READY
SURROUND M.ROOM
INPUT SELECTOR
VOLUME
+
_
MULTI CH
PROCESSING TrueHD D+ DTS-HD
MULTI CH
LPCM BI-AMP
SETUP MIC AUX
TUNE
RETURN
AUTO SPEAKER SETUP
- SETUP OK
SURROUND SPEAKERS A SPEAKERS B
S VIDEO VIDEO L - AUDIO - R
Lights on when BI-AMP is on
Lights on when playing a disc using
high definition format such as
Blu-ray Disc
Lights on when the following multi-
channel playback settings are used
When playing multi-channel sources
When using surround effects for two-
channel sources , etc.
Standby indicator [ ]
When the unit is connected to the AC
mains supply, this indicator lights up in
standby mode and goes out when the
unit is turned on.
Standby/on switch [ ]
Press to switch the unit from on to
standby mode or vice versa.In standby
mode, the unit is still consuming a
small amount of power.
For switching the surround playback on
and off (The indicator lights up when the
surround playback is on.)
For connecting headphones
For connecting the setup microphone
For connecting a video camera etc.
For selecting input
sources
For adjusting volumes
For tuning the radio
For SETUP operations
Lights on during the
auto speaker setup
For selecting front
speakers
Display
A B
2CH MIX
SPEAKERS
BI-WIRE
TUNED MONO ST
PCM
DTS 96/24DTS -ES
DIGITAL EX EX
MDIGITAL INPUT
kHz
MHz
PS PTY SLEEP
m
RDS
Lights on when
2-channel mix is
functioning
Unit display
Radio display
Lights on when PCM FIX is selected
Lights on when the
corresponding digital
source is input
Frequency unit indicatorsGeneral displayDisplays front speakers in use
Lights up under the condition that using the
digital transmitter (SH-FX67) is possible
Lights on when playing a disc using
multi-channel LPCM format
Lights on when sleep
timer is set
12
SA-BX500EB / SA-BX500EE / SA-BX500EG

5.3. Using the VIERA Link “HDAVI Control™”
Using the VIERA Link HDAVI Control
TM
What is VIERA Link HD AVI Control ?
VIERA Link HD AVI Control is a convenient function that offers linked operations of this unit, and
a Panasonic TV (VIERA) or DVD recorder (DIGA) under HD AVI Control . You can use this function
by connecting the equipment with the HDMI cable . See the operating instructions for connected
equipment for operational details.
VIERA Link HDAVI Control , based on the control functions provided by HDMI which is an industry standard known as HDMI
CEC (Consumer Electronics Control), is a unique function that we have developed and added. As such, its operation with other
manufacturers equipment that supports HDMI CEC cannot be guaranteed.
This unit suppor ts HD AVI Control 1 function.
This standard is compatible with Panasonic s conventional HDAVI equipment.
Please refer to individual manuals for other manufacturers equipment supporting VIERA Link function.
1You can select Speaker Selection ( Home Cinema or TV ).
Home Cinema: This unit will be automatically turned on if it is in standby mode and the sound is from the speakers
connected to this unit. You can also adjust the volume level by using the volume control buttons.
TV: TV speakers are active.
2When you switch off the TV (VIERA), this unit automaticall y turns off .
(This operation is unavailable when you set the input source as FM , AM, CD or OPTION P. on this unit.)
When VIERA Link HDAVI Control compatible recorder (DIGA) is connected with HDMI cable, the recorder (DIGA)
also turns off.
Note
When you operate the TV (VIERA) such as selecting a channel this unit s input selector will automatically switch to TV .
When you operate DIGA DVD recorder, this unit s input selector will automatically switch to DVD R. .
To operate other functions, use this unit s remote control.
You can enjoy the followings by using the remote control of TV (VIERA)
Connect your home theater equipment (VIERA Link HD AVI Control compatible VIERA television and DIGA DVD
recorder) with an HDMI cable.
It is recommended that you use Panasonic s HDMI cable.
Recommended part number: RP-CDHG10 (1.0 m), RP-CDHG15 (1.5 m), RP-CDHG20 (2.0 m),
RP-CDHG30 (3.0 m), RP-CDHG50 (5.0 m), etc.
This unit incorporates HDMI (V .1.3 with Deep Colour) technology.
Non-HDMI-compliant cables cannot be utilized.
Please use High Speed HDMI Cables that have the HDMI logo (as shown on the cover).
When outputting 1080p signal, please use the HDMI cables 5.0 meters or less.
Only with HDMI cable connection, you cannot enjoy TV sounds on this unit. Connect TV to this unit with the optical
cable to enjoy TV sound.
Connection
BI-WIRE
LF HF
L
R
FRONT A FRONT B CENTER SURROUND SURROUND BACK
SPEAKERS
OUT IN IN
CD
BD/DVD PLAYER / ANALOG 8CH IN DVD RECORDER
VCR
CABLE/SAT GAME TV
AUDIO
SURROUND BACK SURROUND FRONT SUBWOOFER
OUT IN IN IN
(DVD RECORDER) (BD/DVD PLAYER) (CABLE/SAT)
HDMI 1 HDMI2 HDMI 3
FRONT A FRONT B CENTER SURROUND SURROUND BACK
S VIDEO
COMPONENT VIDEO
L
R
IN IN IN
IN
A C IN~
OUT IN IN OUT OUT IN IN IN IN
TV MONITOR TV MONITOR
DVD RECORDER
VCR
CABLE/SAT
GAME
DVD PLAYER
BD/(BD/
DVD PLAYER)
(DVD RECORDER)
(CABLE/SAT)
123
DIGITAL IN
(DVD RECORDER) (BD/DVD PLAYER)
(TV) (CD)
OPTICAL 1 OPTICAL 2 OPTICAL 3 COAXIAL
SUBWOOFER
Y
P
B
P
R
IN
OUT OUT IN IN IN IN
TV MONITOR DVD RECORDER
VCR CABLE/SAT GAME
DVD PLAYER
BD/
(6-16 WEACH SPEAKER)
A OR B / BI-WIRE (4-16 WEACH SPEAKER) A AND B (6-16 WEACH SPEAKER)
OUT
CENTER
IN
IN
FM ANT
AM ANT
OPTION V 1
LOOP
EXT
DC OUT 5V
500mA MAX
75
W
RLRR L L
LOOP ANT
GND
VIDEO
TV (VIERA)
Rear panel
HDMI IN
Digital audio
out (optical)
HDMI
OUT
DVD recorder
(DIGA)
13
SA-BX500EB / SA-BX500EE / SA-BX500EG

5.4. Main Unit Connections
5.4.1. Video & Audio Terminals
B
Basic connections
Connecting cables to video and audio terminals (Connecting equipment without HDMI terminal)
Video cable Audio cable
Video connection cable (not included) Optical fibre cable (not included) Stereo phono cable (not included)
White (L)
Red (R)
To enjoy TV with surround sound, make connection
or instructed below according to your equipment.
SURROUND SURROUND BACK
OUT IN IN
CD
BD/DVD PLAYER / ANALOG 8CH IN DVD RECORDER
VCR
CABLE/SAT GAME TV
AUDIO
SURROUND BACK SURROUND FRONT SUBWOOFER
OUT IN IN IN
(DVD RECORDER) (BD/DVD PLAYER) (CABLE/SAT)
HDMI 1 HDMI 2 HDMI 3
SURROUND SURROUND BACK
S VIDEO
COMPONENT VIDEO
L
R
IN IN IN
IN
OUT IN IN OUT IN IN IN IN
TV MONITOR TV MONITOR
DVD RECORDER
VCR
CABLE/SAT
GAME
DVD PLAYER
BD/(BD/
DVD PLAYER)
(DVD RECORDER)
(CABLE/SAT)
12 3
(DVD RECORDER) (BD/DVD PLAYER)
(TV) (CD)
OPTICAL 1 OPTICAL 2 OPTICAL 3 COAXIAL
SUBWOOFER
Y
P
B
P
R
IN
OUT OUT IN IN IN IN
TV MONITOR DVD RECORDER
VCR CABLE/SAT GAME
DVD PLAYER
BD/
(6-16 WEACH SPEAKER)
OUT
CENTER
IN
IN
FM ANT
AM ANT
OPTION V 1
LOOP
EXT
DC OUT 5V
500mA MAX
75
W
RR L L
LOOP ANT
GND
VIDEO
OUT DIGITAL IN
VIDEO IN
Digital audio
out (optical)
VIDEO
OUT
(R ) ( L)
Audio out
DVD recorderBlu-ray Disc/
DVD player
Cable box or
satellite receiver
VCR
Rear panel
TV
Game
Digital audio
out (optical)
VIDEO
OUT
VIDEO
OUT
(R) (L)
Audio out
VIDEO
OUT
(R) (L)
Audio out
VIDEO
OUT
Connecting the optical
fibre cable
Note the
shape and
it correctly
into the
terminal.
Do not
bend!
Digital audio
out (optical)
Audio out
(R) (L)
12
B
A
A
14
SA-BX500EB / SA-BX500EE / SA-BX500EG

5.4.2. Connecting equipment with HDMI Terminal
Basic connections
Connection cable
Video and Audio cable
HDMI cable (not included)
Recommended part number:
RP-CDHG10 (1.0 m), RP-CDHG15 (1.5 m), RP-CDHG20 (2.0 m), RP-CDHG30 (3.0 m), RP-CDHG50 (5.0 m), etc.
HDMI cable notes
It is recommended that you use Panasonic s HDMI cable.
This unit incorporates HDMI (V .1.3 with Deep Colour) technology.
Please use High Speed HDMI Cables that have the HDMI logo (as shown on the cover).
When outputting 1080p signal, please use the HDMI cables 5.0 meters or less.
Connecting equipment with HDMI terminal
SURROUND SURROUND BACK
OUT IN IN
CD
BD/DVD PLAYER / ANALOG 8CH IN DVD RECORDER
VCR
CABLE/SAT GAME TV
AUDIO
SURROUND BACK SURROUND FRONT SUBWOOFER
OUT IN IN IN
(DVD RECORDER) (BD/DVD PLAYER) (CABLE/SAT)
HDMI 1 HDMI 2 HDMI 3
SURROUND SURROUND BACK
S VIDEO
COMPONENT VIDEO
L
R
IN IN IN
IN
OUT IN IN OUT OUT IN IN IN IN
TV MONITOR TV MONITOR
DVD RECORDER
VCR
CABLE/SAT
GAME
DVD PLAYER
BD/(BD/
DVD PLAYER)
(DVD RECORDER)
(CABLE/SAT)
12 3
(DVD RECORDER) (BD/DVD PLAYER)
(TV) (CD)
OPTICAL 1 OPTICAL 2 OPTICAL 3 COAXIAL
SUBWOOFER
Y
P
B
P
R
IN
OUT OUT IN IN IN IN
TV MONITOR DVD RECORDER
VCR CABLE/SAT GAME
DVD PLAYER
BD/
(6-16 WEACH SPEAKER)
OUT
CENTER
IN
IN
FM ANT
AM ANT
OPTION V 1
LOOP
EXT
DC OUT 5V
500mA MAX
75
W
RR L L
LOOP ANT
GND
VIDEO
DIGITAL IN
HDMI input
HDMI
Video/Audio out
HDMI
Video/Audio out
HDMI
Video/Audio out
DVD recorder Blu-ray Disc/DVD player
Cable box, satellite receiver , etc.
Rear panel
TV
15
SA-BX500EB / SA-BX500EE / SA-BX500EG

5.4.3. S Video and audio Terminals
Connecting cables to S video and audio terminals
Connection cable
Video cable
S VIDEO connection cab le (not included)
Audio cable
Optical fibre cable (not included) Stereo phono cable
(not included)
White (L)
Red (R)
SURROUND SURROUND BACK
OUT IN IN
CD
BD/DVD PLAYER / ANALOG 8CH IN DVD RECORDER
VCR
CABLE/SAT GAME TV
AUDIO
SURROUND BACK SURROUND FRONT SUBWOOFER
OUT IN IN IN
(DVD RECORDER) (BD/DVD PLAYER) (CABLE/SAT)
HDMI 1 HDMI 2 HDMI 3
SURROUND SURROUND BACK
S VIDEO
COMPONENT VIDEO
L
R
IN IN IN
IN
OUT IN IN OUT OUT IN IN IN IN
TV MONITOR TV MONITOR
DVD RECORDER
VCR
CABLE/SAT
GAME
DVD PLAYER
BD/(BD/
DVD PLAYER)
(DVD RECORDER)
(CABLE/SAT)
12 3
(DVD RECORDER) (BD/DVD PLAYER)
(TV) (CD)
OPTICAL 1 OPTICAL 2 OPTICAL 3 COAXIAL
SUBWOOFER
Y
P
B
P
R
IN
OUT OUT IN IN IN IN
TV MONITOR DVD RECORDER
VCR CABLE/SAT GAME
DVD PLAYER
BD/
(6-16 WEACH SPEAKER)
OUT
CENTER
IN
IN
FM ANT
AM ANT
OPTION V 1
LOOP
EXT
DC OUT 5V
500mA MAX
75
W
RR L L
LOOP ANT
GND
VIDEO
DIGITAL IN
S VIDEO IN
S VIDEO
OUT
Digital audio
out (optical)
(R ) ( L)
Audio out
DVD recorderBlu-ray Disc/
DVD player
Cable box or
satellite receiver
VCR
Connecting the optical
fibre cable
Note the
shape and fit
it correctly
into the
terminal.
Do not
bend!
Rear panel
TV
Game
S VIDEO
OUT
Digital audio
out (optical)
S VIDEO
OUT
(R ) ( L)
Audio out
S VIDEO
OUT
(R ) ( L)
Audio out
S VIDEO
OUT
16
SA-BX500EB / SA-BX500EE / SA-BX500EG

5.4.4. Component and audio terminals
Connecting cables to component and audio terminals
The component video terminals can produce more accurate colours than the S video terminals.
Connection cable
Video cable Audio cable
Video connection cable (not included) Optical fibre cable (not included) Stereo phono cable (not included)
White (L)
Red (R)
SURROUND SURROUND BACK
OUT IN IN
CD
BD/DVD PLAYER / ANALOG 8CH IN DVD RECORDER
VCR
CABLE/SAT GAME TV
AUDIO
SURROUND BACK SURROUND FRONT SUBWOOFER
OUT IN IN IN
(DVD RECORDER) (BD/DVD PLAYER) (CABLE/SAT)
HDMI 1 HDMI 2 HDMI 3
SURROUND SURROUND BACK
S VIDEO
COMPONENT VIDEO
L
R
IN IN IN
IN
OUT IN IN OUT OUT IN IN IN IN
TV MONITOR TV MONITOR
DVD RECORDER
VCR
CABLE/SAT
GAME
DVD PLAYER
BD/(BD/
DVD PLAYER)
(DVD RECORDER)
(CABLE/SAT)
12 3
(DVD RECORDER) (BD/DVD PLAYER)
(TV) (CD)
OPTICAL 1 OPTICAL 2 OPTICAL 3 COAXIAL
SUBWOOFER
Y
P
B
P
R
IN
OUT OUT IN IN IN IN
TV MONITOR DVD RECORDER
VCR CABLE/SAT GAME
DVD PLAYER
BD/
(6-16 WEACH SPEAKER)
OUT
CENTER
IN
IN
FM ANT
AM ANT
OPTION V 1
LOOP
EXT
DC OUT 5V
500mA MAX
75
W
RR L L
LOOP ANT
GND
VIDEO
DIGITAL IN
YP B P R
YP B P R YP B P R YP B P R
COMPONENT
VIDEO IN
COMPONENT
VIDEO OUT
Digital audio
out (optical)
(R) (L)
Audio out
DVD recorder Blu-ray Disc/
DVD player
Cable box or
satellite receiver
Rear panel
TV Connecting the optical
fibre cable
Note the
shape and fit
it correctly
into the
terminal.
Do not
bend!
COMPONENT
VIDEO OUT
COMPONENT
VIDEO OUT
Digital audio
out (optical)
17
SA-BX500EB / SA-BX500EE / SA-BX500EG

5.4.5. Other connections
Other connections
OUT IN IN
CD
BD/DVD PLAYER / ANALOG 8CH IN DVD RECORDER
VCR
CABLE/SAT GAME TV
AUDIO
SURROUND BACK SURROUND FRONT SUBWOOFER
(DVD RECORDER) (BD/DVD PLAYER) (CABLE/SAT)
HDMI 1 HDMI 2 HDMI 3
S VIDEO
COMPONENT VIDEO
IN IN IN
IN
OUT IN IN OUT OUT IN IN IN IN
TV MONITOR TV MONITOR
DVD RECORDER
VCR
CABLE/SAT
GAME
DVD PLAYER
BD/(BD/
DVD PLAYER)
(DVD RECORDER)
(CABLE/SAT)
12 3
(DVD RECORDER) (BD/DVD PLAYER)
(TV)
OPTICAL 1 OPTICAL 2 OPTICAL 3
SUBWOOFER
Y
P
B
P
R
IN
OUT OUT IN IN IN IN
TV MONITOR DVD RECORDER
VCR CABLE/SAT GAME
DVD PLAYER
BD/
OUT
CENTER
IN
IN
FM ANT
AM ANT
OPTION V 1
LOOP
EXT
DC OUT 5V
500mA MAX
75
W
LOOP ANT
GND
VIDEO
L
R
DIGITAL IN
(CD)
COAXIAL
DIGITAL
AUDIO OUT
(CO
AXIAL)
(L) AUDIO
(R) OUT
CD player
To connect the unit to a CD player
Make either digital audio (COAXIAL) output connections ( ) or analogue audio output connections ( ) according to your
equipment and preference.
Rear panel
Connection cable
Video cable
Video connection cable (not included) S VIDEO connection cab le (not included)
Audio cable
Coaxial cable
(not included)
Stereo phono cab le (not included)
White (L)
Red (R)
To enjoy analogue sounds
OUT IN IN
CD
BD/DVD PLAYER / ANALOG 8CH IN DVD RECORDER
VCR
CABLE/SAT GAME TV
AUDIO
SURROUND BACK SURROUND FRONT SUBWOOFER
(DVD RECORDER) (BD/DVD PLAYER) (CABLE/SAT)
HDMI 1 HDMI 2 HDMI 3
S VIDEO
COMPONENT VIDEO
L
R
IN IN IN
IN
OUT IN IN OUT OUT IN IN IN IN
TV MONITOR TV MONITOR
DVD RECORDER
VCR
CABLE/SAT
GAME
DVD PLAYER
BD/(BD/
DVD PLAYER)
(DVD RECORDER)
(CABLE/SAT)
12 3
DIGITAL IN
(DVD RECORDER) (BD/DVD PLAYER)
(TV) (CD)
OPTICAL 1 OPTICAL 2 OPTICAL 3 COAXIAL
SUBWOOFER
Y
P
B
P
R
IN
OUT OUT IN IN IN IN
TV MONITOR DVD RECORDER
VCR CABLE/SAT GAME
DVD PLAYER
BD/
OUT
CENTER
IN
IN
FM ANT
AM ANT
OPTION V 1
LOOP
EXT
DC OUT 5V
500mA MAX
75
W
LOOP ANT
GND
VIDEO
Rear panel
(L) AUDIO
(R) OUT
Blu-ray Disc/
DVD player
DVD recorder
(L) AUDIO
(R) OUT
CK
OUT IN IN
CD
BD/DVD PLAYER / ANALOG 8CH IN DVD RECORDER
VCR
CABLE/SAT GAME TV
AUDIO
SURROUND BACK SURROUND FRONT SUBWOOFER
OUT IN IN IN
(DVD RECORDER) (BD/DVD PLAYER) (CABLE/SAT)
HDMI 1 HDMI 2 HDMI 3
K
S VIDEO
COMPONENT VIDEO
L
R
IN IN IN
IN
OUT IN IN OUT OUT IN IN IN IN
TV MONITOR TV MONITOR
DVD RECORDER
VCR
CABLE/SAT
GAME
DVD PLAYER
BD/(BD/
DVD PLAYER)
(DVD RECORDER)
(CABLE/SAT)
12 3
DIGITAL IN
(DVD RECORDER) (BD/DVD PLAYER)
(TV) (CD)
OPTICAL 1 OPTICAL 2 OPTICAL 3 COAXIAL
SUBWOOFER
Y
P
B
P
R
IN
OUT OUT IN IN IN IN
TV MONITOR DVD RECORDER
VCR CABLE/SAT GAME
DVD PLAYER
BD/
OUT
CENTER
IN
IN
FM ANT
AM ANT
OPTION V 1
LOOP
EXT
DC OUT 5V
500mA MAX
75
W
L
LOOP ANT
GND
VIDEO
( L) SURR OUND
(R) B ACK
SUBW OOFER
CENTER
(L)
(R)
FRONT
(L)
(R) SURR
OUND
Rear panel
Blu-ray Disc/DVD
player etc.
To enjoy high-quality analogue sounds (Analogue 8-channel connections)
A
A
B
B
18
SA-BX500EB / SA-BX500EE / SA-BX500EG

Other connections
BACK
OUT IN IN
CD
BD/DVD PLAYER / ANALOG 8CH IN DVD RECORDER
VCR
CABLE/SAT GAME TV
AUDIO
SURROUND BACK SURROUND FRONT SUBWOOFER
OUT IN IN IN
(DVD RECORDER) (BD/DVD PLAYER) (CABLE/SAT)
HDMI 1 HDMI 2 HDMI 3
CK
COMPONENT VIDEO
L
R
IN IN IN
IN
OUT IN IN OUT OUT IN IN IN IN
TV MONITOR TV MONITOR
DVD RECORDER
VCR
CABLE/SAT
GAME
DVD PLAYER
BD/(BD/
DVD PLAYER)
(DVD RECORDER)
(CABLE/SAT)
12 3
DIGITAL IN
(DVD RECORDER) (BD/DVD PLAYER)
(TV) (CD)
OPTICAL 1 OPTICAL 2 OPTICAL 3 COAXIAL
SUBWOOFER
Y
PB
PR
IN
OUT OUT IN IN IN IN
TV MONITOR DVD RECORDER
VCR CABLE/SAT GAME
DVD PLAYER
BD/
OUT
CENTER
IN
IN
FM ANT
AM ANT
OPTION V 1
LOOP
EXT
DC OUT 5V
500mA MAX
75
W
L
LOOP ANT
GND
VIDEO
S VIDEO
S VIDEO
IN
VIDEO IN
(L)
AUDIO
(R) IN
DVD recor der, etc.
To connect the unit for audio or picture recording
You can record audio or pictures to the equipment connected to DVD recorder output terminal (AUDIO, VIDEO, S VIDEO).
Note
Connect the recording unit and source unit using the same cable.
To connect the unit to a video camera etc.
These terminals are convenient for equipment you want to connect only temporarily.
Note
Use a cable, or that belongs to the same type as the video cable you used for connecting the unit to your TV.
Rear panel
WIRELESS READY
SURROUND M.ROOM
INPUT SELECTOR
VOLUME
+
_
MULTI CH
PROCESSING TrueHD D+ DTS-HD
MULTI CH
LPCM BI-AMP
SETUP MIC AUX
TUNE
RETURN
AUTO SPEAKER SETUP
- SETUP OK
SURROUND SPEAKERS A SPEAKERS B
S VIDEO VIDEO L - AUDIO - R
S VIDEO
OUT
VIDEO
OUT
(L)
AUDIO
(R) OUT
Video
camera
etc.
How to attach or remove the front terminal cover
Attaching the cover is recommended to protect terminals when not in use.
To attach To remove
Place the dent on the left to insert. Press the dent. Hold the protrusion to remove.
The dent
Terminal cover
19
SA-BX500EB / SA-BX500EE / SA-BX500EG

5.4.6. For speakers
Connecting other speakers
Making bi-wire setting
Note
Make sure to connect speakers HF terminals with the unit s FRONT B terminals, and speakers LF terminals with the unit s
FRONT A terminals.
Different amps for high frequency and low frequency signals produce BI-AMP stereo sounds that are clearer and higher in audio
quality when you play on 2 channels sources containing analogue audio and 2-channel PCM signals.
BI-WIRE
LF HF
L
R
FRONT A FRONT B CENTER SURROUND SURROUND BACK
SPEAKERS
CD
FRONT A FRONT B CENTER SURROUND SURROUND BACK
L
R
IN
A C IN~
OUT
TV MONITOR
(DVD RECORDER)
Y
P
B
P
R
(6-16 WEACH SPEAKER)
A OR B / BI-WIRE (4-16 WEACH SPEAKER) A AND B (6-16 WEACH SPEAKER)
RLRR L L
Front speaker (R)
Speaker impedance
Front A or B: 4 to 16
Front A and B: 6 to 16
To connect bi-wire speakers
Make sure to select YES in Making bi-wire setting below when you connect the unit to bi-wire speakers. The speakers
do not produce adequate sounds unless you make this setting.
To connect a second pair of front speakers (SPEAKERS B)
Make the following connections when you wish to install a second pair of speakers in another room and enjoy music there.
Front speaker (L)
Speaker cable
(not included)
BI-WIRE
LF HF
L
R
FRONT A FRONT B CENTER SURROUND SURROUND BACK
SPEAKERS
CD
FRONT A FRONT B CENTER SURROUND SURROUND BACK
L
R
IN
A C IN~
OUT
TV MONITOR
(DVD RECORDER)
Y
P
B
P
R
(6-16 WEACH SPEAKER)
A OR B / BI-WIRE (4-16 WEACH SPEAKER) A AND B (6-16 WEACH SPEAKER)
RLRR L L
HF
LF
HF
LF
Front speaker (R)
Rear view
Speaker impedance
BI-WIRE: 4 to 16
Speaker cable
(not included)
Front speaker (L)
Rear view
Rear panel
Rear panel
Make sure to select YES when you connect the unit to bi-wire speakers. The speakers do not produce adequate sounds
unless you make this setting.
1. To enter the SETUP
2. Press [ ][ ] to select LR BI-WIRE , and press [OK] to confirm.
3. Press [ ][ ] to select YES , and press [OK] to confirm.
YES : When bi-wire speakers are connected
NO : When bi-wire speakers are not connected
Factory setting: NO
4. T o finish the setting
20
SA-BX500EB / SA-BX500EE / SA-BX500EG
