Panasonic GA-ML Series User manual

GA-ML Series
Model Number PN260493N/PN260493H/PN260893/
PN260893H/PN260894/PN261693/
PN262492/PN262493
WEB Reference
• Thank you for purchasing our product.
• This manual provides important information about safe and proper
operations of this Switching Hub.

2
ThetargetmodelforthisWEBreferenceisasfollows
Modelname Modelnumber Firmwareversion
GA-ML4TPoE+ PN260493N 3.0.0.00andabove
GA-MLi4TPoE+ PN260493H 3.0.0.00andabove
GA-ML8TPoE+ PN260893 3.0.0.00andabove
GA-MLi8TPoE+ PN260893H 3.0.0.00andabove
GA-ML8THPoE+ PN260894 3.0.0.00andabove
GA-ML16TPoE+ PN261693 3.0.0.00andabove
GA-ML24TCPoE+ PN262492 3.0.0.00andabove
GA-ML24TPoE+ PN262493 3.0.0.00andabove

1
Table of Contents
1 Introduction .........................................................................................9
1.1 Related Documentation ...................................................................................... 9
2 Web User Interface (Web UI) ............................................................10
2.1 Connecting to the Web UI ................................................................................. 10
2.2 Understanding the Web UI ................................................................................ 12
3 System ................................................................................................13
3.1 Device Information ............................................................................................ 13
3.2 System Information Settings ............................................................................. 14
3.3 Port Settings ..................................................................................................... 15
3.3.1 Port Settings ............................................................................................ 15
3.3.2 Port Status ............................................................................................... 18
3.3.3 Port GBIC ................................................................................................. 19
3.3.4 Port Auto Negotiation .............................................................................. 20
3.3.5 Error Disable Settings ............................................................................... 21
3.3.6 Jumbo Frame ........................................................................................... 22
3.3.7 Port Grouping Configuration .................................................................... 23
3.4 System Log ....................................................................................................... 24
3.4.1 System Log Settings ................................................................................. 24
3.4.2 System Log Discriminator Settings ............................................................27
3.4.3 System Log Server Settings ......................................................................28
3.4.4 System Log .............................................................................................. 30
3.4.5 System Attack Log ................................................................................... 31
3.4.6 System Authentication Log ...................................................................... 32
3.5 Time and SNTP (Simple Network Time Protocol) ................................................ 33
3.5.1 Clock Settings .......................................................................................... 33
3.5.2 Time Zone Settings .................................................................................. 34
3.5.3 SNTP Settings .......................................................................................... 36
3.6 Time Range ....................................................................................................... 37
3.7 PoE Configuration ............................................................................................. 39
3.7.1 PoE Global Configuration ......................................................................... 39
3.7.2 PoE Port Configuration ............................................................................. 41
3.7.3 PoE Schedule Configuration .....................................................................42
3.7.4 PoE Schedule Port List Configuration ........................................................ 44
3.7.5 PoE Date List Configuration ...................................................................... 45
3.7.6 PoE Auto-Reboot Settings ........................................................................ 46
4 Management .....................................................................................49
4.1 User Accounts Encryption .................................................................................. 49
4.2 Login Method ................................................................................................... 50
4.3 IP Setup ............................................................................................................ 52
4.3.1 IP Setup Protocol Settings ........................................................................52
4.4 SNMP ............................................................................................................... 53
4.4.1 SNMP Group Table Settings ..................................................................... 53
4.4.2 SNMP Engine ID Local Settings ................................................................. 55
4.4.3 SNMP User Table Settings ........................................................................56
4.4.4 SNMP Host Table Settings ........................................................................59

2
4.5 RMON (Remote Monitoring) ............................................................................. 61
4.5.1 RMON Global Settings ............................................................................. 61
4.5.2 RMON Statistics Settings ..........................................................................62
4.5.3 RMON History Settings ............................................................................ 64
4.5.4 RMON Alarm Settings .............................................................................. 66
4.5.5 RMON Event Settings ............................................................................... 67
4.6 Telnet/Web ....................................................................................................... 69
4.7 Session Time-out ............................................................................................... 70
4.8 DHCP Auto Configuration ................................................................................. 71
4.9 DNS (Domain Name System) ............................................................................. 72
4.9.1 DNS Global Settings ................................................................................. 72
4.9.2 DNS Name Server Settings .......................................................................73
4.9.3 DNS Host Settings .................................................................................... 74
4.10 File System ...................................................................................................... 75
4.11 SMTP Settings ................................................................................................. 77
4.12 NLB FDB Settings ............................................................................................ 79
5 L2 Features .........................................................................................80
5.1 FDB (Forwarding Database) ............................................................................... 80
5.1.1 Static FDB ................................................................................................ 80
5.1.1.1 Unicast Static FDB ........................................................................... 80
5.1.1.2 Multicast Static FDB ........................................................................82
5.1.2 MAC Address Table Settings ....................................................................83
5.1.3 MAC Address Table .................................................................................. 86
5.1.4 MAC Notification ..................................................................................... 87
5.2 VLAN (Virtual Local Area Network) .................................................................... 89
5.2.1 802.1Q VLAN ........................................................................................... 89
5.2.2 802.1v Protocol VLAN .............................................................................. 91
5.2.2.1 Protocol VLAN Profile ......................................................................91
5.2.2.2 Protocol VLAN Profile Interface .......................................................93
5.2.3 GVRP ....................................................................................................... 94
5.2.3.1 GVRP Global ................................................................................... 94
5.2.3.2 GVRP Port ....................................................................................... 95
5.2.3.3 GVRP Advertise VLAN ..................................................................... 96
5.2.3.4 GVRP Forbidden VLAN ....................................................................97
5.2.3.5 GVRP Statistics Table ......................................................................98
5.2.4 Asymmetric VLAN .................................................................................... 99
5.2.5 MAC VLAN ............................................................................................ 100
5.2.6 VLAN Interface ...................................................................................... 101
5.2.7 Subnet VLAN ......................................................................................... 106
5.2.8 Voice VLAN ............................................................................................ 107
5.2.8.1 Voice VLAN Global ........................................................................ 107
5.2.8.2 Voice VLAN Port ........................................................................... 109
5.2.8.3 Voice VLAN OUI ........................................................................... 111
5.2.8.4 Voice LAN Device .......................................................................... 112
5.2.8.5 Voice VLAN LLDP-MED Device ....................................................... 113
5.2.9 Private VLAN .......................................................................................... 114
5.3 STP (Spanning Tree Protocol) .......................................................................... 117
5.3.1 STP Global Settings ................................................................................ 117
5.3.2 STP Port Settings .................................................................................... 120
5.3.3 MST Configuration Identification ............................................................ 122
5.3.4 STP Instance .......................................................................................... 124
5.3.5 MSTP Port Information .......................................................................... 125

3
5.4 Loop Detection Configuration ......................................................................... 126
5.4.1 Detecting and Blocking the Loop Settings ..............................................126
5.4.2 Loop History Log .................................................................................... 128
5.5 Link Aggregation ............................................................................................ 129
5.6 L2 Protocol Tunnel .......................................................................................... 131
5.7 L2 Multicast Control ........................................................................................ 134
5.7.1 IGMP Snooping ...................................................................................... 134
5.7.1.1 IGMP Snooping Settings ............................................................... 134
5.7.1.2 IGMP Snooping Group Settings .................................................... 137
5.7.1.3 IGMP Snooping Filter Settings .......................................................139
5.7.1.4 IGMP Snooping Multicast Router Information ............................... 143
5.7.1.5 IGMP Snooping Statistics Settings .................................................145
5.7.2 MLD Snooping ....................................................................................... 147
5.7.2.1 MLD Snooping Settings ................................................................147
5.7.2.2 MLD Snooping Group Settings ...................................................... 151
5.7.2.3 MLD Snooping Filter Settings ........................................................ 153
5.7.2.4 MLD Snooping Multicast Router Information ................................ 156
5.7.2.5 MLD Snooping Statistics Settings .................................................. 158
5.7.3 Multicast Filtering Mode ........................................................................160
5.8 LLDP (Link Layer Discovery Protocol) ................................................................161
5.8.1 LLDP Global Settings .............................................................................. 161
5.8.2 LLDP Port Settings .................................................................................. 163
5.8.3 LLDP Management Address List .............................................................165
5.8.4 LLDP Basic TLVs Settings ........................................................................166
5.8.5 LLDP Dot1 TLV Settings .......................................................................... 167
5.8.6 LLDP Dot3 TLV Settings .......................................................................... 169
5.8.7 LLDP-MED Port Settings ......................................................................... 170
5.8.8 LLDP Statistics Information ..................................................................... 171
5.8.9 LLDP Local Port Information ...................................................................172
5.8.10 LLDP Neighbor Port Information ...........................................................174
5.9 RRP (Ring Redundant Protocol) ....................................................................... 175
6 L3 Features .......................................................................................178
6.1 ARP (Address Resolution Protocol) .................................................................. 178
6.1.1 ARP Aging Time ..................................................................................... 178
6.1.2 Static ARP .............................................................................................. 179
6.1.3 ARP Table .............................................................................................. 181
6.2 Gratuitous ARP ............................................................................................... 182
6.3 IPv6 Neighbor ................................................................................................. 184
6.4 Interface ......................................................................................................... 185
6.4.1 IPv4 Interface ......................................................................................... 185
6.4.2 IPv6 Interface ......................................................................................... 189
6.5 IPv4 Default Route .......................................................................................... 194
6.6 IPv6 Default Route .......................................................................................... 195
6.7 IPv6 General Prefix .......................................................................................... 196
7 QoS (Quality of Service) ...................................................................197
7.1 Basic Settings .................................................................................................. 197
7.1.1 Port Default CoS .................................................................................... 197
7.1.2 Port Scheduler Method .......................................................................... 198
7.1.3 Queue Settings ...................................................................................... 200
7.1.4 CoS to Queue Mapping .......................................................................... 202
7.1.5 Port Rate Limiting .................................................................................. 203

4
7.1.6 Queue Rate Limiting .............................................................................. 205
7.2 Advanced Settings .......................................................................................... 207
7.2.1 DSCP Mutation Map .............................................................................. 207
7.2.2 Port Trust State and Mutation Binding ...................................................208
7.2.3 DSCP CoS Mapping ................................................................................ 209
7.2.4 CoS Color Mapping ................................................................................ 210
7.2.5 DSCP Color Mapping ............................................................................. 211
7.2.6 Class Map .............................................................................................. 212
7.2.7 Aggregate Policer .................................................................................. 214
7.2.8 Policy Map ............................................................................................. 220
7.2.9 Policy Binding ......................................................................................... 228
7.3 Egress Buffer Settings ..................................................................................... 229
7.3.1 Egress Buffer Settings ............................................................................ 229
8 ACL (Access Control List) .................................................................230
8.1 ACL Configuration Wizard ............................................................................... 230
8.1.1 MAC ACL ............................................................................................... 232
8.1.2 IPv4 ....................................................................................................... 235
8.1.3 IPv6 ....................................................................................................... 240
8.2 ACL Access List ............................................................................................... 245
8.2.1 Standard IP ACL ..................................................................................... 247
8.2.2 Extended IP ACL ..................................................................................... 250
8.2.3 Standard IPv6 ACL ................................................................................. 255
8.2.4 Extended IPv6 ACL ................................................................................. 258
8.2.5 Extended MAC ACL ................................................................................ 263
8.2.6 Extended Expert ACL .............................................................................. 266
8.3 ACL Interface Access Group ............................................................................ 272
8.4 ACL VLAN Access Map .................................................................................... 274
8.5 ACL VLAN Filter ............................................................................................... 277
9 Security .............................................................................................278
9.1 Port Security ................................................................................................... 278
9.1.1 Port Security Global Settings ..................................................................278
9.1.2 Port Security Port Settings ......................................................................280
9.1.3 Port Security Address Entries ..................................................................282
9.2 802.1X ............................................................................................................ 283
9.2.1 802.1X Global Settings ......................................................................... 283
9.2.2 802.1X Forced Authorized MAC Settings ............................................... 285
9.2.3 802.1X Unauthorized MAC Settings ....................................................... 286
9.2.4 802.1X Ports Settings ............................................................................ 287
9.2.5 EAP Port Config ..................................................................................... 292
9.2.6 802.1X Authentication Statistics Information ........................................ 293
9.2.7 802.1X Supplicant Global Settings ........................................................ 294
9.2.8 802.1X Supplicant Port Settings ............................................................. 295
9.2.9 802.1X Supplicant Statistics Information ................................................ 297
9.3 AAA (Authentication, Authorization, and Accounting) ....................................298
9.3.1 AAA Global Settings .............................................................................. 298
9.3.2 AAA Authentication Settings .................................................................. 299
9.3.3 AAA Authentication User Settings ..........................................................302
9.3.4 AAA Authentication MAC Settings .........................................................304
9.3.5 Application Authentication Settings ....................................................... 306
9.3.6 Application Accounting Settings ............................................................. 307
9.3.7 Authentication EXEC Settings ................................................................. 309

5
9.3.8 Accounting Settings ............................................................................... 311
9.4 Authentication ................................................................................................ 314
9.4.1 Authentication Dynamic VLAN Settings .................................................. 314
9.4.2 Authentication Status Table ...................................................................315
9.4.3 2-Step Authentication Settings ...............................................................316
9.5 RADIUS (Remote Authentication Dial-In User Service) ...................................... 317
9.5.1 RADIUS Global Settings ......................................................................... 317
9.5.2 RADIUS Server Settings .......................................................................... 319
9.5.3 RADIUS Group Server Settings ............................................................... 320
9.5.4 RADIUS Statistics ................................................................................... 322
9.6 TACACS+ (Terminal Access Controller Access-Control System Plus) .................. 323
9.6.1 TACACS+ Global Settings ....................................................................... 323
9.6.2 TACACS+ Server Settings ....................................................................... 324
9.6.3 TACACS+Group Servers Settings ............................................................ 325
9.6.4 TACACS+Statistics ................................................................................. 327
9.7 SAVI (Source Address Validation Improvements) .............................................328
9.7.1 IPv4 ....................................................................................................... 328
9.7.1.1 DHCPv4 Snooping ......................................................................... 328
9.7.1.1.1 DHCP Snooping Global Settings ............................................ 328
9.7.1.1.2 DHCP Snooping Port Settings ...............................................329
9.7.1.1.3 DHCP Snooping VLAN Settings .............................................330
9.7.1.1.4 DHCP Snooping Database ..................................................... 331
9.7.1.1.5 DHCP Snooping Binding Entry ............................................... 333
9.7.1.2 Dynamic ARP Inspection ............................................................... 334
9.7.1.2.1 ARP Access List .....................................................................334
9.7.1.2.2 ARP Inspection Settings ........................................................ 336
9.7.1.2.3 ARP Inspection Port Settings .................................................339
9.7.1.2.4 ARP Inspection Statistics Information ....................................340
9.7.1.2.5 ARP Inspection Log ...............................................................341
9.7.1.3 IP Source Guard ............................................................................ 342
9.7.1.3.1 IP Source Guard Port Settings ...............................................342
9.7.1.3.2 IP Source Guard Binding .......................................................343
9.7.1.3.3 IP Source Guard HW Entry .................................................... 345
9.8 BPDU Guard .................................................................................................... 346
9.9 NetBIOS Filtering ............................................................................................. 348
9.10 MAC Authentication ..................................................................................... 349
9.11 Web Authentication ...................................................................................... 351
9.11.1 Web Authentication Settings ...............................................................351
9.11.2 Web Page Contents Settings ................................................................353
9.12 Trusted Host ................................................................................................. 355
9.13 Storm Control ............................................................................................... 356
9.14 SSH (Secure Shell) ......................................................................................... 360
9.14.1 SSH Global Settings ............................................................................. 360
9.14.2 Host Key .............................................................................................. 361
9.14.3 SSH Server Connection ......................................................................... 362
9.14.4 SSH User Settings ................................................................................ 363
9.15 SSL (Secure Sockets Layer) ............................................................................ 364
9.15.1 SSL Global Settings .............................................................................. 364
9.15.2 Crypto PKI Trustpoint ........................................................................... 365
9.15.3 SSL Service Policy ................................................................................. 366
10 OAM (Operations, Administration & Management) ....................368
10.1 Cable Diagnostics .......................................................................................... 368

6
10.2 DDM (Digital Diagnostic Monitoring) ............................................................. 369
10.2.1 DDM Settings ...................................................................................... 369
10.2.2 DDM Temperature Threshold Settings .................................................. 371
10.2.3 DDM Voltage Threshold Settings ..........................................................372
10.2.4 DDM Bias Current Threshold Settings ................................................... 373
10.2.5 DDM TX Power Threshold Settings ....................................................... 374
10.2.6 DDM RX Power Threshold Settings ...................................................... 375
10.2.7 DDM Status Table ................................................................................ 376
10.3 Ethernet OAM ............................................................................................... 377
10.3.1 Ethernet OAM Configuration ............................................................... 377
10.3.2 Ethernet OAM (Discovery Information) .................................................379
10.3.3 Ethernet OAM Statistics ....................................................................... 380
10.4 CFM .............................................................................................................. 383
10.4.1 CFM Status .......................................................................................... 383
10.4.2 CFM Maintenance Intermediate Point .................................................. 384
10.4.3 CFM Maintenance End Point ................................................................385
10.4.4 CFM Maintenance Association .............................................................386
10.4.5 CFM Loop-back .................................................................................... 387
10.4.6 CFM Linktrace ...................................................................................... 388
11 Monitoring .....................................................................................389
11.1 Utilization ..................................................................................................... 389
11.1.1 Port Utilization ..................................................................................... 389
11.2 Statistics ....................................................................................................... 390
11.2.1 Port ..................................................................................................... 390
11.2.2 Interface Counters ............................................................................... 392
11.2.3 Counters .............................................................................................. 394
11.3 Mirror Settings .............................................................................................. 396
11.4 Device ........................................................................................................... 399
12 ECO Mode ......................................................................................400
12.1 Power-Saving ................................................................................................ 400
12.2 EEE (Energy Efficient Ethernet) ......................................................................401
12.3 LED-Base Mode ............................................................................................. 402
13 sFlow ..............................................................................................403
13.1 sFlow ............................................................................................................ 403
13.1.1 sFlow Settings ...................................................................................... 403
14 Tool Bar .........................................................................................405
14.1 Save .............................................................................................................. 405
14.1.1 Save Configuration .............................................................................. 405
14.2 Tool .............................................................................................................. 405
14.2.1 Firmware Upgrade & Backup ................................................................405
14.2.1.1 Firmware Upgrade from HTTP (Servers) .......................................405
14.2.1.2 Firmware Upgrade from TFTP ...................................................... 407
14.2.1.3 Firmware Upgrade from FTP Servers ...........................................408
14.2.1.4 Firmware Upgrade from RCP ....................................................... 409
14.2.1.5 Firmware Backup to HTTP ........................................................... 410
14.2.1.6 Firmware Backup to TFTP ............................................................411
14.2.1.7 Firmware Backup to FTP Servers .................................................. 412
14.2.1.8 Firmware Backup to RCP ............................................................. 413
14.2.2 Configuration Restore & Backup ..........................................................414

7
14.2.2.1 Configuration Restore from HTTP ................................................ 414
14.2.2.2 Configuration Restore from TFTP ................................................ 415
14.2.2.3 Configuration Recovery from FTP Servers .................................... 416
14.2.2.4 Configuration Restore from RCP .................................................417
14.2.2.5 Configuration Backup to HTTP .................................................... 418
14.2.2.6 Configuration Backup to TFTP .....................................................419
14.2.2.7 Configuration Backup to FTP Servers ...........................................420
14.2.2.8 Configuration Backup to RCP ...................................................... 421
14.2.3 Log Backup .......................................................................................... 422
14.2.3.1 Log Backup to HTTP ....................................................................422
14.2.3.2 Log-backup to TFTP ..................................................................... 423
14.2.3.3 Log Backup to RCP .....................................................................424
14.2.4 Ping ..................................................................................................... 425
14.2.5 Trace Route ......................................................................................... 428
14.2.6 Reset ................................................................................................... 430
14.2.7 Reboot System ..................................................................................... 431
14.3 Language ...................................................................................................... 432
14.4 Log Out ........................................................................................................ 433
15 Appendix - System Log Entries ......................................................434
15.1 802.1X .......................................................................................................... 434
15.2 AAA .............................................................................................................. 435
15.3 ARP .............................................................................................................. 438
15.4 Authentication (2 Steps) ................................................................................ 439
15.5 BPDU Guard .................................................................................................. 441
15.6 Command ..................................................................................................... 442
15.7 Configuration/Firmware ................................................................................ 443
15.8 DAD .............................................................................................................. 446
15.9 DDM ........................................................................................................... 447
15.10 Debug Error ................................................................................................ 448
15.11 DHCPv6 Client ............................................................................................. 449
15.12 Dynamic ARP .............................................................................................. 451
15.13 Interface ..................................................................................................... 452
15.14 PoE ............................................................................................................. 453
15.15 PoE Scheduler ............................................................................................. 454
15.16 PoE Auto Reboot ........................................................................................ 455
15.17 Verifying IP Source Guard ........................................................................... 456
15.18 LLDP-MED ................................................................................................... 457
15.19 LACP ........................................................................................................... 459
15.20 Detecting Loops .......................................................................................... 460
15.21 MAC-based Access Control ......................................................................... 461
15.22 MSTP Debug Extension ............................................................................... 462
15.23 Port Security ............................................................................................... 464
15.24 RADIUS ....................................................................................................... 465
15.25 RRP ............................................................................................................. 466
15.26 SNMP ......................................................................................................... 467
15.27 System ........................................................................................................ 468
15.28 Telnet ......................................................................................................... 469
15.29 Temperature ............................................................................................... 470
15.30 Traffic Control ............................................................................................. 471
15.31 Voice VLAN ................................................................................................. 472
15.32 WAC ........................................................................................................... 473
15.33 Web ............................................................................................................ 474

8
16 Appendix - System Trap Entries .....................................................475
16.1 BPDU Guard .................................................................................................. 475
16.2 DDM ............................................................................................................. 476
16.3 DHCP Server Protect ..................................................................................... 477
16.4 Gratuitous ARP ............................................................................................. 478
16.5 LLDP-MED ..................................................................................................... 479
16.6 Detecting Loops ............................................................................................ 480
16.7 MAC Based Access Control ........................................................................... 481
16.8 MAC Notification .......................................................................................... 482
16.9 MSTP ............................................................................................................ 483
16.10 Port Security ............................................................................................... 484
16.11 Port ............................................................................................................. 485
16.12 RMON ........................................................................................................ 486
16.13 SNMP Authentication .................................................................................. 487
16.14 System ........................................................................................................ 488
16.15 Temperature ............................................................................................... 489
16.16 Traffic Control ............................................................................................. 490
Troubleshooting ..................................................................................491
◆LED ............................................................................................................ 491
◆If the Communication Speed is Slow ..........................................................492
◆If Your Device does not Work ..................................................................... 492
Warranty and After-service: ...............................................................493

9
1Introduction
1.1 Related Documentation
1Introduction
The manual for Web User Interface (Web UI) targets engineers or
professionals who are familiar with the principle of Ethernet and computer
networking. This document describes software features available in the
Web UI of switches of this series. The switches are equipped with an
identical set of software features available in the Web UI, and will be
referred to as the “switch” in this document.
Refer to the instruction found on our website (Panasonic Life Solutions
Networks) or the manual of our products regarding the name of each part
of them, the installation-method, and the separately sold option.
1.1 Related Documentation
Not only Web UI, but CLI (Command Line Interface) can be used for
configuring and managing the switch. See the “CLI Reference” manual for
details on CLI.

10
2 Web User Interface (Web UI)
2.1 Connecting to the Web UI
2Web User Interface (Web UI)
2.1 Connecting to the Web UI
You can directly or indirectly access the Web UI of a switch from any
networking nodes, which are connected to an Ethernet port, by using the
standard web browser. Implement the additional security settings on the
Web UI to control the access to the switch. By default, an IPv4 address of
the switch is set to 0.0.0.0. Use CLI from a console port to configure the
IPv4 address of the switch, first. Refer to “CLI reference manual” for
details. Next, launch the Web browser. Enter the IPv4 address of the
switch on the address bar of Uniform Resource Locator (URL), and then
press Enter.
Figure 2-1 Enter IPv4 Address
By default, you can enter “manager” in the spaces provided for a user-
name and a password, as illustrated in the figure below. Then click the
Log-in button.
Figure 2-2 Password
After logging in the screen above, you can access the Web UI as below.

11
2 Web User Interface (Web UI)
2.1 Connecting to the Web UI
Figure 2-3 Main Window of Web UI

12
2 Web User Interface (Web UI)
2.2 Understanding the Web UI
2.2 Understanding the Web UI
The Web UI is divided into two sections (frame A and B) as illustrated in
the figure below.
Figure 2-4
All the features available in the Web UI of the switch are categorized into
folders in frame A above. Click on a folder in the frame A (e.g. system),
and then click on a feature link (e.g. system information settings) to access
the configuration window in the frame B. Next, implement the settings
and management in the frame B.
The following chapters describe all the software features in the order they
are displayed in the frame A.
AB

13
3System
3.1 Device Information
3System
3.1 Device Information
Use the following window to display general switch information and
utilization (or usage). As you log-into the Web UI of the switch, the
window is displayed from the beginning.
Click the GA-MLxxT link (in Frame A) to display the following window.
Figure 3-1 Device Information

14
3System
3.2 System Information Settings
3.2 System Information Settings
Use the following window to implement the system information settings
and display its settings.
Choose System > System Information Settings to display the following
window.
Figure 3-2 System Information Settings
In the section of System Information Settings, you can configure the
following parameters.
Click Apply to reflect the change made.
Parameter Overview
System Name Enter the system name of a switch. Use the name to
identify the switch in the network.
System Location Enter and describe an overview of the switch location.
System Contact Enter the name of the PIC for a switch. In general, this
means the name of the person or company in charge of
configuring and maintaining the switch.

15
3System
3.3 Port Settings 3.3.1 Port Settings
3.3 Port Settings
3.3.1 Port Settings
Use the following window, and then implement the port settings on the
switch to display its settings.
Choose System > Port Configuration > Port Settings to display the
following window.
Figure 3-3 Port Settings
In the Port Settings section, you can configure the following parameters.
Parameter Overview
From port -
To Port
Choose the port you use.
Selecting a Media Choose a media type for ports. The options available are
Automatic,RJ45 and SFP. SFP stands for Small Form-
Factor Pluggable.
Media Type Choose a media type for ports. The options available are
RJ45 and SFP.
State This parameter enables or disables a physical port.

16
3System
3.3 Port Settings 3.3.1 Port Settings
MDIX Choose an object of MDIX (Medium Dependent
Interface Crossover). The options available are as
follows.
•Auto - This value automatically senses an optimum
type of cables.
•Normal - Choose this for normal cables. Selecting it
makes a port to become the MDIX mode, and that
allows a straight-through cable to connect to a PC
LAN adapter. Or, employ a cross-over cable to
connect it to a port of a different switch (MDI
mode).
•Cross - Choose this for employing a cross-over cable.
Selecting this option allows a port to become the
MDI mode, and that allows a straight-cable to
connect to a port of the different switch (MDIX
mode).
Flow Control Set the flow control to ON or OFF. On the port where it
is set to full duplex, use the flow control of 802.3x, and
use the one (of two), which is automatically selected on
an Automatic port.
Duplex Choose the duplex mode you use. The options available
are Automatic and Full.
Speed Choose the option of a port speed. This option allows
you to implement the forced settings manually for the
connection-speed on the port, which is selected for
connecting with the speed specified. If Master
Configurations are implemented, you can advertise
the functions, which are related to types of duplex
communication, the speed and physical layer, on ports.
Also, this action determines the relationship between a
master and a slave on the joint where two physical
layers exist (or contact each other). The relationship is
necessary for establishing a timing-control between the
two physical layers above. The timing-control is
configured on a physical layer of the master by a local
source. A loop timing is used for the slave settings. In
this case, the timing is obtained from the data stream
received from the master. If one connection is set to the
master, the other connection must be set to the slave. If
other configurations are implemented, the condition of
a “link-down” occurs on both ports.
Parameter Overview

17
3System
3.3 Port Settings 3.3.1 Port Settings
Click Apply to reflect the change made.
Speed The following options are available to choose.
•Automatic - In the case of a copper-port, an auto
negotiation starts, and then it allows the speed and
flow control to negotiate with its link-partner. In the
case of fiber-ports, the auto negotiation starts, and
then it allows the clock and full-control to negotiate
with its link-partner.
•10M - This value sets the port speed to 10 Mbps,
forcefully. This option is available for 10 Mbps
copper-cable connection, only.
•100M - This value sets to the port speed to
100Mbps, forcefully. This option is available for
100Mbps copper-cable connection, only.
•1000M - This value sets the port speed to 1Gbps,
forcefully. This option is available for 1Gbps fiber-
connection, only.
•1000M Master - This value sets the port speed to
1Gbps forcefully, and functions as the master, and
facilitates the timing of an operation for sending and
receiving. This option is available for 1Gbps copper-
cable connection, only.
•1000M Slave - This value sets the port speed to
1Gbps forcefully, and also functions as the slave to
facilitate the timing of an operation for sending and
receiving. This option is only available for 1Gbps
copper-cable connection.
Capability Advertised If you set the Speed to Auto, these functions are
advertised during the Auto Negotiation.
Description Describe an overview of the corresponding ports. The
number of characters can be up to 64.
Parameter Overview

18
3System
3.3.2 Port Status
3.3.2 Port Status
Use the following window to display the physical port-status and settings
of the switch.
Choose System > Port Configuration > Port Status to display the
following window.
Figure 3-4 Port Status
