Panasonic Toughbook U1 Ultra User manual

Panasonic recommends Windows®7.
1.800.662.3537 panasonic.com/toughbook/U1-Ultra
SOLUTIONS IS OUR MIDDLE NAME
■Genuine Windows®7 Professional1
■Sunlight-viewable Up to 6000 Nit in Direct Sunlight
■Optional Integrated Camera, GPS and Barcode
and Fingerprint Readers
■Wi-Fi, Bluetooth®and Optional 3G Gobi™WWAN
■Numeric and QWERTY Keyboard Options
■Twin Hot-swappable Batteries for Continuous Use
ThE NExT gENERATION Of hANDhELD pOwER
wITh wINDOwS®7 pROfESSIONAL.1
The Panasonic Toughbook®U1 Ultra is the newest member
of the Toughbook U1 family, and is the clear alternative for
legacy Windows®Mobile solutions when you need your
mobile workers to do more in the eld and need an advanced
mobile solution that can work anywhere. The U1 Ultra features
a brilliant LED screen capable of up to 6000 nit in direct
sunlight and can automatically adjust its screen brightness
to t its environment. Genuine Windows®71support means
an easier to use interface and more off-the-shelf commercial
applications than any OS on the planet. Plus, the U1 Ultra
features a rugged modular design and a host of integrated
options like GPS, Gobi™mobile broadband, a 2MP camera
and barcode readers—there are no limits to productivity.
The U1 Ultra is ideally suited for multitasking applications
such as SAP, CRM, turn-by-turn directions, drawings,
schematics, GEO tagging and paperless forms, to name
a few. And for more basic applications and usage
environments, the Toughbook U1 Essential is the perfect
companion with a combination of value and versatility.
The first MIL-STD-810G
certified handheld PC2
ThE TOUghBOOK
U1
ULTRA

Panasonic recommends Windows®7.
DURABILITY ■MIL-STD-810G certified (6' drop, shock, vibration, rain, dust, sand, altitude,
freeze/thaw, high/low temperature, temperature shock, humidity, salt, fog)2
■MIL-STD-461F certified (requires special model)2
■IP65 certified sealed all-weather design2
■UL1604 class I, division 2, groups ABCD certified model
■Magnesium alloy chassis encased with ABS and elastomer
■Removable reinforced flex-connect SSD3
■Pivoting hand strap
■Reinforced locking port covers
SOfTwARE ■Genuine Windows®7 Professional1
■Panasonic Utilities, Recovery DVD
CpU ■Intel®Atom™Processor Z530
– 1.60GHz
– 512KB L2 cache
– 533MHz FSB
STORAgE & MEMORY ■2GB SDRAM (DDR2)4,5
■64GB removable reinforced flex-connect SSD3,4
DISpLAY ■5.6" widescreen WSVGA touchscreen LED 1024 x 600
■TransflectivePlus sunlight-viewable display
– 2-6000 nit (depending on lighting conditions and settings)6
– AR, AG and circular polarizer
– Ambient light sensor
■Intel®SCH (GMA 500 video controller) max. 256MB UMA VRAM7
■External video support up to 1280 x 768 at 16 million colors
AUDIO ■Intel®high-definition audio compliant
■Integrated speaker
■Keyboard volume and mute controls
KEYBOARD & INpUT ■Touchscreen
■Integrated stylus holder (x 2)
■Backlit 61-key with Windows®key and keyboard lock
■Optional backlit 29-key numeric keypad with large buttons including
navigation, Windows®and keyboard lock buttons
■Zoom (in/out) and scroll (up/down) buttons
■4 user-defined programmable buttons
ExpANSION SLOTS ■SD card (SDHC)
■Optional magnetic stripe reader (with mini-dock)
■Optional SmartCard reader (with mini-dock)
INTERfACE ■Docking connector Dedicated 19-pin
■Headphones/speaker Mini-jack stereo
■Microphone/line in Mini-jack stereo
■USB 2.0 (x 1) 4-pin
■Optional Ethernet (RJ-45) With mini-dock
■Optional serial With mini-dock
wIRELESS ■Optional integrated Gobi™2000 3G mobile broadband
■Intel®Wireless Wi-Fi Link 5100 802.11a/b/g/draft-n
■Bluetooth®v2.1 + EDR (Class 1)
■Security
– Authentication: LEAP, WPA, 802.1x, EAP-TLS, EAP-FAST, PEAP
– Encryption: CKIP, TKIP, 128-bit and 64-bit WEP, Hardware AES
■Slide on/off switch
pOwER SUppLY ■Twin hot-swappable Li-Ion battery packs (7.2V, 2900mAh each)
■Battery operation: 9 hours8
■Battery charging time: 5.5 hours off, 5.5 hours on8
■AC Adapter: AC 100V-240V 50/60Hz
pOwER MANAgEMENT ■Suspend/Resume Function, Hibernation, Standby, ACPI BIOS
SECURITY fEATURES ■Password Security: Supervisor, User, Hard Disk Lock
■Kensington cable lock slots (x 2)
■Trusted platform module (TPM) security chip v.1.2
■Computrace®theft protection agent in BIOS9
■Optional fingerprint reader
■Optional SmartCard reader (with mini-dock)
INTEgRATED fEATURES ■Package 1: Base model
■Package 2: Camera
■Package 3: Gobi2000, barcode reader
■Package 4: Gobi2000, camera
■Package 5: Gobi2000, camera, GPS
■Package 6: Gobi2000, camera, GPS, dual pass, barcode reader
Camera = 2MP camera with auto focus and dual LED light
Barcode Reader = Choice of 1D laser or 2D imager (1D and 2D capable)
GPS = GPS receiver (DGPS enabled)
Dual Pass = Dual pass-through connectors (for external antenna)
wARRANTY ■3-year limited warranty, parts and labor
DIMENSIONS & wEIghT ■5.9"(L) x 7.2"(W) x 2.2"(H)
■2.3 lbs. (with strap and both batteries)
1.800.662.3537 /panasonic.com/toughbook /U1-Ultra
Financing options now available from Panasonic Finance Solutions;
please call number above for more details.
Panasonic is constantly enhancing product specifications and accessories. Specifications subject to change without notice.
Trademarks are property of their respective owners. ©2012 Panasonic Corporation of North America. All rights reserved.
INTEgRATED OpTIONS10
■Numeric keypad with large buttons including navigation
■Fingerprint reader
ACCESSORIES10
■AC Adapter (3-prong) CF-AA1633AM
■Lithium Ion Battery Pack CF-VZSU53AW
■4-Bay Battery Charger CF-VCBU11U
■LIND Car Adapter 120W CF-LNDDC120
■LIND Car Adapter 120W
Mounting Bracket CF-LNDBRK120
■LIND Car/AC Adapter 90W
(with USB port) CF-LNDACDC90
■LIND Car Adapter 90W MIL-STD CF-LNDMLDC90
■LIND Car Adapter 80W CF-LNDDC80
■LIND Shutdown Timer CF-LNDLPT
■InfoCase U1 Holster TBCU1HSTR-P
■InfoCase U1 Harness TBCU1HRNS-P
■InfoCase U1 Harness Clear Cover TBCU1CLRCVR-P
■InfoCase U1 Strap TBCU1MSTP-P
■InfoCase U1/H1 Battery Pouch TBCU1BPCH-P
■LaCie External USB Multi Drive TT-DVDRW8XL91U
■Desktop Cradle/Spare 2-Bay
Battery Charger CF-VEBU11BU
■Mag Stripe Reader Mini-dock CF-VCRU11U
■Serial/LAN/SmartCard Mini-dock CF-VEBU12U
■Serial/LAN/USB Micro-dock CF-MPU11UTT
■Personal Identification Mini-dock (PIMD)11 Project Driven
■Havis Vehicle Dock
– no pass-through DS-PAN-301
– dual pass-through DS-PAN-301-2
– no electronics DS-PAN-302
■Touchscreen Replacement Stylus CF-VNP003U
■Tether CF-VNT002U
■5.6" LCD Protector Film CF-VPF12U
SSU1Ultra_01/12
Please consult your reseller or Panasonic representative before purchasing.
1A full set of Windows XP drivers are available at panasonic.com/toughbook/support.
2Tested by a national independent third party lab following MIL-STD-810G Method
516.6 Procedure IV for transit drop test and IEC 60529 Sections 13.4, 13.6.2,
14.2.5 and 14.3 for IP65.
3SSD should only be removed by a technician with the proper equipment.
41GB = 1,000,000,000 bytes.
5Total usable memory will be less depending upon actual system configuration.
6
380 nit without ambient light assistance. Up to 6000 nit in clear sunny
conditions under direct sunlight.
7
Max with standard RAM. The size of the VRAM cannot be set by the user and
varies by operating system as well as size of RAM.
8
Battery performance features such as charge time and life span vary based on
the conditions under which the computer and battery are used. Battery operation
and recharge times will vary based on many factors, including brightness, applications,
features, power management, battery conditioning and other customer preferences.
Battery test results from MobileMark 2005.
9Requires software and activation to enable theft protection.
10Accessories and Integrated Options may vary depending on your configuration.
11
PIMD includes an OCR (3 track MRZ) + RFID reader (ISO 15693, 14443
Type A/B) + fingerprint reader (FIPS 201).
*Shown with optional numeric keypad.
Screen image is for demonstration purposes only.
