Panasonic Toughbook FZ-T1 Series User manual

Operating I nstructions
Smart Handh eld
EB-3901
Model No. FZ-T1 series
Operating Instructions
Read Me First
Tablet Computer
Safety Precautions ..................................................................2
Regulatory Information ......................................................... 10
Trademark and License Information....................................... 16
Panasonic Warranty............................................................... 19
• Refer to the Reference Manual by downloading from the URL below
URL:- https://pc-dl.panasonic.co.jp/itn/manual/menu_en.html
Thank you for purchasing a Panasonic product.
Before operating this product, please read these instructions and
precautions, and save them for future use.

2
Safety Precautions
To reduce the risk of injury, loss of life, electric shock, fire,
malfunction, and damage to equipment or property, always
observe the following safety precautions.
Explanation of symbol word panels
The following symbol word panels are used to classify and
describe the level of hazard, injury, and property damage caused
when the denotation is disregarded and improper use is
performed.
The following symbols are used to classify and describe the type
of instructions to be observed.
Explanation of symbol word panels
Denotes potential hazards that will result
in serious injury or death.
Denotes potential hazards that could
result in serious injury or death.
Denotes potential hazards that could
result in minor injury.
This symbol is used to alert users to specific operating
procedures that must not be performed.
This symbol is used to alert users to specific operating
procedures that must be followed in order to operate the
product safely.
DANGER
WARNING
CAUTION

3Safety Precautions
Battery
The battery is for use solely with this product. Do
not use it with any other products.
Electrolyte leakage, overheating, smoke, rupture, or fire
may result.
Charge the battery using the specified method.
Failure to do so may result in electrolyte leakage,
overheating, smoke, rupture, or a fire.
Do not throw the battery into a fire or expose it to
excessive heat.
Electrolyte leakage, overheating, smoke, rupture, or fire
may result.
Do not disassemble, modify, insert sharp foreign
objects into the battery, or subject it to impact.
Electrolyte leakage, overheating, smoke, rupture, or fire
may result.
Do not short the positive (+) and negative (–)
contacts. Do not carry the battery around or store it
together with necklaces, hairpins, etc.
Electrolyte leakage, overheating, smoke, rupture, or fire
may result.
Keep the battery away from extreme heat, such as
fire and direct sunlight.
Failure to do so may result in electrolyte leakage,
overheating, smoke, rupture, or a fire.
Do not expose the battery to water or other liquids.
Electrolyte leakage, overheating, smoke, rupture, or fire
may result.
DANGER

4
Do not throw the battery or subject it to strong
impact such as dropping or applying high pressure.
Electrolyte leakage, overheating, smoke, rupture, or fire
may result.
• Stop using the product if the battery is subjected to
strong impact or if the battery is noticeably damaged
or deformed.
If the battery deteriorates, replace it with a new one.
Failure to do so may result in electrolyte leakage,
overheating, smoke, rupture, or a fire.
Do not directly touch electrolyte that has leaked
from the battery.
Electrolyte may enter the eyes and cause blindness, or
may come into contact with skin or clothing and cause
rashes.
• Flush with clean water without rubbing and seek
medical advice.
Do not place the battery in microwave ovens or
pressurized containers.
Sudden application of heat or pressure may damage the
battery, resulting in electrolyte leakage, overheating,
smoke, rupture, or a fire.
If the battery smells or leaks electrolyte, keep the
battery away from fire.
Failure to do so may result in electrolyte leakage,
overheating, smoke, rupture, or a fire.
WARNING

5Safety Precautions
This product and charger
When using the product for extended periods, do
not expose your skin to this product for a prolonged
period.
Generated heat can cause low-temperature burns.
Do not disassemble, repair, or modify the product.
Doing so may cause a short circuit or overheating, which
may result in a fire or electric shock.
Do not insert foreign objects into the product.
Doing so may cause a short circuit or overheating, which
may result in a fire or electric shock.
Do not allow conductive materials such as metal
objects to touch the expansion bus connector.
This may cause a short circuit and overheating, which
may result in battery electrolyte leakage, overheating,
smoke, rupture, or a fire.
Do not place the product in microwave ovens or
electromagnetic cookers.
Doing so may cause overheating, smoke, or rupture,
which may result in a fire.
Do not touch the product or charger during lightning
storms if the product is connected to a charger.
There is a remote chance of electric shock.
WARNING

6
Do not turn the volume up too loud when using
headphones, etc.
Listening at high volumes for extended periods may
result in loss of hearing. Also, the surrounding sounds
will become difficult to hear when the volume is too high,
which can cause accidents.
• Turn down the volume before connecting headphones,
etc. to prevent sudden loud sounds.
Keep small parts, including SD cards and SIM cards,
out of the reach of infants and small children.
Accidental swallowing of small objects can have
physically harmful effects. In such a case, seek medical
advice immediately.
Do not operate the product while walking, driving,
riding a bicycle, etc.
Being distracted while engaging in these kinds of
activities can cause accidents or falls.
Use only specified batteries.
Use of unspecified batteries may result in electrolyte
leakage, overheating, smoke, rupture, or a fire.
Immediately stop using the product if any of the
following occurs.
–Product is damaged
–Water or foreign objects enter the product
–Product emits smoke
–Product emits unusual smell or sound
–Product becomes unusually hot
Continuing use may result in a fire or electric shock.
Immediately turn the product off, disconnect it from the
power supply, remove the battery, and then contact your
technical support representative.

7Safety Precautions
Close the interface cover when using the product
near water or other liquids, and in areas with a high
concentration of moisture, steam, dust, oily vapors,
etc.
Foreign material that enters the product may cause fire
or electric shock. If foreign material enters the product,
turn the product off, disconnect it from the power supply,
and then remove the battery. Contact your technical
support representative for support or repair.
Stop using the product immediately and consult
your doctor if you feel any discomfort when staring
at flashing lights on the screen.
A very small percentage of individuals may experience
seizures or blackouts when exposed to certain light
patterns or flashing lights for extended periods.
Do not use the product near electronic devices that
are used for high-precision control or weak signals.
RF signals generated by the product may interfere with
such electronic devices and result in an accident due to
malfunction.
• Examples of electronic devices to be aware of:
Hearing aids, implantable cardiac pacemakers and
implantable cardioverter defibrillators, other medical
devices, fire alarms, automatic doors, and other
automatic control devices. For those who use
implantable cardiac pacemakers, implantable
cardioverter defibrillators, or other medical devices,
confirm the effects of RF signals with the relevant
medical device manufacturer or distributor.

8
Do not leave the product in areas with a high
concentration of moisture, steam, dust, oily vapors,
etc. for extended periods.
Foreign material that enters the product may cause a fire
or electric shock.
Do not move the product while the charger is
connected.
This may result in a fire or electric shock.
Make sure not to charge the product when it is wet.
This may result in a fire or electric shock.
Do not leave the product in extremely high
temperature environments for an extended period.
Leaving the product where it will be exposed to
extremely high temperatures, such as near fire or in
direct sunlight, may deform the product or cause
damage or malfunction to its internal components. Using
the product in these conditions may cause short circuit,
insulation defects, etc., which may in turn cause a fire or
electric shock.
Do not expose the skin to the product when using
the product in hot or cold environments.
Burns, low-temperature burns, or frostbite may result. If
direct contact with the skin is necessary, perform the
operation as quickly as possible.
Do not place the product on an unstable surface.
The product may drop, resulting in an injury.
Do not stack the product.
If balance is lost, the product may fall over or drop,
resulting in an injury.
CAUTION

9Safety Precautions
Do not look directly at the light emitter of the
barcode reader (for models with a barcode reader)
or photo light, or point it at another person's eyes.
This may damage the eyes or cause temporary loss of
eyesight which could result in an accident.
Do not expose the camera lens to direct sunlight for
extended periods.
This may result in a fire, burns, or injury due to the
converging effect of the lens.
Use the supplied or specified items.
Use of unsupplied and unspecified items may result in a
fire or electric shock.
For safety purposes, pull the plug when cleaning the
product or if you will not use it for extended periods.
Failure to do so may result in a fire or electric shock.
If the display is damaged, be careful of broken glass,
internal components, or leaked substances that may
become exposed.
Failure to do so can cause injury.
Also, if substances from internal components come into
contact with your skin or clothes, they can cause injury to
your eyes and skin. Immediately wash the affected area
with clean water without rubbing, and seek medical
advice.
Take a 10–15 minute break every hour when using
the product.
Using the product continuously for extended periods
may cause strain injuries and may have detrimental
health effects on your eyes, hands, or other parts of your
body.

10
Regulatory Information
This pro duct and your heal th
This product, like other radio devices, emits radio frequency
electromagnetic energy. Because this product operates within the
guidelines found in radio frequency safety standards and
recommendations, we believe this product is safe for use by
consumers. These standards and recommendations reflect the
consensus of the scientific community and result from
deliberations of panels and committees of scientists who
continually review and interpret the extensive research literature.
In some situations or environments, the use of this product may
be restricted by the proprietor of the building or responsible
representatives of the organization. These situations may for
example include:
• Using this product on board of airplanes, or
• In any other environment where the risk of interference to other
devices or services is perceived or identified as harmful.
If you are uncertain of the policy that applies on the use of
wireless devices in a specific organization or environment (e.g.
airports), you are encouraged to ask for authorization to use this
product prior to turning on the product.
Information to the us er
We are not responsible for any radio or television interference
caused by unauthorized modification of this product. The
correction of interference caused by such unauthorized
modification will be the responsibility of the user. We and our
authorized resellers or distributors are not liable for damage or
violation of government regulations that may arise from failing to
comply with these guidelines.
This product and your health
Information to the user

11Regulatory Information
Additional safe ty precautions
Posted facilities
• Turn off the product when in hospitals, health care facilities, or
any facility where posted notices require you to do so.
Hospitals and health care facilities may be using equipment
that could be sensitive to external RF energy.
Pacemakers
• Medical device manufacturers recommend a minimum
separation of 15 cm between a wireless device and an
implanted medical device, such as a pacemaker or implanted
cardioverter defibrillator, to avoid potential interference with the
medical device.
• Persons with pacemakers:
– Should ALWAYS keep this product more than 15 cm from
their pacemaker when this product is turned ON;
– Should use the ear opposite the pacemaker to minimize the
potential for interference;
– Should not carry this product in a breast pocket;
– Should turn off the product immediately if there is any reason
to suspect that interference is taking place.
Hearing aids
• Some digital wireless products may interfere with some hearing
aids. In the event of such interference, consult the
manufacturer of your hearing aid to discuss alternatives.
Other medical devices
• If you use any other personal medical device, consult the
manufacturer of your device to determine if it is adequately
shielded from external RF energy. Your physician may be able
to assist you in obtaining this information.
Additional safety precautions

12
Aircraft
• Turn off the product after boarding an aircraft, when instructed
by flight staff. Obey instructions from flight staff regarding the
use of the product in flight. Using this product in an aircraft may
be hazardous to the aircraft’s operation and disrupt wireless
communication, and may also be illegal.
Potentially explosive atmosphere
• Turn off the product in areas where a potentially explosive
atmosphere exists and obey all signs and instructions. Sparks
in such areas could cause an explosion or fire resulting in injury
or even death.
• Areas with potentially explosive atmosphere may include
fueling areas, chemical plants, below deck on boats, fuel or
chemical transfer or storage facilities, vehicles using petroleum
or natural gas, or areas where the atmosphere contains
particles such as grain, dust, or metallic powders, and any
other area where you would normally be advised to turn off
your vehicle engine.
Electronic devices
• This product receives and transmits radio frequency signals
while switched on. Most electronic equipment is shielded from
RF signals. However, certain electronic equipment may not be
shielded against the RF signals from this product. Therefore,
the use must be restricted in certain situations to avoid
interference.
Driving
• Give full attention to driving. Driving safely is your first
responsibility.
• Pull off the road and park before placing or answering a call. It
is unsafe to operate the product while driving.
• Check the laws and regulations in the areas where you drive,
and always obey them.

13Regulatory Information
• Only qualified personnel should install the product in a vehicle.
Check regularly that the product is securely mounted in your
vehicle and operating properly.
• Do not place or install the product in the area over the air bag
or in the air bag deployment area. If the air bag inflates, serious
injury and/or damage could result.
• RF signals may affect improperly installed or inadequately
shielded electronic systems in motor vehicles. Consult the
manufacturer (or its representative) of the vehicle and any
equipment that has been added to the vehicle regarding the
use of mobile products.
• Use hands-free operation, if available and legally permitted.
Emergency communications
• Never rely solely on a mobile product for essential or
emergency communications. Network connections can be
affected by remaining battery level, radio signals, service
networks, and other conditions, and as a result, emergency
communications cannot be guaranteed in all conditions.
Antenna
• Do not replace the antenna. Unauthorized antennas,
modifications, or attachments could damage the product and
may violate regulations.
• Do not touch or cover the antenna area while the product is on.
Call quality, power levels, and the overall performance of the
product may be affected.
Volume
• Do not turn the volume up too loud when using headphones
and earphones.
• Exposure to excessive sound pressure levels for extended
periods may cause hearing damage.
• Being unable to hear sounds in your environment may lead to
accidents.

14
Intended use
• This product is not intended for use as, or as part of, nuclear
equipment/systems, air traffic control equipment/systems,
aircraft cockpit equipment/systems*1, medical devices or
accessories*2, life-support systems or other equipment/
devices/systems that are involved with ensuring human life or
safety. Panasonic will not be responsible for any liability
resulting from the use of this product arising out of the
foregoing uses.
*1 Aircraft cockpit equipment/systems include Class 2
Electrical Flight Bag (EFB) Systems and Class 1 EFB
Systems when used during critical phases of flight (e.g.,
during take-off and landing) and/or mounted on to the
aircraft. Class 1 EFB Systems and 2 EFB Systems are
defined by FAA: AC (Advisory Circular) 120-76A or JAA:
JAA TGL (Temporary Guidance Leaflets) No.36.
*2 As defined by the European Medical Device Directive
(MDD) 93/42/EEC.
• Panasonic cannot guarantee any specifications, technologies,
reliability, safety (e.g., Flammability/Smoke/Toxicity/Radio
Frequency Emission, etc.) requirements related to aviation
standards and medical equipment standards that differ from the
specifications of our COTS (Commercial-Off-The-Shelf)
products.
• This product is not intended for use in medical equipment
including life-support systems, air traffic control systems, or
other equipment, devices or systems that are involved with
ensuring human life or safety. Panasonic cannot be held
responsible in any way for any damages or loss resulting from
the use of this unit in these types of equipment, devices or
systems, etc. This product has been designed so as to
minimize shock to the LCD, the leakage of liquid (e.g., water)
on to the buttons, etc., but no warranty is provided against such
Intended use

15Regulatory Information
trouble. Therefore, as a precision instrument, be extremely
careful in the handling of the product.
General information
• For body-worn operation, this product has been tested when
used with a Panasonic accessory designated for this product
and when used with an accessory that contains no metal and
that positions front or back of this product a minimum of 5 mm
from the body.
Caution
Risk of explosion if battery is replaced by an incorrect type.
Dispose of used batteries according to the instructions.
Explanation of graphical symbols on nameplate
: Direct current
General information

16
Trademark and License Information
Trademarks
• The Bluetooth
®
word mark and logos are registered trademarks
owned by Bluetooth SIG, Inc. and any use of such marks by
Panasonic Corporation is under license.
• microSDXC Logo is a trademark of SD-3C, LLC.
• The N-Mark is a trademark or registered trademark of NFC Forum,
Inc. in the United States and in other countries.
• Android is a trademark of Google, Inc.
•Wi-Fi
®
, the Wi-Fi logo, the Wi-Fi CERTIFIED logo and Wi-Fi
CERTIFIED are trademarks or registered trademarks of Wi-Fi
Alliance
®
.
• All other trademarks identified herein are the property of their
respective owners.
License information
• This product is licensed under the MPEG-4 Visual patent portfolio
license for the personal and non-commercial use of a consumer for
(i) encoding video in compliance with the MPEG-4 Visual Standard
(“MPEG-4 Video”) and/or
(ii) decoding MPEG-4 Video that was encoded by a consumer
engaged in a personal and non-commercial activity and/or was
obtained from a video provider licensed by MPEG LA to provide
MPEG-4 Video.
No license is granted or shall be implied for any other use.
Additional information including that relating to promotional,
internal and commercial uses and licensing may be obtained from
MPEG LA, L.L.C. See http://www.mpegla.com.

17Trademark and License Information
•This product is licensed under the AVC patent portfolio license
for the personal use of a consumer or other uses in which it
does not receive remuneration to
(i) encode video in compliance with the AVC Standard (“AVC
Video”) and/or
(ii) decode AVC Video that was encoded by a consumer
engaged in a personal activity and/or was obtained from a
video provider licensed to provide AVC Video.
No license is granted or shall be implied for any other use.
Additional information may be obtained from MPEG LA, L.L.C.
See http://www.mpegla.com.
• This product contains software licensed in compliance with
GNU General Public License Version 2.0 (GPL v2.0), GNU
Lesser General Public License (LGPL) or any other license.
The program is free software; you can copy it, redistribute it,
and modify it under the terms of the GPL v2.0, LGPL or any
other license.
At least three (3) years from delivery of products, Panasonic
Mobile Communications Co., Ltd. will give to any third party
who contacts us at the contact information provided below, for
a charge no more than our cost of physically performing source
code distribution, a complete machine-readable copy of the
corresponding source code covered under GPL v2.0 and LGPL
or any other license.
Contact Information
oss-cd-reque[email protected]ic.com
Source code is also freely available to the public via the web
site listed below.
https://panasonic.net/cns/oss/index.html
Please note that we cannot respond to any inquiries regarding
the source code.
For more details on the relevant software (including license
information of GPL v2.0 and LGPL), refer to the information
displayed on the following screen: swipe up the home screen,

18
and then in the app list, tap [Settings] [System] [About
tablet] [Legal information].
• This product includes software developed by the OpenSSL
Project for use in the OpenSSL Toolkit.
(http://www.openssl.org/source/license.html)
• This product includes the Independent JPEG Group's software.
This software is based in part on the work of the Independent
JPEG Group.
• Portions of this software are copyright 2017 The FreeType
Project (www.freetype.org). All rights reserved. This software is
based in part on the work of FreeType Project.
• This product includes the following software; ICU 1.8.1 and
later Copyright (c) 1995-2011 International Business Machines
Corporation and others.
• This product includes other free software or open source
software.
• For more details on the relevant software (including license
information), refer to the information displayed on the following
screen: swipe up the home screen, and then in the app list, tap
[Settings] [System] [About tablet] [Legal
information].
• TouchSense®Technology licensed from Immersion
Corporation. TouchSense and other Immersion software
contained herein are protected under one or more of the U.S.
Patents found at the following address 
www.immersion.com/patent-marking.html and other patents
pending.

19Panasonic Warranty
Panasonic Warranty
Personal / Notebook Computers - 36 Month Warranty from
Date of Purchase
1. Subject to the conditions of this warranty Panasonic or its
Authorised Service Centre will perform necessary service on
the product without charge for parts or labour, if in the opinion
of Panasonic, the product is found to be faulty within the
warranty period.
2. This warranty only applies to Panasonic products purchased
in Australia and sold by Panasonic Australia or its Authorised
Distributors or Dealers and only where the products are used
and serviced within Australia or it's territories. Warranty cover
only applies to service carried out by a Panasonic Authorised
Service Centre and only if valid proof of purchase is presented
when warranty service is requested.
3. This warranty only applies if the product has been installed
and used in accordance with the manufacturer’s
recommendations (as noted in the operating instructions)
under normal use and reasonable care (in the opinion of
Panasonic). The warranty covers normal use only.
4. Toughbook/Toughpad accessories as packed in the original
box such as (stylus, pens, AC charger, combo drive, etc) are
covered in warranty for 12 months from the date of purchase.
5. Batteries as packed in the original box are covered in warranty
for 6 months from the date of purchase. A battery is
considered good if it maintains 50 % of its charge capacity
during the warranty period.
6. Additional Accessories sold separate to the main Toughbook/
Toughpad box are covered in warranty for 12 months.
7. Consumables sold separate to the main Toughbook/
Toughpad box are covered in warranty for 6 months.
8. This warranty does not cover any of the following:

20
•No Fault Found (NFF); any costs incurred where it is found
that the Toughbook/Toughpad is functioning normally (“No
Fault Found”). Panasonic reserves the right to charge the
logistics cost and inspection fee for every NFF case directly to
the customer.
•Negligence, abuse, misuse; Abuse or misuse in respect of
the Toughbook/Toughpad including but not limited to: damage,
malfunction or failure resulting from use of incorrect voltages,
incorrect installation, accident, misuse, neglect, buildup of dirt
or dust, abuse, maladjustment of customer controls, mains
supply problems, thunderstorm activity, infestation by insects or
vermin, tampering or repair by unauthorised persons (including
unauthorised alterations), exposure to abnormally corrosive
conditions or any foreign object or matter having entered the
product.
•Tolerance on LCD defect; The Warranty excludes 3 or less
faulty pixels on screen.
•Wear and Tear; The cost of remedying or making good solely
due to:
– Wear and Tear, gradual deterioration or oxidisation,
gradually developing defects, cracks, flaws or fractures;
– Scratching or chipping of any surfaces.
•Data:
– Loss of or damage to Internal Data. It is the customer’s
responsibility to backup all data from the hard disk drive
before sending equipment for repair. If a problem is related to
the HDD or SSD, or the HDD or SSD has to be replaced,
Panasonic will only reload the factory pre-installed software
for the product onto the replacement drive.
– Loss of or damage to External Data carrying material and the
value to you of data stored on your Toughbook/Toughpad
device. External data carrying materials and any computer
program or data information recorded thereon unless stated
above.
