Panasonic KX-TG2336 User manual

2.4 GHz Digital Cordless Phone
Operating Instructions
Model No. KX-TG2336
Pulse-or-tone dialing capability
The unit is Caller ID compatible. To display the caller’s name and phone number,
you must subscribe to Caller ID service.
PLEASE READ BEFORE USE AND SAVE.
Panasonic World Wide Web address: http://www.panasonic.com
for customers in the USA or Puerto Rico
Charge the battery for 6 hours before initial use.
PQQX13986YA.book 1 ページ ２００４年１月２２日 木曜日 午後５時４０分

2
Thank you for purchasing your new Panasonic cordless
telephone.
Please read the IMPORTANT SAFETY INSTRUCTIONS on
page 63 before use. Read and understand all instructions.
Trademarks:
openLCR, openLCR.com, and the openLCR logo are the trademarks of
openLCR.com, Inc.
Accessories (included)
For extra orders, call 1-800-332-5368.
For hearing or speech impaired TTY users, call 1-866-605-1277.
Caller ID, Call Waiting and Voice Mail Service, where available, are telephone
company services. After subscribing to Caller ID this phone will display a caller’s
name and phone number. Call Waiting Caller ID, which displays a second
caller’s name and phone number while the user is on another call, requires a
subscription to both Caller ID and Call Waiting with Caller ID Services (CWID).
After subscribing to Voice Mail Service, this unit will give you visual indication to
let you know when there are messages in the mailbox.
AAC Adaptor (p. 8)
Order No. PQLV1Z (PQLV1)
one
ATelephone Line Cord (p. 8)
Order No. PQJA10075Z
one
ABattery (p. 9)
Order No. HHR-P104
one
AHandset Cover (p. 9)
Order No. PQKK10141Z1
one
ABelt Clip (p. 50)
Order No. PQKE10375Z3
one
AShoulder Rest Attachment (p. 50)
Order No. PQKE10364Z1
one
Attach your purchase receipt here.
PQQX13986YA.book 2 ページ ２００４年１月２２日 木曜日 午後５時４０分

3
For assistance, please call: 1-800-211-PANA(7262)
For Best Performance
Battery Charge
The handset is powered by a rechargeable Nickel-
Metal Hydride (Ni-MH) battery. Charge the battery
for 6hoursbefore initial use (p. 9).
Base Unit Location/Noise
Calls are transmitted between the base unit and handset using wireless radio
waves. For maximum distance and noise-free operation, the recommended
base unit location is:
Note:
• If you use the handset near a microwave oven which is being used, noise may be
heard from the receiver or the speaker. Move away from the microwave oven and
closer to the base unit.
• If you use the handset near another cordless phone’s base unit, noise may be
heard. Move away from the other cordless phone’s base unit and closer to your
base unit.
Raise the antenna.
Away from electrical appliances such
as a TV, personal computer or another
cordless phone.
In a HIGH and CENTRAL location
with no obstructions such as walls.
PQQX13986YA.book 3 ページ ２００４年１月２２日 木曜日 午後５時４０分

4
Contents
Location of Controls . . . . . . . 6
Installation . . . . . . . . . . . . . . . 8
Connections . . . . . . . . . . . . . 8
Installing the Battery in the
Handset . . . . . . . . . . . . . . . 9
Battery Charge . . . . . . . . . . . 9
Programmable Settings . . . . 11
Programming Guidelines . . . 11
Function Menu Table . . . . . 12
Display Language . . . . . . . 13
Dialing Mode . . . . . . . . . . . 13
Line Mode . . . . . . . . . . . . . 14
Auto Talk . . . . . . . . . . . . . . 14
Ringer Volume . . . . . . . . . . 15
Ringer Tone . . . . . . . . . . . . 16
LCD Contrast . . . . . . . . . . . 18
Message Alert . . . . . . . . . . 18
Making Calls . . . . . . . . . . . . . 19
Using the Handset . . . . . . . 19
Using the Base Unit . . . . . . 22
Answering Calls . . . . . . . . . . 23
Caller ID Service . . . . . . . . . . 24
Talking Caller ID . . . . . . . . 25
Using the Caller List . . . . . . 26
Viewing the Caller List . . . . 27
Calling Back from the Caller
List . . . . . . . . . . . . . . . . . . 27
Editing the Caller’s Phone
Number . . . . . . . . . . . . . . 28
Caller ID Number Auto
Edit . . . . . . . . . . . . . . . . . 29
Storing Caller Information
in the Phone Book . . . . . . 30
Erasing Caller Information . . 31
Phone Book . . . . . . . . . . . . . . 32
Storing Names and
Numbers . . . . . . . . . . . . . 32
Dialing from the Phone
Book . . . . . . . . . . . . . . . . . 34
Chain Dial . . . . . . . . . . . . . . 35
Editing an Item in the Phone
Book . . . . . . . . . . . . . . . . . 36
Erasing an Item in the Phone
Book . . . . . . . . . . . . . . . . . 36
Intercom . . . . . . . . . . . . . . . . 37
Making Intercom Calls . . . . 37
Answering Intercom Calls . . 38
Transferring a Call . . . . . . . . 39
Conference Calls . . . . . . . . . 41
Call Share . . . . . . . . . . . . . 41
Voice Mail Service . . . . . . . . 42
Storing a Voice Mail Access
Number . . . . . . . . . . . . . . 42
Setting Voice Mail (VM) Tone
Detection . . . . . . . . . . . . . 43
Listening to Voice Mail
Messages . . . . . . . . . . . . . 44
Special Features . . . . . . . . . . 46
Temporary Tone Dialing
(For Rotary or Pulse Service
Users) . . . . . . . . . . . . . . . 46
Muting Your Conversation . . 46
For Call Waiting Service
Users . . . . . . . . . . . . . . . . 46
Using the PAUSE Key
(For PBX Line/Long
Distance Calls) . . . . . . . . . 47
FLASH Button . . . . . . . . . . 47
Incoming Call Tone . . . . . . 48
Key Tone . . . . . . . . . . . . . . 49
Re-registering the
Handset . . . . . . . . . . . . . . 49
Preparation
Basic Operation
Advanced Operation
PQQX13986YA.book 4 ページ ２００４年１月２２日 木曜日 午後５時４０分

For assistance, please call: 1-800-211-PANA(7262) 5
Contents
Preparation Useful InformationAdvanced OperationBasic Operation
Belt Clip . . . . . . . . . . . . . . . . . 50
Shoulder Rest Attachment . . 50
Wall Mounting . . . . . . . . . . . . 51
Optional Headset . . . . . . . . . 52
Direct Commands . . . . . . . . . 53
If the Following Appear
on Your Display... . . . . . . . . 55
Troubleshooting . . . . . . . . . . 56
openLCR Service
for Caller IQ . . . . . . . . . . . . . 59
Turning Caller IQ on or off . . 59
Downloading Data . . . . . . . 60
Important Safety
Instructions . . . . . . . . . . . . . 63
FCC and Other Information . . 64
Index . . . . . . . . . . . . . . . . . . . 67
Warranty . . . . . . . . . . . . . . . . 69
Specifications . . . . . . . . . . . . 71
Useful Information
Important:
Throughout these Operating Instructions, and
are used to indicate with which unit an operation can be performed.
: Perform with the handset.
: Perform with the base unit.
: Perform with the handset and base unit
separately.
: Perform with the handset and base unit
together.
Handset Base Unit
Handset
Base Unit
Handset Base Unit
Handset & Base Unit
PQQX13986YA.book 5 ページ ２００４年１月２２日 木曜日 午後５時４０分

6
Location of Controls
Base unit
CHARGE Indicator (p. 9)
[REDIAL] Button (p. 22)
VOLUME Button [<], [>](p. 16, 22)
MIC (Microphone) (p. 22)
[SP-PHONE] (Speakerphone)
Button and Indicator (p. 22)
[HOLD/CONF]
(Conference) Button
(p. 22, 41)
[MUTE] Button (p. 46)
[FLASH/CALL WAIT]
Button (p. 46, 47)
[LOCATOR/INTERCOM]
Button (p. 37)
Hook (p. 51)
Charge Contacts
(p. 10)
[*](TONE) Button
(p. 46)
Antenna
(p. 3)
Speaker
IN USE Indicator (p. 23)
[VM] (Voice Mail) Button (p. 45)
VM (Voice Mail) Indicator (p. 44)
PQQX13986YA.book 6 ページ ２００４年１月２２日 木曜日 午後５時４０分

Preparation
For assistance, please call: 1-800-211-PANA(7262) 7
Location of Controls
Handset
Handset soft keys
• When a function name does not appear above a soft key, the soft key has no
function.
Handset navigator key
Two soft keys are used to select functions displayed
directly above each key. Functions displayed above the
keys will change depending on the state of use.
On this sample display, “ (VE)” and “Mute ” are
displayed above soft keys.
Scrolls up [
B ]and down [ d ]the function menu, the
Caller List and the phone book.
Increases [
B ]or decreases [ d ]the handset ringer and
receiver/speaker volumes.
Throughout these Operating Instructions:
• The soft keys are indicated by what is displayed above the keys.
Ex. “Press Mute.” indicates “Press the soft key below Mute ”.
• The navigator key is indicated by the arrows [
d ]or [ B ].
Antenna
Display
Receiver
Soft Keys (see below)
[OFF] Button
(p. 11, 19)
[MENU] Button (p. 11)
Navigator Key
([
d ],[ B ]) (see below)
Back side
Speaker
Headset Jack (p. 52)
[C](TALK) Button (p. 19)
[s](Speakerphone) Button (p. 19)
[*](TONE) Button (p. 46)
[FLASH/CALL WAIT]
Button (p. 46, 47)
[REDIAL] Button (p. 20
)
Charge Contacts (p. 10)
Microphone (p. 19)
[HOLD/INTERCOM] Button
(p. 20, 37)
Ringer/Message Alert
Indicator (p. 18, 23)
J5
Talk
00-00-32
(VE) Mute
KL KL
Pressing the right soft key selects mute “Mute ”.
L
Pressing the left soft key selects Voice Enhancer “ (VE) ”.
K
L
PQQX13986YA.book 7 ページ ２００４年１月２２日 木曜日 午後５時４０分

8
Installation
Connections
• USE ONLY WITH Panasonic AC ADAPTOR PQLV1 (Order No. PQLV1Z).
• The AC adaptor must remain connected at all times. (It is normal for the adaptor to
feel warm during use.)
• If your unit is connected to a PBX which does not support Caller ID and voice mail
services, you cannot access those services.
• The unit will not work during a power failure. We recommend connecting a
standard telephone to the same telephone line or to the same telephone jack
using the Panasonic KX-J66 T-adaptor.
Fasten the cords.
Single-Line Telephone Jack (RJ11C)
Telephone Line Cord
Power Outlet
(AC 120 V, 60 Hz)
AC Adaptor
Hooks
PQQX13986YA.book 8 ページ ２００４年１月２２日 木曜日 午後５時４０分

Preparation
For assistance, please call: 1-800-211-PANA(7262) 9
Installation
Installing the Battery in the Handset
Insert the battery (1), and press it down until it snaps into the compartment (2).
Close the cover.
To replace the battery:
Press the notch on the cover firmly and slide it as indicated
by the arrow. Replace the old battery with a new one
(p. 10). Close the cover and charge the battery for 6 hours.
Battery Charge
Place the handset on the base unit.
Charge for 6 hours before initial use.
• The unit beeps once, the CHARGE indicator
lights, and “Charging” is displayed.
• When the battery is fully charged, “Charge
completed” is displayed.
Battery strength
You can confirm battery strength
on the handset display.
Battery strength is indicated by
the icons shown in the chart to
the right.
Display prompt Battery strength
5Fully charged
6Medium
7Low
074(flashing) Needs to be recharged.
8Discharged
1
2
OR
CHARGE
Indicator
PQQX13986YA.book 9 ページ ２００４年１月２２日 木曜日 午後５時４０分

Installation
10
Recharge
Recharge the battery when:
—“Recharge battery” is displayed on the handset,
—“7” flashes, or
—the handset beeps intermittently while it is in use.
• The display will continually indicate “Recharge battery” and/or “7” will
flash when the handset battery is charged for less than 15 minutes and the
handset is lifted off the base unit.
• If the battery has been discharged, the handset will display “Charge for 6h”
and “8” when you place the handset on the base unit. The handset will not
work unless the battery is charged. Continue charging.
A nickel metal hydride battery that is recyclable powers the
product you have purchased. Please call 1-800-8-BATTERY for
information on how to recycle this battery.
Battery information
• A fully charged battery will give you up to 5 hours of continuous talk time, or keep
your handset in Standby mode to receive incoming calls for up to 11 days (if no
phone calls are made). Battery power is consumed whenever the handset is off of
the base unit, even when the handset is not in use. The longer you leave the
handset off of the base unit, the time you can actually talk on the handset will be
shortened. Actual battery performance depends on a combination of how often
the handset is in TALK mode and how often it is in Standby mode.
• If the battery is fully charged, you do not have to place the handset on the base
unit until “Recharge battery” is displayed and/or “7” flashes. This will
maximize the battery life.
• If you want to keep the battery fully charged at all times, place the handset on the
base unit when the handset is not used. The battery cannot be overcharged.
•Clean the charge contacts of the handset and the base unit with a soft, dry
cloth once a month. Clean more often if the unit is subject to grease, dust or
high humidity. Otherwise the battery may not charge properly.
Battery replacement:
If you cleaned the charge contacts and fully charged the battery, but after a few
telephone calls, “Recharge battery” is displayed and/or “7” continues to
flash, or “Charge for 6h” and “8” are displayed, the battery may need to
be replaced. Please order a new Panasonic HHR-P104 battery at the telephone
number shown on page 2. To replace the battery, see page 9.
After your Panasonic battery
is fully charged, you can
expect the following
performance:
Operation Operating time
While in use (TALK) Up to 5 hours
While not in use (Standby) Up to 11 days
Recharge battery
PQQX13986YA.book 10 ページ ２００４年１月２２日 木曜日 午後５時４０分

11
For assistance, please call: 1-800-211-PANA(7262)
Preparation
Programmable Settings
Programming Guidelines
This unit has several programmable functions which can be selected from the
function menu on the display (p. 12).
How to select a function item from the menu
• To go back to the previous menu, press Back, or press Select while
“---(Go back)----” is displayed. If you press this key in the main menu, the
unit will exit programming mode.
• After programming is complete, the display will return to the main menu or the
sub-menu depending on which menu the selected item is located. (See the menu
table on page 12.)
• You can exit programming mode at any time by pressing [OFF].
• If you do not press any buttons for 60 seconds, the handset will exit programming
mode.
• If the unit detects a problem, an error message will be displayed (p. 55) and/or
error beeps will sound.
Make sure the handset and base unit are not being used. The handset
must be operated near the base unit and while off the base unit.
1Press [MENU].
• The main menu is displayed (p. 12).
2Scroll to the desired item by pressing [ d ]or
[
B ].
3Press Select to select the desired item.
4If the item has a sub-menu, select the menu item (p. 12). Repeat
steps 2 and 3 until the desired item is displayed. If the item has no
sub-menu, go to step 5.
5Select the desired setting by pressing [ d ]or
[
B ], then press Save to save your setting.
• A confirmation tone will be heard and the setting
will be saved.
6Press [OFF] to exit programming mode.
Handset
Back Select
[MENU] enters the
function menu.
When “
d ” or “ B ”is
displayed, navigator key
scrolls through the menu.
[OFF] exits
programming.
The soft keys selects the
functions displayed above
each soft key.
Initial setting
Back Select
K d BL
Back Select
Back Save
PQQX13986YA.book 11 ページ ２００４年１月２２日 木曜日 午後５時４０分

Programmable Settings
12
Function Menu Table
You can use the following functions to customize your unit. See the corresponding
pages for function details.
• After pressing [MENU], you can also program menu items directly by pressing ([0]
to [9], [*]and [#]) instead of using the soft keys (p. 53
– 54).
Handset
Main menu Sub-menu ISub-menu II
Voice enhancer
Caller IQ
Talk Caller ID
Initial setting
Ringer setting
Store VM access#
VM tone detect
Caller ID edit
Auto talk
Key tone
Set tel line
Message alert
Voice Mail
Change language
Set base unit
LCD contrast
Set dial mode
Set flash time
Set line mode
V.M. access
Get new Info.?
Turn CIQ off?
View Info.?
Ringer tone
Incoming call.
Ringer volume
Ringer tone
Incoming call.
Talk Caller ID
(p. 42)
(p. 13)
(p. 47)
(p. 44)
(p. 21)
(p. 25)
(p. 15)
(p. 16)
(p. 62)
(p. 61)
(p. 59)
(p. 18)
(p. 14)
(p. 18)
(p. 48)
(p. 14)
(p. 49)
(p. 13)
(p. 17)
(p. 48)
(p. 43)
(p. 26)
(p. 29)
*“Activate CIQ?” is
displayed if you have
not subscribed to
openLCR service.
“Turn CIQ on?” is
displayed when Caller
IQ is turned off (p. 59).
PQQX13986YA.book 12 ページ ２００４年１月２２日 木曜日 午後５時４０分

Preparation
For assistance, please call: 1-800-211-PANA(7262) 13
Programmable Settings
Display Language
You can select either “English” or “Spanish” as the display language. The factory
preset is “English”.
• If you select a language you cannot read, change the display language again
using direct commands (p. 54).
Dialing Mode
If you have touch tone service, set the dialing mode to “Tone”. For rotary or pulse
service, set to “Pulse”. The factory preset is “Tone”.
1Press [MENU].
2Scroll to “Initial setting” by pressing [ d ]
or [
B ], then press Select.
3Scroll to “Change language” by pressing [ d ]
or [
B ], then press Select.
4To change from English to Spanish, press
Español.
To change from Spanish to English, press
English.
• The display changes to the selected language.
• You can also select a language by pressing [
d ]or
[
B ].
5When Spanish is selected, press Salvar, then press [OFF].
When English is selected, press Save, then press [OFF].
1Press [MENU].
2Scroll to “Initial setting” by pressing [ d ]
or [
B ], then press Select.
3Scroll to “Set tel line” by pressing [ d ]or
[
B ], then press Select.
4Press Select at “Set dial mode”.
5Select “Pulse” or “Tone” by pressing [ d ]or
[
B ].
6Press Save, then press [OFF].
Handset
Initial setting
Back Select
K
d BL
Change language
Back Select
K
d BL
Display
:English
Español Save
KL
Handset
Initial setting
Back Select
K
d BL
Set tel line
Back Select
K
d BL
Set dial mode
Back Select
K
d BL
Set dial mode
:Tone
Back Save
K
d BL
PQQX13986YA.book 13 ページ ２００４年１月２２日 木曜日 午後５時４０分

Programmable Settings
14
Line Mode
The line mode is preset to “B” and generally should not be adjusted. If “Line in
use” on the handset is not displayed properly or the IN USE indicator on the base
unit does not light properly, the line mode selection is incorrect. Set line mode to
“A”.
Auto Talk
The Auto Talk feature allows you to answer calls by simply lifting the handset off the
base unit. You do not need to press [C]or [s]. The factory preset is OFF.
• In order to view Caller ID information after you lift the handset to answer a call,
leave the Auto Talk feature turned off.
1Press [MENU].
2Scroll to “Initial setting” by pressing [ d ]
or [
B ], then press Select.
3Scroll to “Set tel line” by pressing [ d ]or
[
B ], then press Select.
4Scroll to “Set line mode” by pressing [ d ]or
[
B ], then press Select.
5Select “A” or “B” by pressing [ d ]or [ B ].
6Press Save, then press [OFF].
1Press [MENU].
2Scroll to “Initial setting” by pressing [ d ]
or [
B ], then press Select.
3Scroll to “Auto talk” by pressing [ d ]or [ B ],
then press Select.
4Select “On” or “Off” by pressing [ d ]or [ B ].
5Press Save, then press [OFF].
Handset
Initial setting
Back Select
K
d BL
Set tel line
Back Select
K
d BL
Set line mode
Back Select
K
d BL
Set line mode
:B
Back Save
K
d BL
Handset
Initial setting
Back Select
K
d BL
Auto talk
Back Select
K
d BL
Auto talk
:Off
Back Save
K
d BL
PQQX13986YA.book 14 ページ ２００４年１月２２日 木曜日 午後５時４０分

Preparation
For assistance, please call: 1-800-211-PANA(7262) 15
Programmable Settings
Ringer Volume
You can select the handset or base unit ringer volumes to high, medium, low, or off.
The factory preset is HIGH. If the handset and base unit ringer is turned off, the
handset or base unit will ring at the low level for intercom calls, and will not ring for
outside calls. Caller names will not be announced even if the Talking Caller ID
feature is turned on (p. 25, 26).
Handset ringer volume
• If the handset ringer is turned off, “Ringer off” will be displayed while not in
use. If the handset is off the base unit when there are missed calls or new
messages in your voice mailbox (p. 44), “Ringer off” is not displayed.
• You can adjust the ringer volume while an outside call is ringing. Press [
d ]or [ B ]
while the handset is ringing.
Temporary ringer off
While the handset is ringing for an outside call, you can turn the ringer off
temporarily by pressing [OFF]. The handset will ring again as normal the next time
a call is received.
1Press [MENU].
2Scroll to “Ringer setting” by pressing [ d ]
or [
B ], then press Select.
3Press Select at “Ringer volume”.
4Select the desired volume level by pressing
[
d ]or [ B ].
• The volume will change and ring.
• The number of steps indicates the volume level.
•To turn the ringer off, press [ d ]repeatedly until
“Off ?” is displayed.
5Press Save.
Handset
Ringer setting
Back Select
K
d BL
Ringer volume
Back Select
K
d BL
Ringer volume
Low High
Back Save
K
d BL
Ex. High
PQQX13986YA.book 15 ページ ２００４年１月２２日 木曜日 午後５時４０分

Programmable Settings
16
Base unit ringer volume
Make sure the base unit is not being used.
To set the ringer volume to high (preset), medium, or low, press
VOLUME [<]or [>].
• To increase volume, press VOLUME [>].
To decrease volume, press VOLUME [<].
• To stop ringing, press [0].
To turn the ringer off, press and hold VOLUME [<]until 2 beeps sound.
To turn the ringer on, press VOLUME [<]or [>].
• The base unit will ring at the low level.
• You can adjust the ringer volume while an outside call is ringing. Press VOLUME
[<]or [>]while the base unit is ringing.
To turn the ringer off, press and hold VOLUME [<]until 2 beeps sound.
Ringer Tone
You can set the handset and base unit ringers to use one of 7 ringer patterns for
outside calls. “Tone 1” to “Tone 3” are bell ringer patterns. “Melody 1” to “Melody 4”
are preset melody patterns. The factory preset is “Tone 1”.
• You cannot change the ringer tone for intercom calls.
• If you subscribe to a Distinctive Ring Service (such as IDENTA-RING) from your
telephone company with 2 or 3 consecutive rings, select a bell ringer pattern
(Tone 1 to 3). If you select a melody pattern, you will not be able to distinguish
lines by their ringers.
• If you select one of the melody ringer patterns, the ringer will continue to sound for
several seconds if:
— the caller hangs up before you answer the call, or
— another person answers the call using another phone connected on the same
line.
Handset ringer tone
1Press [MENU].
2Scroll to “Ringer setting” by pressing [ d ]
or [
B ], then press Select.
3Scroll to “Ringer tone” by pressing [ d ]or
[
B ], then press Select.
Base Unit
Handset
Ringer setting
Back Select
K
d BL
Ringer tone
Back Select
K
d BL
PQQX13986YA.book 16 ページ ２００４年１月２２日 木曜日 午後５時４０分

Preparation
For assistance, please call: 1-800-211-PANA(7262) 17
Programmable Settings
Base unit ringer tone
(use either the handset or the base unit)
Make sure the base unit is not being used.
Setting the base unit ringer tone by using the
4Select the desired ringer tone by pressing [ d ]
or [
B ].
• The handset will ring and the ringer tone will
change. If the ringer volume has been turned off,
the handset will not ring (p. 15).
• You can also select the ringer tone by pressing [1]
to [7].
5Press Save, then press [OFF].
Press VOLUME [<]or [>], then select the desired ringer tone by pressing
[1] to [7].
[1] to [3] : Bell ringer patterns [4] to [7] : Melody patterns
• After pressing VOLUME [<]or [>], the base unit will ring using the current ringer
tone.
• The base unit will ring and the ringer tone will change.
• To stop ringing, press [0].
1Press [MENU].
2Scroll to “Initial setting” by pressing [ d ]or [ B ], then press
Select.
3Scroll to “Set base unit” by pressing [ d ]or [ B ], then press Select.
4Press Select at “Ringer tone”.
5Select the desired ringer tone by pressing [ d ]or [ B ].
• The base unit will ring and the ringer tone will change. If the base unit ringer
volume has been turned off, the base unit will not ring (p. 16).
• You can also select the ringer tone by pressing [1] to [7].
6Press Save, then press [OFF].
Ringer tone
1:Tone 1
Back Save
K
d BL
Base Unit
Handset
PQQX13986YA.book 17 ページ ２００４年１月２２日 木曜日 午後５時４０分

Programmable Settings
18
LCD Contrast
There are 6 levels of LCD contrast. The factory preset is “level 3”.
Message Alert
You can select whether or not the Ringer/Message Alert indicator on the handset
will flash slowly when new messages in your voice mailbox have been recorded
(p. 44). The factory preset is OFF.
• The Ringer/Message Alert indicator will not flash for new messages while the
handset is in use.
• The Ringer/Message Alert indicator acts both as a ringer indicator and as a
message alert indicator. This indicator will flash rapidly when a call is received
whether this feature is on or off.
• Battery operating time may be shortened when using this feature (p. 10).
1Press [MENU].
2Scroll to “Initial setting” by pressing [ d ]
or [
B ], then press Select.
3Scroll to “LCD contrast” by pressing [ d ]or
[
B ], then press Select.
4Select the desired contrast by pressing [ d ]or
[
B ].
• The contrast will change.
5Press Save, then press [OFF].
1Press [MENU].
2Scroll to “Initial setting” by pressing [ d ]
or [
B ], then press Select.
3Scroll to “Message alert” by pressing [ d ]or
[
B ], then press Select.
4Select “On” or “Off” by pressing [ d ]or [ B ].
5Press Save, then press [OFF].
Handset
Initial setting
Back Select
K
d BL
LCD contrast
Back Select
K
d BL
LCD contrast
Low High
Back Save
K
d BL
Ex. Level 3
Handset
Initial setting
Back Select
K
d BL
Message alert
Back Select
K
d BL
Message alert
:Off
Back Save
K
d BL
PQQX13986YA.book 18 ページ ２００４年１月２２日 木曜日 午後５時４０分

Basic Operation
For assistance, please call: 1-800-211-PANA(7262) 19
Making Calls
Using the Handset
To have a hands-free phone conversation
1Press [C].
•“Talk” is displayed.
2Dial a phone number.
• The dialed number is displayed.
• After a few seconds, the display
will show the length of the call.
3To hang up, press [OFF] or
place the handset on the base
unit.
1Press [s].
•“SP-phone” is displayed.
2Dial a phone number.
• The dialed number is displayed.
• After a few seconds, the display will show the length of the call.
3When the other party answers, talk into the microphone.
4To hang up, press [OFF] or place the handset on the base unit.
Hands-free Digital Duplex Speakerphone
For best performance, please note the following:
• Talk alternately with the other party in a quiet room.
• If you or the other party has difficulty hearing, press [ d ]to decrease the
speaker volume.
• While talking using [C], you can switch to a hands-free phone conversation
by pressing [s]. To switch back to the receiver, press [C].
Handset
Display
[ d ], [ B ]
[C]
[s]
[REDIAL]
Microphone
[OFF]
Soft Keys
[HOLD/INTERCOM]
PQQX13986YA.book 19 ページ ２００４年１月２２日 木曜日 午後５時４０分

Making Calls
20
To dial after confirming the
entered number
To adjust the receiver/
speaker volume during a
conversation
There are 3 volume levels for the
receiver and 6 volume levels for the
speaker.
To increase volume, press [ B ].
To decrease volume, press [
d ].
• The display shows the current volume
setting.
• If you try to increase/decrease
volume when it is at the maximum/
minimum level, the handset will beep
3times.
To redial the last number
dialed
To redial using the redial
list (Memory Redial)
The last 5 phone numbers dialed are
stored in the redial list.
•To erase an item, scroll to the item
then press Erase.
•If“No items stored” is displayed,
the list is empty.
To put a call on hold
To return to the call, press [C]
or [s].
• The base unit user can also take the
call by pressing [SP-PHONE].
• If another phone is connected on the
same line (p. 8), you can also take the
call by lifting its handset.
• If a call is kept on hold for 6 minutes,
an alarm tone will start to sound and
the Ringer/Message Alert indicator
will start to flash rapidly. After
4 additional minutes on hold, the call
will be disconnected.
1Enter a phone number.
• If you misdial, press Clear.
Enter the correct number.
• If a pause is required when
dialing, press Pause where
needed (p. 47).
• To cancel, press [OFF].
2Press [C]or [s].
3To hang up, press [OFF] or
place the handset on the base
unit.
Press [C]or [s], then press
[REDIAL].
3334444 |
Clear Pause
KL
Ex. Receiver volume: High
Speaker volume: Level 6
Volume
Low High
(VE) Mute
KL
1Press [REDIAL].
• The last number dialed is
displayed.
2Scroll to the desired number by
pressing [
d ]or [ B ].
• You can also scroll down through
the list by pressing [REDIAL].
• To exit the list, press [OFF].
3Press [C]or [s].
1Press [HOLD/INTERCOM]
during a conversation.
•“Line on hold.” is displayed.
• To transfer the call to the base
unit, see page 39.
2Press [HOLD/INTERCOM]
again.
•“Hold” is displayed.
333-4444
Erase
K d B
PQQX13986YA.book 20 ページ ２００４年１月２２日 木曜日 午後５時４０分
