Panasonic KX-TGP600 User manual

Page 1
65 Desk Phone
And the KX-UDT131 Cordless Phone
TIPT (Telstra IP Telephony)

Page 2
1 WHAT’S INSIDE
02 Let’s get started
03 Getting connected
04 Connecting additional cordless phones
05 Working in Parallel Mode
06 Changing the Handset Number and Name Display
07 Disassociating an Additional Handset from the Main Number
08 Registering/De-Registering a Desk Phone to the KX-TGP600 Base Unit
09 Re-Pairing a Cordless Phone and Base Unit [KX-UDT131]
10 Problem Solving [KX-TPA65 Desk Phone]
11 Problem Solving [KX-UDT131 Cordless Phone]

Page 3
2 LET’S GET STARTED
Your package contains the following:
•1x This Quick Start Guide
•1x Panasonic KX-TGP600 Base Unit
•1x KX-TPA65 Desk Phone
•1x Ethernet Cable for Base Unit
•1x AC Adapter for Base Unit
•1x AC Adapter for Desk Phone
•1x Handset Cord
•1x Handset
•1x Stand
•Manufacturer Warranty Card
•1x Wall mount kit KX-A440 (optional)
If you have Purchased the KX-UDT131 Cordless phone you will also receive:
•1x KX-UDT131 Cordless Phone
•1x Charger (Cordless Phone Cradle)
•1x AC Adapter for Charger (Cordless Phone Cradle)
•1x Ethernet Cable
•1x Battery and battery cover
•1x Belt Clip Replacement Cover

Page 4
3 GETTING CONNECTED
This section details the setting up a new TGP600 Base unit and the included Desk phone.
Step 1: Set up the new KX-TGP600 Base Unit
•Connect the Ethernet cable (included) to your base unit and to the Ethernet port located
on the back of your TIPT switch/PC.
•Connect the AC adapter for the base unit to the base unit and a power socket.
Ensure that you have plugged the adapter in securely.
•The status indicator on the Base Unit will flash as follows.
1) Solid –Red: When the base unit is turned on, the status indicator turns red for ~40
seconds.
2) Slow Flashing –Amber: The base unit is obtaining an IP address / configurations and
registering with your phone system. Please wait.
3) Solid –Green: The base unit is connected to the TIPT network.
Step 2: Set up the included KX-TPA65 Desk Phone
•Attach the AC adapter to the desk phone and a power socket.
•Attach the Corded Handset and headset (if required) to the desk phone.
Step 3: Attach the Stand to the KX-TPA65 Desk Phone
•Insert the stand into the hooks located in the unit.
•Gently rotate the stand in the direction indicated until it is released
Step 4: Adjusting the Stand Position
•Push the PUSH marks in the direction indicated, with both hands, and tilt the stand until it
becomes fixed in the desired position.
•Choose the High Position or Low Position.

Page 5
Step 5: Removing the Stand
•Tilt the stand in the direction indicated while pushing the PUSH marks with both hands.
Step 5: Set up the included KX-UDT131 Cordless Phone (to be used if you have purchased the
additional KX-UDT131 cordless Phone)
•Open the battery cover and insert the battery, close the cover.
•Connect the AC adapter to the charger (phone cradle) and a power socket.
•Complete the charging cycle by replacing the cordless phone in the charger for 6 hours –
you may choose to complete the charging cycle when you have completed the set up.
Step 6: Activate your TIPT service (this can only be performed from the KX-UDT65 Desk phone)
•Select Menu > System Settings > System Settings > Authentication
•Select ID –Enter details and select OK.
•Select Password –Enter details and select OK.
•Press the Back button x 3 to return to the main display and complete the activation
process.
•The status indicator on the base unit will flash as follows:
a) Solid –Red: The status indicator will flash solid red for ~20 seconds.
b) Slow flashing –Amber: Next, the status indicator will flash amber for ~50 seconds.
c) Solid –Green: If the configuration is correct, the status indicator will flash solid green.
Quick Tip
Q: Where can I find my Authentication ID and Password?
A: Your ID and Password will be sent to you via email. If you choose to use an additional KX-TPA60 or KX-UDT131 cordless
phone(s) you do not require an authentication ID or Password –these details are displayed as NULL.
Q: I am still unable to connect successfully, what do I do?
A: Check that you have entered the correct ID and Password by repeating the Step 3. Next, restart the system by
disconnecting and reconnecting the base unit from the power supply. Failing this, call the TIPT Help Desk on 1800 648
116.

Page 6
4a CONNECTING ADDITIONAL CORDLESS PHONES [KX-TPA65 Desk Phone]
If you need to use a portable cordless phone with your desk phone:
•Press and hold the Handset Locator button on the base unit for ~3 seconds.
•The status indicator on the Base Unit will flash as follows:
a) Slow flashing –Red: The base unit is registering to a phone.
•Select Menu > System Settings > System Settings > Register H/S
•Select the handset you would like to register > Select OK
•The phone will display the following prompts:
a) “Executing”: Please wait till the registration process is completed.
b) “Registered”: Initial registration is completed.
•Press the Back button to return to the main screen and complete the registration process.
4b CONNECTING ADDITIONAL CORDLESS PHONES [KX-UDT131]
•Press and hold the Handset Locator button on the base unit for ~3 seconds.
•The status indicator on the Base Unit will flash as follows:
a) Slow flashing –Red: The base unit is registering to a phone.
•Select Menu > Setting Handset > System Option > Register H/S
•Select the base unit you would like to register the handset to (default: Base Unit 1) > Select
OK
•The phone will display the following prompts:
a) “Executing”: Please wait till the registration process is completed.
b) “Registered”: Initial registration is completed.
•Press the Power / Cancel button to complete the registration process.
Quick Tip
You can register a maximum of 8 phones to a base unit.

Page 7
5 Working in Parallel Mode [KX-TPA65 desk phone]
By using a desk phone as the master phone (KX-TPA65), a portable cordless phone (KX-TPA60)
or [KX-UDT131] can be set to be paired with it so that the phone number (account) of the
master desk phone is applied to the potable (paired) handset(s). With pairing settings, the desk
phone can be used while you are sitting at your desk, and the portable handset can be used
while away from your desk.
•Select Menu > System Settings > System Settings
•Navigate to select Parallel Setting and Select OK
•Select the desk phone (KX-TPA65) to use as the Master handset and Select OK.
•Select Pairing and Select OK
•Select the portable handset to use as the paired unit and Select OK
•Select Mode and Select OK
To make one unit receive a busy signal while the other is on a call:
•Select Busy and Select OK
To make one unit take over a call when the other is on a call
•Select Take Over Call and Select OK

Page 8
6 Changing the Handset Number and Name Display [KX-TPA65 &
KX-UDT131]
Each handset can be assigned a unique name / number that can be displayed on the handset
screen. Identifying your desk phone will enable you to easily transfer calls between phones
registered to the same base unit (i.e. internal call transfer).
Step 1: Assign a name / number to a phone:
•Select Menu > Setting Handset > Display option > Handset Name
•Toggle the alpha-numeric keypad and enter the desired name / number
•Select OK to save entry
Quick Tip
Q: I have saved a handset name / number, but it’s not appearing on the display – What do I do?
A: Ensure that you have selected the option to display the handset name by following these steps:
•Select Menu > Setting Handset > Display option > Handset Name
•Toggle the alpha-numeric keypad and retype the desired name / number
•Select OK to save entry
Or Call the TIPT Help Desk on 1800 648 116.

Page 9
7 Disassociating an Additional Handset from the Main Number [KX-TPA65]
If you have purchased multiple handsets, by default all handsets will ring when the main number is
dialled. You can assign different numbers to the handsets from one handset or from the desk
phone.
Step 1: To disassociate a handset from the main number for incoming calls:
•Note the handset name
•Press Menu
•Select System Settings and Press OK
•Select System Settings and Press OK
•Select Multiline Setting and Press OK
•Select Incoming Call and Press OK
•Select the number –and Select OK
•Select the Handset name/number –Handset 1 or Handset 2 or telephone number, Select ✓
•Press OK
•Press the Back button x 5 times to return to the main screen
Step 1: To disassociate a handset from the main number for outgoing calls.
•Note the handset name
•Press Menu
•Select System Settings and Press OK
•Select System Settings and Press OK
•Select Multiline Setting and Press OK
•Select Outgoing Call and Press OK
•Select the Handset name –Handset 1 or Handset 2 etc, Press OK.
•Select the number –and Select ✓
•Press OK
•Press the Back button x 5 times to return to the main screen

Page 10
8 Registering/De-Registering a Desk Phone to the KX-TGP600 Base Unit
[KX-TPA65]
Before operating the handset/desk phone, confirm that the STATUS indicator of the base unit is
Green (On/Slow Flashing/Quick Flashing).
Step 1: Deregister the Desk phone from a base unit:
1. Select Menu > System Settings > Select OK
2. Use the navigation buttons to scroll to System Settings and Press OK
3. Scroll to Cancel Register > Select OK
4. Select a handset/desk phone and Select OK
Step 2: Register the Desk phone to a base unit:
1. Select Menu > System Settings > Select OK
2. Use the navigation buttons to scroll to System Settings and Press OK
3. Scroll to Register H/S > Select OK
4. Select a handset/desk phone and Select OK
9 RE-PAIRING A CORDLESS PHONE AND BASE UNIT [KX-UDT131]
Step 1: Deregister the cordless phone from a base unit:
5. Select Menu > Setting Handset > System option
6. Scroll to Cancel Base > Select OK > Select Base Name >Select ✓ to confirm > Select OK
7. You will be prompted “Confirm Delete?” – Select Yes
8. Screen will display “Register Unit” once successfully deregistered
Step 2: Register the cordless phone to a base unit:
5. Long-press the Handset Locator Button on the base unit for ~5 seconds
6. The status indicator on the Base Unit will flash as follows:
a) Slow flashing –Red: The base unit is registering a phone
7. From screen display “Register Unit” – Select OK
8. The phone will display the following prompts:
a) “Please wait...”: Please wait till the registration process is completed.
b) “Registered”: Registration is completed.
Note: You can register a handset/desk phone to up to 4 base units. You can register a base
unit up to 8 handsets/desk phones.

Page 11
10 PROBLEM SOLVING [KX-TPA65]
“How do I go Off and On Hook on my desktop phone?”
To go off-hook:
1. Lift the corded handset off its cradle.
2. Using the SP-PHONE button (on the phone) to enable hands-free mode.
3. Press SP-PHONE button (on the phone) when using a headset
To go On-hook:
1. Replace the corded handset on its cradle.
2. Press SP-PHONE button (on the phone) when using a headset or when you are in hands-free
mode and Press the CANCEL button to go on-hook.
“How do I make a call using my new handset?”
1. Take the phone off-hook by lifting the corded handset
2. Dial the number
3. Press
‘How do I make a call to another handset?’
To make an Intercom Call:
1. Press ]
2. Press
3. Use the navigation buttons to select the handset
4. Press OK
“How do I make a call Using the Incoming Call Log?”
1. Press the Function button on the phone
2. Scroll and Select Incoming Log (6) and Press OK
3. Scroll and Select Incoming Log Press OK
4. Scroll and Select the number you want to call and Press OK (number will ring)
5. Hang up the receiver to end the call.
“How do I end a call?”
1. Whilst on an active call hang up the corded handset.
“How do I view my phone number (on the phone)?”
To view the phone number of a particular handset:
1. Press the Line button on the phone.
The phone number and available lines will now be displayed.
“How do I redial a number?”
1. Press the REDIAL button on the phone

Page 12
“How do I make a call Using the Handset Phonebook?”
1. Press
2. Enter the desired name
3. Press
4. Lift the cordless handset or press the SP-PHONE button (on the phone). The number will ring.
“How do I use the Volume control on the phone?”
To change the volume on the phone
1. Press the –or +buttons on the volume control to change the volume.
“How do I Mute My Call using the Handset?”
To Mute your call:
1. Whilst on the call Press the MUTE button. The Mute icon will flash on the screen
2. Press the MUTE button again to take your call off Mute.
“How do I receive a call?”
To answer an incoming call:
1. Pick up the handset or press the SP-PHONE button on the phone
“How do I Reject an incoming call?”
You can reject an incoming call from your handset:
1. While an incoming call is ringing, Press (soft key)
2. The call will be rejected,
“How do I place a call on Hold?”
Whilst on an active call:
1. Press the HOLD button (on the phone), screen will display ‘Line on Hold’.
2. Press HOLD button (on the phone) again to take the call off hold.
“How do I transfer a call to another external number?”
To transfer whilst on a call:
1. Press the TRANSFER button (on the phone)
2. Dial the party you want to transfer to (wait a few seconds for the call to connect)
3. Wait until the other party answers to announce the transfer
4. Press TRANSFER button (on the phone) again. The call is now transferred.
Note: To return to the call before the transfer destination answers, press
“How do I do a Blind Transfer?”
To perform a blind transfer:

Page 13
1. Whilst on an active call Press
2. Dial the party you want to transfer to and Press or the number will dial automatically.
When the caller answers the call is automatically transferred.
Note: If blind transfers are not permitted, this soft key is not displayed. Contact your administrator
for further information.
“How do I transfer a call from my desk phone to another phone that shares the same phone
number?”
You will need to follow the steps below to perform an Internal Blind or Supervised Transfer.
Blind Transfer (transfer without announcing the call to the party)
Whilst on an active call:
1. Select Menu .
2. Select Intercom to display all the available handsets.
3. Use the navigation buttons to scroll to party’s handset/desk phone.
4. Select OK.
5. When the party answers hang up.
Consult Transfer (transfer after announcing the call to the party)
Whilst on an active call:
1. Select Menu .
2. Select Intercom to display all the available handsets.
3. Use the navigation buttons to scroll to party’s handset/desk phone.
4. Select OK.
5. When the party answers announce the caller and then hang up.
“How do I talk to Two Parties and Flip between two calls?”
When talking to one party while the other party is on hold, you can swap the calls back and forth.
To call a third party and then alternate between the two
1. Whilst on an active call Press the HOLD button (on the phone), screen will display ‘Line on Hold’
2. Dial the other party’s number, lift the handset or Press the SP-PHONE button
3. After talking to the other party, press HOLD button (on the phone)
4. This will take you back to talk to the original party. Continue to press the HOLD button (on the
phone), to toggle between the two parties.
5. Place the receiver on the hook to end the current call and then toggle to the second call and
hang up to end that call.
“How do I make a Conference Call?”
1. Whilst on an active call Press the Conf button on the phone
2. Dial the party you want to add to the conversation and Press
3. When the party answers, Press to join the callers in the conference call.
“How do I End a Conference Call?”

Page 14
1. Whilst on an active Conference hang up the receiver.
“How do I activate DND”?
1. Press the Function button (on the phone)
2. Select FWD/DND (2) and Select OK
3. Select Line/Number and Select OK
4. Select DND and Select OK
5. Select ON and Select OK
6. Select the Back button x 2 to return to the Main screen
“How do I de-activate DND”?
1. Press the Function button (on the phone)
2. Select FWD/DND (2) and Select OK
3. Select Line/Number and Select OK
4. Select DND and Select OK
5. Select OFF and Select OK
6. Select the Back button x 2 to return to the Main screen
“How do I Call Forward?”
1. Press the Function button (on the phone)
2. Select FWD/DND (2) and Select OK
3. Select Line/Number and Select OK
4. Select from Fwd (All), Fwd (Busy), Fwd (NA) and Select OK
5. Select Phone Number and Select OK
6. Enter the Number to forward calls too and Select OK
7. Select the Back button x 3 to return to the Main screen
“How do I de-activate Call Forward?”
1. Press the Function button (on the phone)
2. Select FWD/DND (2) and Select OK
3. Select Line/Number and Select OK
4. Select from Fwd (All), Fwd (Busy), Fwd (NA) and Select OK
5. Select On/Off and Select OK
6. Select Off and Select OK
7. Select the Back button x 3 to return to the Main screen
“How do I Listen to Voicemail Messages?
When you have received, a new voicemail message the light on the phone will flash slowly. The
phone display will show . To retrieve your messages:
1. Press the Message button on the phone
2. Select the Line/number and Select OK
You will now hear the recorded message, follow the prompts to retrieve your messages
“I am trying to get my base unit and Desk phone connected with my TIPT service. I have entered
my authentication ID and password, but am still unsuccessful –What do I do?”

Page 15
•Call the TIPT Help Desk on 1800 648 116
“I am not able to use my new phone line – What do I do?”
•You will need to perform a local restart on your base unit:
Disconnect and reconnect your base unit from the power supply. If you are still having
issues call the TIPT Help Desk on 1800 648 116.
“What do I do if this icon appears and I can’t Make a call?"
1. If flashes on the phone display, move closer to the base unit and dial again.

Page 16
11 PROBLEM SOLVING [KX-UDT131]
“How do I switch on my portable phone?”
1. To switch on your phone:
2. Press and hold .
“How do I make a call using my new handset?”
1. Press
2. Dial the number
3. Press
‘How do I make a call to another handset?’
To make an Intercom Call:
1. Press ]
2. Press
3. Use the navigation buttons to select the handset
4. Select the desired handset/desk phone
5. Press OK
“How do I make a call Using the Incoming Call Log?”
1. Press
2. Select Incoming Log.
3. Scroll and Select the number you want to call and Press
4. Press to end the call.
“How do I end a call?”
1. Whilst on an active call Press
“How do I view my phone number (on the phone)?”
To view the phone number of a particular handset:
1. Press the Flex button on the phone.
The phone number will now be displayed.
“How do I make a call Using the Handset Phonebook?”
1. Press or
2. Select the desired item in the phonebook and Press
“How do I receive a call?”
To answer an incoming call:

Page 17
1. Press
“How do I Reject an incoming call?”
You can reject an incoming call from your handset:
1. While an incoming call is ringing, Press
2. The call will be rejected, and the handset will return to standby mode.
“How do I place a call on Hold?”
Whilst on an active call:
1. Press , the screen will display ‘Line on Hold’.
2. Press again to take the call off hold.
“How do I transfer a call to another external number?”
To transfer whilst on a call:
1. Press
2. Dial the party you want to transfer to and press or wait a few seconds and the number
will automatically call
3. Wait until the other party answers to announce the transfer
4. Press
Note: To return to the call before the transfer destination answers, press
“How do I perform a Blind Transfer?”
To perform a blind transfer:
1. Whilst on an active call Press
2. Dial the party you want to transfer to and Press or wait for the number to dial
automatically. When the caller answers the call is automatically transferred.
Note: If blind transfers are not permitted, this soft key is not displayed. Contact your administrator
or the TIPT Help Desk on 1800 648 116 for further information.
“How do I transfer a call from one cordless phone to another phone that shares the same phone
number?”
You will need to follow the steps below to perform an Internal Blind or Supervised Transfer.
Blind Transfer (transfer without announcing the call to the party)
Whilst on an active call:
1. Select Menu .
2. Select Intercom to display all the available handsets.

Page 18
3. Use the navigation buttons to scroll to the party’s handset.
4. Select OK.
5. Select OK again when the party’s phone rings and complete the transfer.
Consult Transfer (transfer after announcing the call to the party)
Whilst on an active call:
1. Select Menu .
2. Select Intercom to display available handsets.
3. Use the navigation buttons to scroll to the party’s handset.
4. Select OK.
5. Wait till the other party answers to announce the call.
6. Select OK again after the party accepts the call and complete the transfer.
“How do I talk to Two Parties and Flip between two calls?”
When talking to one party while the other party is on hold, you can swap the calls back and forth.
To call a third party and then alternate between the two
1. Whilst on an active call Press the screen will display ‘Line on Hold’
2. Dial the other party’s number and Press
3. Press
4. After talking to the other party, press
5. This will take you back to talk to the original party. Continue to press to toggle between
the two parties.
6. Press to end the current call and then toggle to the second call and Press to end
that call.
“How do I make a Conference Call?”
1. Whilst on an active call Press and then Press Conference (3
2. Dial the party you want to add to the conversation and Press or wait a few seconds for
the number to automatically call
3. When the party answers, Press to join the callers in the conference call. The display will
show ‘Conference’.
“How do I End a Conference Call?”
1. Whilst on an active Conference Call Press .
“I am trying to get my base unit and cordless phone(s) connected with my TIPT service. I have
entered my authentication ID and password, but am still unsuccessful –What do I do?”
•Call the TIPT Help Desk on 1800 648 116
“I am not able to use my new phone line –What do I do?”

Page 19
•You will need to perform a local restart on your base unit:
Disconnect and reconnect your base unit from the power supply. If you are still having
issues call the TIPT Help Desk on 1800 648 116.
“What do I do if this icon appears and I can’t Make a call?"
1. If flashes on the phone display, move closer to the base unit and dial again.
