Panasonic NA-F80VB7 Product guide

Model No. NA-F80VB7
NA-F75S7
NA-F70S7
Contents
Safety Precautions 2
Part Names 3
Operation Panel 4
Variety of Programs 5
Detergent 6
Washing 7
Washing Options 8
• Delicate
• Blanket
• Air Dry
• Wash / Rinse / Spin
Convenient Functions 10
Maintenance 10
Installation 12
Troubleshooting 14
Error Display 15
Specications 16
Thank you for purchasing this
product.
- Read these instructions carefully for
optimum performance and safety
before use.
- Keep this manual for future reference.
Operating & Installation
Instructions
Fully Automatic Washing Machine
(Household use)
W9901-9NT30
A0415-3109(M)
Printed in Vietnam
10-2019
W9901-9NT30

2
Safety Precautions
May cause serious
injury or death.
Never do the following about the
power plug and cord
(To prevent re or electric shock)
●Do not plug in or unplug the power cord with wet
hands.
●Do not hold or pull on the cord when removing the
plug from the socket.
●Do not use a power cord or plug that is damaged.
If the power cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualied persons to avoid a hazard.
Observe the following about the
power plug and cord
(To prevent re or electric shock)
● Use a socket that satises the rating requirement
solely for this appliance. Do not use a plug adaptor
or extension cord.
●Always fully insert the power plug into the socket.
●Wipe the power plug periodically with a dry cloth.
(Accumulated dust collects moisture, which may
cause insulation failure, resulting in re.)
●Unplug the power cord before cleaning.
Never disassemble, repair or modify
the appliance yourself.
●In case of malfunction or failure, immediately stop
use, unplug the power cord, and ask your nearest
service centre for repair.
Do not allow children to use on their
own.
●This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
●Children should be supervised to ensure that they
do not play with the appliance.
Keep away from re.
Do not put ammable materials or
clothes with such things attached in
the tub. Keep them away from the
appliance.
(To prevent explosion or re)
● For example: Kerosene, gasoline, benzine/thinner,
alcohol, etc.
Do not touch the tub until it
completely stops.
(To prevent injury)
●If the tub does not stop within 15 seconds when
the lid is opened during spin process, switch o󰀨 the
appliance immediately and call a service person.
Provide a ground.
(To prevent electric shock by short circuit)
●Ask a service person to do the grounding work.
●In case of a 2-pin power cord, establish a ground.
Keep magnets and magnetized
objects away from the operation
panel.
The tub may rotate even when the lid is open, resulting
in injury.
Read and follow these safety precautions.
WARNING

3
Part Names
May cause injury or
property damage.
Do not wash, rinse, or spin
waterproof sheets or clothes.
(To prevent injury, damage to the main unit, walls, oor
or laundry, or water leakage if the appliance falls over
or oscillates extremely while spinning)
●Raincoats, wet suits, etc.
Observe the following
●New hose-sets supplied with the appliance are to be
used and old hose-sets should not be reused.
● Be careful not to get your ngers caught when
opening and closing the lid.
●Do not insert your hands or feet under the main unit.
(To prevent injury by rotating parts.)
●Do not climb or put heavy objects on the appliance.
(To prevent deformation and breakage resulting in
injury)
●If the lid is broken, immediately stop using the
appliance.
(To prevent deformation and breakage resulting in
injury)
●Do not connect to the hot water supply.
●Do not directly pour hot water of 50 ºC or higher into
the tub.
●Do not obstruct the openings of the bottom face with
carpet, etc.
Turn o󰀨 the water faucet after
operation.
(To prevent water leakage)
This appliance is only suitable for
textiles labelled washing machine
washable.
Pulsator
Lint lter
(P. 10)
Lid
Tub
Operation
Panel
(P. 4)
Bleach / Liquid
detergent inlet
(P. 6)
Power cord
and plug
(P. 13)
Softener
inlet
(P. 6)
Adjustable leg
(P. 13)
External drain water
hose (P. 12)
Water supply valve
(P. 13)
Accessories
●Water
supply
hose (1)
●Water tap
adaptor (1)
●External
drain water
hose (1)
●Bottom cover (1) ●Screw (1)
Attached
with tape.
CAUTION
Safety Precautions Part Names

4
Operation Panel
• Operation panel of NA-F80VB7
Program selection (P. 5)Wash/Rinse/Spin
(P. 9)
Start/Pause
Child Lock lamp (P. 10)
Auto Restart
In case of a power failure
during operation, operation
will resume from the point
where it was stopped when
the power is recovered.
Power On/O󰀨
The power turns
o󰀨 automatically if
you do not press
“Start/Pause”
within 10 minutes
after power-on.
Change water level
During the wash process, press “Water
Level” to change the water level.
●Some water levels cannot be selected
depending on the program.
●When the remaining time is displayed,
press “Water Level” to check the water
level.
Water level /
Remaining time
Indicates the selected program (No.)
After starting operation, indicates the
water level according to the amount of
laundry.
After approx. 5 seconds, indicates the
approximate remaining time (min).
Water level /
Detergent volume
The detergent volume guideline
corresponding to the water level
indication is shown below.
( : 1 scoop of detergent)
Detergent volume
Water level
Preset
Set the time to nish washing (in hours).
e.g.) 8 hours later
●Setting range: 2 - 24 hours later, in one-
hour increments. (3 - 24 hours later for
the 6Soak program)
●Not available for the following programs:
2Delicate
4Fragrance
9Air Dry
10
Tub Hygiene

5
Variety of Programs
Laundry preparation and check
For clothes losing colour easily
Wash separately.
Pre-laundry check
To prevent damage to clothes,
malfunction and drainage failure
●Remove coins, pins, paper clips, nails, etc.
● Fasten buttons and close zippers.
●Do not wash items (such as paper
diapers) other than laundry.
●Reverse clothes with surface likely to
ake o󰀨.
●Use a brush to remove pet and
human hair, sand, etc.
●Tie strings, etc.
For delicate underwear only
Use laundry nets.
●Underwire brassieres
●Lacy clothes, lingerie and stockings
When using a net
●Do not overpack.
● Put the zipper's slider into the cover.
(To prevent damage to clothes and
the main unit)
●Do not use the 9Air Dry program.
(To prevent uneven drying and wrinkles)
Purpose Program
NOTE ●1Normal program and 8Water Save program are recommended for a normally soiled load at the
rated capacity of this washing machine.
Maximum capacity
NA-F80VB7 NA-F75S7 NA-F70S7
Everyday
clothes Daily washing 1Normal (P. 7) 8.0 kg7.5 kg7.0 kg
Delicates
Washing
delicates gently
2
Delicate
(P. 8)
3.5 kg3.5 kg3.5 kg
Clothes for babies &
people with sensitive skin
Rinsing
thoroughly 3
Baby-care
(P. 7)
8.0 kg7.5 kg7.0 kg
Using extra
softener Stronger scent 4
Fragrance
(P. 7)
8.0 kg7.5 kg7.0 kg
Blankets 5
Blanket
(P. 8)
4.2 kg4.2 kg4.2 kg
Heavily soiled
clothes
Presoaking to
wash 6
Soak (P. 7) 8.0 kg7.5 kg7.0 kg
Saving energy and time
* Reduces the power consumption
of
1
Normal program by 5 %.
Speedy
washing for light
soil
7
Energy Save
(Speedy) (P. 7)
8.0 kg7.5 kg7.0 kg
Saving water
* To rinse thoroughly, use the 1Normal or
3Baby-care program.
8
Water Save
(P. 7)
8.0 kg7.5 kg7.0 kg
Tub cleaning
Preventing
black mould
and smell
9Air Dry (P. 9)
― ― ―
10
Tub Hygiene
(P. 11)
If black mould or
smell is present 10
Tub Hygiene
(P. 11)
― ― ―
Drying synthetic bre clothes 9Air Dry (P. 9) 2.0 kg2.0 kg2.0 kg
Operation Panel Variety of Programs

6
Detergent
Putting in bleach
●Do not use chlorine bleach for coloured clothes to
prevent loss of colour.
●After using chlorine bleach, wash the tub with the
10 Tub Hygiene program without bleach. (P. 11)
●Do not use bleach for the 2Delicate program.
Putting in softener
● Softener is automatically released during the nal
rinse process.
●To add softener during operation, press “Pause”
rst.
●Up to about 40 ml can be added. To add more
softener, use the 4Fragrance program.
●When using
concentrated softener,
dilute it with water
before putting it in.
NOTE
●Softener cannot be used with the 8Water Save
program.
● Do not use separated or solidied softener.
●If “Pause” is pressed during spin cycle, the softener
will be added too early and its e󰀨ectiveness will
decrease.
●The softener will not be added automatically if not
put in by the time wash process is complete.
Concentrated
softener Water
Put in detergent, bleach and
softener according to the water
level displayed.
●Follow the instructions on each package.
■Powder detergent/bleach
■Softener
■Liquid detergent/bleach
Putting in detergent
●When powdered detergent is poorly soluble, dissolve
in warm water before putting in.
Water of approx. 30 ºC
(approx. 5 L)
• Put in the detergent little
by little while stirring to
prevent it from getting
hard or remaining in a
powder state.
●If there are many thick or large clothes (jeans,
sheets, etc.) in the tub, the detergent may remain
undissolved. Dissolve the detergent according to the
above method, or reduce the amount of laundry.
●In case of excessive foaming, reduce the amount of
detergent or change the detergent.
●Turn the tub by
hand if it is di󰀩cult
to put in the softener
inlet. (P. 10)

7
Washing
Preparation:
●Check if the washing machine is properly installed. (P. 12)
●Turn on the water faucet.
1After loading laundry
Turn the power on.
2Select a program.
(P. 5)
e.g.) 1Normal
program
■Timer preset
3Start.
The pulsator moves without water
and measures the amount of
laundry (approx. 5 seconds).
Water level indication
(approx. 5 seconds)
Water begins to be supplied.
Remaining time indication
●To check the water level
→Press “Water Level”.
●To check the program
→Press “Program”.
4According to the water level indication
Put in detergent.
5Close the lid.
Operation ends with beeps.
Set how many hours later to nish
operation. (P. 4)
●2 minutes after start-up, all indications except
“Preset” turn o󰀨.
● To conrm after the timer has been set, press
“Preset”.
● To cancel or change, press “On/O󰀨”.
● The hours that can be set di󰀨er depending on
the program.
When the 4Fragrance program is
selected
The buzzer sounds before the nal rinse and
operation is paused. Put the desired amount of
softener which has been diluted with water directly
into the tub.
5 beeps
● If the lid is left closed, the buzzer sounds every
10 minutes for up to 1 hour.
●If the lid is left closed for more than 1 hour,
operation resumes.
●The 4Fragrance program cannot be selected
when Child Lock (P. 10) is set.
■After pressing “Start”
●You can change the water level until the end of
the wash process.
●You cannot change the program.
Timer preset 213
• Operation panel of NA-F80VB7
WashingDetergent

8
Washing Options
Blanket
■Washable blankets
• Material: 100 % synthetic bre or 100 % cotton
• Weight: 4.2 kgor less
• Blankets with a machine-washable tag attached
●Put a blanket in the net and load it in the tub.
Roll ● The zipper part
should face up.
(To prevent
damage to the net)
NOTE
●Use liquid detergent.
●The water level indication shows the maximum and
cannot be changed.
Delicate
Use this program to gently wash delicate
clothes and stylish garments.
Load laundry evenly.
● Load lighter items rst and press
them from above.
●Use laundry nets for delicate
underwear only.
●Amount that can be washed at
one time:
42 L 3.5 kg
37 L 2.0 kg
NOTE
●Do not use bleach.
●Use liquid delicate detergent.
●After operation ends, take out clothes immediately.
(To prevent wrinkles and colour staining)
Change process settings Select a program
• Operation panel of NA-F80VB7

9
Wash / Rinse / Spin
Preparation: Turn on the water faucet.
1After loading laundry
Turn the power on.
2According to your purpose
Change process
settings.
●Change the water level as
necessary.
●You cannot select rinse process
alone.
3After closing the lid
Start.
Operation ends with
beeps.
Air Dry
Water is removed from clothes by the air
blown from the tub rotation.
■Clothes that can be dried
• Material: Synthetic bre
• Weight: 2.0 kgor less
1After loading clothes and closing the lid
Turn the power on.
2Select 9Air Dry
program.
3Start.
After 90 minutes, drying
ends with beeps.
NOTE
● Clothes may not be su󰀩ciently dried depending on
the amount and type of clothes, the temperature, and
the installation condition of the washing machine.
●Since no heater is used for this function, you may
feel that clothes are cold and half dry.
Contents of Programs
Program Total time
(approx.) Wash Rinse Spin
1Normal 55 min 14 min Twice 4 min
2Delicate 35 min 3 min Twice 1 min
3Baby-care 50 min 8 min Twice 4 min
4Fragrance 70 min 12 min Twice 5 min
5Blanket 60 min 12 min Twice 5 min
6Soak 120 min 1) 84 min 2) Twice 4 min
7Energy Save (Speedy) 45 min 12 min Twice 4 min
8Water Save 50 min 12 min Twice 5 min
10
Tub Hygiene 135 min 1) 63 min Twice 30 min
NOTE
●Total time is an estimation.
(When the standard water supply rate is
15 L / min)
●Total time may increase depending on low water
pressure, bad draining conditions, and the amount
and type of clothes.
1) Remaining time of 90 minutes or less will be
displayed.
2) This includes soaking time and washing time.
Washing Options

10
Maintenance Convenient Functions
Cancelling end buzzer
1Pressing down,
press.
Then hold on for
3 seconds. 2 short
beeps
●To reset, do the same procedure.
4 short
beeps
Setting Child Lock
To prevent children from falling into the tub and
drowning, if the lid is opened while the washing
machine is operating, this function sounds a buzzer
until it is closed. Not closing it within 10 seconds
ushes the water out.
●This function does not lock the lid and button operations.
●When water is drained forcibly, “U 99” is displayed.
(P. 15)
1After closing the lid
Turn the power on.
2Press and hold for
5 seconds. 2 short
beeps
●To cancel, do the same procedure. 4 short
beeps
Turning the tub by hand
If it is di󰀩cult to reach the softener inlet.
1Turn the power on.
2When a clicking sound is heard
Turn the tub.
(Clockwise only)
NOTE
●If there is water in the tub or “Start” is pressed, the
tub cannot be turned.
Lint lter
After each operation
Lint lter
1Remove the
lter.
2Open the lter
and remove
lint.
● If lint is di󰀩cult to
remove, soak and
wash the lter in
water.
3Attach the lter in its original
position.
12
34Click
NOTE
● Do not wash laundry without the lter.
(To prevent damage to clothes)
● Turn the tub by hand if it is di󰀩cult to remove the
lter.
● If the lter is broken, purchase a new one at nearest
Panasonic Service Centre.

11
Water supply lter
If water does not ow smoothly
●Follow the procedure below to prevent
splashing of water.
1After turning o󰀨 the water faucet
Turn the power
on.
2Start.
3After approx. 10 seconds
Turn the power o󰀨.
4Loosen the
nut and
remove the
hose.
5Remove the lter and remove
dirt on the lter.
Water supply lter
Main unit, lid
If stained with detergent or softener
Wipe with a soft cloth.
(To prevent damage to resin parts or metal corrosion)
●For heavy soil, wipe with a neutral kitchen detergent.
●Do not splash water.
Tub
Once a week <Air Dry>
1After operation ends
Run the 9 Air Dry program
without loading laundry.
(P. 9)
Once a month <Tub Hygiene>
Preparation: Turn on the water faucet.
1Without loading laundry
Turn the power on.
2Select the
10
Tub
Hygiene program.
3Start.
When the tub is lled with water
Pause.
4Put bleach in the tub.
●Use chlorine bleach for
clothes.
Approx. 200 ml
5After closing the lid
Start.
After approx. 2 hours, tub
cleaning ends.
Convenient Functions Maintenance

12
Installation
2. Attach the bottom cover.
Preparation: Set a cardboard, etc. and lay the washing
machine on it, avoiding product damage and
deformation. (Face the front side down.)
1I
nsert the bottom cover with its
screw hole set at the bottom.
Screw hole
2
Set 6 holes to the corresponding
projections and x with one screw.
Screw hole
Projection
1Connect.
Insert all the way.
2Slide the
hose band
in the arrow
direction.
●Slide all the way
until it stops.
Hose band
NOTE
●Do not put the
hose tip under
water.
●Do not raise the
hose higher than
10 cm above the
oor.
10 cm or
less
●Do not extend the
overall length to
more than 3 m.
3 m or less
1. Check the location.
■Avoid the following locations for installation.
• Locations with a possibility of freezing
• Damp locations or locations where it may be exposed to rain, etc.
(To prevent electric shock or re)
• Locations exposed to direct sunlight
(To prevent malfunction or deformation)
• Uneven or unstable locations
(on blocks, timbers, a table with wheels, etc.)
External drain
water hose
Water
supply hose
Water tap adaptor
Water supply
valve screw
Bottom cover
3. Attach the external drain water hose.

13
■Make sure to ask a service person for installation. Do not install by yourself.
■If the installation, test run and inspection of the washing machine are not carried out following this installation
method, Panasonic will not be liable for any accident or damage caused.
4. Connect the water tap adaptor and water supply hose.
1Connect the water tap
adaptor to the water
faucet.
1Turn part A to the left until approx. 4
mm of the thread becomes visible.
2Loosen the 4 screws.
3Connect to the faucet and tighten
the screws.
4Turn part A to the right and tighten
securely. (To prevent water leakage)
2Connect the water supply
hose to the water tap
adaptor.
Insert the hose into the adaptor while
pushing down the lever, and hook the
claw of the lever on the ange of the
adaptor.
3Connect the water supply
hose to the water supply
valve screw.
1
Hold the elbow and tighten the nut.
2Check that the elbow is not loose.
Water faucet
Water supply hose
Water tap adaptor
CAUTION
● Tighten the nut rmly.
●Do not twist, squash, modify
or cut the hose.
Part A
Flange
Thread
Lever
Claw
Screw
5. Connect the power plug and grounding wire.
●Ask a service person to do the grounding work.
●In case of a 2-pin power cord, establish a ground.
6. Check that the washing machine does not wobble.
■If the washing machine wobbles
3Turn to the right to
tighten.
1Turn the adjustable leg knob to
the left to loosen.
2Turn the adjustable
leg to eliminate
wobble.
To lowerTo raise
7. Perform a trial operation.
●Check that there is no water leakage, abnormal sounds or error display.
Elbow
Water supply hose
Nut
Water supply
valve screw
Installation

14
Troubleshooting
Symptoms Points to be checked
Time
Time indication
increases or does not
change
●Time indication is approximate. Remaining time is corrected during
operation and displayed.
Operation time is longer
than the time indication.
Operation does not stop
even after the preset time.
●The operation time may be longer if laundry is concentrated on one
side or the water supply or drainage is not good.
(P. 15 “U 11” “U 14”)
Main unit
No operation
●Power failure?
●Is the lid closed completely?
●Has the power fuse blown or the breaker tripped?
●Is the power plug inserted completely?
●Is the water faucet turned on?
●Did you press “Start”?
●Is the timer preset?
Wash
No water supply
●Is the water faucet turned on?
●Water outage?
● Is the water supply lter clogged with dirt? (P. 11)
Water is supplied in the
middle of wash process.
●If the water level drops, water is added automatically.
●With a large amount of laundry, water is added several times
automatically.
The water level is too
high for the amount of
laundry.
●If laundry is wet or there is water in the tub before operation, the
water level may be higher.
The water level is too
low for the amount of
laundry.
● With light clothes (of synthetic bre, etc.), the water level may be
lower.
Rinse/Spin
Operation started with
rinse, but water is not
supplied.
●If there is no water in the tub, water is supplied after spin.
●If there is water in the tub, water is supplied after water discharge.
Operation suddenly
changes to rinse process
in the middle of spin.
Only spin is desired, but
operation starts with
rinse.
●If clothes are concentrated on one side of the tub, the washing
machine automatically corrects unevenness by starting rinse
process.
(Place clothes as evenly as possible.)
Irregular rotation during
spin ●The tub rotation speed is adjusted to reduce foaming during spin.
Others
Power failure/
The breaker has tripped.
●Operation will resume from the point where it was stopped when the
power is recovered (Auto Restart).
Water outage
●When water supply is recovered, remove the water supply hose,
release turbid water from the faucet, and then start the washing
machine.
Cannot select the
4Fragrance program.
●If Child Lock (P. 10) is set, the 4Fragrance program cannot be
selected.
Operation stops in the
middle of wash or rinse
process.
● Is the lamp ashing?
→The pulsator occasionally stops to soak clothes while the lamp
keeps ashing. This is not abnormal.

15
Error Display
● The buzzer sounds and “U”/“H” and a number are alternately displayed.
●Cancel Child Lock (P. 10) if it is set.
Error display Points to be checked
Water cannot drain.
Check the drain water hose for the following abnormalities:
●Is it crushed?
●Is it clogged with lint?
●Is the hose tip under water?
● Is it partially raised higher than 10 cm above the oor? (P. 12)
●Is the total length longer than 3 m (including the extension hose)? (P. 12)
When the above problems are solved, you can resume operation by opening and
closing the lid.
The lid is open.
●Did you try to run the washing machine with the lid open?
→Close the lid.
Spin or Air Dry is not possible.
●Are clothes concentrated on one side of the tub?
→Distribute the clothes evenly and close the lid.
●Is the washing machine installed on an unstable or
inclined surface?
→ You can resume operation by opening and closing
the lid.
Water cannot be supplied.
●Is the water faucet turned on?
●Water outage?
● Is the water supply lter clogged with dirt? (P. 11)
→You can resume operation by opening and closing the lid.
Water has been forcibly drained.
●Water has been forcibly drained because the lid was open for 10 seconds or more
with Child Lock (P. 10) set.
→ Unplug the power cord and plug it in again after 5 seconds.
Inspection is required.
●Unplug the power cord. Then, report the error displayed (2-digit number after “H”)
to a service person.
Troubleshooting Error Display

16
Specications
NA-F80VB7 NA-F75S7 NA-F70S7
Rated voltage 220 - 240 V
Rated frequency 50 Hz
Rated power consumption 450 W
Standard water amount 55 L 53 L 52 L
Maximum capacity (Dry cloth) 8.0 kg7.5 kg7.0 kg
Product dimensions 525 mm (W) × 571 mm (D) × 929 mm (H)
Product weight 28 kg
Pressure of tap water 0.01 - 1 MPa
http://www.panasonic.com
© Panasonic Appliances Vietnam Co., Ltd. 2015

No. Model NA-F80VB7
NA-F75S7
NA-F70S7
Kandungan
Langkah Berjaga-jaga
Keselamatan 2
Nama Bahagian 3
Panel Operasi 4
Pelbagai Program 5
Detergen 6
Membasuh 7
Pilihan Membasuh 8
• Delicate (Halus)
• Blanket (Selimut)
• Air Dry (Kering Udara)
• Wash (Basuh) / Rinse
(Bilas) / Spin (Perah)
Fungsi Menyenangkan 10
Penyenggaraan 10
Pemasangan 12
Penyelesaian Masalah 14
Paparan Ralat 15
6SHVL¿NDVL 16
Terima kasih kerana membeli
produk ini.
-Untuk mendapatkan prestasi
dan keselamatan yang optimum,
sila baca arahan ini dengan teliti
sebelum menggunakan.
-Simpan manual ini untuk rujukan
pada masa akan datang.
W9901-9NT30
A0415-3109(M)
Dicetak di Vietnam
10-2019
:17
Arahan Pengendalian &
Pemasangan
Mesin Basuh Automatik Sepenuhnya
(Kegunaan domestik)

2
Langkah Berjaga-jaga Keselamatan
Boleh
mengakibatkan
kecederaan serius
atau kematian.
Jangan lakukan perkara berikut
terhadap palam dan kord kuasa
(Untuk mencegah kebakaran atau kejutan elektrik)
ƔJangan pasang atau cabut palam menggunakan
tangan yang basah.
ƔJangan pegang atau tarik kordnya apabila hendak
menanggalkan palam kuasa.
ƔJangan gunakan kord atau palam kuasa yang
rosak. Jika kord kuasa rosak, ia mesti diganti
oleh pengilang, wakil servisnya, atau orang yang
berkelayakan bagi mengelakkan bahaya.
Patuhi perkara berikut berhubung
palam dan kord kuasa
(Untuk mencegah kebakaran atau kejutan elektrik)
ƔGunakan soket khas yang memenuhi keperluan
kadaran untuk mesin basuh ini. Jangan gunakan
penyesuai palam atau kord pemanjangan.
ƔSentiasa cucukkan palam kuasa sehingga santak ke
dalam soket.
ƔLap palam kuasa secara berkala menggunakan
kain yang kering. (Habuk yang terkumpul akan
memerangkap lembapan, yang boleh menyebabkan
kegagalan penebatan, lalu mengakibatkan
kebakaran.)
ƔCabut kord kuasa sebelum membersihkannya.
Jangan ungkai, baiki atau ubah suai
sendiri mesin basuh ini.
ƔSekiranya mesin mengalami pincang tugas atau
gagal berfungsi sila berhenti menggunakannya
serta-merta, cabut talian kuasa dan hubungi pusat
perkhidmatan terdekat anda untuk dibaiki.
Jangan benarkan kanak-kanak
menggunakannya sendirian.
ƔPerlengkapan ini bukan untuk kegunaan individu
WHUPDVXNNDQDNNDQDN\DQJNXUDQJNHXSD\DDQ¿
zikal, deria atau mental, atau kurang pengalaman
atau pengetahuan, kecuali jika mereka telah
diberikan penyeliaan atau arahan berkaitan
penggunaan perlengkapan ini oleh individu yang
bertanggungjawab keatas keselamatan mereka.
ƔKanak-kanak harus diperhatikan untuk memastikan
yang mereka tidak bermain dengan perlengkapan
ini.
Jauhkan daripada api.
Jangan masukkan benda yang
mudah terbakar atau pakaian yang
mempunyai barangan sedemikian
ke dalam tab.
Jauhkan dari mesin basuh.
(Untuk mencegah letupan atau kebakaran)
ƔContohnya: Minyak tanah, petrol, benzina/pencair,
alkohol, dll.
Jangan sentuh tab sehingga ia
betul-betul berhenti.
(Untuk mencegah kecederaan)
ƔJika tab tidak berhenti dalam masa 15 saat apabila
penutup dibuka semasa proses memerah, matikan
mesin basuh dengan segera dan hubungi juruservis.
Pastikan anda menyediakan tempat
pembumian.
(Untuk mencegah kejutan elektrik oleh litar pintas)
ƔMinta juruservis untuk melakukan kerja pembumian.
ƔSekiranya ia mempunyai kord kuasa 2 pin, sila
bumikan.
Jauhkan magnet dan objek
bermagnet dari panel operasi.
Tab boleh berputar walaupun penutup terbuka, dan
mengakibatkan kecederaan.
Sila baca dan ikut langkah berjaga-jaga keselamatan ini.
AMARAN

3
Nama Bahagian
Pulsator
Penapis rumbai
(H. 10)
Penutup
Tab
Panel
Operasi
(H. 4)
Tempat masuk
cecair pemutih /
detergen (H. 6)
Kord dan
palam kuasa
(H. 13)
Inlet
pelembut
(H. 6)
Kaki boleh laras
(H. 13)
Hos air saliran luar
(H. 12)
Injap pembekal air
(H. 13)
Kelengkapan
ƔHos
pembekal
air (1)
ƔPenyesuai
pili air (1)
ƔHos air saliran
luar (1)
ƔPenutup bawah (1) ƔSkru (1)
Dilampirkan
dengan pita.
Mengakibatkan
kecederaan atau
kerosakan harta
benda.
Jangan basuh, bilas atau perah kain
atau pakaian yang kalis air.
(Untuk mencegah kecederaan, kerosakan kepada
unit utama, dinding, lantai atau kain basuhan, atau
kebocoran air jika mesin basuh tergolek atau berputar
terlalu laju semasa berpusing)
ƔBaju hujan, sut basah, dll.
Perhatikan perkara berikut
ƔAnda hendaklah menggunakan set hos baru yang
dibekalkan dengan mesin basuh ini dan jangan
gunakan semula set hos yang lama.
ƔBerhati-hati agar jari anda tidak tersepit semasa
membuka dan menutup penutup.
ƔJangan masukkan tangan atau kaki anda ke bawah
unit utama.
(Untuk mencegah kecederaan jika tersentuh
bahagian yang berputar)
ƔJangan panjat atau letakkan benda berat di atas
mesin basuh.
(Untuk mencegah ia berubah bentuk dan pecah, lalu
mengakibatkan kecederaan)
ƔJika penutupnya rosak, berhenti menggunakan mesin
basuh dengan serta-merta.
(Untuk mencegah ia berubah bentuk dan pecah, lalu
mengakibatkan kecederaan)
ƔJangan sambungkan kepada bekalan air panas.
ƔJangan curah air panas bersuhu 50 ºC atau lebih
terus ke dalam tab.
ƔJangan halang bukaan muka bawah dengan karpet,
dll.
Tutup paip air selepas operasi selesai.
(Untuk mencegah kebocoran air)
Mesin basuh ini hanya sesuai untuk
tekstil yang dilabelkan sebagai
boleh dibasuh dengan mesih basuh.
AWAS
Langkah Berjaga-jaga
Keselamatan Nama Bahagian

4
Panel Operasi
• Panel Operasi NA-F80VB7
Pemilihan program (H. 5)
Basuh / Bilas / Perah
(H. 9)
Mula/Jeda
Lampu Kunci Kanak-kanak (H. 10)
Auto Hidup Semula
Sekiranya bekalan kuasa
terputus semasa operasi,
operasi akan bersambung
semula di mana ia berhenti
apabila kuasa pulih.
Tukar jumlah air
Semasa proses membasuh, tekan “Water
Level (Paras air)” untuk menukar jumlah
air.
ƔBeberapa jumlah air tidak boleh dipilih
bergantung kepada program.
ƔApabila masa yang tinggal dipaparkan,
tekan “Water Level (Paras air)” untuk
memeriksa jumlah air.
Jumlah air /
Baki masa
Menunjukkan program yang dipilih (No.)
Selepas memulakan operasi, ia
menunjukkan jumlah air mengikut
jumlah basuhan.
Selepas kira-kira 5 saat, ia menunjukkan
anggaran baki masa (min).
Pratetapan
Tetapkan masa untuk menyiapkan
pencucian (dalam jam).
cth.) 8 jam
kemudian
ƔJulat tetapan: 2 - 24 jam kemudian,
dalam tokokan satu jam.
(3 - 24 jam kemudian untuk program
6Soak (Rendam))
ƔTidak boleh dipilih untuk program-
program berikut:
2Delicate (Halus)
4Fragrance (Harum)
9Air Dry (Kering Udara)
10
Tub Hygiene (Kebersihan Tab)
Kuasa Hidup
/ Mati
Kuasa akan mati
secara automatik
jika anda tidak
menekan “Start
(Mula.) / Pause
(Jeda.)” dalam
masa 10 minit
selepas kuasa
hidup.
Jumlah air /
Isi padu detergen
Garis panduan jumlah detergen yang
sepadan dengan tanda paras air
ditunjukkan di bawah.
( : 1 sudu detergen)
Isipadu detergen
Jumlah air
