Panduit MSPT-1.3 User manual

MSPT-1.3
PA26214A01
Rev. 01 18-Sep-09
© Panduit Corp. 2009
TOOL SPECIFICATIONS.......................................................................................... 1
Safety ........................................................................................................................ 1
PRECAUTIONS AND GENERAL GUIDELINES ...................................................... 2
TOOL OPERATION .................................................................................................. 3
Bushings.................................................................................................................... 3
MAINTENANCE ........................................................................................................ 3
SPARE PARTS LISTING .......................................................................................... 5
Website: www.panduit.com
Email: [email protected]
Panduit Corp. • USA Headquarters • Tinley Park, IL
Tel: [phone], ext. 3255 • Fax: [phone]

MSPT-1.3
MSPT-1.3: PA26214A01_01 Page: 1 of 5 18-Sep-09
The Panduit MSPT-1.3 Stud Punch tool punches a 34.1 mm (1-11/32") round hole
in 25 GA. min. to 20 GA max. mild steel studs.
TOOL SPECIFICATIONS
7.0 lbs. (3.2 kg)
NOTE: In the interest of higher quality and value, Panduit products are continually being
improved and updated. Consequently, pictures may vary from the enclosed product.
Safety
Safety is essential in the use and maintenance of Panduit tools and equipment. This manual and any
markings on the tool provide information for avoiding hazards and unsafe practices related to the use of
this tool. Observe all of the safety information provided.

MSPT-1.3
MSPT-1.3: PA26214A01_01 Page: 2 of 5 18-Sep-09
PRECAUTIONS AND GENERAL GUIDELINES
This symbol is used to call your attention to hazards or unsafe practices which could result in an
injury or property damage. The signal word, defined below, indicates the severity of the hazard.
The message after the signal word provides information for preventing or avoiding the hazard.
WARNING Hazards which, if not avoided, COULD result in severe injury or death.
CAUTION Hazards or unsafe practices which, if not avoided, MAY result in injury or
property damage.
WARNING
Read and understand all of the instructions and safety information in this manual
before operating or servicing this tool.
WARNING
Wear eye protection when operating or servicing this tool.
Failure to wear eye protection can result in serious eye injury from flying debris.
WARNING
Electric Shock Hazard:
This tool is not insulated. When using this unit on or near energized electrical lines,
use proper personal protective equipment.
CAUTION
Inspect the tool prior to use. Replace worn, damaged or missing components with replacement parts.
A damaged or improperly assembled tool may break. Use this tool for manufacturer’s intended use
only. Use other than that which is described in this manual may result in injury or damage to the tool.
CAUTION
Do not add extensions (cheaters) to the handles. Using excessive force may result in injury or
damage to the tool. If excessive force is required to complete a punch, verify that the type and
thickness of material do not exceed the capacity of the tool.
IMPORTANT INFORMATION
Do not use on heavier than 20 gauge mild steel.

MSPT-1.3
MSPT-1.3: PA26214A01_01 Page: 3 of 5 18-Sep-09
TOOL OPERATION
Position the punch on the metal stud. Squeeze the handles together. The slug will fall free when the
hole is complete.
Bushings
Bushings are available for the holes punched by the MSPT-1.3 tool. Bushings protect wire insulation
from the sharp edges of the metal stud. Complies with NEC Article 300-4(b)(1).
Fig. A
Panduit Part No. Description Qty.
MSG-1.3-C
Metal Stud Grommet
for 1-11/32” hole
(see Fig. A)
100 pc. Pack
MSG-1.3-M 1,000 pc. Pack
Fig. B
MSGV-1.3-C Metal Stud Grommet
for 1-11/32” hole
(Anti-vibration; for
½” to 1” pipe)
(see Fig. B)
100 pc. Pack
MSGV-1.3-M 1,000 pc. Pack
MAINTENANCE
Lubricate all moving parts with light weight oil.
To replace the punch, refer to the illustration on the next page, and follow this procedure:
1. Remove the locknut (A) from the pivot bolt (B),
and then remove the pivot bolt from the punch holder (8).
2. Remove the entire punch holder shaft and sleeve from the C-frame.
3. Depress the sleeve and unscrew the punch from the punch holder.

MSPT-1.3
MSPT-1.3: PA26214A01_01 Page: 4 of 5 18-Sep-09
MSPT-1.3 ILLUSTRATION
NOTE: All parts shown for
reference only.
Consult factory for lead time and
part availability.

MSPT-1.3
MSPT-1.3: PA26214A01_01 Page: 5 of 5 18-Sep-09
MSPT-1.3 STUD PUNCH SPARE PARTS LISTING
KEY PART # DESCRIPTION QUANTITY
50212850 Stud punch complete
1 52027489 Lever unit 1
2 Link (see below for service parts) 1
4 Locknuts 3
5 50213032 Washer, flat .968 x 1.62 x .062 1
6 50215574 Spring, compression 1
9 90513614 Retaining ring, .865; Truarc #5100-93-S-PP 1
12 50248235 Punch, conduit 1
13 50212974 Die 1
14 52027490 Handle, green 1
15 C-Frame unit 1
17 90507649 Screw, set, 1/4–20 x .375 socket w/locking patch 1
18 90506170 Screw, set, 1/4–20 x .250 socket w/locking patch 1
20 Bolts, pivot, 1/4 x 20 3
25 50213016 Bushing 1
MSPT-1.3 STUD PUNCH REPAIR KITS LISTING
50060155 Pin kit (includes items 4 and 20)
50059327 Link kit (includes items 2, 4 and 20)
** 52026022 Sliding mechanism service kit (includes items 7 and 8)
** Use one flat washer (50213032), as shown in the illustration, when replacing the punch holders.
For ordering parts, call 1-888-506-5400, ext. 3226.
