INSTALLATION INSTRUCTIONS
For Technical Assistance call: 866-405-6656
TWO GANG DEEP JUNCTION BOX
CONDUIT APPLICATION
POWER/DATA APPLICATION
RECTANGULAR
BREAKOUT
The mounting hardware used to secure the base shall be appropriate for the mounting surface
IN-WALL BOX APPLICATION
1/2”(12.7mm)
3/4”(19.05mm)
RECTANGULAR
BREAKOUT
RACEWAY
BREAKOUTS
DIVIDED INSERT APPLICATION
CABLE / ENTRANCE
BREAKOUTS (SOLD SEPARATELY)
OPTIONAL USE
FOR DATA
1”(25.4mm)
DATA
POWER
FOR USE WITH PANDUIT
SURFACE RACEWAY
ROUTING SYSTEM
Part Numbers: JBP2D, JBD2

BASE BREAKOUTS
POWER JUNCTION BOX INSTALLATION INSTRUCTIONS
Instruction Sheet RW04D
COVER BREAKOUTS
COVER RACEWAY ADAPTER
