INSTALLATION GUIDE
USB Light Strip Kit (ACD01)
The USB Light Strip Kit is designed to illuminate the inside of a cabinet to improve visibility when the cabinet door is open.
The Light Strip also provides added security by signaling when the cabinet door is opened.
Note: The USB Light Strip Kit is only designed to connect to a G5 iPDU. Connecting it to another device may
result
in damage.
INVENTORY
Door Switch
Sensor
USB Light Strip
Cable Ties
Double-Sided
Tape
Adhesive
Backed Mounts
Screws
