Panduit AT-OMNI-111-WP User manual

Atlona Manuals
Networked AV
AT-OMNI-111-WP
Wallplate Networked AV Encoder
OmniStream™

AT-OMNI-111-WP 2
Version Information
Version Release Date Notes
1 Sep 2019 Initial release

AT-OMNI-111-WP 3
©2019 Atlona, Inc. All Rights Reserved. All trademarks are the property of their respective owners.
Atlona reserves the right to make changes to the hardware, packaging, and documentation without notice.
Thank you for purchasing this Atlona product. We hope you enjoy it and will take a extra few moments to register
your new purchase.
Registration only takes a few minutes and protects this product against theft or loss. In addition, you will receive
notications of product updates and rmware. Atlona product registration is voluntary and failure to register will not
aect the product warranty.
To register your product, go to http://www.atlona.com/registration
Sales, Marketing, and Customer Support
Welcome to Atlona!
Operating Notes
IMPORTANT: Visit http://www.atlona.com/product/AT-OMNI-111-WP for the latest rmware
updates and User Manual.
Main Oce
Atlona Incorporated
70 Daggett Drive
San Jose, CA 95134
United States
Oce: +1.877.536.3976 (US Toll-free)
Oce: +1.408.962.0515 (US/International)
Sales and Customer Service Hours
Monday - Friday: 6:00 a.m. - 4:30 p.m. (PST)
http://www.atlona.com/
International Headquarters
Atlona International AG
Ringstrasse 15a
8600 Dübendorf
Switzerland
Oce: [phone]
Sales and Customer Service Hours
Monday - Friday: 09:00 - 17:00 (UTC +1)
• The Atlona Management System (AMS) is a free downloadable application from Atlona that provides network
conguration assistance for this product. This application is available only for the Windows® Operating System
and can be downloaded from the Atlona web site.
NOTE: Scaling and deinterlacing is not supported at 1080i.

AT-OMNI-111-WP 4
Atlona, Inc. (“Atlona”) Limited Product Warranty
Coverage
Atlona warrants its products will substantially perform to their published specications and will be free from defects
in materials and workmanship under normal use, conditions and service.
Under its Limited Product Warranty, Atlona, at its sole discretion, will either:
• repair or facilitate the repair of defective products within a reasonable period of time, restore products to their
proper operating condition and return defective products free of any charge for necessary parts, labor and
shipping.
OR
• replace and return, free of charge, any defective products with direct replacement or with similar products
deemed by Atlona to perform substantially the same function as the original products.
OR
• refund the pro-rated value based on the remaining term of the warranty period, not to exceed MSRP, in cases
where products are beyond repair and/or no direct or substantially similar replacement products exist.
Repair, replacement or refund of Atlona products is the purchaser’s exclusive remedy and Atlona liability does not
extend to any other damages, incidental, consequential or otherwise.
This Limited Product Warranty extends to the original end-user purchaser of Atlona products and is non-transferrable
to any subsequent purchaser(s) or owner(s) of these products.
Coverage Periods
Atlona Limited Product Warranty Period begins on the date of purchase by the end-purchaser. The date contained on
the end-purchaser ‘s sales or delivery receipt is the proof purchase date.
Limited Product Warranty Terms – New Products
• 10 years from proof of purchase date for hardware/electronics products purchased on or after June 1, 2013.
• 3 years from proof of purchase date for hardware/electronics products purchased before June 1, 2013.
• Lifetime Limited Product Warranty for all cable products.
Limited Product Warranty Terms – Refurbished (B-Stock) Products and Discontinued Products
• 3 years from proof of purchase date for all Refurbished (B-Stock) and Discontinued hardware and electronic
products purchased on or after June 1, 2013.
Remedy
Atlona recommends that end-purchasers contact their authorized Atlona dealer or reseller from whom they
purchased their products. Atlona can also be contacted directly. Visit atlona.com for Atlona’s contact information
and hours of operation. Atlona requires that a dated sales or delivery receipt from an authorized dealer, reseller
or end-purchaser is provided before Atlona extends its warranty services. Additionally, a return merchandise
authorization (RMA) and/or case number, is required to be obtained from Atlona in advance of returns.
Atlona requires that products returned are properly packed, preferably in the original carton, for shipping. Cartons not
bearing a return authorization or case number will be refused. Atlona, at its sole discretion, reserves the right to reject
any products received without advanced authorization. Authorizations can be requested by calling 1-877-536-3976
(US toll free) or 1-408- 962-0515 (US/international) or via Atlona’s website at atlona.com.
Exclusions
This Limited Product Warranty excludes:
• Damage, deterioration or malfunction caused by any alteration, modication, improper use, neglect, improper
packaging or shipping (such claims must be presented to the carrier), lightning, power surges, or other acts of
nature.

AT-OMNI-111-WP 5
• Damage, deterioration or malfunction resulting from the installation or removal of this product from any
installation, any unauthorized tampering with this product, any repairs attempted by anyone unauthorized by
Atlona to make such repairs, or any other cause which does not relate directly to a defect in materials and/or
workmanship of this product.
• Equipment enclosures, cables, power supplies, batteries, LCD displays, and any accessories used in conjunction
with the product(s).
• Products purchased from unauthorized distributors, dealers, resellers, auction websites and similar unauthorized
channels of distribution.
Disclaimers
This Limited Product Warranty does not imply that the electronic components contained within Atlona’s products
will not become obsolete nor does it imply Atlona products or their electronic components will remain compatible
with any other current product, technology or any future products or technologies in which Atlona’s products may
be used in conjunction with. Atlona, at its sole discretion, reserves the right not to extend its warranty oering in
instances arising outside its normal course of business including, but not limited to, damage inicted to its products
from acts of god.
Limitation on Liability
The maximum liability of Atlona under this limited product warranty shall not exceed the original Atlona MSRP for
its products. To the maximum extent permitted by law, Atlona is not responsible for the direct, special, incidental or
consequential damages resulting from any breach of warranty or condition, or under any other legal theory. Some
countries, districts or states do not allow the exclusion or limitation of relief, special, incidental, consequential or
indirect damages, or the limitation of liability to specied amounts, so the above limitations or exclusions may not
apply to you.
Exclusive Remedy
To the maximum extent permitted by law, this limited product warranty and the remedies set forth above are
exclusive and in lieu of all other warranties, remedies and conditions, whether oral or written, express or implied.
To the maximum extent permitted by law, Atlona specically disclaims all implied warranties, including, without
limitation, warranties of merchantability and tness for a particular purpose. If Atlona cannot lawfully disclaim
or exclude implied warranties under applicable law, then all implied warranties covering its products including
warranties of merchantability and tness for a particular purpose, shall provide to its products under applicable law.
If any product to which this limited warranty applies is a “Consumer Product” under the Magnuson-Moss Warranty
Act (15 U.S.C.A. §2301, ET SEQ.) or other applicable law, the foregoing disclaimer of implied warranties shall not
apply, and all implied warranties on its products, including warranties of merchantability and tness for the particular
purpose, shall apply as provided under applicable law.
Other Conditions
Atlona’s Limited Product Warranty oering gives legal rights, and other rights may apply and vary from country to
country or state to state. This limited warranty is void if (i) the label bearing the serial number of products have been
removed or defaced, (ii) products are not purchased from an authorized Atlona dealer or reseller. A comprehensive
list of Atlona’s authorized distributors, dealers and resellers can be found at www.atlona.com.
Atlona, Inc. (“Atlona”) Limited Product Warranty

AT-OMNI-111-WP 6
FCC Statement
FCC Compliance and Advisory Statement: This hardware device complies with
Part 15 of the FCC rules. Operation is subject to the following two conditions: 1)
this device may not cause harmful interference, and 2) this device must accept any
interference received including interference that may cause undesired operation. This
equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a commercial installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed or used in accordance with the instructions, may cause harmful interference
to radio communications. However there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be determined by turning
the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following
measures: 1) reorient or relocate the receiving antenna; 2) increase the separation between the equipment and the
receiver; 3) connect the equipment to an outlet on a circuit dierent from that to which the receiver is connected;
4) consult the dealer or an experienced radio/TV technician for help. Any changes or modications not expressly
approved by the party responsible for compliance could void the user’s authority to operate the equipment. Where
shielded interface cables have been provided with the product or specied additional components or accessories
elsewhere dened to be used with the installation of the product, they must be used in order to ensure compliance
with FCC regulations.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this product near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8. Do not install or place this product near any heat
sources such as radiators, heat registers, stoves, or
other apparatus (including ampliers) that produce
heat.
9. Do not defeat the safety purpose of a polarized
or grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding
type plug has two blades and a third grounding
prong. The wide blade or the third prong are
provided for your safety. If the provided plug does
not t into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the
product.
11. Only use attachments/accessories specied by
Atlona.
12. To reduce the risk of electric shock and/or damage
to this product, never handle or touch this unit or
power cord if your hands are wet or damp. Do not
expose this product to rain or moisture.
13. Unplug this product during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualied service personnel.
Servicing is required when the product has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the product, the product has been
exposed to rain or moisture, does not operate
normally, or has been dropped.
CAUTION: TO REDUCT THE RISK OF
ELECTRIC SHOCK
DO NOT OPEN ENCLOSURE OR EXPOSE
TO RAIN OR MOISTURE.
NO USER-SERVICEABLE PARTS
INSIDE REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The exclamation point within an equilateral triangle is intended to alert the user to
the presence of important operating and maintenance instructions in the literature
accompanying the product.
The information bubble is intended to alert the user to helpful or optional opera-
tional instructions in the literature accompanying the product.
Important Safety Information

AT-OMNI-111-WP 7
Introduction 8
Features 8
Package Contents 8
Panel Description 9
Connection Instructions 10
Connection Diagram 11
Conguration 12
Accessing Encoders in AMS 12
Conguring a Static IP Address 16
Input Selection 17
Input Selection 17
Verifying the Input 18
Session Conguration 19
Basic Operation 20
LED Indicators 20
Rebooting OmniStream 21
Unicast Mode 22
Multicast Mode 24
802.1X Authentication 26
AES67 Audio 29
EDID Management 30
Selecting an EDID Preset 30
Using a Custom EDID 30
Copying an EDID from the Display 32
Encoder Grouping 35
Scrambling 37
Standard Method 37
Using the Virtual Matrix 38
Setting the Video Mode 39
Slate / Logo Insertion 40
Adding Slates / Logos 40
Deleting Slates / Logos 43
Text Insertion 44
The AMS Interface 45
Device Info page 45
Input page 47
Serial page 50
Session page 51
Network page 54
Other page 56
Logo 56
Text 57
PTP 58
The Virtual Matrix 60
Layout and Operation 61
Appendix 63
Updating the Firmware 63
FEC Details 65
Matrix Size, Overhead, and Latency 65
FEC and Video Bitrate 65
FEC, Latency, and Lip Sync 66
Specications 67
Table of Contents

AT-OMNI-111-WP 8
The Atlona OmniStream™ 111 Wallplate (AT-OMNI-111-WP) is a single-channel networked AV encoder for HDMI
2.0 sources up to 4K @ 60 Hz and HDR (High Dynamic Range), plus embedded audio. It features a US two-gang,
Decora-style wallplate form factor, and includes interchangeable black and white wallplates and faceplates. The
OmniStream 111 WP is part of the OmniStream Pro Series, designed for high performance, exible distribution
of AV over standard, o-the-shelf Gigabit Ethernet switches in commercial audiovisual applications. It is HDCP
2.2 compliant and ideal for the latest Ultra High-Denition and HDR sources. This networked AV encoder features
advanced high-quality, VC-2 visually lossless video compression technology with user-selectable, video quality
optimization engines designed for computer-generated imaging, or motion video content. The Atlona OmniStream
111 WP achieves extremely low, sub-frame latency when paired with OmniStream AV decoders.
With its wallplate form factor, the OmniStream 111 WP enables convenient installation wherever an aesthetically
appealing or discreet AV source connection is required.
Introduction
Features
Package Contents
1 x AT-OMNI-111-WP
1 x Black faceplate
1 x White Decora® wallplate
1 x Black Decora® wallplate
1 x 3.5 mm-to-DE-9 (M-F) cable
4 x Spare screws
1 x Installation Guide
• Best-in-class AV over IP performance and reliability
over Gigabit Ethernet.
• US two-gang enclosure for Decora-style wallplate
openings – interchangeable black or white trim kits.
• AV encoder for HDMI up to 4K/UHD, plus embedded
audio.
• Networked AV redundancy.
• Supports UHD @ 60 Hz plus HDR formats.
• High performance, visually lossless video
compression.
• HDCP compliance.
• Network error resilience with FEC (forward error
correction).
• Simplify integration with plug-and-play network
switch compatibility.
• Remote PoE (Power over Ethernet) powering.
• Secure content distribution with AES-128 encryption.
• Supports industry-standard, network security
features and protocols.
• AES67-compatible audio over IP streaming.
• Simultaneous OmniStream and AES67 audio
streaming.
• Enhance AV presentations with visual enhancements.
• EDID management.
• Encoder grouping.
• Audio processing and pass-through.
• System management.
• Award-winning 10 year limited product warranty.

AT-OMNI-111-WP 9
RS-232
AT-OMNI-111-WP
PWR
HDMI
LINK
RESET
TM
O MNI S TREAM
HDMI IN
ETHERNET
Panel Description
1
2 7 8
3
4
5
6
1 HDMI IN
Connect an HDMI cable from this port to an HD
source.
2 RS-232
This is a service port used for future management
purposes.
3 PWR
This LED indicator glows bright green when the
unit is powered.
4 HDMI
This LED indicator shows the input status.
5 LINK
This LED indicator is green when the link integrity
between the AT-OMNI-111-WP and the switch is
good.
6 RESET
Press and release this button to reboot the AT-
OMNI-111-WP. Note that this operation does not
reset the unit to factory-default settings.
7 ETHERNET
Connect an Ethernet cable from this port to the
Local Area Network (LAN).
8 Fan
This fan provides internal cooling by forcing hot air
from the wallplate chassis. Make sure adequate
ventilation is provided when installing the AT-
OMNI-111-WP.
Front Side Rear

AT-OMNI-111-WP 10
RS-232
AT-OMNI-111-WP
PWR
HDMI
LINK
RESET
TM
OMNISTREAM
HDMI IN
ETHERNET
Connection Instructions
Installation
PWR indicator
1. Connect an Ethernet cable from the ETHERNET port on the AT-OMNI-111-WP to a PoE-capable switch on the
Local Area Network (LAN).
2. Install the AT-OMNI-111-WP into a 2-gang electrical box or mud ring.
3. Attach the included Decora® wallplate to secure the AT-OMNI-111-WP to the wall/surface.
4. Connect an HDMI cable from a HD/UHD source to the HDMI IN port on the AT-OMNI-111-WP.
5. The PWR indicator, on the front panel, displays the power status. When the AT-OMNI-111-WP is powered, the
PWR LED initially turns red. After a few moments it will turn amber, and nally green.
6. The AT-OMNI-111-WP is now ready for operation.
IMPORTANT: The venting holes, surrounding the enclosure, along with the fan assembly on the
back of the unit, provides cooling by expelling warm air from the enclosure. To prevent overheating,
make sure these holes and the fan assembly are not blocked.

AT-OMNI-111-WP 11
Connection Diagram
Installation
Ethernet
Ethernet / PoE
Ethernet / PoE
Ethernet
Ethernet / PoE
Ethernet
Ethernet / PoE
Ethernet
HDMI
HDMI
HDMI
Ethernet
Ethernet
Ethernet / PoE
HDMI
HDMI
AT-OMNI-112
HDMI
PWR LINK
TM
O
MNI
S
TREAM
VOLUME
DISPLAY
INPUT
ID
1 2 1 2
AT-OMNI-122
1 2
ID
PWR LINK
TM
O
MNI
S
TREAM
Display
Display
Display
Display
Display
Laptop
Media Player
Camera
LAN
LAN
AT-OMNI-111-WP
LAN
HDMI
HDMI
AT-OMNI-122
1 2
ID
PWR LINK
TM
O
MNI
S
TREAM
HDMI
AT-OMNI-121
1 2
ID
PWR LINK
TM
O
MNI
S
TREAM
HDMIIN
AT-OMNI-111-WP
PWR
HDMI
LINK
RESET
TM
O
MNI
S
TREAM

AT-OMNI-111-WP 12
Accessing Encoders in AMS
It is recommended that the Atlona Management System (AMS) be used to congure and control OmniStream
devices. AMS uses multicast Domain Name Server (mDNS) to automatically discover each encoder on the network.
AMS is free and can be downloaded from https://www.atlona.com/ams.
By default, encoders are set to DHCP mode, allowing a DHCP server (if present) to assign the encoder an IP address.
Once an IP address has been assigned, the Atlona Management System (AMS) can be used to manage the product
on the network. Note that AMS will only be able to discover encoders if they are on the same VLAN.
In order for AMS to automatically assign multicast IP addresses to OmniStream encoders, the destination IP
addresses for the session streams must be cleared.
Conguration
NOTE: The following steps are required only if a pre-existing multicast IP address is assigned to
each session and if automatic assignment of these multicast IP addresses, using AMS, is desired.
1. Launch a web browser and enter the IP address of AMS, in the address bar.
2. Enter the required login credentials. The default login is:
Username: admin
Password: Atlona
3. Click the Login button.
4. The AMS Dashboard will be displayed.
5. Click the icon, in the upper-left corner of the AMS Dashboard.

AT-OMNI-111-WP 13
6. Click Devices from the y-out menu.
Conguration
Arrow buttons
7. Click the Unassigned option.
8. If the device isn’t immediately listed, click the left and right arrows, at the bottom of the Unassigned list, to scroll
through all available devices.

AT-OMNI-111-WP 14
All available encoders will be displayed under the Unassigned category. When an encoder is unassigned, it
means that it has not been assigned to a site, building, and/or room. Refer to the AMS User Manual for more
information on these topics.
If a DHCP server is not found within 60 seconds, the encoder will be placed in Auto IP mode and assigned an IP
address within the range of 169.254.xxx.xxx. If this occurs, congure the network interface of the computer that
is running AMS, located on the same subnet (169.254.xxx.xxx, subnet mask 255.255.0.0). Refer to Conguring a
Static IP Address (page 16) for more information on conguring an encoder in Auto IP mode.
If no OmniStream encoders are found, then verify the following:
• The computer that is running AMS must be on the same network as the OmniStream device.
• Remove any network restrictions that may be in place. In order for mDNS to function properly, there
must not be restrictions applied to the network.
Conguration
9. Click the desired encoder within the Unassigned list.
10. Once the unit is selected, the control interface for the encoder will be displayed.

AT-OMNI-111-WP 15
Conguration
11. Click SESSION in the top menu bar.
12. Locate the Video section.
13. Delete the value in the Destination Multicast / Unicast Address eld.
Destination Multicast/Unicast Address field
14. Locate the Audio section and delete the value in the Destination Multicast / Unicast Address eld.
SAVE button
Destination Multicast/Unicast Address field
15. Scroll down to the bottom of the page and click the SAVE button at the bottom of the Stream 1 window group.

AT-OMNI-111-WP 16
Conguring a Static IP Address
The following section is only required to when setting an encoder to a static IP address. If a DHCP server is not
found within 60 seconds, encoders are automatically placed in Auto IP mode and will be assigned an IP address
within the range 169.254.xxx.xxx. If this occurs, a static IP address can be assigned to the encoder in order for AMS
to locate it on the network.
1. Make sure that the encoder is powered. The AT-OMNI-111-WP is powered by connecting an Ethernet cable from
the encoder to a PoE-capable switch.
2. Connect an Ethernet cable from the PC, directly to the Ethernet port on the rear of the encoder. Make sure that
the computer being used has AMS installed.
3. Congure the PC to a static IP address that is on the same subnet as the encoder.
4. Login to AMS. Refer to Accessing Encoders in AMS (page 12) for information on the login process.
5. Locate the encoder under the Unassigned section within AMS.
6. Click on the device.
7. Under AMS, click NETWORK in the menu bar.
8. Click the DHCP Mode drop-down list and select Static.
IMPORTANT: Windows: Before continuing, write down the current IP settings in order to restore
them, later. If Obtain an IP address automatically and Obtain DNS server automatically are selected,
then this step is not required.
9. Enter the required network information for the encoder in the IP Address, Subnet, and Gateway elds.
10. Click the Save button in the bottom-right corner, to apply the changes.
11. Disconnect the encoder from the PC and connect the encoder to the network.
12. The encoder is now ready for use.
Conguration

AT-OMNI-111-WP 17
Conguration
Input Selection
Once the OmniStream encoder is congured, and can be located on the network, the encoder will need to be
instructed on how to handle source devices and to which stream each source is assigned.
1. Under AMS, click INPUT in the menu bar.
2. Click the Input drop-down list for HDMI Input 1 and select the input.
Input Selection
3. Enter the desired bit rate in the Bit Rate eld. Specifying lower bit rates will reduce video quality. This value is in
megabits-per-second (Mbps). 4K/UHD streams should be set to 900 Mbps. The recommended bandwidth for
1080p60 video is also 450 Mbps. Setting this eld below these recommended values will result in lower-quality
video.
4. Enter the bit depth from the Bit Depth drop-down list.
5. Select the chroma subsampling value from the Subsampling drop-down list. Available values are 4:2:0, 4:2:2,
and 4:4:4.
6. Click the Force YUV toggle switch to enable or disable the use of YUV color space. Enable (the toggle switch
will be green) this feature to force the output of the encoder to output YUV, regardless of whether the input is
RGB or YUV. In order for the chroma scaling to work on RGB inputs, this feature must be enabled.
Bit Rate
7. Click the SAVE button in the right-hand corner of the HDMI Input 1 window group to commit changes.

AT-OMNI-111-WP 18
Conguration
1. Click INPUT in the menu bar.
Verifying the Input
Cable Present indicator
2. Check the Cable Present indicator. If a cable is connected from a source to an input on the encoder, then the
indicator will be green. If no cable is connected, then the indicator will be red.
Note that this indicator may also reect the integrity of the cable: if the cable is bad or does not maintain a
secure connection, then the Cable Present indicator may also be displayed as red. If this is the case, try a
dierent HDMI cable.

AT-OMNI-111-WP 19
Conguration
Once the inputs have been assigned to the desired source, the next step is to congure each session. A session is a
class-D multicast IP address that is assigned to an AV stream. If each stream is congured for bit rates less than 450
Mbps (only recommended for 1080p and lower resolutions), a single Ethernet cable can transport two sessions.
The single-channel encoder supports a maximum of two sessions to enable redundancy for single 1080p-use cases.
1. Under AMS, click Session in the menu bar.
2. Click the eth1 physical interface from the Interface drop-down list.
3. Select the HDMI Input 1 from the Encoder drop-down list.
4. Under the Video section, make sure that the Enable Video toggle switch is enabled (green). To disable video at
any time, click the toggle switch so that it appears gray.
5. Enter the destination multicast IP address in the Destination Multicast/Unicast IP Address eld, within the
range 224.0.0.0 through 239.255.255.255.
6. Enter the port number in the Destination UDP Port eld.
Session Conguration
IMPORTANT: AMS does not allow the same port numbers to be used on both video and audio.
Always specify unique ports for both video and audio.
Video
Audio
1. Locate the Audio section.
2. Click the Source drop-down list and select the HDMI source.
NOTE: If AES67 audio will be used, refer to AES67 Audio (page 29) for more information.
3. Click the Enable Audio toggle switch and make sure it is enabled (green). To disable audio at any time, click the
toggle switch so that it appears gray.
4. Enter the specic destination IP address, if desired, in the Destination Multicast/Unicast IP Address eld.
By default, AMS will automatically populate this eld.
5. Enter the port number in the Destination UDP Port eld.

AT-OMNI-111-WP 20
LED Indicators
The following table provides a listing of front-panel LED indicators and their status:
LED Description
PWR Off • If using a PoE switch, make sure that the port on the switch that is
connected to the encoder, has PoE enabled. When the encoder is
powered using PoE, the PWR indicator will be green.
• Check the Ethernet cable for possible damage or loose connections.
Red • The encoder is booting.
Green • The encoder is ready.
HDMI Red • No source is connected to the input.
• Check the HDMI cable for possible damage or loose connections.
Green • The link integrity between the source and the encoder is good.
LINK Red • Check the Ethernet cable for possible damage or loose connections.
Green • Link integrity is good between the encoder and the network.
Basic Operation
