Panio CH8810K User manual

PANIO
CH8810K User Manual
V2.1

１
Contents
1、Packing........................................................................................................................ 2
2、Panel description.....................................................................................................2
3、Font buttons switching operation .................................................................... 2
4、WEB GUI Browser control.....................................................................................3
5、TCP/IP/RS232 control............................................................................................ 4
6、Remote Control ........................................................................................................5
7、APP control................................................................................................................ 5

２
1、Packing
1 x CH8810K 1 x DC24V 1A 1 x IR (battery not provided) 1 x Quick guide
2、Panel description
Front panel
INPUT : HDMI1-HDMI8 input buttons
OUTPUT : HDMI1-HDMI8 output buttons
MENU：Press to enter main menu
UP / DOWN：Up and down buttons
ENTER : OK button
POWER：Power indicator light, always on after power on.
Back panel
DC24V Power supply port
AUDIO IN : 3.5mm audio input ports
AUDIO OUT : 3.5mm audio out ports
INPUT : HDMI input ports
OUTPUT : HDMI output ports
RS232 ports for the 3rd party control
RJ45 port for the WEB GUI/TCP/IP control
3、Font buttons switching operation
Before switching, press any key to enter the main menu, and the words menu will appear on
the front panel screen before switching.

３
1 to 1 switch : select the input button + select the corresponding output button.
1-to-many switch : Select the input button + select the corresponding multiple output buttons.
1-to-all switch: select the input button + select the UP button.
4、WEB GUI Browser control
The default IP address is 192.168.1.188, Open the browser and enter the IP address of the matrix
switch to perform web page control operations：
*Default login account: admin Password: admin
*Modify the IP address of the control computer to be on the same network segment.
Video switching：
Switch : Select input source and then select output port
ToAll : Select the input firstly, and then click the-ToAll button, 1-to-all switch.
Save and Recall : It will take 2 steps to Save or Recall the scenes, select the scene
number first, and then click- Save or -Recall button, you will hear the beep sound
from the matrix, it was successfully. ( Can save 16 sets of scenes )
Close : Click the -close button firstly and select the output you want to close(no image
on screen), you will hear the beep sound from the matrix, it was successfully.
Video Wall：
Step1 : Configure the VW size by slecet the X screen size and Y screen size.
Step2 : Slecet the input you want
Step3 : Slecet the output for the video wall.
Step4 : Slecet the on to open the video wall.

４
EDID Management：
Switch : Slecet the output, and then click the input, then will copy the EDID of input to
output.
Recall : Slecet the EDID in the system, and then slecet the input, it's mean copy the EDID
in the system to input.
Save : Slecet the output, and then slecet the system, then will save the output EDID to
system.
System Setting :
General setting : User can closed and open the buzzer, and change the language
Network Settings : User can change the IP and TCP
Serial Settings : User can change the band rate, data bit
Input Audio Settings : User can slecet the Internal HDMI or Extenal 3.5mm audio for the 8
input
Output Settings : User can ON or OFF the auto switch, slecet the out format, slecet the
resolution and brightness, saturation and contrast.
Auto switch : Usre can slecte Auto mode and Last mode or off
Auto mode : that means when the input source are disconnected, the matrix will auto
switch the input 1 to the screen, if input 1 also have not source connected, the matrix will
auto switch input 2 to the screen, matrix will follow the principle from input 1 to input 8
based connect some input sources.
Last Mode : that means the screen will be showed the last signal of connection, and will
off the auto switch function, when the input source are disconnected, the display will be
black.
Out format : User can slecet the output format to DVI or HDMI
Resolution Setting : User can slecet the EDID from the 20 kinds which build-in
Rename : User can enter the name and save it for the input, output and sence.
5、TCP/IP/RS232 control
Baud rate: 115200 (factory default), N, 8, 1; Protocol: TCP(8080)

５
Commend
Function
#SW:[X]to[Y].
Switch input [X] to output [Y]
#ASW:[X],[Y].
output [X]，slecet the swich mode
[Y]- 0:off, 1:Automode, 2:Lastmode
#SAVE:[X].
Save sence，[X] is 1--32
#RECALL:[X].
Racall sence，[X] is 1--32
#BUZZER:[X].
On or Off the Buzzer，[X]- 0:OFF, 1:ON
#RESET.
Restore to factory setting
#VSW:?.
Review the video switchover status
6、Remote Control
7、Application control
The matrix can support APP control. iOS users can directly search for MCS in the Apple
store to download the APP, and Android users can download and install it through the
website.
Before switching, press any key to enter the main menu, and the
words menu will appear on the front panel screen before switching
1 to 1 switch : select the input button + select the corresponding
output button.
1-to-many switch : Select the input button + select the corresponding
multiple output buttons.
1-to-all switch: select the input button + select the UP button.
Scene Save: Press SAVE then press the scene number from 1~8, and
finally press ENTER
Scene Recall : Press RECALL then press the scene number from 1~8,
and finally press ENTER
Other buttons have no function on this model
