Pantheon PM20 User manual

Operating Manual
Mixer Range
Planetary Mixer Collection
PM10, PM20, PM30
Product Range Also Includes:
Induction Hobs / Combination Ovens / Pizza Ovens / Mixers
Salamander Grills / Contact Grills / Pie Warmers / Fryers
Heated Displays / Veg Prep Machines / Bains Marie / Mincers and more

Planetary Mixer Collection Operating Manual –PM10, PM20, PM30
Tel: [phone]
Fax: [phone]
Web: www.pantheonce.co.uk
Email: [e-mail]
Pantheon Catering Equipment
Vulcan Works, Dixon Street,
Bolton, BL6 7PH
This Manual covers the following Devices from the Mixer Range:
PM10 –10 Litre Planetary Mixer
(Pictured bottom Left)
PM20 –20 Litre Planetary Mixer
(Pictured Top Right)
PM30 –30 Litre Planetary Mixer
(Pictured bottom Right)
Featured Devices
Planetary Mixer Collection

Planetary Mixer Collection Operating Manual –PM10, PM20, PM30
Tel: [phone]
Fax: [phone]
Web: www.pantheonce.co.uk
Email: [e-mail]
Pantheon Catering Equipment
Vulcan Works, Dixon Street,
Bolton, BL6 7PH
Introduction………………………………………………………………………………………………………………………..………
Warnings and Precautions…………………………………………………………………………………………..………………
Technical Data Specifications………………………………………………………………………………………………………
Accessories………………………………………………………………………………………………………………………………….
Installation………………………………………………………………………………………………………………………………....
Operating Instructions…………………………………………………………………………………………………………………
Maintenance……………………………………………………………………………………………………………………………….
Cleaning……………………………………...………………………………………………………………………………
Troubleshooting………………………………………………………………………………………………………………………….
Table of Contents
1
1
1
1
2
2
3
3
3

Planetary Mixer Collection Operating Manual –PM10, PM20, PM30
Tel: [phone]
Fax: [phone]
Web: www.pantheonce.co.uk
Email: [e-mail]
Pantheon Catering Equipment
Vulcan Works, Dixon Street,
Bolton, BL6 7PH
Introduction
Thank you for purchasing a Pantheon Catering Equipment product. In this booklet you will find
instructions for the safe operation of the product so please read carefully and retain for future
reference.
Warnings and Precautions
The following warnings and precautions are important and must be observed:
Ensure voltage and frequency power requirements for the mixer match that of the supply.
The machine must be earthed when used. There is a danger of electric shock if it is not
earthed.
In case of emergency, please turn off the power switch and unplug the machine.
If the electric wire becomes damaged, a qualified engineer or the manufacturer must
replace it.
Pantheon Catering Equipment is not responsible for any accidents or faults caused by amendments
made to the machine or improper use by the user.
Technical Data Specifications:
Model
PM10
PM20
PM30
Voltage
220-240V 50Hz
220-240V 50Hz
220-240V 50Hz
Power (W)
500
1100
1100
Maximum Load (kg)
4
8
12
Weight (Kg)
75
107
204
Dimensions (mm)
485w x 410d x 635h
500w x 600d x 780h
550w x 600d x 1115h
Specifications are subject to change. Please check the rating label on the back of the machine.
Accessories
All of the devices featured in this manual come with the following accessories as standard:
1 x Beater
1 x Whisk
1 x Dough Hook
Also the Planetary Mixer range can be equipped with some optional extras at a cost these include
Mincing Attachments
Shredding Attachments
Mobile and static Stands
1

Planetary Mixer Collection Operating Manual –PM10, PM20, PM30
Tel: [phone]
Fax: [phone]
Web: www.pantheonce.co.uk
Email: [e-mail]
Pantheon Catering Equipment
Vulcan Works, Dixon Street,
Bolton, BL6 7PH
Installation
General
The installation of the unit must only be performed by a qualified technician.
Confirm that the device is positioned on a solid, even, safe and stable surface that tolerates
the weight of the unit.
Ensure no flammable products are placed near the unit.
Position the device appropriately so that the plug is always accessible.
Check the unit isn’t placed close to any water.
Establish that there is sufficient operating space around the machine.
Please Note: The Information in this section applies for all of the devices in the manual
Operating Instructions
Be sure to follow the instructions below and use ‘figure 1’ to correctly operate the planetary mixer:
Slide the guard across and pour the ingredients into the bowl
Close the guard and confirm the speed setting is set to the lowest speed to begin with.
Switch on the mixer using the green start button
It is advised to start the mixer at the lowest speed and if required work up to the quickest
speed.
Do not change the gear whilst the mixer is running. Always stop the mixer to select gears,
and then press “start”.
If the machine is stopped during the mixing process, be sure to return to the lowest speed
before starting the machine up again.
After use, press the stop button and ensure the mixer has completely stopped before
opening the guard
1. Gear Change Hand Lever
2. Stirring Shaft
3. Mixer
4. Stainless Bowl
5. Power Switch
6. Bowl Lift Lever
7. Safety Guard
8. Support
“Figure 1”
Please Note: The Information in this section applies for all of the devices in the manual
2

Planetary Mixer Collection Operating Manual –PM10, PM20, PM30
Tel: [phone]
Fax: [phone]
Web: www.pantheonce.co.uk
Email: [e-mail]
Pantheon Catering Equipment
Vulcan Works, Dixon Street,
Bolton, BL6 7PH
Maintenance
Cleaning
Prior to cleaning always ensure the unit switched off and unplugged at the mains.
Spilled food should be removed immediately from all exterior surfaces, simply using a damp
cloth.
Cleaning the mixer on a regular basis will help to prolong its life.
Please Note: The Information in this section applies for all of the devices in the manual
Troubleshooting
Problem
Possible Causes
Solution
The mixer will not
start
The power is not connected
properly
The safety guard is not shut
correctly
Ensure the plug is securely in the wall
Ensure the safety guard is shut correctly
The guard switch
isn’t operating
correctly
The guard switch isn’t connected
correctly
Open the guard to double check the
guard switch is connected correctly and
isn’t blocked by food products.
The mixer has
overheated
The mixer has been operated for
too long or has been running
with an excessive load
Ensure the mixer hasn’t been overloaded.
Then try pressing the reset button at the
rear of the mixer
Please Note: If none of these resolve the issue please cease use of the product and contact the
manufacture
Please Note: The Information in this section applies for all of the devices in the manual
