Panther Panther EMS475 SERIES User manual

Easy Installation
A wireless push plate integrated
with an F433 transmitter, which
offers code-encrypted security.
The fully-assembled unit installs
using the quick plate mounting kit
or a standard two or four bolt gang
box. In addition, the push plate
housing can be directly installed
to any flat surface such as a wall or
push plate mounting post using
standard screws.
EasyMount Wireless
Stainless Steel 4.75" Square Style
Push Plate
Pow rful D sign
The sleek, NEMA-4 unit is
tamper-resistant with a recessed
front plate and beveled edges.
Aesthetically pleasing with a slim line
1.5 in. depth and no visible mounting
holes on the front page.
BEA-Quality Plat
All active plate made of durable
stainless steel. Lifetime warranty
on face plate.
QQuuaalliittyy
IInnttlllliiggnncc
PPrrcciissiioonn
WWW.BEASENSO S.COM
PUSH PLATE
SLIM PROFILE
ONLY 1.5 in.
EMS475 SERIES

1
3
4
DIMENSIONAL D AWINGS
APPLICATIONS
E L A T E D P O D U C T S
C O M P O N E N T S
T E C H N I C A L S P E C S
Out r Dim nsions
(Housing Ass mbly)
5.12 in. (W) x 5.12 in. (H)
x 1.42 in. (D)
Mounting Options
EasyMount kit
Standard single gang box
Standard double gang box
Flat surface direct mounting
without mounting kit or gang
box
Transmitt r Op ration
Wireless design
433 Mhz digital frequency
olling code encrypted
for security
FCC IC part 15 approved
Finish
16 gauge, 304 2B stainless steel
face plate with:
Brush finish
Powder coat with clear coat
WWW.BEASENSO S.COM
EMS475 Housing
Allows for direct mounting
without mounting kit or gang
box.
10EMS475 - Text only 10EMS475L - Logo only 10EMS4751 - Text and Logo
E M S 4 7 5 S E I E S
Slight pressure applied to anywhere on the all-active
plate will open the low energy door.
PUSH PLATE
0
31
21.5
03
1
2
1.
5
1.
63
24.1
5.12 in.
130 mm.
Side View
3D Perspective
Front View
5.12 in.
130 mm.
1.42 in.
36.1 mm.
eceiver SuperScanI MC Linx Switch75
2
1
2
3
Front Plate
F 433 Transmitter Board
Housing
Mounting Bracket
4
EMS475 SERIES
Contact Information
BEA Inc.
IDC Park West
100 Enterprise Drive
Pittsburgh PA, 15275
PHONE [phone]
FAX [phone]
TOLL F EE 1-800-523-2462
BEA W st
190 East Arrow Highway
Suite A
San Dimas, CA 91773-3314
FAX [phone]
TOLL F EE 1-877-232-9378
EasyMount Wireless
Stainless Steel 4.75" Square Style
Push Plate
