Pantone PT-BS007L User manual

WIRELESS PORTABLE SPEAKER
MODELS: PT-BS007L, PT-BS007P, PT-BS007Y, PT-BS007N
PRODUCT OVERVIEW
Top View Rear View
1 4
5
6 7
8
9
2
3
1. (mode) : press and hold to turn the speaker on. Press and hold again to
turn the speaker off.
2. : press to decrease volume level. Press and hold to play the previous song.
3. LED light indicator
4. : press to play/pause the song.
5. : press to increase volume level. Press and hold to play the next song.
6. AUX port: use a 3.5mm audio cable (not included) to connect to an external
audio device.
7. USB port: plug in your USB stick to play the songs stored in your USB.
8. Micro SD card slot: insert your Micro SD card to play the songs stored in
your Micro SD card.
9. Micro USB port: use the supplied Micro USB cable to charge the speaker.
OPERATION
Power on and charging
Before rst time use, charge the speaker using the supplied micro USB cable.
Plug the cable into the Micro USB port on the speaker and the other end to a
power source. Charge for 6 hours. The LED light indicator will light up red
during charging and will turn off once fully charged.
Press and hold the (mode) button to turn the speaker on. The LED light
indicator will light up blue for 2 seconds.
Bluetooth mode
When the speaker is turned on, it will automatically enter Bluetooth mode. The
LED light indicator will light ash blue, indicating that the speaker is ready for
pairing. On your Bluetooth device, look for PT-BS007 in the list of detected
devices, and pair with it. Once successfully paired, a notication sound will ring
and the Bluetooth LED light indicator will light up blue.
The speaker and your Bluetooth device will remember each other and
automatically connect when they are both turned on.
AUX input mode
Press the button to play/pause the song. You can also control via your
Bluetooth device.
Press the / buttons to decrease/increase volume level. You can also
control via your Bluetooth device.
Press and hold the / buttons to play the previous/next song. You can also
control via your Bluetooth device.
Connect your audio device to the AUX port on the speaker using a 3.5mm
audio cable (not included). The speaker will automatically enter AUX mode.
Press the button to play/pause the song. You can also control via your
audio device.
Press the / buttons to decrease/increase volume level. You can also
control via your audio device.
USB and Micro SD card mode
Insert a USB stick or Micro SD into the USB port or Micro SD card slot on
the speaker. The speaker will automatically enter media playback.
Press the button to play/pause the song.
Press the / buttons to decrease/increase volume level.
Press and hold the / buttons to play the previous/next song.

FM mode
Connect the supplied micro USB cable as the FM antenna to the micro USB
port on the speaker.
Press the (mode) button to switch to FM mode.
Press and hold the button to auto search for available channels.
Press the button to mute the channel after channel is selected.
Press the / buttons to decrease/increase volume level.
Press and hold the / buttons to play the previous/next channel.
Hands free phone call
Press the button to answer incoming calls.
Press the button again to end the current call.
Press and hold the button to reject an incoming call.
TWS (True Wireless Stereo) mode
Troubleshooting
The speaker supports TWS and can pair with another speaker (same model).
Press and hold the (mode) button on both speakers to turn both on.
After turning on both speakers, LED light indicator will ash blue rapidly,
indicating it is ready to pair with each other.
Once successfully paired with each other, a notication sound will ring and one of
the speakers will ash blue slowly, whilst the other speaker will light up blue.
On your Bluetooth device, look for PT-BS007 in the list of detected devices, and
pair with it.
Music will now be played on both speakers simultaneously.
After rst time pairing, the two speakers will automatically pair with each other.
Compliance and Responsible Disposal
This product complies with the Australian Safety Standard AS/NZS 62368.1
to ensure the safety of the product.
Specifications
Battery capacity 3.7V, 900mAh
Output power 4W
Charging time 4 hours
Play time 6 hours
Bluetooth
operation range <10m
Weight 228 g
Dimensions (mm) 96(W) x 68(H) x 65(D)
Problem Solution
Speaker is not
turning on • Charge the speaker for 4 hours and try again.
No audio • Increase the volume level on your Bluetooth device.
Music keeps
dropping out • Move the speaker closer to your Bluetooth device.
Failed to connect
to Bluetooth
• Place the phone and speaker closer together.
• Check the Bluetooth menu on your phone to ensure it
is connected to the correct device.
• Restart the speaker. On your device, turn Bluetooth off
and then back on, and search again.
Unclear and/or
no stations in FM
mode
• Connect a micro USB cable/FM antenna to the micro
USB port of the speaker.
• In FM mode, press and hold the button to start auto
searching stations. Depending on your local signal,
some stations received might not be received clearly.
• Change direction of micro USB cable/FM antenna.
For Technical and Warranty Support
1300 886 649
tempo.org
tempo.org/support
Distributed by Tempo (Aust) Pty Ltd,
PO Box 132, Frenchs Forest NSW 1640
