Papago GoSafe S810 User manual

S810
Quick Start Guide
使用說明
Manual Usuario
Manual Do Usuário
Guide d'utilisation

Disclaimer
1.Please follow the set-up and usage instructions in the print material that
came with this Dashboard Camera (dash cam) product.
2.You should not set/install this dash cam at a place that would obstruct or
reduce a driver’s view; make sure your use complies with pertinent vehicle
codes of your state, province, territory or country.
3.You should post the required notices of recordation to occupants inside the
vehicle, if voices or other information/signal pertaining to in-vehicle
activities will be recorded.
4.You should not change the dash cam’s setting or mode of operation when
the vehicle is in motion.
5.The optional driving warning signals, including any visual or audible
reminder signals, should not replace your decision-making and judgment
that are needed for the proper operation of the vehicle.
6.You should not leave the dash cam in a visible spot when no one is inside
the vehicle, to avoid attracting break-ins to steal the unit, or other property.
7.You should avoid extended exposure of the dash cam to direct sunlight or
extreme temperatures (either high or low temperature) which tend to
degrade or damage the unit and its normal functionality.
8.You should examine, check and/or verify the dash cam at least every six
(6) months, including the associated memory cards, to ensure the video
reception and recording are working properly. For each use, you should
verify that the dash cam unit, the visible lights and the audible sounds are
working normally. If there are signs of non-operation or mal-function, you
should immediately seek to replace the product and check to see if the
product is covered under any applicable warranty.
9.The dash cam unit may have additional functionality, such as transmission
and recording of audio or GPS signal or other identification information. If
you have privacy concerns about these functions, make sure you follow
the instruction to disable these functions.
10.You should use the dash cam unit in the way it was intended. You should
not use the dash cam unit in a way that would be illegal, physically
damages the unit, or tends to cause danger to the safe operation of the
vehicle and/or occupants.
English 1

Attention please
English 2
【About Usage】
1. If your vehicle still provides power when the vehicle is off, unplug the
device when you plan to have your vehicle parked for a long period of
time to avoid draining your vehicle's battery.
2. The embedded supercapacitors can help to save your recorded file
even if the power is off.
3. To avoid file corruption, don’t eject the Micro SD Card immediately
after powering off.
4. It is recommended to use provided adapter.
5. To enable motion detection and monitor function, the unit must receive
constant power.
【About Micro SD Card】
1. Please use Micro SD card with the size / memory of at
least 16GB,Class 10 (up to 128GB).
2. Format Micro SD card before using.
To format card press When you get to settings ---- Format

1.1 Package Contents
Check the items in your package with the list below. If any of the items are
damaged or missing, contact your retailer.
1. Product Introduction
English 3
● Device
● Suction Cup Mount
● Sticker Mount
● Car Charger
● Cable(Long cable for rear camera/Short cable for inside the car)
● Warranty Card
● Quick Start Guide
● 16GB MicroSD

1.2 Driving Recorder Overview
English 4
①Mount Bracket
② Lens
③Speaker
④MicroSD Slot
⑤Reset
⑥Mini USB Slot
⑦GPS Slot
⑧Display
⑨Buttons
⑩Rear Camera
Cable Slot
Cable
Rear Camera
Sticker Mount
⑧
⑨
⑤
⑥
⑩
①
②
③
④
⑦

English 5
2. Location Installation
1 For better view, try to install in the center of the windshield.
in the packge contents,we have the two kind of cable for mount,you can
mounted in the front window for short cable,or choice for the long cable
to mounted in the back window.
2 To ensure view is clear, make sure the lens is located in a place where
the windshield wiper wipes the window.
3 Make sure device is not installed where it will interfere with the air bag.
4 Make sure the device will not be obstructed by windshield’s
window tint.
5 Clean the area you wish to place the dash cam before mounting the
device. DO NOT move the device for a 24-hour period.
2.1 Two Way Installation
Caution: We are not responsible for any damage caused to,
or caused by, the air bag due to incorrectly placing the
device within the range of the safety bag area.
Best
mounting
location
Connect to
car charger
Second
Camera
WINDSHIELD
Front & Rear Installation Front & Cabin Installation
REAR WINDSHIELD
Second Camera

LED Color
Green ON
Green OFF
Behavior
Power ON, Recording
Power OFF, not Recording
Insert the car charger cable into the car’s cigarette lighter and the other end
into the mini USB port on the device. Make sure to install the Micro SD Card
into the Micro SD Card slot on device. After turning on, the system will start
recording automatically. The LED light will turn green when recording mode
has started.
*Reminder: Please format Micro SD card before you start recording. Please
refer to page 2 for instructions.
3.1 Power On
Hold down the power button at least 5 seconds to turn off device. To avoid
corrupting the last file recorded, do not eject SD Card immediately after
powering off.
If you need to turn it back on simply hold the power button for at least 3
seconds.
3.2 Power Off
3.3 LED
English 6
3. Start and Go

English 7
Buttons
Behavior
Recording mode： Enter Emergency mode
Playlist： Back to previous menu
Replay/Setting Menus：Back to camera mode
Recording mode： Enter Playback Menu
Playlist/Setting：Up
Replay mode：Delete
Recording mode: One short click leads to setting menu
One long press and device will take a snapshot
Playlist/Setting：Down
Replay mode： Lock / Unlock
Recording mode: One long press to turn audio recording on/off
Playlist/Setting：Select
Replay mode：Play/Pause/Resume
3.4 Buttons

English 8
3.5 Recording
Emergency Recording
GPS (Option:GPS connection needed)
Current Date
Time
Audio record indicator
Video recording time
Stop & Go
Motion Detection
Monitor Mode
Stop Sign Recognition
Battery

English 9
Press the button to enter “Settings”.
● Record Mode
a. Automatic Recording
b. Monitor Mode: When this mode is selected, your device will take
snapshots every second while recording.
c. Motion Detection: When this mode is selected, recording starts when
dash cam detects movement. If there is no movement for more than 60
seconds, recording will stop and be switched to detection mode.
This function only works when the device has a continual power
source after the vehicle´s engine is turned off.
● Driving Safety
a.Stop Sign Recognition : The device will recognize any Stop Sign and
warn you with a beep.
b.Stop & Go : After you stop for at least 10 seconds (as for red lights), the
device will detect when the car in front has proceeded and it will give an
audio alert to remind you to proceed driving as well.
c.Driver Fatigue Alarm : When activated, the user can setup an alarm
clock, periodically reminding you to rest. Options available are : 30
minutes/1 hour/2 hours/4 hours/off.
d.Light Reminder : When activated, if driving in a dark environment (such
as tunnel or parking structure), it will have an audio alert and display the
light alert icon on the screen. The alert can be turned on/off.
e.TPMS : Supports the TireSafe D10E (sold separately). The TireSafe
D10E is a Tire Pressure Monitoring System that allows you to view each
of your tire's pressure and temperature on your device's display.
4. Settings

● Volume : Set Volume.
● Microphone : Enable or disable voice recording.
● EV (Exposure Value)
Adjust EV for better effect in different lighting condition.
● Resolution : Set recording resolution.
● Back Camera Setup
● Display Mode
●Bump Recording : Set the impact sensitivity of the G-sensor.
English 10
Note: This device does not support both the GPS
antenna and TPMS simultaneously. Please use only
one of the optional accessories at a time
F.L.
18 psi
25 °C
R.L.
18 psi
24 °C
F.R.
18 psi
25 °C
R.R.
18 psi
24 °C
Tire Pressure
Tire Temperature
Tire Pressure & Temperature display
Front Left Front Right
Rear Left Rear Right
White
Green
Blue
Red
Temperature is
normal.
Warning, please
check Tire.
Start the car
engine,no signal.
Pressure is
normal.

English 11
● Date/Time : Set date, time, and date format.
● Time Zone : Set Time Zone.
● Daylight Saving Time : Enable or disable daylight saving time.
● Screen Saver : Set screen saver for stand-by .
● Power on/off Sound : Set power sound on or off.
●Video Stamp
a. Date Stamp
Enable or disable date stamp on recordings.
b. GPS Stamp
Enable or disable coordinate stamp on recordings.
● Language : Set display language. Options include
简体中文, 繁體中文, English, Français, Español, Deutsch, Italiano,
日本語, Português, and Русский.
● Format memory Card
All data on the MicroSD will be deleted.
Data is irrecoverable after formatting.
Please backup videos and photos before
formatting the MicroSD.
● Format Warning : Set format prompt interval. Options include
15 days, 30 days, 60 days, or OFF.
● Default : Reset all values to factory default.
● Version : Check the current firmware version.

English 12
5.1 Video Recording Circulation
1Video recording will start looping after powering on with the Micro SD Card
plugged in.
2 Each recorded file is 5 minutes long, with old footage being replaced when
the MicroSD Card is full.
5.2 Emergency Recording
①Manual File Backup
Hold down the button , to backup file so that it will not
be overwritten. You will see an icon at the top left of the LCD
screen that looks like this This occurs when an emergency file is being
recorded.
②Auto Backup
Once the G-Sensor is activated by sudden impact, the device will
automatically lock the file so that it is not overwritten.
5. Record/Play/Delete record Snapshot function

5.3 Snapshot
①Hold for 3 seconds to take a snapshot while in recording mode.
②The snapshot images are located on the Micro SD Card in the PHOTOS
folder. This is also where you can find the video files that are recorded.
③The icon will be shown after you take a snapshot. This will not disturb
video recording mode.
5.4 Copying Files with USB Connection
①Connect device to your computer using a USB to mini-USB cable. It should
be recognized as a removable device or show up as an icon titled “No Name”
on your desktop.
②There are video recording files located in folder \PAPAGO (looping video
recording files) and (emergency video recording files) on the “removable
device”.
③Copy the files to your computer. Please follow the copy and paste or drag
and drop procedure for your computer model.
5.5 Copying Files from Micro SD Card
①Shut down the device and eject the Micro SD Card. (To avoid
corrupting the last file recorded, do not eject SD Card immedia-
tely after powering off.)
②Insert the Micro SD Card onto adapter. Insert adapter into the MicroSD Card
reader and your computer will automatically detect the SD Card.
③There are video recording files located in folder \PAPAGO (looping video
recording files) and (emergency video recording files) on the “removable
device”.
④Copy the files to your computer. Please follow the copy and paste
or drag and drop procedure for your computer model.
English 13

5.6 Play/Delete Video or Photo
①Hold down to enter playback menu and to preview the
recorded files.
②Choose Type : Videos (regular recorded videos), Emergency (videos
recorded in emergency mode) or Photos (snapshots taken).
③Press "up/down buttons" to browse the files. Click OK to
choose which file you want to preview.
④Click to OK to play file, or delete the file.
English 14

【使用相關】
① 車輛熄火後，點煙器仍供電的使用者，在離開車時務必關閉電源或將點
煙器插頭拔起，避免耗光電瓶內的電力，或造成其它意外狀況發生。
② 在車輛熄火、電源開關關閉或任何引發電源被切斷狀況發生時，內置超
級電容可將已錄製的影像儲存。
③ 在關機過程中勿立即將記憶卡取出，避免錄製的影像損毀 。
④ 請用本公司專用的車充線，以免規格不符。
⑤ 本機所具有的監控模式和移動偵測功能需要配合電瓶使用，無供電時無
法實現此功能。
【記憶卡相關】
①建議使用 Class10、16GB 以上的記憶卡。
②使用記憶卡前，請務必將記憶卡格式化。
本機使用注意事項
繁體中文 1

繁體中文 2
1. 產品介紹
1.1 包裝內容
包裝內應有下列所有配件，若有任何配件損壞或遺漏，請立
即向您購買經銷商反映。
●行車記錄器
●吸盤車架
● 粘式支架
●車充
●連接線(長連接線用於拍攝後車外/短連接線用於拍攝車內)
●保固卡
●使用說明
●16GB MicroSD

1.2 主機介面
①支架固定槽
②鏡頭
③ 麥克風
④記憶卡插槽
⑤重置鈕
⑥ Mini USB介面
⑦ GPS介面
⑧螢幕
⑨功能按鍵
⑩ 連接後鏡頭介面
繁體中文 3
後鏡頭連接線
後鏡頭
粘貼支架
⑧
⑨
⑤
⑥
⑩
①
②
③
④
⑦

繁體中文 4
2.1 兩種安裝方式
切勿安裝在安全氣囊彈蓋上或安全氣囊的工作範圍內。
本公司對因車輛碰撞或汽車安全氣囊方面的問題
而導致的傷害或死亡不承擔任何責任。
①盡可能安裝在靠近車內後視鏡附近、影像視野較佳處。
包裝中我們有兩種後鏡頭連接線，短連接線可以安裝在前擋風玻璃上，
或者選擇使用長連接線安裝在後擋風窗。
②鏡頭拍攝位置處於雨刷清潔範圍內，確保雨天可以清晰拍攝。
③不要安裝在汽車安全氣囊活動範圍內。
④不要安裝在汽車隔熱紙上，以免損毀汽車隔熱紙。
⑤安裝位置不受汽車隔熱紙影響或者任何具有干擾性的電子產品周圍。
2. 安裝位置
後擋風玻璃 前擋風玻璃
最佳安裝
位置
連接車充
第二顆
鏡頭
前擋安裝位置後擋安裝位置
第二顆鏡頭

繁體中文 5
3.1 開機
車充連接汽車點煙器與主機 Mini USB 介面後，將記憶卡
插入主機記憶卡插槽，汽車發動，主機即開啟。
3.2 關機
開機狀態下，按下電源開關鍵至少 5 秒，主機關閉。
待電源完全關閉後再取出記憶卡，以免錄製的影像損毀。
再次開機時，按下電源開關鍵 3 秒，主機即可開啟。
3.3 LED指示燈
3. 開始使用
指示燈顏色
綠燈恆亮
綠燈關閉
定義
電源開啟，影像錄製中
非錄影模式 / 系統關閉
