Paper Replika CESSNA 112 User manual

Materials :
1. 5mm Depron/ Polyfoam
2. 3mm Plywood
3. 2.5 mm bicycle wheel spoke
4. 0.3 mm mica plastic
5. 10 pcs ice cream sticks
6. White packing tape
Electronics
- Turnigy 2826 1000kv motor (1000-1400kv)
- ESC 30A
- Battery Lipo 3S 2200mah / Li-ion 3S 3300 mah
- 4 plastic gear 9 gram servos
- Propeller : 9x4x3 / 10x5
Specs :
1. Wingspan 120 cm / 47.2 inches
2. Flying weight : 800 gram / 28.2 oz
3. Wing loading : 39.2 g.dm2 / 12.9 oz/sq.ft
4. Wing cube loading : 8.7
5. Wing Area 20.4 dm2 - 316 sq.in
Designed by Julius Perdana 2019 paper-replika.com
1200mm
Model : 05/2019
Build Instructions :
1. paper-replika.com
2. youtube channel : Julius Perdana

JOINHERE
JOIN HERE
RIGHT Fuselage Wall
POLYFOAM 5 mm
F3
LEFT COWL POLYFOAM 5 mm
F5
LEFT COWL POLYFOAM 5 mm F6
RIGHT COWL POLYFOAM 5 mm
F7
RIGHT COWL POLYFOAM 5 mm F8

JOIN HERE
JOIN HERE
F3

JOIN HERE
JOIN HERE
FUSELAGE BASE
POLYFOAM 5 mm
F9

JOIN HERE
JOIN HERE
LEFT Fuselage Wall
POLYFOAM 5 mm
F2

JOINHERE
JOINHERE
F2
FUSELAGE BASE
POLYFOAM 5 mm
F10

JOINHERE
JOIN HERE
F2 SERVO PLATFORM
POLYFOAM 5 mm
F13
COWL
POLYFOAM 5 mm
2X
F20
F2

J INHEREO
J N ROIHE E
BOTTOM Fuselage
POLYFOAM 5 mm
F1
[This side is OUTSIDE]
BATTERY TRAY
2X MIRRORED
POLYFOAM 5 mm
F15
LANDING GEAR
LG BASE
PLYWOOD 3 mm
G2

J N R
OI HE E
JIN HEREO
F1
LANDING GEAR

J N R
OI HEE
JNR
OIHE E
F1
BATTERY TRAY
POLYFOAM 5 mm
F14
[This side UP]
FIREWALL 2X
POLYFOAM 5 mm
F16

FIREWALL PLYWOOD 3 mm
F4
[This side face forward]
FUSELAGE FORMER PLYWOOD 3 mm
F11
FUSELAGE FORMER PLYWOOD 3 mm
F12

TOP COWL
POLYFOAM 5 mm
F17
[This side is UP]
WING MOUNT PLYWOOD 3 mm
C5
BATTERY HATCH DOOR

TOP TAIL
POLYFOAM 5 mm
F18
COWL
POLYFOAM 5 mm
2X
F19

JOINHERE
HOR-STAB
POLYFOAM 5 mm
S1
ELEVATOR
POLYFOAM 5 mm
2X
S4

JOIN HERE
S1
RUDDER
POLYFOAM 5 mm
S3

JOINHERE
VER-STAB
POLYFOAM 5 mm
S2
WINDSHIELD FORMER
PLYWOOD 3 mm
C3
LG BASE
PLYWOOD 3 mm
G1
W2 W2 PLYWOOD 3 mm
PLYWOOD 3 mm

JOINHERE
S2
WINDOW
MICA 0.3 mm
C4
WINDOW FRAME GUIDE
C4
W2 W2
PLYWOOD 3 mm
PLYWOOD 3 mm

WINDOW
MICA 0.3 mm
C1 WINDOW
MICA 0.3 mm
C1
WINDOW FRAME GUIDE
WINDOW
MICA 0.3 mm
C2
C1

LANDING GEAR

J N R
OI HE E
BOTTOM WING
2X MIRRORED
POLYFOAM 5 mm
W1
FRONT
JIN RE
OHE
SPAR
