Paradyne 1862 Original operating instructions

1862 VoIP IAD
Quick Installation Instructions
Document Number 1862-A2-GZ10-10
September 2005
Installation
➊If you will use the USB port, install the USB driver:
– Insert the CD in your CD-ROM drive
– Browse to the USB Driver directory
– Start setup.exe
– Follow the instructions on your screen
➋Connect the power adapter to the Power jack of the IAD,
then plug the power adapter into an AC wall outlet.
➌Connect the FXS port of the IAD to your analog telephone with an RJ11 connector cable.
➍Optionally, connect the USB port of the IAD to a free USB port on your PC with a standard USB cable.
➎Alternatively, connect the LAN port of the IAD to your PC's Ethernet port, or to an Ethernet switch or hub, with an RJ45 cable.
➏Connect the ADSL port to the wall outlet, a POTS splitter, or micro filter (consult your service provider), with an RJ11 connector cable.
➐Turn on the power switch on the rear panel.
Using the Web Interface
Configuration of the Gateway is performed using its built-in web interface. To use the web interface, start your Internet browser. Type
the default IP address for the Gateway into the address field: http://192.168.1.1 Your PC must be on the same subnet as the Gateway.
The web interface requires a user name and password. The default username is root. The default password is b3gvoip for MGCP units
(Model Number 1862-A1-40x) and 1234 for SIP units (Model Number 1862-A1-42x). See the user’s guide on the CD for details.
*1862-A2-GZ10-10*
*1862-A2-GZ10-10*
LAN LINEUSBFXS
PowerOn
Off
04-17597
Power
Switch
AC Power
Input VoIP Service
USB
PC/LAN
To POTS
Splitter,
Micro Filter
or
W ll Outlet
Copyright 2005 Paradyne Corporation. Printed in U.S.A.
