WATER PURIFYING SYSTEM
INSTALLATION MANUAL
E
C
O
F
R
I
E
N
D
L
Y
P
A
R
A
M
O
U
N
T
C
E
R
T
I
F
I
E
D

2
PLEASE REVIEW THE OWNER’S MANUAL AND INSTALLATION GUIDE IN ITS ENTIRETY AND
HEED ALL SAFETY INFORMATION. Failure to follow these instructions and warnings can result in
DEATH OR SERIOUS INJURY.
DANGER DANGER indicates a hazardous situation which,
if not avoided, will result in death or serious injury.
WARNING WARNING indicates a hazardous situation which,
if not avoided, could result in death or serious injury.
CAUTION CAUTION indicates a hazardous situation which,
if not avoided, could result in minor or moderate injury.
NOTICE NOTICE is used to address practices not related to physical
injury.
Signal Words and Symbols Used In This Manual
This Owner’s Manual and Installation Guide contains specific precautions and symbols to identify safety-
related information. You will find DANGER, CAUTION, WARNING and NOTICE symbols which require
special attention. Please read them carefully and follow these precautions as indicated! They will explain
how to avoid hazards that may endanger you or persons using or maintaining your pool or spa.
CONTENTS
SAFETY INSTRUCTIONS ............................................................................................................................................................. 3
WHAT IS OZONE AND HOW DOES IT WORK ................................................................................................................. 4
SELECTING LOCATION & MOUNTING UNIT...................................................................................................................... 5
MAKING ELECTRICAL CONNECTIONS............................................................................................................................... 6
ALTERNATE ELECTRICAL CONNECTION FOR MULTI-SPEED PUMP
WITHOUT A CONTROLLER OR TIME CLOCK .................................................................................................................. 7
MAKING PLUMBING CONNECTIONS.................................................................................................................................. 8
PLUMBING FOR THE CLEAR03 ............................................................................................................................................10
USING THE VENTURI INJECTOR METHOD......................................................................................................................10
PLUMBING THE CLEAR03 WITH THE ULTRA UV AND
OFF LINE CHLORINE FEEDER USING THE VENTURI INJECTOR METHOD....................................................11
PLUMBING THE CLEAR O3 AND ULTRA UV WITH OZONE
INTRODUCED AT THE PUMP AND AN INLINE CHLORINATOR..............................................................................12
PLUMBING THE CLEAR O3 AND ULTRA UV WITH OZONE
INTRODUCED AT THE PUMP AND AN OFFLINE CHLORINATOR .........................................................................12
SETTING AIR FLOW .....................................................................................................................................................................13
EXTERNAL SAFETY AIR BLEED KIT INSTRUCTIONS (OPTIONAL)........................................................................13
BULB REPLACEMENT................................................................................................................................................................14
TROUBLESHOOTING & SERVICE........................................................................................................................................16
CLEAR O3 PART NUMBERS....................................................................................................................................................16

3
IMPORTANT SAFETY INSTRUCTIONS: READ COMPLETELY BEFORE PROCEEDING WITH
INSTALLATION. SAVE THESE INSTRUCTIONS
When using this electrical equipment, basic safety precautions should always be followed, including the
following:
SAFETY INSTRUCTIONS
WARNING
• ALWAYS wear safety glasses when using power equipment
during the installation process.
• Install at least 5 ft from pool or spa water using nonmetallic
plumbing. Mount ozone generator near pool equipment at least
one (1) foot above maximum water level to prevent water from
contacting electrical equipment. Install in accordance with the installation instructions.
• Short-term inhalation of high concentrations of ozone and long-term inhalation of low concentrations of
ozone gas can cause serious harmful physiological affects. Do not inhale gas produced by this unit. If
installed in an enclosed space make sure to account for adequate ventilation.
• UV LIGHT PRODUCED BY THIS UNIT IS HARMFUL TO THE EYES AND MAY CAUSE
BLINDNESS. DO NOT LOOK DIRECTLY AT A LIT BULB!
NOTICE TO INSTALLER/OWNER:
• Save these instructions and deliver to pool owner when installation is complete.
• Lamp contains mercury. Dispose of in accordance with local and state regulations.
CAUTION
READ AND FOLLOW ALL INSTRUCTIONS
• Follow all applicable electrical codes.
• A qualified licensed electrician should perform electrical hookup.
• Turn off power at main source before making any electrical connections or servicing the unit.
• Use only liquid-tight flexible nonmetallic conduit for electrical connections.
• A terminal marked G is located inside the supply terminal compartment. To reduce the risk of electric
shock, this terminal must be connected to the grounding means provided in the electrical supply
service panel with a continuous copper wire equivalent in size to the circuit conductors supplying this
equipment.
• At least one lug marked “BONDING LUG” provided on the external surface of the unit. To reduce
the risk of electric shock, connect the local common bond grid in the area of the pool or spa to this
terminal with an insulated or bare copper conductor not smaller than 6 AWG.

4
• Ozone is created from oxygen using a simple yet powerful system of UV bulbs, to be used as a pure shock
(oxidizer) for the swimming pool.
• Ozone is injected into the pool water using the Clear O3®suction injection system, where the ozone enriched
air is mixed with the water going into the pool circulation pump. This creates a dynamic environment that best
mixes the air and water at high pressure as it is sent into the filter
• Once in the water, the ozone breaks down materials such as ammonia, oils, and other non-living waste that
are detrimental to chlorine’s function in the pool. This occurs between the pump and filter and also in the filter.
Chlorine is in a group of the least stable elements and must be combined with another material to become
stable. In swimming pools, this process creates the formation of combined chlorines, like chloramines, which
do not sanitize and have adverse effects on human skin. Use of ozone allows the chlorine to work primarily as
a water disinfectant.
• Pool water treatment can be broken down into three primary categories:
1. Disinfectant - The killing of living organisms (virus, bacteria, algae). This consumes only 10-20% of the
chlorine normally placed in a pool.
2. Oxidation - The removal of non-living waste from pool water. This consumes up to 70% of the chlorine
placed in standard treated pools
3. Residual - The remaining, measurable sanitizer is left in the pool as a safety net to maintain the water quality
until it is brought through the pool equipment again. Usually less than 10% of the chlorine originally placed in
a pool is left over as residual.
Installing a Clear O3® Water Purification system will reduce the amount of chlorine needed to maintain a pool
by up to70%.
The benefits of using ozone include:
• Fewer chemicals to maintain the pool.
• Less work to maintain the pool water.
• More enjoyable water, being treated similar to bottled water.
• Longer filter cycles, and increased life for the salt chlorinator cells (if present).
WHAT IS OZONE AND HOW DOES IT WORK
TO COMPLETE INSTALLATION YOU WILL NEED THE
FOLLOWING ITEMS (NOT INCLUDED)
(1) Six (6) feet ½" non-metallic conduit outdoor rated.
(1) ½" conduit compression fitting.

5
SELECTING LOCATION & MOUNTING UNIT
1. Select a location on a wall near the pool
equipment or insert posts into the ground,
which will be used to hang unit. The Clear O3®
unit should be at least one (1) foot above
maximum water level, and for extra safety
the unit must be mounted higher than the
filter. The unit should be within five (5) feet of
an electrical source, and within nine (9) feet
of plumbing connection. Mounting brackets
are horizontally adjustable to line up with hard
points on the mounting surface. The unit must be
mounted horizontally and level on the wall. Electrical
connections should be facing downward.
2. Use provided screws and plastic wall inserts
or poles and pole mount clamps (not included)
depending on installation surface available.
3. Four (4) mounting brackets are included (two for the
top slot and two for the bottom slot.
4. Install anchors and screws in desired location for
the top hangers. They must be no further apart than
twelve (12) inches. Do not tighten screws all the
way. (Fig. 1)
5. Hang the Clear O3 from the two top brackets by
sliding the keyhole slots over the screws.
6. Mark the location for the two bottom brackets. (Fig.
2)
7. Remove the Clear O3 from the wall and install the
wall anchors.
8. Place the Clear O3 unit back on the screws and
line up the two lower brackets with the wall anchors.
(Fig. 3)
9. Install the bottom two screws and tighten all
screws.
Fig. 2
Fig. 3
12" Maximum
Fig. 1

6
1. A licensed electrician should make all electrical
connections. The unit must grounded by connecting
to the pool equipments bond wire to comply with local
electrical codes.
2. Turn off power to the filtration system pump at the
circuit breaker.
3. Install an approved seal tight flex conduit (not
included) rated for outdoor use, between the
ClearO3 unit and power source.
4. The ClearO3 must be wired to a power source that
energizes the bulb when the pump that the air line is
connected to is running. This includes suction and
mazzei pressure side installations. Power sources can
be but not limited to control panels and time clocks.
The ClearO3 ballast is voltage sensing. The wiring can
be done in 120v or 220v. A second bonding lug for a
bond wire is on the outside of the ClearO3 housing.
Current draw is 120V=.7A, 203V=.44A
MAKING ELECTRICAL CONNECTIONS
Neutral
Hot
Ground Lug
Wiring for 220v: The two hot wires can be
connected to either of the two posts and the
green ground wire to the grounding lug.
Wiring for 120v: Connect the neutral wire to
the left post, the hot wire to the right post and
the green ground wire to the grounding lug.
Posts Ground Lug
Turn off power at main source before making any electrical
connections or servicing the unit. UV light produced by this
unit is harmful to the eyes and may cause blindness! Do not look
directly at a lit bulb!
DANGER
Ground Lug
1. Use external ground lug to connect the Clear O3 to the
pool pump ground bond. (Fig. 4)
2. Using your chosen power source, turn on the system to
make sure the ClearO3 and the pump responsible for
creating the suction through the ClearO3 are coming on
together. (Fig. 5)
Fig. 5
Fig. 4
Ground Lug
NOTICE The Clear O3
must run with the
filter pump as the
filter pump creates the air draw through the unit needed to
create ozone. Do not set the Clear O3 to run when the filter
pump is off and not pulling air through the unit.

7
Fig. 6 breaker panel
Clear03
steel tight flex
conduit
flow switch
Some variable and multi speed pumps have a built in controller. This requires the ClearO3 to have its own
controlling device. A common method in this type of instillation is to use a flow switch.
Paramount has available an add-on paddle flow switch (Paramount part# 004-402-0010-00 or Grid Controls part #
57-F1-225-00W). The power is run through this switch and then to the ClearO3. The flow switch is plumbed in the
main line of the pool return. When it senses flow the ClearO3 is turned on.
ALTERNATE ELECTRICAL CONNECTION FOR MULTI-SPEED
PUMP WITHOUT A CONTROLLER OR TIME CLOCK
The ClearO3 should be wired to run with the filter pump which creates the air draw through the
unit needed to create ozone. Do not set the ClearO3 to run when the filter pump is off.

8
Note: When the ClearO3 starts up, the light will be orange for around 10 seconds before it turns blue. If
the light stays orange or red, turn the unit off immediately. Failure to do so will damage the ballast.
Turn on power to the filtration system pump. Check
the glow tube on the left front of the ClearO3. (Fig. 8)
A light blue light indicates the lamp is lit and the unit
should be producing ozone.
Use the external ground lug to connect the ClearO3
to the pool pump bond wire. (Fig. 7)
Fig. 7 Fig. 8
Light Blue Glow Tube
Ground Lug
1. Turn off power to the filtration system pump at
the circuit breaker.
2. Pump strainer pot installation: (Fig. 9)
2.1 Check pump elevation above water level.
Refer to (Chart 1)for proper check valve
selection. The 0.5 lb valve comes standard
with Clear O3 and others are available to
order separately.
2.2 Remove strainer pot plug. If there is an
O-Ring on plug take O-Ring off of pot plug
and slide over threaded end of check valve.
2.3 Wrap the check valve four times with teflon
tape and install into the strainer pot plug-
hole. Add more tape if valve does not seal.
(Fig. 10)
2.4 Install the combination needle valve flow
meter on the bottom of the Clear O3 unit.
(Fig. 11)
2.5 Install 3/8" OD x 1/4" ID tubing to
compression end of check valve. (Fig. 12)
3. Pre-pump standpipe installation: (Fig. 12, Fig.
13)
3.1 Cut cap off standpipe.
3.2 Glue a 3/4" elbow and a 3/4" x 1/4" NPT
reducer bushing on end of standpipe.
3.3 Install the threaded end of the check valve
included in the reducer bushing.
3.4 Install 3/8" OD x 1/4" ID tubing to valve
using the compression nut. (Fig. 12)
MAKING PLUMBING CONNECTIONS
Chart 1
Pump Elevation
Above Water Level
Check Valve
Rating
Part Numbers
1' (30cm) 0.5 lb 005-402-1250-00
2' (60cm) 1.5 lb 005-402-2502-00
4' (120cm) 3.0 lb 005-401-2503-00
5' (150cm) 4.0 lb 005-401-2504-00
Fig. 11
Fig. 12
Fig. 10
Pump
Check Valve
Fig. 9

9
Fig. 13 NOT TO SCALE
WATER LINE
WATER LINE
2" PIPE
2" PIPE
3/4" PIPE 3/4" PIPE
3/4" PIPE
4. OPTIONAL SUBMERGED EQUIPMENT
INSTALLATION
(Fig. 14)
To complete this installation option you will need a two
way valve not included.
4.1 Install the two way valve on the inlet pipe to
the pump suction. (before the standpipe if
installed)
4.2 Make all other connections before the two way
valve.
4.3 Make tubing connections to the pump pot or
standpipe as in standard pump above water
level installation.
4.4 Start the pump with the valve fully open.
4.5 Note the filter pressure. Then close the valve
slightly until the pressure on the filter drops two
or three psi.
4.6 Go to setting the airflow on page 13 to
finish setting airflow. The slight restriction this
creates on the pump is the same as if it was
set at approximately one foot above water level
and allows the pump to draw air in at the pump
pot or standpipe.
(Fig. 14)
5. Lay the 3/8 tubing along desired route to the
compression fitting on the combination needle valve
flow meter on the Clear O3 unit.
6. Connect the tubing to the compression fitting. (Fig.
15)
7. Use the provided wires ties to tie the loose tubing to
the conduit or plumbing. (Fig. 16)
WATER LINE
TO SKIMMER
TO MDX
CLEAR O3
3-
WAY VALVE
2-WAY VALVE
*NOT TO SCALE*
2-WAY VALVE
3/4" PIPE
2" PIPE
WATER LINE
CLEAR O3
Fig. 14
Fig. 15
Fig. 16

10
The injector manifold must be installed in the pool’s main return line after the pool filter, heater, chlorinator and
spa return. (Fig. 17) shows the basic installation. Locate the appropriate section of the return line and install
the injector manifold using PVC primer and glue on all mating surfaces. Glue in a minimum 2” return line. Water
flow arrows on the manifold must be followed and the injector needs to be facing up with the bypass down.
See Fig. 17, Fig. 18.
The Clear03 ozone suction line will hook directly up to the bottom of the Clear03 and the other end to the
injector with the check valve provided with the Clear03. No flow meter is needed or provided.
NOTE: The ClearO3 unit must be mounted at least 1' above pool water level to prevent water from
contacting electrical equipment.
PUMP FILTER HEATER
VENTURI INJECTOR
CLEAR03
CHECK VALVE
RETURN WATER
SUCTION FROM
POOL OR SPA
PLUMBING FOR THE CLEAR03
USING THE VENTURI INJECTOR METHOD
Fig. 17
Fig. 18

11
PLUMBING THE CLEAR03 WITH THE ULTRA UV AND OFF LINE
CHLORINE FEEDER USING THE VENTURI INJECTOR METHOD
When installing a Clear O3 and an Ultra UV with a Pressure Side Venturi Injector Manifold in the same pool
system it is recommended, for maximum sanitation, that the Venturi Manifold be installed after the filter followed
by the Ultra UV.
Pool systems that have erosion type chlorine/bromine feeders we recommend installing a feeder designed for
off line plumbing installations offered by several pool equipment manufacturers.
The inlet water being supplied to the feeder should be tapped between the pump discharge and the inlet to
the filter. The discharge from the feeder should return to the piping to the pool after the heater or after the last
component in the system. Follow the feeder manufacturer’s instructions for installation of the feeder.
Please refer to the Plumbing Diagram Figure 1.
PUMP FILTER HEATERULTRA UV
OFFLINE CHLORINE
FEEDER WITH FLOW KIT
VENTURI INJECTOR
MANIFOLD
CLEAR O3
CHECK
VALVE
CHECK VALVE
RETURN WATER
SPA, WATER FEATURES
SUCTION FROM
POOL OR SPA
Figure 1
This piping arrangement is required to prevent air and ozone from getting into the chlorine feeder and
hampering it’s performance, and to prevent chlorine from getting into the Ultra UV or other equipment and
causing damage.

12
PLUMBING THE CLEAR O3 AND ULTRA UV WITH OZONE
INTRODUCED AT THE PUMP AND AN INLINE CHLORINATOR
When installing a Clear O3 and an Ultra UV in the same pool system, where the Ozone is piped into the pump
strainer pot or into a standpipe before the pump suction, it is recommended that an air bleed be installed to
remove excess air from the filter and return it to the pool piping downstream of the inline chlorinator, which
should be the last component in the system.
The Clear O3 Air Bleed Kit is available from Paramount. Item No: 006-402-3872-00.
Please refer to the Plumbing Diagram Figure 2.
Figure 2
PUMP FILTER HEATERULTRA UV INLINE CHLORINE
FEEDER
CLEAR O3
CHECK
VALVE
RETURN WATER
SPA, WATER FEATURES
CLEAR O3 AIR BLEED KIT
SUCTION FROM
POOL OR SPA
PLUMBING THE CLEAR O3 AND ULTRA UV WITH OZONE
INTRODUCED AT THE PUMP AND AN OFFLINE CHLORINATOR
When installing a Clear O3 and an Ultra UV on the same pool system, where the Ozone is piped into the
pump strainer pot or into a standpipe before the pump suction, it is recommended that an air bleed be installed
to remove excess air from the filter and return it to the pool piping downstream of the Heater, or the last
component in the system.
The Clear O3 Air Bleed Kit is available from Paramount. Item No: 006-402-3872-00.
Please refer to the Plumbing Diagram Figure 3.
Figure 3
PUMP FILTER HEATERULTRA UV
OFFLINE CHLORINE
FEEDER WITH FLOW KIT
CLEAR O3
RETURN WATER
SPA, WATER FEATURES
SUCTION FROM
POOL OR SPA
CHECK
VALVE

13
1. Clean filter and pump basket before setting airflow.
2. Turn the knob on the needle valve/flow meter clockwise to close
valve completely.
3. Turn the power on to the pump.
4. Turn the knob on the needle valve/flow meter counter clockwise
until the ball reads in the middle of the two lines on the flow meter.
(Fig. 19)
Note: From time to time condensation may collect in the flow meter,
especially in moist climates or following a rain storm. The
moisture may cause the orange ball to become stuck. The
flow meter is not broken. The water will eventually dry up and
the ball will begin to float again. To check draw to the pump
look for air bubbles entering the pump pot.
IMPORTANT NOTES REGARDING THE FLOW METER:
1. IF THE PUMP THAT THE CLEAR 03 UNIT IS INSTALLED ON IS A PUMP RUNNING A PARAMOUNT
IN-FLOOR SYSTEM, lock the water valve on pause (the pause control is located on top of the Paramount
water valve) when the valve is switching ports and therefore at it’s maximum flow. Set the flow meter so the
ball is on the upper line of the “normal” range.
2. WHEN USING MULTIPLE SPEED PUMPS, SET THE FLOW METER WITH THE PUMP RUNNING ON
THE HIGHEST SPEED THAT WILL BE USED.
3. The Clear O3 flow meter is very sensitive and the red ball may drop down below the ‘normal’ marker after it
has been set. If this happens on your unit, please be aware that this is normal. The flow meter will still deliver
the proper amount of ozone as long as the blue light is on. You do not need to reset the flow meter until after
you clean your filter.
SETTING AIR FLOW
EXTERNAL SAFETY AIR BLEED KIT INSTRUCTIONS
(OPTIONAL)
Sometimes the internal air bleed on the filter is not
sufficient to handle the extra air in the system with an
ozonator installed. An External Safety Air Bleed Kit
(006-402-3872-00) (Fig. 20) for in-ground swimming
pools is available to remove excess air from the filter and
send it downstream (up to 15’) past all equipment. After
installing always test per instructions that air is vented
from the filter when the pump is running. You must install
an external air bleed if the filter is old, does not have an
internal air bleed, there is a solar system on the pool or
there is a robotic pressure side cleaner.
Fig. 20
Fig. 19

14
Mounting Instructions
1. Turn the power off to the pump.
2. Remove the pressure gauge from the filter.
3. Install the nipple into one end of the brass tee.
4. Install the pressure gauge by threading into
the other end of the brass tee supplied.
5. Install the tubing compression fitting by
threading into the side of the brass tee.
6. Install the tee assembly by threading into the
hole where you removed the pressure gauge
(Fig. 21).
7. Insert one end of the tubing into the compression fitting (Fig. 21).
8. Turn the power on to the pump and check that air is coming from the other end of the tubing.
9. Turn the power off to the pump.
10. Pick a spot on the return pipe downstream of all other devices (heater, chlorinator, pressure cleaner, etc.)
11. Drill a 7/16” hole through the return pipe at the location selected.
12. Install the saddle clamp with the fitting over the hole. Make sure the gasket is in place between the fitting
and the pipe. (Fig. 21)
13. Lay the tubing along the return pipe to the saddle clamp fitting and cut off excess length.
14. Connect the end of the tubing to the compression fitting on the saddle clamp (Fig. 21). The tubing can be
secured to the pipe using cable ties (not included).
Installation of External Safety Air Bleed Kit
Fig. 21
12 3
4
FROM
PUMP
FILTER
HEATER CHLORINATOR
BIOSTAT/
BIOCIDE
RETURN
LINE
NOTE: Ozone production from direct UV light will decline over time. UV bulbs continue to illuminate after they
stop producing an effective level of ozone to clean your pool water. To make sure your pool continues to receive
all the benefits of ozone, Paramount recommends that you replace your bulb every three (3) years or 13,000
operating hours.
BULB REPLACEMENT
Turn off power at main source before making any electrical
connections or servicing the unit. UV light produced by this
unit is harmful to the eyes and may cause blindness! Do not look
directly at a lit bulb!
DANGER

15
REPLACING UV BULB
DO NOT TOUCH THE GLASS, HANDLE BY CERAMIC ENDS OF BULB
Turn the power off to filtration system pump at
circuit breaker. Remove three screws in left end
side cap labeled “electrical connections”.
Remove and throw away the old gasket. Make sure
new gasket is in place on replacement bulb. Align
with key and slide into hole until bulb is completely
into unit.
Press plug onto light bulb. Replace side cap and
three screws. Turn on power to filtration system
pump.
Remove side cap. Grasp light bulb plug and pull
light out about one inch.
Pull light bulb free from Clear O3 unit.Remove plug from light bulb.
Check glow tube on the left front of the Clear O3. A light blue light indicates lamp is lit and the
unit is producing ozone.
Replace
old gasket

16
The ballast resets instantly on restoration of power. When the lamp restarts, it will light up orange first then turn
blue in about 10 seconds. If the UV bulb still does not illuminate 1-800-627-5886 and ask for customer service
for further instructions.
ISSUE SOLUTION
No air bubbles entering system or pool Clean filter then adjust airflow needle valve
Filter empties and pump loses prime Replace check valve fitting at strainer pot
Light bulb does not light
Check power to the ClearO3, if you have power and
the bulb still doesn’t light up, turn off the power and
replace the bulb.
TROUBLESHOOTING & SERVICE
CLEAR O3 PART NUMBERS
Item Part Number Description
Single Unit
1. 004-402-3880-00 Clear O3®Single Assembly
2. 005-402-3834-00 Lamp
3. 005-402-3820-00 Mounting Brackets (4Pk)
4. ** Ground Lug
5. 005-402-1384-00 Conduit Compression Fitting 1/2"
6. 005-402-3361-00 Tubing With Check Valve Pump Mount, & Wire Ties
7. ** Tubing 3/8" OD x 1/4" ID x 10'
8. ** Pump Mount Check Valve 1/4" NPT x barb
9. ** Wire Ties (4Pk)
10. 005-402-3247-00 Flow Meter Kit
11. ** Compression Nut 1/4" x 3/8"
12. ** Anchor #10
13. ** Screw: 10 x 3/4" PHIL PH
14. 005-402-1050-00 Clear O3 Adapter Pot Plug (Optional)
Air Bleed
15. 006-402-3872-00 Clear O3 Air Bleed Kit (Optional)
16. 004-402-3873-00 Pressure Side Mazzei Injector Manifold
17. 005-252-3260-00 Clear O3 Mazzei Conversion Kit
** Not available to purchase individually

17
4
5
11
10
2
1
3
7
9
8
6
13
12 (optional)
14
(optional)
15
16
(optional)
17
(optional)

18
Paramount Pool & Spa Systems (PP&SS) | 295 E. Corporate Place, Suite 100 | Chandler AZ 85225 | 1.800.621.5886 | 1Paramount.com
U.S. and Foreign patents and patents pending go to: www.1paramount.com/about/patents/
004-027-7997-00 REV060914
Clear O3TM Warranty Certificate
In compliance with the Magnuson-Moss Warranty-Federal Trade Commission Act (Public Law 930637, Paramount Pool & Spa Systems (PP&SS) provides the following limited warranties.
CONDITIONS This limited warranty shall be subject to the original owner complying with the following conditions: PP&SS warrants to original owner, materials, and equipment to be free of defects for a period of two (2) years from the date of swimming pool start-up or retail purchase. The materials, parts and/or related component parts supplied or distributed by PP&SS are covered under this two (2) year limited warranty. (PVC plumbing installed, labor, material and all other work performed by contractors is not covered under PP&SS Warranty.) PP&SS offers in field warranty service through a network of authorized Warranty Service Stations (W.S.S.) for one (1) year from the date of swimming pool start up or retail purchase. This warranty service must be arranged through your builder or retailer with Paramount. There is no reimbursement for any labor charges incurred outside of the Paramount W.S.S. network. Replacement parts are warranted for a period of one (1) year from date of purchase and are not sold with any field service program. REPLACEMENT CONDITIONS
Contact PP&SS for an RMA number, and return it to PP&SS. Ship part in question freight pre-paid, and upon confirmation of defect, PP&SS will repair or replace the PP&SS warranted item at no charge to the original owner. The repaired or replaced PP&SS item will be returned to the original owner with the return freight paid by original owner. Labor to re- install the repaired or replaced item is the sole responsibility of the owner.
LIMITATIONS No warranty extends to any part of the PP&SS parts or components which is caused by any of the following conditions or events: 1. Defects or failures caused by abuse, lack of responsible care, lack of necessary
maintenance, improper operation, vandalism, acts of God.
2. Damages or failures caused by abuse, lack of responsible care, lack of necessary
maintenance, improper operation, vandalism, acts of God.
3. PP&SS expressly denies any responsibility or liability for incidental or
consequential damages arising out of, or as a result of, use or ownership of your PP&SS parts or as a result of use or ownership of your PP&SS parts or components, or other related products covered under this limited warranty.
4. Any defects caused by acts of God, such as storms, earthquakes, ground
movement, or freezing, etc., that are beyond the normal conditions.
5. Installation of the PP&SS System by a non-authorized installer may render this
warranty null and void.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to you. Implied warranties are limited in duration to the duration of the written limited warranty here within. Some states do not allow limitations on how long an implied warranty lasts, so the above limitations may not apply to you. This warranty gives you specific legal rights, and you may also have other rights that may vary from state to state.

19
POOL OWNER INFORMATION
Name:
Address:
City:
State:
Zip Code:
Telephone:
Fax:
E-mail:
Pool Start-Up Date Purchased:
Type of Pool (check one): Concrete Vinyl Fiberglass
Type of Pool System (check one):
PCC 2000 PV3 PVR Cyclean
Pool Valet Vanquish Vantage EcoPool
POOL BUILDER INFORMATION
Name:
Address:
City:
State:
Zip Code:
PLACE WARRANTY REGISTRATION IN ENVELOP AND MAIL TO
Paramount Pool & Spa Systems.
295 East Corporate Place, Suite 100 • Chandler, AZ 85225
Fax: [phone]
E-mail: [email protected]
Web: www.1Paramount.com/products/warranty.php
Limited manufacturer’s warranty. 2 years on parts & 1
year on labor (labor only through authorized warranty
service stations)

20
NOTES
