Outdoor Bottle Filing Station with Pet Station
SKU: 605wf110-1 Installation
INSTALLER
To assure you install these models easily and correctly, PLEASE READ THESE SIMPLE
INSTRUCTIONS BEFORE STARTING THE INSTALLATION. CHECK YOUR INSTALLATION FOR
COMPLIANCE WITH PLUMBING, ELECTRICAL, AND OTHER APPLICABLE CODES. After
installation, leave these instructions with the Fountain for future reference.

PAGE 2
1. This fountain is to be mounted on a smooth, at, nished surface with adequate support structure. NOTE: Mounting structure
must be capable of supporting 300 lb. load on fountain.
2. Refer to rough-in for plumbing.
3. Install shut-off valve on water supply. (Valve not furnished)
4. Locate and install fountain using 3/8" minimum fasteners. (Fasteners not furnished)
5. Prior to installing the bottle ller to the center mounting position of fountain, insert the drain pipe (Item #15) by positioning the
short end of drain pipe through mounting plate of bottle ller. Install bottle ller to fountain and secure with supplied hardware.
6. Prior to installing the bottle ller to the arm mount of fountain, insert the drain pipe (Item #14) into the arm tunnel and adjust
drain to lean to the left side of the arm when facing the button. Install bottle ller to arm being sure drain tube is above
mounting plate of ller. Install ller to fountain and secure with supplied hardware.
7. Connect water supply and fountain drain. Connect drain waste "Tee" to fountain drain tubes. Connect outlet of "Tee" to
drainage system. Water connection and drain must comply with local codes.
8. Turn on water supply and check all connections for leaks.
CAUTION: This fountain is rated for inlet water pressure of 20-105 PSI. A pressure reducing regulator should be used if the
inlet water supply exceeds 105 PSI. Any damage caused by reason of connecting this product to supply line
pressures lower than 20 PSI or higher than 105 PSI is not covered by warranty.
9. Water supply 3/8" O.D. unplated copper tube. Waste 1-1/2" IPS. Contractor to supply waste trap and service stop valve in
accordance with local code.
10. Connecting lines to be made of unplated copper and should be thoroughly ushed to remove all foreign matter before being
connected to fountain. This fountain is manufactured in such a manner that it does not in any way cause taste, odor,color,
or sediment problems.
11. Connect fountain to supply line with a shut-off valve and install a 3/8" unplated copper water line between the valve and
the fountain. Remove any burrs from outside of water line. Push the tubes straight into the ttings until they reach a
positive stop, approximately 3/4" (See Fig. 3). DO NOT SOLDER TUBES INSERTED INTO PLASTIC FITTINGS AS
DAMAGE TO THE O-RINGS MAY RESULT.
IMPORTANT
ALL SERVICE TO BE PERFORMED BY AN AUTHORIZED SERVICE PERSON
IMPORTANT! INSTALLER PLEASE NOTE.
THE GROUNDING OF ELECTRICAL EQUIPMENT SUCH AS TELEPHONE, COMPUTERS, ETC. TO WATER LINES
IS A COMMON PROCEDURE. THIS GROUNDING MAY BE IN THE BUILDING OR MAY OCCUR AWAY FROM THE
BUILDING. THIS GROUNDING CAN CAUSE ELECTRICAL FEEDBACK INTO A FOUNTAIN, CREATING AN
ELECTROLYSIS WHICH CAUSES A METALLIC TASTE OR AN INCREASE IN THE METAL CONTENT OF THE
WATER. THIS CONDITION IS AVOIDABLE BY USING THE PROPER MATERIALS AS INDICATED. ANY DRAIN
FITTINGS PROVIDED BY THE INSTALLER SHOULD BE MADE OF PLASTIC TO ELECTRICALLY ISOLATE THE
FOUNTAIN FROM THE BUILDING PLUMBING SYSTEM.
INSTALLATION INSTRUCTIONS

PAGE 3
6 9/16"
167mm
30"
762mm
C
A
1-1/2"DRAIN
B
B
8"
203mm
41 7/16"
1053mm
ORIFACE
HEIGHT
10"
254mm
O
8- O.500"HOLES
EQUALLY SPACED ON
TWO O12.00"B.C.
26"
660mm
O14"
356mm
(2 PL)
22"
559mm
19"
483mm
40 5/16"
1025mm
RIM
HEIGHT
3"
76mm
29"
737mm
10"
254mm
O
27 1/8"
689mm
37 1/8"
943mm
14 9/16"
371mm
10"
254mm
O
57 1/8"
1451mm
LEGEND
A = 3/8" O.D. UNPLATED COPPER TUBE CONNECT - SHUT OFF VALVE BY OTHERS
B = ACCESS PANEL ( 8" X 10" )
C = REMOVABLE BOTTOM COVER
FINISHED FLOOR
* ADA REQUIREMENT
*

PAGE 4
B
B
C
1-1/2"DRAIN
A
8- O.500"HOLES
EQUALLY SPACED ON
TWO O12.00"B.C.
26"
660mm
O14"
356mm
(2 PL)
22"
559mm
10"
254mm
O
10"
254mm
O
10"
254mm
O
64"
1626mm
8"
203mm
6 9/16"
167mm
30"
762mm
44"
1118mm
14 9/16"
371mm
19"
483mm
29"
737mm
27 1/8"
689mm
33 7/16"
850mm
RIM
HEIGHT
34 9/16"
878mm
ORIFACE
HEIGHT
3"
76mm
LEGEND
A = 3/8" O.D. UNPLATED COPPER TUBE CONNECT - SHUT OFF VALVE BY OTHERS
B = ACCESS PANEL ( 8" X 10" )
C = REMOVABLE BOTTOM COVER
FINISHED FLOOR
* ADA REQUIREMENT
*

PAGE 5
Vandal-Resistant Bubbler
FIG. 1
BASIN
16
ARM ONLY 14
27
22
28
27
28
28
2
23
11
25
18, 27
19, 27
26
826
6
17
10
1
24
20
25
4
4
4
4
16 1
3
1
16
9
13
15
21

PAGE 6
B CA
SIMPLY PUSH IN
TUBE TO ATTACH
TUBE IS SECURED
IN POSITION
PUSH IN COLLET
TO RELEASE TUBE
OPERATION OF QUICK CONNECT FITTINGS
PUSHING TUBE IN BEFO
RE
PULLING IT OUT HELPS T
O
RELEASE TUBE
OPERATION OF QUICK CONNECT FITTINGS
SIMPLY PUSH IN
TUBE TO ATTACH
TUBE IS SECURED
IN POSITION
PUSH IN COLLET
TO RELEASE TUBE
PUSHING TUBE IN BEFORE
PULLING IT OUT HELPS TO
RELEASE TUBE
A B C
ITEM
NO.
PART NO.
ITEMIZED PARTS LIST
DESCRIPTION
28467C
1000003814*
40551C
0000000325
1000003812*
1000003813*
45926C
45724C
45726C
0000000466
45931C
55996C
66346C
66816C
66815C
97446C
101570540560
75724C
97247C
98678C
98530C
98679C
98680C
98681C
1000003692
1000003693
98682C
1000003694
1000003695
98683C
98684C
98685C
98686C
1000003490
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
NS
Basin
Cover - Round Plate
Tailpipe
Kit - Drain Plug/Gasket
Access Panel
Bottom Cover
Drain Tube - 1-1/2" x 27-1/2" Lg.
Tailpipe - 1-1/4" x 10"Lg.
Drain Plug 1-1/2" (Dog Bowl)
Kit - Bubbler (Dog Bowl)
Plug - Drain (BF)
In - Line Strainer
Drain Tube
Tube - Drain (Arm Only)
Tube - Drain
Kit - Bubbler (VR)
Gasket
Screw - 1/4"x20 x 3/4" LG. Pinned Torx
Kit - VR Torx Screws/Bit
Kit - 1.0 GPM Regulator (BF Only)
Kit -
Kit - Nozzle
Kit - Aerator/Key
Kit - Blank Bottle Filler Trim
Kit - LK4420BFDB Bottle Filler Trim
Kit - 4420BFDB Bottle Filler Trim
Kit - Push Button w/Blank Nameplate
Kit - Push Button w/LK4420BFDB Nameplate
Kit - Push Button w/4420BFDB Nameplate
Kit - Plastic Drain
Kit - 90° Plastic Drain
Kit - 4400 Series Hardware
Kit - Bottle Filler Waterway
Drain Tube (Not Shown)
5
27
12
5
11
See Fig. 4
10
TROUBLESHOOTING AND MAINTENANCE
STREAM HEIGHT ADJUSTMENT:
Stream height is factory set at 35 PSI. If supply pressure
varies greatly from this, insert a small straight bladed
screwdriver through the access hole in the center of the
push button and turn the adjustment screw. Clockwise
adjustment will raise the stream and counterclockwise
adjustment will lower the stream. For best adjustment,
the stream should be approximately 1 1/2" above the
top of the bubbler . (See Fig. 4)
FIG. 4
ACTUATION OF QUICK CONNECT WATER FITTINGS:
Fountain is provided with lead-free connectors which utilize an
o-ring water seal. To remove tubing from the tting, relieve water
pressure, push in on the gray collar while pulling on the tubing. (see
Fig.2) To insert tubing, push tube straight into tting until it reaches
a positive stop, approximately 3/4".
*select color option to complete part number
Matte nish: Evergreen = EVG
Gloss nish:
Beige = BGE Gray = GRY Terracotta = TER
Black = BLK Orange = ORN White = WHT
Blue = BLU Purple = PUR Yellow = YLW
Brown = BRN Red = RED
FIG. 3
FIG. 2
NOTE: WATER FLOW
DIRECTION
BUILDING WATER INLET
SERVICE STOP
(NOT FURNISHED)
1/4" O.D. TUBE
WATER INLET
TO COOLER
3/8" O.D. UNPLATED COP-
PER TUBE CONNECT
COLD WATER SUPPLY
NS = Not Shown
