Parker 8903/FA User manual

8903/FA
FireWire IEEE 1394a
Communications Option
Technical Manual
HA469265U001 Issue 5
©Copyright 2010 Parker Hannifin Ltd.
All rights strictly reserved. No part of this document may be stored in a retrieval system, or transmitted in any
form or by any means to persons not employed by a Parker Hannifin Ltd., Automation Group, SSD Drives
Europe without written permission from Parker Hannifin Ltd., Automation Group, SSD Drives Europe. Although
every effort has been taken to ensure the accuracy of this document it may be necessary, without notice, to
make amendments or correct omissions. Parker Hannifin ltd., Automation Group, SSD Drives Europe cannot
accept responsibility for damage, injury, or expenses resulting there from.
WARRANTY
Parker Hannifin Ltd., Automation Group, SSD Drives Europe, warrants the goods against defects in design, materials
and workmanship for the period of 24 months from the date of manufacture, or 12 months from the date of delivery
(whichever is the longer period) on the terms detailed in Parker SSD Drives Standard Conditions of Sale IA500504.
Parker Hannifin Ltd., Automation Group, SSD Drives Europe reserves the right to change the content and product
specification without notice.

Cont.2
FAILURE OR IMPROPER SELECTION OR IMPROPER USE OF THE PRODUCTS
DESCRIBED HEREIN OR RELATED ITEMS CAN CAUSE DEATH, PERSONAL
INJURY AND PROPERTY DAMAGE.
This document and other information from Parker-Hannifin
Corporation, its subsidiaries and authorized distributors
provide product or system options for further investigation by
users having technical expertise.
The user, through its own analysis and testing, is solely
responsible for making the final selection of the system and
components and assuring that all performance, endurance,
maintenance, safety and warning requirements of the
application are met. The user must analyze all aspects of the
application, follow applicable industry standards, and follow
the information concerning the product in the current product
catalog and in any other materials provided from Parker or its
subsidiaries or authorized distributors.
To the extent that Parker or its subsidiaries or authorized
distributors provide component or system options based upon
data or specifications provided by the user, the user is
responsible for determining that such data and specifications
are suitable and sufficient for all applications and reasonably
foreseeable uses of the components or systems.

Cont.3
Requirements
IMPORTANT: Please read this information BEFORE installing the equipment.
Intended Users
This manual is to be made available to all persons who are required to install, configure or
service equipment described herein, or any other associated operation.
The information given is intended to highlight safety issues, EMC considerations, and to enable
the user to obtain maximum benefit from the equipment.
Complete the following table for future reference detailing how the unit is to be installed and
used.
INSTALLATION DETAILS
Model Number
(see product label)
Where installed
(for your own
information)
Unit used as a:
(refer to Certification
for the Inverter)
οComponent οRelevant Apparatus
Unit fitted: οWall-mounted οEnclosure
Application Area
The equipment described is intended for industrial motor speed control utilising DC motors, AC
induction or AC synchronous machines
Personnel
Installation, operation and maintenance of the equipment should be carried out by qualified
personnel. A qualified person is someone who is technically competent and familiar with all
safety information and established safety practices; with the installation process, operation and
maintenance of this equipment; and with all the hazards involved.
Product Warnings
Caution
Risk of electric
shock
Caution
Refer to
documentation
Earth/Ground
Protective
Conductor
Terminal
Safety Information
!

Cont.4
Hazards
DANGER! - Ignoring the following may result in injury
1. This equipment can endanger life by exposure to
rotating machinery and high voltages.
2. The equipment must be permanently earthed due to the
high earth leakage current, and the drive motor must be
connected to an appropriate safety earth.
3. Ensure all incoming supplies are isolated before
working on the equipment. Be aware that there may be
more than one supply connection to the drive.
4. There may still be dangerous voltages present at power
terminals (motor output, supply input phases, DC bus
and the brake, where fitted) when the motor is at
standstill or is stopped.
5. For measurements use only a meter to IEC 61010
(CAT III or higher). Always begin using the highest
range.
CAT I and CAT II meters must not be used on this
product.
6. Allow at least 5 minutes for the drive's capacitors to
discharge to safe voltage levels (<50V). Use the
specified meter capable of measuring up to 1000V
dc & ac rms to confirm that less than 50V is present
between all power terminals and earth.
7. Unless otherwise stated, this product must NOT be
dismantled. In the event of a fault the drive must be
returned. Refer to "Routine Maintenance and
Repair".
WARNING! - Ignoring the following may result in injury or damage to equipment
SAFETY
Where there is conflict between EMC and Safety requirements, personnel safety shall always take precedence.
•Never perform high voltage resistance checks on the
wiring without first disconnecting the drive from the
circuit being tested.
•Whilst ensuring ventilation is sufficient, provide
guarding and /or additional safety systems to prevent
injury or damage to equipment.
•When replacing a drive in an application and before
returning to use, it is essential that all user defined
parameters for the product’s operation are correctly
installed.
•All control and signal terminals are SELV, i.e.
protected by double insulation. Ensure all external
wiring is rated for the highest system voltage.
•Thermal sensors contained within the motor must
have at least basic insulation.
•All exposed metalwork in the Inverter is protected
by basic insulation and bonded to a safety earth.
•RCDs are not recommended for use with this
product but, where their use is mandatory, only Type
B RCDs should be used.
EMC
•In a domestic environment this product may cause radio
interference in which case supplementary mitigation
measures may be required.
•This equipment contains electrostatic discharge (ESD)
sensitive parts. Observe static control precautions
when handling, installing and servicing this product.
•This is a product of the restricted sales distribution
class according to IEC 61800-3. It is designated as
“professional equipment” as defined in
EN61000-3-2. Permission of the supply authority
shall be obtained before connection to the low
voltage supply.
CAUTION!
APPLICATION RISK
•The specifications, processes and circuitry described herein are for guidance only and may need to be adapted to the
user’s specific application. We can not guarantee the suitability of the equipment described in this Manual for
individual applications.
RISK ASSESSMENT
Under fault conditions, power loss or unintended operating conditions, the drive may not operate as intended.
In particular:
•Stored energy might not discharge to safe levels as
quickly as suggested, and can still be present even
though the drive appears to be switched off
•The motor's direction of rotation might not be controlled
•The motor speed might not be controlled
•The motor might be energised
A drive is a component within a drive system that may influence its operation or effects under a fault condition.
Consideration must be given to:
•Stored energy •Supply disconnects •Sequencing logic •Unintended operation
Safety Information
!

Cont.5
Contents
Contents Page
FIREWIRE COMMUNICATIONS OPTION 1
Introduction ..................................................................................................... 1
Product Features ........................................................................................................ 1
Product Order Code................................................................................................... 1
Compatible Firmware................................................................................................. 1
Restrictions................................................................................................................. 1
Installation....................................................................................................... 2
Wiring the System............................................................................................ 5
Terminology .............................................................................................................. 5
Powering the Node .................................................................................................... 5
Connecting the Nodes................................................................................................ 5
Extenders................................................................................................................... 6
Initial Set-up .................................................................................................... 8
Configuring the 890 Drive.......................................................................................... 8
Status LED Indications ................................................................................................ 9
Disposal ........................................................................................................... 9

1
8903/FA Firewire IEEE 1394a Communications Interface
FIREWIRE COMMUNICATIONS OPTION
Introduction
This manual describes the Parker SSD Drives' FireWire®Communications Interface Option.
Product Features
Note: FireWire is also known as IEEE1394 and is a high speed peer-to-peer serial bus.
•Suitable for use with 890CD Common Bus Drive, 890SD Standalone Drive and 890PX
Drive.
•LED to indicate option and communications status
•Plug-and-play operation. No user settings required
Product Order Code
Not fitted order code: 8903-FA-00
Factory fitted order code: 890xx-xxxxxxxx-xxx-xxxxA
Compatible Firmware
This option will work with all versions of 890 firmware.
Restrictions
Option must be fitted in Slot B.
Figure 1. Front of the 8903/FA FireWire Communications Interface Option (Option)
STATUS LED
X42
POWER INPUT
CONNECTOR
X43
FIREWIRE PORT 0
X43
FIREWIRE PORT 1
X43
FIREWIRE PORT 2

2
8903/FA Firewire IEEE 1394a Communications Interface
WARNING!
Before installing, ensure that the drive
wiring is electrically isolated and cannot be
made “live” unintentionally by other
personnel. Wait 5 minutes after
disconnecting power before working on
any part of the system or removing the
covers from the drives.
Figure 2. 890 showing Control Board
withdrawn with Options fitted
2
1
1
Figure 3. Front of 890 drive showing
Control Board fitted
Legacy 890 drive without
the STO feature
2
Installation
To Remove the Control Board
1. Remove the blanking plates, each secured by a single
screw, that fits over the option slots (1).
2. Loosen the top and bottom screws from the handles
of the Control Board (2).
3. Pull gently on the handles and slide the Control
Board out of the drive.
Note:
Save the blanking plate and screw for future
use. The drive should not be operated without either
an option or blanking plate fitted. When fitted, these
maintain the drive's IP20 rating.
Caution
This Option contains ESD (Electrostatic
Discharge) sensitive parts. Observe static control
precautions when handling, installing and
servicing this Option.

3
8903/FA Firewire IEEE 1394a Communications Interface
Fitting the Option
The Option fits on to the Control Board.
1. Insert the connector into the Option as shown. The legs of the connector will protrude
through into the connector on the other side of the Option.
2. Press the assembly into the BOTTOM connector (adjacent to terminals X13, X14 and X15)
on the Control Board. Ensure that the front panel of the Option overlaps the front of the
Control Board.
Figure 4. Fitting the connector to the Option

4
8903/FA Firewire IEEE 1394a Communications Interface
Re-fitting the Control Board
1. Slide the board into the drive, engaging the edges of the boards into the slots. Push until
the back edge of the Control Board PCB locates with the connectors in the drive.
2. Tighten in position using the top and bottom screws in the handles of the Control Board.
3. Screw the Option in position using the captive screw on the front of the Option.
Figure 5. 890 Control Board with FireWire Communications Option fitted

5
8903/FA Firewire IEEE 1394a Communications Interface
Wiring the System
Terminology
Node : Any single piece of IEEE1394 connected apparatus
Bus : The network of interconnected IEE1394 nodes
Hop : Any single IEEE1394 interconnecting cable
Lonely : No other active nodes detected
Powering the Node
IMPORTANT: DO NOT power the Option using the drive's 24V.
The IEEE1394 bus requires a separate,floating 24Vdc (12-24Vdc) supply connected to the
Power Input Connector, terminal X42.
As a guide, each node may take up to 20mA at 24V from this supply. A node will draw more
current at lower supply voltages, for example, a node may draw up to 40mA using a 12V
supply.
Supply 24Vdc to one of the nodes on the bus. The 24Vdc is transferred to other nodes on the
bus via the IEEE1394 cable.
Pin 01 = 24V
Pin 02 = 0V
If you do power more than one node on the same bus (for instance, one supply in each of two
enclosures allowing for one of the enclosures to be isolated yet maintaining the bus), the
supplies must again be separate,floating supplies.
Connect the 24V supply to the X42 terminal block using twisted pair cable.
Connecting the Nodes
Use an IEEE 1394a cable to connect two nodes together. These cables are considered
electrically sensitive. In electrically noisy environments, FireWire messages may be corrupted.
If this occurs, the system will automatically recover by restarting the communications. This
process is called a Bus Reset and can take up to 0.5 seconds to complete. During this time data
will not be transferred by the bus.
To avoid Bus Resets, keep electrically noisy and sensitive cables apart. Pay particular attention
to screening and earthing of motor cables. Where necessary, sensitive cables should cross noisy
cables at 90° to minimise capacitive coupling.
(The occurrence and frequency of Bus Resets can be monitored from the keypad).
The quality of RF earthing is important when using FireWire systems. In noisy environments, it
is recommended that each drive front plate is strapped to an adjacent drive using a copper braid,
to ensure a low impedance path for RF signals.
If some drives are mounted remotely, it is recommended that the FireWire cable between the
drives is fitted with a ferrite RF absorption clamp (SSD Part Number : DJ467799).
We can supply the following recommended cables:
SSD Part Number Cable Length
CM469189U002 0.2m
CM469189U003 0.28m
CM469189U010 1m
CM469189U045 4.5m
CM469189U100 10m
If using 10m cables, note that an
additional limitation applies: the cable
length limit between the two most distant
nodes on the network is 72m. 10m cables
should be used sparingly, and short (1m)
cables should be used wherever possible
to ensure this limit is not exceeded. See
"Extenders" below.

6
8903/FA Firewire IEEE 1394a Communications Interface
Each port is interchangeable – any message transmitted by the node exits all three ports. Any
message received on one port is repeated on the other two ports.
Nodes can be connected in a Daisy Chain or a Tree configuration but loops are not allowed.
The maximum number of hops between the most distant nodes on the network is 16, so for 17
or more nodes a Tree is essential. The maximum number of nodes is 63. Refer to Figure 6 on
next page.
Note:
The network power draw is approximately 20mA per node at 24V, approximately 40mA
at 12V. Note that 63 nodes at 24V (20mA per) is 1.26A total. The power system has
thermally self-resetting fuses for 1.5A. So, at 12V it is not possible to wire for more than
37 nodes reliably.
Daisy Chain Configuration
X43 X43 X43 X43 X43 X43 X43 X43 X43
X43 X43 X43
Loops like this are NOT allowed
Tree Configuration
Extenders
If any hop needs to be longer than 10m, then an extender is required to repeat the bus over
CAT5 cable or optical fibre. There are commercially available units such as:
www.fwdepot.com … FW2UTP-01 1x IEEE1394a port, 1xRJ45 CAT5 port
FW2UTP-02A 1x IEEE1394a port, 2xRJ45 CAT5 port
FW2UTP-02B 1x IEEE1394a port, 2xRJ45 CAT5 port
Any 2 of the above can be used with a CAT5 crossover cable of up to 100m.
www.newnex.com … FireNex-MX (TM) 2xIEEE1394a ports, 1x optical duplex LC port
Two of the above can be used with 100m of LC to LC ,62.5125um, multi-mode optical cable.
X43 X43 X43 X43 X43 X43 X43 X43 X43
1 hop 1 hop

7
8903/FA Firewire IEEE 1394a Communications Interface
Figure 6. Example 4 Rack, 47 Drive Network

8
8903/FA Firewire IEEE 1394a Communications Interface
Initial Set-up
Configuring the 890 Drive
All drives in the system MUST be fitted with a FireWire Option that is wired correctly.
The FireWire Option is plug-and-play, requires no setting-up, and can be used in the following
ways:
1. The Drive may exchange data with other Drives using Network inputs and outputs
configured using DSE.
2. DSE :use FireWire to connect DSE to all drives in the system.
3. Peer-To-Peer : use FireWire to link drive parameters.
4. Virtual Axis : use FireWire to broadcast synchronised information to all drives on the
system (e.g. a shaftless printing application).
You can use the diagnostics provided in the FIREWIRE block to see your system at work.
FIREWIRE
SETUP::COMMS::FIREWIRE
The FireWire block parameterises FireWire communications, providing a series of diagnostics.
There are no user settable parameters in this block.
Parameter Descriptions
OWN ID PREF: 117.01 Default: 99 Range: —.
FireWire network ID of the drive. This is the physical address, not the net address, as declared as
part of the DSE Configuration. Note that this network ID can change after a Bus Reset.
IRM ID PREF: 117.02 Default: 99 Range: —.
FireWire network ID of the drive acting as the Isochronous Resource Manager. The IRM ID can
change after a Bus Reset.
NUMBER OF NODES PREF: 117.03 Default: 0 Range: —.
Total number of FireWire Nodes connected to the network..
CYCLE TIMER PREF: 117.04 Default: 0 Range: —.
Timer which should be synchronised across the FireWire network.
BUS RESETS PREF: 117.05 Default: 0 Range: —.
Number of times the FireWire bus has reset since power-on.
MY BUS RESETS PREF: 117.15 Default: 0 Range: —.
Number of Bus Resets initiated by this node. An incrementing value may indicate that the
Firewire cabling needs attention.
BAD MESSAGES PREF: 117.13 Default: 0 Range: —.
Number of incoming Firewire messages that are received malformed. An incrementing value
may indicate that the Firewire cabling needs attention.
MCAP ADVERTS PREF: 117.06 Default: 0 Range: —.
Count of Multicast Advertisements received by this node.
MAX HOPS PREF: 117.07 Default: 0 Range: —.
Maximum number of cable hops between the two most distant nodes on the network.
OFFSET (40.69ns) PREF: 117.08 Default: 0 Range: —.
Time delay between this node and the node hosting the Cycle Time Master.
The DSE Configuration Tool is Parker SSD Drives’ Windows-based block programming
software and is supplied with each 890 drive.

9
8903/FA Firewire IEEE 1394a Communications Interface
Status LED Indications
The Status LED on the Option indicates the following states:
Flash Sequence Bus State
50-50 OFF-RED No Bus Power
100 AMBER Bus Reset
50-50 OFF-GREEN Bus Power On, only drive
5-95 OFF-GREEN Bus Running, multiple drives
Disposal
This product contains materials which are consignable waste under the Special Waste
Regulations 1996 which complies with the EC Hazardous Waste Directive - Directive
91/689/EEC.
We recommend you dispose of the appropriate materials in accordance with the valid
environmental control laws. The following table shows which materials can be recycled and
which have to be disposed of in a special way.
Material Recycle Disposal
metal yes no
plastics material yes no
printed circuit board no yes
The printed circuit board should be disposed of in one of two ways:
1. High temperature incineration (minimum temperature 1200°C) by an incinerator authorised
under parts A or B of the Environmental Protection Act
2. Disposal in an engineered land fill site that is licensed to take aluminium electrolytic
capacitors. Do not dispose of in a land fill site set aside for domestic waste.
Packaging
During transport our products are protected by suitable packaging. This is entirely
environmentally compatible and should be taken for central disposal as secondary raw material.

10
8903/FA Firewire IEEE 1394a Communications Interface
ISS. MODIFICATION ECN No. DATE DRAWN CHK'D
1 Initial Issue (HA469265U001) 17320 14/04/05 CM AFL
2 RF earthing details added - page 5 19213 10/02/06 CM AFL
3 Changes to parameter details - page 8.
Company name change
19768 09/01/07 CM KJ
4 Company name change 19591 06/08/07 CM KJ
5 Updated Warranty information and conditions of sale. (20358)
Photos and screenshots updated.
Standardised Safety pages over 3 pages.
Product code - added new coding.
Replaced DSE 890 with DSE and Techcard with Option.
Page 2 – Replaced photo to show new Safe Torque Off
feature.
Other minor corrections and amendments. 20814 12 Feb 09 FEP MF
FIRST USED ON MODIFICATION RECORD
8903/FA FireWire
Communications Interface
DRAWING NUMBER
ZZ469265C001
SHT. 1
OF 1
