Parker SensoNODE Blue User manual

www.parker.com/conditionmonitoring 763.544.7781
SensoNODE
TM
Blue
Sensors
ID: 2ACDM-SNG4
IC: 11983A-SNG4

FCC Disclaimer
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. This device complies with Part 15
of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may cause harmful interference,
and (2) this device must accept any interference received,
including interference that may cause undesired operation.
If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:

• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
Changes or modifications not expressly approved by the
party responsible for compliance could void the user’s
authority to operate the equipment.
This equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment. End
user must follow the specific operating instructions for
satisfying RF exposure compliance. This transmitter
must not be co-located or operating in conjunction with
any other antenna or transmitter. The portable device
is designed to meet the requirements for exposure to
radio waves established by the Federal Communications
Commission (USA).

This device complies with Industry Canada license-
exempt RSS standard(s). Operation is subject to the
following two conditions: (1) this device may not cause
interference, and (2) this device must accept any
interference, including interference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie
Canada applicables aux appareils radio exempts
de licence. L’exploitation est autorisée aux deux
conditions suivantes : (1) l’appareil ne doit pas produire
de brouillage, et (2) l’utilisateur de l’appareil doit
accepter tout brouillage radioélectrique subi, même
si le brouillage est susceptible d’en compromettre le
fonctionnement.

Install Battery
1. Unlock: Remove T-15 Torx drive screws.
2. Remove cap: Pull the cap away from
the body.
3. Insert: Insert the battery (CR123A or
Parker PN# QX-008-121) in the proper
orientation (symbols are molded in
housing for easy identification).
4. Install cap: Push the cap onto the body.
5. Lock: Install the T-15 Torx drive screws.

LED Status
• Red àGreen àBlue: Startup sequence.
This will change to just blue flashing.
Note: if this keeps repeating after startup, the battery is
low and needs to be replaced.
• Blue (flashing) – Sensor looking for a
connection.
Gen2 generation sensors will continue the blue flashing
while in unconnected state.
Gen4newest generation of SensoNODE, after
approximately 1 minute the LED will change from the
flashing blue LED to now mimic the Connected Mode**
LED status to provide a visual indication of the sensor
measurement value.

LED Status
• Green (single brief flash) – Sensor
measurement – Sensor reading between
0% and 25% of span
• Yellow (single brief flash) – Sensor
measurement – Sensor reading between
25% and 50% of span
• Orange (single brief flash) – Sensor
measurement – Sensor reading between
50% and 75% of span
• Red (single brief flash) – Sensor
measurement – Sensor reading between
75% and 100% of span
(Connected Mode)**

Components
a. Cap
b. Antenna
c. Body
d. T-15 Battery
Cover Screw
e. LED
f. Power Button
a
d
b
c
e
f

Power On
Press the power button. (Sensor will power
up when battery is inserted.)
Power Off
Pushing and holding the power button down
for more than 3 seconds will turn off the
sensor. As the button is held down, you will
see the red LED remains solid, then after 3
seconds the LED will flash orange and then
red again, and the sensor will turn off.

This SensoNODE Sensor delivers data
through Parker’s Voice of the Machine
Mobile App.
Visit the App Store or Google Play to
download the free Mobile App.
Voice of the Machine Mobile requires iOS 9
or newer and Android 4.4 or newer.
Voice of the MachineTM
Mobile App

Download Voice of the Machine
Mobile App
Enable Bluetooth on mobile device
Open app on mobile device
Tap ‘OK’ on the informational popup
Tap ‘ALLOW’ on the permissions popup
Tap the ‘+’ icon
Tap the desired, available sensor
Tap ‘ADD’
Start reading sensor measurements
Quick Start Guide

Broadcast vs Connected
Mode Differences
Broadcast
Mode
Always on, always available.
Viewable on multiple devices
simultaneously.
Connected
Mode
Viewable by single connected
device.
Bi-directional communication
to change settings on sensor.
Digital Transmission System
Frequency Range: 2402.0 MHz - 2480.0 MHz
Output Power: 0.0077 Watts (8.9 dBm EIRP)

Scan/Transmission Rates
Data
Transmission
Interval (secs)
Broadcast Mode
Runtime (days)
Connected Mode
Runtime (days)
1 95 50
2 160 86
5 300 156
10 440 215
30 480 290
60 618 302
120 721 317

Support
Parker Hannifin Corporation
Quick Coupling Division
Minneapolis, MN
Package Contents
• SensoNODETM Sensor
For resources and FAQ’s visit:
“Este equipamento opera em caráter secundário, isto é, não tem direito a
proteção contra interferência prejudicial, mesmo de estações do mesmo tipo,
e não pode causar interferência a sistemas operando em caráter primário.”
00179-18-11018

www.parker.com/conditionmonitoring 763.544.7781
SensoNODE
TM
Blue-
sensoren
ID: 2ACDM-SNG4
IC: 11983A-SNG4

Componenten
a. Deksel
b. Antenne
c. Hoofdgedeelte
d. T-15-schroef
batterijdeksel
e. LEDJE
f. AAN/UIT-knop
a
d
b
c
e
f

Inschakelen
Druk op de AAN/UIT-knop. (Sensor wordt
ingeschakeld na plaatsing van de batterij.)
Uitschakelen
Schakel de sensor uit door de AAN/UIT-knop
gedurende meer dan 3 seconden ingedrukt
te houden. Terwijl de knop is ingedrukt,
blijft het rode ledje constant branden. Na
3 seconden knippert het ledje oranje en
vervolgens opnieuw rood en de sensor wordt
uitgeschakeld.

Ledstatus (verbindingsmodus)
• Groen (één korte flits) – sensormeting –
sensorwaarde tussen 0% en 25% van bereik
• Geel (één korte flits) – sensormeting –
sensorwaarde tussen 25% en 50% van bereik
• Oranje (één korte flits) – sensormeting –
sensorwaarde tussen 50% en 75% van bereik
• Rood (één korte flits) – sensormeting –
sensorwaarde tussen 75% en 100% van bereik

Ledstatus
• Rood dan Groen dan Blauw – sensor
wordt opgestart (als dit keer op keer wordt
herhaald, is de batterijspanning te laag om de
radio op te starten)
• Blauw (één korte flits) – sensor is bezig met
uitzenden
• Rood (brandt constant terwijl de knop is
ingedrukt), Oranje (knippert), Rood (knippert)
– sensor is bezig met uitschakelen

Batterij installeren
1. Ontgrendelen: verwijder de T-15-torxschroeven.
2. Deksel verwijderen: trek het deksel van het
hoofdgedeelte weg.
3. Inbrengen: Breng de batterij (CR123A of Parker-
onderdeelnr. QX-008-121) correct uitgericht in (de
symbolen staan gemakshalve op de behuizing).
4. Deksel installeren: druk het deksel vast op
het hoofdgedeelte.
5. Vergrendelen: installeer de T-15-torxschroeven.
