Parker Helac PowerTilt PT-4.5 Installation and operating manual

PowerTilt 4.5
Service and Repair Manual

2Parker Hannifin Corporation
Helac/Cylinder Division
Enumclaw, Washington USA
www.helac.com
PowerTilt Tilting Coupler
PT-4.5 Service & Repair Manual
HY34-1370
Introduction
Product Introduction
This manual contains instructions for the repair,
disassembly and reassembly of the PowerTilt
Model PT-4.5 only. For complete product,
installation, service and safety information, refer
to the PowerTilt Instruction, Service and Repair
Manual for the PT, PTAand PTB Series.
For additional information on maintaining, servicing
orrepairing thePT-4.5, pleasecontact Parker-Helac:
Phone: [phone]
Fax: [phone]
E-Mail: [email protected]
Web: www.helac.com
PT-4.5 Specications
* Weights may vary depending on model size. Approximate weights for PTA and PTB Series do not include mounting brackets or couplers.
** Actual rotation may vary slightly.
Max Machine
Weight
Approximate
PowerTilt Weight*
Total Tilt Driving Torque Holding Torque Required Oil
Flow
Circuit Pressure
Range
4000 lbs 75 lbs 180˚ ** 8200
in-lbs @ 3000 psi
21900
in-lbs @ 3000 psi
.5 - 1
GPM
2175-3250 psi
1800 kg 35 kg 180˚ ** 930
Nm @ 210 bar
2470
Nm @ 210 bar
2 - 4
l/min
150-225 bar

3Parker Hannifin Corporation
Helac/Cylinder Division
Enumclaw, Washington USA
www.helac.com
PowerTilt Tilting Coupler
PT-4.5 Service & Repair Manual
HY34-1370
Drawings
PT-4.5 Assembly Drawing
2X .50 13 8.50 215.9
R 1.72 43.8
2X
1.50 38.0
2X
1.186
1.182
30.13
30.02
THRU, IN LINE
4.65 118.0
2X
1.186
1.182
30.13
30.02
THRU, IN LINE
5.53 140.5
4.09 104.0
2X
6.12 155.5
6.1 6.2
2X 3.9 98
7.20
±.06 183.0 ±1.5
.50 12.7
2X
.35 THRU 9.0
2X
2.48 63.0
4X
.07 1.7
4X
7.60 ±.06 192.9 ±1.52
4.69
- .00
+ .04 119.0 0.0 + 1.0
90°
1
2.01 51.0
4X
4.69
- .00
+ .04 119.0 0.0
+ 1.0
.24 6.0
4X
7.60 ±.06 192.9 ±1.5
6X ASSEMBLY FEATURES
THIS END, 2X SHAFT END
ORIENTATION IS RANDOM
113
BOLT & IDLER FOOT
NOT SHOWN FOR CLARITY
109
113
AA
106
111
111
112
107112
107
(2X PORT ISO 1179-1 - G1/8
AUXILIARY PORT P1)
(2X PORT ISO 1179-1 - G1/4
PORT V1 THIS SIDE
PORT V2 OPPOSITE)
(AUXILIARY PORT P2)
SECTION A-A
409
114
115
421
412
02
304
206 208 205 302 200 202 03 302 205 208
206
304
410 411
421
04
01
204 207
401
NOTE: UNLESS OTHERWISE SPECIFIED
ACTUATOR IS SHOWN AND SHIPPED IN MID POSITION. AS
PRESSURE IS APPLIED TO PORT V1, THE SHAFT WILL
ROTATE IN DIRECTION INDICATED BY ARROW. SHAFT IS
TIMED WITHIN 2
OF POSITION SHOWN AND SHOULD
ROTATE 180 2
ACTUATOR IS ASSEMBLED AND TIMED PER ESP-045.
1
2.
UNLESS OTHERWISE SPECIFIED, DIMENSIONS
ARE INCHES, [mm]. TOLERANCES ARE:
ANGLES
2°
[mm]
[X.XX] = [
.25]
[X.X] = [
1]
[X] = [
2]
INCHES
.XXX =
.010
.XX =
.030
.X =
.060
1 2 3 4 5 6 7 8
F
E
D
C
B
A
1
2 3 4 5 6 7 8
F
E
D
C
B
A
THIS DRAWING IS THE PROPERTY OF HELAC CORPORATION. THE RECIPIENT AGREES BY ACCEPTING IT NOT TO
DISCLOSE ANY INFORMATION REGARDING IT TO ANY UNAUTHORIZED PERSON. ALL DESIGN, MANUFACTURING,
AND SALES RIGHTS REGARDING THIS DRAWING ARE HEREBY EXPRESSLY RESERVED BY HELAC CORPORATION.
HELAC PROPRIETARY NOTICE
DATE
ECO #
REV DESCRIPTION
REVISIONS
RESP
THIRD ANGLE
PROJECTION
DO NOT SCALE DRAWING
PERFORMANCE SPECIFICATIONS
REV.
SHEET:
DATE
SIZE
SCALE:
CAD FILE:
DRAWING NUMBER
APPROVALS
DRAWN
MFG ENGR
RESP ENG
SIMILAR TO
ENGR MGR
ESTIMATED WEIGHT (lb) [kg]
RATED PRESSURE (psi) [bar]
DISPLACEMENT (in³) [cc]
ROTATION (Degrees)
TEST PRESSURE (psi) [bar]
N/A
N/A
(70 ) [32]
(1)
(250-600) [17.3-41.4]
(0/+ 160) [-17/+71]
(4,500) [310]
(14.6) [239]
(8,200) [930 ]
(3,000) [210 ]
(180 )
J. WALSTON
M. HULL
D. LECKMAN
J. WALSTON
01/09/13
01/09/13
01/09/13
01/09/13
1 of 1 72422.SLDDRW
1:1.5
72422
0 B
PTS-4.5-PB-HITZX18-180-N-TI-N
ASSEMBLY
POWERTILT
INITIAL RELEASE PER ET#3309
0
9112
01/09/13
M. HULL
CANTILEVER MOMENT RATING (in-lb) [N-m]
DIMENSIONING AND
TOLERANCING PER
ASME Y14.5M-1994
HELAC CORPORATION
225 BATTERSBY AVE.
ENUMCLAW, WASHINGTON 98022
RATED DRIVING TORQUE (in-lb) [N-m]
TEMPERATURE RANGE (°F) [°C]
BREAK AWAY PRESSURE (psi) [bar]
MAXIMUM BACKLASH (Degrees)
STRADDLE MOMENT RATING (in-lb) [N-m]
71322

4Parker Hannifin Corporation
Helac/Cylinder Division
Enumclaw, Washington USA
www.helac.com
PowerTilt Tilting Coupler
PT-4.5 Service & Repair Manual
HY34-1370
Drawings & Parts List
Parts List
PT-4.5 Exploded View
PARTS
Item Description Quantity
01..........Housing...........................................................1
02..........Shaft................................................................1
03..........Piston Sleeve..................................................1
04..........End Cap..........................................................1
6.1.........Torque Foot.....................................................1
6.2.........Idler Foot.........................................................1
106........Plugs (BSPP 1/8)............................................2
107........Grease Relief Cover........................................2
109........Dowel Pin........................................................2
111 ........Grease Fitting..................................................2
112........Grease Relief..................................................2
113........Screw..............................................................6
114........Screw..............................................................8
115........Washer............................................................8
401........Valve ...............................................................1
409........Screw..............................................................1
410........Spacer.............................................................1
411........Nut...................................................................1
412........Lock Plate .......................................................1
421........Bushing...........................................................2
SEAL KIT
Sold as “kit” only
Item Description Quantity
200........T-Seal............................................................. 1
202........T-Seal............................................................. 1
204........O-Ring............................................................ 1
205........Cup Seal ........................................................2
206........O-Ring............................................................ 2
207........Back-Up Ring................................................. 1
208........O-Ring............................................................ 2
BEARING KIT
Sold as “kit” only
Item Description Quantity
302........Bearing........................................................... 2
304........Thrust Washer................................................ 2
4X
410
2X
302
2X
304409
114 115 412 6.1 113
421 02 208 206
208
205 106 401 01
200 03 204 207 302 205 304 206
04
8X
113
112
421
411
109
2X
202
2X
107
2X
6.2
2X
111

5Parker Hannifin Corporation
Helac/Cylinder Division
Enumclaw, Washington USA
www.helac.com
PowerTilt Tilting Coupler
PT-4.5 Service & Repair Manual
HY34-1370
Parts List & Disassembly
Disassembly
Cross Port Relief Valve
3 4
2
1
Item Description Quantity
1............Manifold Body .................................................1
2............O-Ring.............................................................2
3............Dual Relief.......................................................1
4............Dual PO Check ...............................................1
All numbers that appear in
parenthesis ( ) in the following
sections are referring to items on
Page 3.
1. First remove the tie rod, washer and nut
assembly (409, 410, 411, 412), cap screws
(114) and washers (115) to remove the lower
coupler, bucket, attachments and/or other
assemblies.
2. Next remove the port plugs (106) and
drain the oil. Inspect the oil for signs of
contamination, i.e. water, metal shavings.
3. During the end cap removal process, begin
with removing the set screws (113) that
cover the end cap lock pins (109). Using
a 4 mm drill bit, drill a hole in the center of
each lock pin to a depth of approximately
9.5 mm. Remove the lock pins using a screw
extracting tool. Insert two appropriately
sized screws and service pins in the grease
ports. Unthread the end cap (4) by turning it
counterclockwise using a pry bar. Remove the
end cap and set aside
for inspection.
4. Rotate the shaft (2) and piston sleeve (3) so
both components are ush with the ring gear
inside the housing (1). Do not remove the
Secure product to work bench.
NOTICE
SECTION A-A
SCALE 1 : 1
PARTS LIST PART NUMBER
VENDORDESCRIPTIONQTY
ITEM C3773AHPS
MANIFOLD (ALUMINUM)
11 DC08-40-0-N-25HYDRAFORCEDUAL PO CHECK12 RVBD-08-N-S-0-50 @ 3250 PSICOMMAND CONTROLS
DUAL RELIEF1
32-012 VPARKERO-RING24
AA
===== PROPRIETARY NOTICE =====
C
2012
HYDRA-POWER SYSTEMS, INC.
HYDRA-POWER SYSTEMS, INC.
THIS DRAWING, SKETCH OR TEXT CONTAINS
CONCEPTS, DESIGNS, PRODUCTS AND INFORMATIO N
THAT IS PROPRIETARY TO HYDRA-POWER SYSTEMS,
INC. AND MAY NOT BE REPRODUCED OR GIVEN TO
A THIRD PARTY WITHOUT THE WRITTEN CONSENT OF
HYDRA-POWER SYSTEMS, INC.
CHK
Portland, Oregon
BY
SCALE
DATE OF
SHT
CURRENT JOB #
PREVIOUS JOB #'s
REFERENCE DWG's
CUSTOMER
REV
4 C3678
1
1
10/16/12
1:1
VEST
PO CHECK
MANIFOLD ASSY
HELAC
C3773A (MACH)
M24684
"C"
ASSEMBLY
REVISION HISTORY
REV DESCRIPTION DATE APPROVED
1 RELEASE FOR APPROVAL 10/16/2012 ETS
2 REDUCED BLOCK HEIGHT TO 1.500" 10/17/2012 ETS
3CHANGED P/N OF ITEM 3 10/17/2012 ETS
4CHANGED BLOCK SIZE, MOVED V1 & V2
PORTS PER CUST REQUEST 10/23/2012 ETS
3.50
5.09
3.00
1.50
2
32
32
3
2.11
1.06
2.11
1.06
4
4
44
4
.25
.50 .05
.33.68.70.70.68
2.75
1.50
4
From Excavator

6Parker Hannifin Corporation
Helac/Cylinder Division
Enumclaw, Washington USA
www.helac.com
PowerTilt Tilting Coupler
PT-4.5 Service & Repair Manual
HY34-1370
Disassembly
Disassembly
It is not necessary to remove the
valve block and cartridge unless
leakage is suspected.
the piston sleeve (3) and can be removed.
Gently tap the end of the shaft with a plastic
mallet and mandrel if needed.
7. As in Step 6 above, before removing the
piston sleeve (3), mark the housing (1) ring
gear in relation to the piston sleeve outside
diameter gear with a marker as seen in the
photo below. Be sure to gently push the piston
sleeve (3) out of the housing (1) until the gear
teeth just come out of engagement with the
housing gear teeth. Then remove the piston
sleeve (3). Use a plastic mallet and mandrel
if necessary.Avoid scratching or denting the
inside of the housing bore.
8. Remove all seals, bearings and thrust
washers from the end cap (4), shaft (2), piston
sleeve (3) and housing (1). Note their order
and orientation to aid assembly.
shaft; it must remain in the housing so that
gear timing marks can be located in Step 5.
5. Locate the timing marks on the piston sleeve
(3) gearing and shaft (2). Every PowerTilt has
two sets of small punched timing marks that
indicate timing between the gear sets. One
set indicates the timing between the shaft (2)
and the piston sleeve (3) as seen in the photo
above (the shaft timing marks may be located
in the root or “V” of the gearing). The second
set indicates timing between the piston sleeve
and the housing (1) as seen in the photo
below.
6. Prior to removing the shaft (2), use a felt
marker to highlight the punched timing marks
between the shaft and piston sleeve (3) as
seen in the photo below to simplify timing when
the PowerTilt is reassembled. Rotate the shaft
(2) counterclockwise until it disengages from
NOTICE

7Parker Hannifin Corporation
Helac/Cylinder Division
Enumclaw, Washington USA
www.helac.com
PowerTilt Tilting Coupler
PT-4.5 Service & Repair Manual
HY34-1370
Assembly
Assembly
5. Insert the shaft (2) into the piston sleeve (3),
aligning the timing marks of the shaft with
the piston sleeve. Once the timing marks
are veried, rotate the shaft inward until the
pressure seal (205) contacts the housing (1).
Then tap gently to compress the seal and
rotate the shaft into the housing.
6. Thread the end cap (4) onto the shaft (2).
Using a pry bar, tighten the end cap until the
lock pin (109) holes align. Then insert the lock
pins (109) into the holes with the dimple side
up. Using a punch, tap the lock pins to the
bottom of the hole. Insert the set screws (113)
over the lock pins and tighten to 2.8 Nm. Install
the port plugs (106).
1. Before installation, coat the seals and
machined surfaces with a high quality
hydraulic oil.
2. Coat the end cap (4) threads and both
sides of the thrust washers (304) with
lithium grease.
3. Install all the seals, bearings and thrust
washers on the end cap (4), piston sleeve
(3) shaft (2) and housing (1). Refer to the
Assembly Drawing on Page 2 and PT-4.5
Exploded View on Page 3 for correct locations
and orientations.
4. Carefully insert the piston sleeve (3) into the
housing (1) until it contacts the housing ring
gear. Rotate the piston sleeve until the timing
marks applied to the piston and housing
during the disassembly process align. Using
a plastic mallet or mandrel, tap the piston into
the housing until the gear teeth contact.
Replace all seals, bearings and
thrust washers (304) as required.
NOTICE
As the shaft is installed, be careful not
to disengage the piston sleeve and
housing gearing.
NOTICE
Torque Values for Port Plugs
Torque Values for Metric Fasteners
Plug Size
Torque Value - Hollow Hex
Head Plugs
Nm
Torque Value - Hex Head
Port Plugs
Nm
BSPP G1/8 14 +/- 1 14 +/- 1
BSPP G1/4 31 +/- 1 31 +/- 1
BSPP G3/8 65 +/- 4 65 +/- 4
Fasteners
Socket Head Bolt
(grd 12.9)
Nm
Hex Head Bolt
(grd 10.9)
Nm
Jam Nut
(grd 12.9)
Nm
M10 x 1,50 60 +/- 3 44 +/- 3 27 +/- .2
M12 x 1,75 103 +/- 5 75 +/- 4 41 +/- .3
M16 x 2,00 258 +/- 7 187 +/- 5 54 +/- .5
M20 x 2,50 502 +/- 20 365 +/- 14 61 +/- 1
M24 x 3,00 868 +/- 27 630 +/- 20 68 +/- 2
M30 x 3,50 1 723 +/- 41 1 253 +/- 34
Fastener Torque Specications

8Parker Hannifin Corporation
Helac/Cylinder Division
Enumclaw, Washington USA
www.helac.com
PowerTilt Tilting Coupler
PT-4.5 Service & Repair Manual
HY34-1370
Post Assembly
Greasing and Testing
If the equipment is available, the PowerTilt
should be tested on a hydraulic test bench. The
breakaway pressure — the pressure at which the
shaft begins to rotate — should be approximately
28 bar. Cycle the actuator at least 25 times at 210
bar pressure.
Testing for internal leakage
Connect hydraulic lines to the housing ports.
Bleed all air from the PowerTilt. Rotate the shaft
to the end of rotation at 210 bar and maintain
pressure. Remove the hydraulic line from the
non-pressurized side. Continuous oil ow from
the open housing port indicates internal leakage
across the piston or cross port relief valve.
Replace the line and rotate the shaft to the end
of rotation in the opposite direction. Repeat the
test procedure outlined above for the other port. If
there is an internal leak, disassemble, inspect and
repair.
Greasing
Testing
After the actuator is assembled but before it is
put into service, the thrust washer area must be
packed with Lithium grease.
1. There are two grease ports located on both
the shaft ange and the end cap. They are
plugged with cap screws (113) or set screws.
Remove the grease port screws from the shaft
ange and end cap. (See exploded view on
page 4)
If a hydraulic test bench is not
available, the actuator can be
rotated by hand, open the pressure
ports and use a pry bar with cap
screws inserted into the shaft
ange to turn the shaft in the
desired direction.
2. Insert the tip of a grease gun into one port
and apply grease to the shaft ange. Continue
applying until grease ows from the opposite
port. Cycle the actuator ve times and apply
grease again. Repeat this process on the end
cap. Insert the cap screws into the grease
ports and tighten to 25 in-lbs. (2.8 Nm).
NOTICE

9Parker Hannifin Corporation
Helac/Cylinder Division
Enumclaw, Washington USA
www.helac.com
PowerTilt Tilting Coupler
PT-4.5 Service & Repair Manual
HY34-1370
Install Quick Coupler
1. Install coupler on PowerTilt. Insert 8 ea. M10
screws (114) with washers (115) through lock
plate (412) and torque to 68 Nm (50 ft-lbs).
.
2. Insert screw (409), 1” tie-rod bolt through
center of PowerTilt from the torque foot end,
install spacer (410) and lock-nut (411) and
torque to 920 Nm (680 ft-lbs).
.
Install Quick Coupler

10 Parker Hannifin Corporation
Helac/Cylinder Division
Enumclaw, Washington USA
www.helac.com
PowerTilt Tilting Coupler
PT-4.5 Service & Repair Manual
HY34-1370
Maintenance
1. Grease the thrust washers at the two grease
ttings with a high quality Lithium-based
grease. Apply grease until clean grease ows
from the grease reliefs. Severe operating
conditions such as abrasive dust or prolonged
submersion in water may require more
frequent grease applications.
2. Make sure the grease reliefs are functioning
properly. Open or replace non-functioning
grease reliefs immediately.
NOTICE
Never replace the grease relief
valves with grease ttings or
plugs.
NOTICE
Do not operate the PowerTilt if the
grease reliefs are not functioning.
1. Check shaft end play. When the end play
exceeds 0.38 mm, the end cap must be
tightened.
2. Retighten torque foot M10 bolts (114) to 68
Nm (50 ft-lbs) and tie rod bolt nut (411) to 920
Nm (680 ft-lbs)
Daily Monthly
Maintenance

11 Parker Hannifin Corporation
Helac/Cylinder Division
Enumclaw, Washington USA
www.helac.com
PowerTilt Tilting Coupler
PT-4.5 Service & Repair Manual
HY34-1370
PowerTilt Warranty
Helac Corporation warrants its products to be free from defects in material and factory workmanship for a
period of two (2) years or 2,000 service hours, whichever occurs rst, for applications dened as medium
duty, on the machine for which the HelacAttachment (PowerTilt® or PowerGrip®) was originally designed
and with cross port or work port relief valves installed according to Helac Corporation’s recommendations.
The warranty period shall begin when the Helac Attachment is rst placed into service as documented on
the Warranty Registration Card. Parts and labor will be covered for the rst 12 months or 1000 service
hours after the start of the warranty period. Parts only will be covered for the remainder of the warranty
period.
This warranty shall be voided as to any products which have been repaired, worked upon, or altered by
persons not authorized by Helac Corporation, or which have been subject to misuse, misapplication,
negligence, accident, overload, eld alteration, severe use or service applications beyond what the Helac
Attachment was designed to perform. In no event shall Helac Corporation be liable for any incidental
or consequential damages or claims including, but not limited to, the application in which the product
was placed, eld travel, freight charges, oil samples, downtime, etc. Warranty related repair and/or
replacement issues will be satised according to how the product was originally purchased.
Helac Corporation reserves the right to make changes in the design or construction of any of its products
at any time without incurring any obligations to make changes or alterations to products previously sold.
Helac Corporation reserves the right to alter this warranty and/or its terms at any time. This warranty
is in lieu of all other and/or prior warranties, expressed or implied, and no other company or person is
authorized to represent or assume for Helac Corporation any liability in connection with the sale of Helac
Corporation products other than set forth herein.
Warranty Information

Parker Hannifin Corporation
Helac/Cylinder Division
225 Battersby Avenue
Enumclaw, WA 98022 USA
phone [phone]
fax [phone]
www.helac.com
11/17 / HY34-1370
