Parkside PAT 20-Li A1 User manual

CORDLESS STAPLER PAT 20-Li A1
CORDLESS STAPLER
Translation of the original instructions
AKKU-TACKER
Originalbetriebsanleitung
ACCU-SPIJKERPISTOOL
Vertaling van de originele gebruiksaanwijzing
IAN 346166_2004
CV_346166_PAT20-LiA1_LB6.indd 1-3 02.11.20 09:59

GB/IE/NI Translation of the original instructions Page 1
NL/BE Vertaling van de originele gebruiksaanwijzing Pagina 15
DE/AT/CH Originalbetriebsanleitung Seite 27
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Vouw vóór het lezen de pagina met de afbeeldingen open en maak u vertrouwd met alle functies van het
apparaat.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.
CV_346166_PAT20-LiA1_LB6.indd 1-3 02.11.20 09:59

10 20 30 40 50
AB
C
CV_346166_PAT20-LiA1_LB6.indd 4-6 02.11.20 09:59

20V max.
18V
All Parkside tools and the chargers PLG 20 A1/PLG 20 A2/PLG 20 A3/PDSLG 20 A1 of the
X20V Team series are compatible with the PAP 20 A1/PAP 20 A2/PAP 20 A3 battery pack.
Charging times
Charging currents
2 Ah
Battery pack
PAP 20 A1
3 Ah
Battery pack
PAP 20 A2
4 Ah
Battery pack
PAP 20 A3
max. 2.4 A
Charger PLG 20 A1
60 min
2,4 A
90 min
2,4 A
120 min
2,4 A
max. 3.5 A
Charger PLG 20 A2
45 min
3,5 A
60 min
3,5 A
80 min
3,5 A
max. 4.5 A
Charger PLG 20 A3
35 min
3,8 A
45 min
4,5 A
60 min
4,5 A
max. 4.5 A
Charger PDSLG 20 A1
35 min
3,8 A
45 min
4,5 A
60 min
4,5 A
CV_346166_PAT20-LiA1_LB6.indd 4-6 02.11.20 09:59

PAT 20-Li A1 GB│IE│NI │ 1■
Contents
Introduction............................................................ 2
Intended use........................................................................2
Features ...........................................................................2
Package contents ....................................................................2
Technical data ......................................................................2
General Power Tool Safety Warnings ...................................... 3
1. Work area safety ..................................................................4
2. Electrical safety ...................................................................4
3. Personal safety....................................................................4
4. Power tool use and care ............................................................5
5. Use and handling of the cordless electrical power tool.....................................5
6. Service ..........................................................................5
Appliance-specific safety instructions for electric staple guns...................................6
Safety guidelines for battery chargers ....................................................6
Original accessories/auxiliary equipment .................................................7
Before use ............................................................. 7
Charging the battery pack (seefig.A)....................................................7
Attaching/disconnecting the battery pack to/from the appliance...............................7
Checking the battery charge level .......................................................7
Filling the magazine shaft..............................................................8
Setting the impact force ...............................................................8
Operation ............................................................. 8
Switch on ..........................................................................8
Switching on the LED work light .........................................................8
Troubleshooting .....................................................................8
Maintenance and cleaning................................................ 9
Kompernass Handels GmbH warranty ..................................... 9
Service ...............................................................11
Importer .............................................................11
Disposal..............................................................11
Translation of the original Conformity Declaration ...........................12
Ordering a replacement battery..........................................13
Telephone ordering .................................................................13

PAT 20-Li A1
■ 2 │ GB│IE│NI
CORDLESS STAPLER PAT 20-Li A1
Introduction
Congratulations on the purchase of your new
appliance. You have chosen a high-quality product.
The operating instructions are part of this product.
They contain important information about safety,
usage and disposal. Before using the product,
please familiarise yourself with all operating and
safety instructions. Use the product only as
described and for the range of applications speci-
fied. Please also pass these operating instructions
on to any future owner.
Intended use
This appliance is intended for stapling cardboard,
insulating material, leather, material (textiles or
natural fibre) and comparable materials onto
hardwoods, softwoods, chipboard or plywood-like
material in private households. The appliance is
only for use in dry rooms. Any other uses of or
modification to the appliance is deemed to be
improper and carries the risk of serious personal
injury. The manufacturer accepts no responsibility
for any damage attributable to misuse.
This appliance is not intended for commercial use.
Features
Trigger
Button for the LED work light
Release button for the battery pack
Battery pack*
Battery display LED
Battery charge level button
Magazine slider
Release
Magazine shaft
Scale
Fill level indicator (wire staples)
Tacker nose
Face plate
LED work light
Impact force control
High-speed charger*
Red charge control LED
Green charge control LED
Package contents
1 cordless stapler
500 staples 20 mm
500 nails 20 mm
1 carrying case
1 set of operating instructions
Technical data
Cordless stapler PAT 20-Li A1
Rated voltage 20 V (DC)
Operations up to 30 impacts/min
Magazine shaft capacity 50 pcs
Battery pack PAP 20 A1*
Type LITHIUM ION
Rated voltage 20 V (DC)
Capacity 2.0 Ah
Cells 5

PAT 20-Li A1 GB│IE│NI │ 3■
Charger PLG 20 A1*
INPUT
Rated voltage 230–240 V ∼, 50 Hz
(AC)
Rated power consumption 65 W
Fuse (internal) 3.15 A
OUTPUT
Rated voltage 21.5 V (DC)
Rated current 2.4 A
Charging time approx. 60 min
Protection class II/ (double insulation)
Wire staples
Type 55
15–25mm
Staple width 6 mm
Staple length 15–25 mm
Type 47
15, 20, 25,
32 mm Nail length 15, 20, 25, 32 mm
* BATTERY AND CHARGER ARE NOT INCLUDED
Noise emission value
Noise measurement value determined in accord-
ance with EN 60745. The A-rated noise level of
the power tool is typically as follows:
Sound pressure level LpA = 84.1 dB (A)
Uncertainty KpA = 3 dB
Sound power level LWA = 95.1 dB (A)
Uncertainty KWA= 3 dB
Wear hearing protection!
Total vibration value
Vibration values determined in accordance with
EN 60745:
Vibration emission value ah,W = 3.65 m/s2
Uncertainty K = 1.5 m/s2
NOTE
► The vibration emission value specified in
these instructions has been measured in
accordance with a standardised measuring
procedure and can be used to make equip-
ment comparisons. The specified vibration
emission value can also be used to make an
initial exposure estimate.
WARNING!
► The vibration emission value varies in accord-
ance with the use of the power tool and may
be higher than the value specified in these
instructions in some cases. Regular use of the
power tool in such a way may cause the user
to underestimate the vibration. Try to keep the
vibration loads as low as possible. Examples
of measures for reducing the vibration load
are wearing gloves when using the tool and
limiting the working time. Wherein all states
of operation must be included (e.g. times
when the power tool is switched off and times
where the power tool is switched on but
running without load).
General Power Tool
Safety Warnings
WARNING!
► Read all safety warnings and all instructions.
Failure to follow the warnings and instructions
may result in electric shock, fire and/or
serious injury.
Save all warnings and instructions for future
reference.
The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or battery-
operated (cordless) power tool.

PAT 20-Li A1
■ 4 │ GB│IE│NI
1. Work area safety
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmos-
pheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
2. Electrical safety
a) The mains plug of the power tool must fit into
the socket. Never modify the plug in any way.
Do not use any adapter plugs with earthed
(grounded) power tools. Unmodified plugs
and matching outlets will reduce risk of electric
shock.
b) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of
electric shock if your body is earthed or
grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord
for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.
e) When operating a power tool outdoors, use
an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces
the risk of electric shock.
f) If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces
the risk of electric shock.
3. Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired
or under the influence of drugs, alcohol or
medication. A moment of inattention while
operating power tools may result in serious
personal injury.
b) Use personal protective equipment. Always
wear eye protection. Protective equipment such
as dust mask, non-skid safety shoes, hard hat,
or hearing protection used for appropriate
conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the
switch is in the off-position before connecting
to power source and/or battery pack, picking
up or carrying the tool. Carrying power tools
with your finger on the switch or energising
power tools that have the switch on invites
accidents.
d) Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key
left attached to a rotating part of the power tool
may result in personal injury.
e) Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewel-
lery or long hair can be caught in moving parts.
g) If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use
of dust collection can reduce dust-related
hazards.

PAT 20-Li A1 GB│IE│NI │ 5■
4. Power tool use and care
a) Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at
the rate for which it was designed.
b) Do not use the power tool if the switch does
not turn it on and off. Any power tool that
cannot be controlled with the switch is
dangerous and must be repaired.
c) Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing
accessories or storing power tools. Such
preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool. Power tools are
dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalign-
ment or binding of moving parts, breakage of
parts and any other condition that may affect
the power tool’s operation. If damaged, have
the power tool repaired before use. Many
accidents are caused by poorly maintained
power tools.
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits
etc. in accordance with these instructions,
taking into account the working conditions
and the work to be performed. Use of the
power tool for operations different from those
intended could result in a hazardous situation.
5. Use and handling of the cordless
electrical power tool
a) Charge a rechargeable battery unit using
only the charger recommended by the manu-
facturer. Chargers are often designed for a
particular type of rechargeable battery unit.
There is the danger of fire if other types of
rechargeable battery units are used.
b) Only the rechargeable battery units supplied
are to be used with an electrical power tool.
The use of other rechargeable battery units may
lead to the danger of injury or fire.
c) When they are not being used, store
rechargeable battery units away from paper-
clips, coins, keys, nails, screws or other small
metal objects that could cause the contacts to
be bridged. Short-circuiting the contacts of a
rechargeable battery unit may result in heat
damage or fire.
d) Fluids may leak out of rechargeable battery
units if they are misused. If this happens,
avoid contact with the fluid. If contact occurs,
flush the affected area with water. Seek addi-
tional medical help if any of the fluid gets into
your eyes. Escaping battery fluid may cause
skin irritation or burns.
CAUTION! RISK OF EXPLOSION!
Never charge non-rechargeable
batteries.
Protect the recharge-
able battery from heat (for example, from
continuous exposure to sunlight), fire, water
and moisture. There is a risk of explosion.
6. Service
a) Have your power tool serviced by a qualified
repair person using only identical replace-
ment parts. This will ensure that the safety of
the power tool is maintained.

PAT 20-Li A1
■ 6 │ GB│IE│NI
Appliance-specific safety instructions
for electric staple guns
■Always assume that the power tool
contains staples. Careless handling of the
tacker can lead to unexpected ejection of
staples which could cause injuries.
■Never aim the power tool at yourself or
other people in the vicinity. Unintended
triggering will cause a staple to be shot out,
which can lead to injuries.
■Do not activate the power tool until it is
pressed firmly against the workpiece. If the
power tool is not in contact with the workpiece
the staple can rebound off the fastening point.
■Disconnect the power tool from the mains
or battery if a staple becomes jammed
in the power tool. If the tacker is connected,
it could be unintentionally activated while
removing a jammed staple.
■Be careful when removing a jammed
staple. The system may be under tension and
the staple could be forcefully ejected while you
attempt to unblock the jam.
■Never use this tacker for fastening elec-
trical cables. It is not suitable for the installa-
tion of electrical lines, can damage the insula-
tion of electrical cables and thus cause
electrical shocks and increase the risk of fire.
Safety guidelines for battery
chargers
■ This appliance may be used by
children aged 8 years and above
and by persons with limited phys-
ical, sensory or mental capabilities
or lack of experience and knowl-
edge, provided that they are under
supervision or have been told how
to use the appliance safely and are
aware of the potential risks. Do not
allow children to use the appliance
as a toy. Cleaning and user mainte-
nance tasks may not be carried out
by children unless they are super-
vised.
The charger is suitable for
indoor use only.
ATTENTION!
♦ This charger can only charge the following
batteries: PAP 20 A1/PAP 20 A2/PAP 20 A3.
♦ A current list of battery compatibility can be
found at www.lidl.de/Akku.
WARNING!
■ If the connecting cable needs to be replaced,
this must be carried out by the manufacturer
or an authorised representative in order to
avoid safety hazards.

PAT 20-Li A1 GB│IE│NI │ 7■
Original accessories/auxiliary
equipment
■Only use the accessories and additional
equipment that are specified in the oper-
ating instructions and compatible with the
appliance.
WARNING!
► Do not use any accessories not recom-
mended by PARKSIDE. This can lead to
electric shock and fire.
Before use
Charging the battery pack
(seefig.A)
CAUTION!
► Always unplug the appliance before you
remove the battery pack from or connect the
battery pack to the charger.
NOTE
► Never charge the battery pack if the ambient
temperature is below 10°C or above 40°C.
If a lithium-ion battery is to be stored for an
extended period, the charge level should be
checked regularly. The optimum charge level
is between 50% and 80%. The storage
climate should be cool and dry and the
ambient temperature should be between 0°C
and 50°C.
♦ Connect the battery pack to the high-speed
battery charger (see fig. A).
♦ Insert the power plug into the socket.
The control LED lights up red.
♦ The green LED indicates that the charging
process is complete and the battery pack
is ready.
ATTENTION!
♦ If the red control LED flashes, this means
that the battery pack has overheated and
cannot be charged.
♦ If the red and green control LEDs both
flash, this means that the battery pack is
defective.
♦ Push the battery pack into the appliance.
♦ Switch off the charger for at least 15 minutes
between successive charging sessions. Also
disconnect the power plug from the mains
power socket.
Attaching/disconnecting the battery
pack to/from the appliance
Inserting the battery pack
♦ Allow the battery pack to click into place in
the appliance.
Removing the battery pack
♦ Press the release button and remove the
battery pack .
Checking the battery charge level
♦ Press the battery charge level button to
check the status of the battery (see also main
diagram).
The status will be shown on the battery display
LED as follows:
RED/ORANGE/GREEN = maximum charge
RED/ORANGE = medium charge
RED = low charge – charge the battery

PAT 20-Li A1
■ 8 │ GB│IE│NI
Filling the magazine shaft
Remove the battery before carrying out any
work on the power tool (e.g. maintenance,
changing tools, etc.) as well as during the
transport and storage of the power tool.
Unintentional activation of the trigger can result in
injury.
♦ Remove the battery pack from the appliance.
♦ Turn the appliance around.
♦ Press the release together (see fig. B).
♦ Pull the magazine slider backwards
(see fig. B).
♦ Fill the magazine shaft with staples or nails
(see fig. C).
NOTE
► Ensure the correct position for the nails (see
main diagram, face plate on the appli-
ance).
♦ After filling, push the release into the maga-
zine shaft as far as the stop until it clicks into
place.
NOTE
► The fill level indicator shows whether the
magazine contains staples.
Setting the impact force
NOTE
► Select the lowest impact force sufficient for
stapling. Take into account the length of the
staples or nails you are using as well as
hardness of the material you are working
with.
Increasing the impact force
♦ Turn the impact force control clockwise.
Reducing the impact force
♦ Turn the impact force control anticlockwise.
Operation
Switch on
♦ Press the tacker nose onto the location on
the material that you want to staple until it is
pushed in a few millimetres.
♦ Press the trigger .
Switching on the LED work light
♦ Press the button for the LED work light to
illuminate your workspace in unfavourable
lighting conditions.
Troubleshooting
Cause
A staple is blocking the appliance.
Solution
♦ Remove the battery pack from the appliance.
♦ Turn the appliance around.
♦ Press the release together (see fig. B).
♦ Pull the magazine slider backwards
(see fig. B). This will release the tension.
♦ Remove the staple.
WARNING!
■ Do not hold the power tool by the trigger
if the staple is jammed in the power tool.
While removing a jammed staple, the
trigger can be accidentally activated.

PAT 20-Li A1 GB│IE│NI │ 9■
Maintenance and cleaning
WARNING! RISK OF INJURY!
Always switch the tool off and
remove the battery before carrying
out any work on it.
■ The appliance is maintenance-free.
■ The appliance must always be kept clean, dry
and free from oil or grease.
■ Use a soft, dry cloth to clean the housing.
■ Never permit liquids to penetrate inside the
appliance.
■ If a lithium-ion battery is to be stored for an
extended period, the charge level should be
checked regularly. The optimum charge level is
between 50% and 80%. The optimum storage
environment is cool and dry.
NOTE
► Replacement parts not listed (such as carbon
brushes, switches) can be ordered via our
service hotline.
Kompernass Handels GmbH
warranty
Dear Customer,
This appliance has a 3-year warranty valid from the
date of purchase. If this product has any faults, you,
the buyer, have certain statutory rights. Your statu-
tory rights are not restricted in any way by the
warranty described below.
Warranty conditions
The warranty period starts on the date of purchase.
Please keep your receipt in a safe place. This will
be required as proof of purchase.
If any material or manufacturing fault occurs within
three years of the date of purchase of the product,
we will either repair or replace the product for you
or refund the purchase price (at our discretion).
This warranty service requires that you present the
defective appliance and the proof of purchase
(receipt) within the three-year warranty period,
along with a brief written description of the fault
and of when it occurred.
If the defect is covered by the warranty, your
product will either be repaired or replaced by us.
The repair or replacement of a product does not
signify the beginning of a new warranty period.
X 12 V and X 20 V Team Series battery packs
come with a 3-year warranty valid from the date of
purchase.

PAT 20-Li A1
■ 10 │ GB│IE│NI
Warranty period and statutory claims for
defects
The warranty period is not prolonged by repairs
effected under the warranty. This also applies to
replaced and repaired components. Any damage
and defects present at the time of purchase must be
reported immediately after unpacking. Repairs
carried out after expiry of the warranty period shall
be subject to a fee.
Scope of the warranty
This appliance has been manufactured in accord-
ance with strict quality guidelines and inspected
meticulously prior to delivery.
The warranty covers material faults or production
faults. The warranty does not extend to product
parts subject to normal wear and tear or to fragile
parts which could be considered as consumable
parts such as switches or parts made of glass.
The warranty does not apply if the product has
been damaged, improperly used or improperly
maintained. The directions in the operating instruc-
tions for the product regarding proper use of the
product are to be strictly followed. Uses and
actions that are discouraged in the operating
instructions or which are warned against must be
avoided.
This product is intended solely for private use and
not for commercial purposes. The warranty shall be
deemed void in cases of misuse or improper
handling, use of force and modifications/repairs
which have not been carried out by one of our
authorised Service centres.
The warranty period does not apply to
■ Normal reduction of the battery capacity
overtime
■ Commercial use of the product
■ Damage to or alteration of the product by the
customer
■ Non-compliance with safety and maintenance
instructions, operating errors
■ Damage caused by natural hazards
Warranty claim procedure
To ensure quick processing of your case, please
observe the following instructions:
■ Please have the till receipt and the item number
(e.g.IAN12345) available as proof of purchase.
■ You will find the item number on the type plate
on the product, an engraving on the product,
on the front page of the operating instructions
(below left) or on the sticker on the rear or
bottom of the product.
■ If functional or other defects occur, please
contact the service department listed either by
telephone or by e-mail.
■ You can return a defective product to us free of
charge to the service address that will be
provided to you. Ensure that you enclose the
proof of purchase (till receipt) and information
about what the defect is and when it occurred.
You can download these instructions
along with many other manuals,
product videos and installation
software at www.lidl-service.com.
This QR code will take you directly to the Lidl
service page (www.lidl-service.com) where you
can open your operating instructions by entering
the item number (IAN) 346166_2004.

PAT 20-Li A1 GB│IE│NI │ 11 ■
WARNING!
►Have the power tool repaired by the
service centre or a qualified electrician and
only using genuine replacement parts. This
will ensure that the safety of the appliance is
maintained.
►Always ensure that the power plug or the
mains cable is replaced only by the manu-
facturer of the appliance or its customer
service. This will ensure that the safety of the
appliance is maintained.
Service
Service Great Britain
Tel.: [phone]
E-Mail: [email protected]
Service Ireland
Tel.: [phone]
(0,08 EUR/Min., (peak))
(0,06 EUR/Min., (off peak))
E-Mail: [email protected]
IAN 346166_2004
Importer
Please note that the following address is not the
service address. Please use the service address
provided in the operating instructions.
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com
Disposal
The packaging is made from environ-
mentally friendly material and can be
disposed of at your local recycling plant.
Do not dispose of power tools
in your normal domestic waste!
European Directive 2012/19/EU
requires that worn-out power tools be
collected separately and recycled in an environ-
mentally compatible manner.
Do not dispose of batteries in
your normal household waste!
Defective or worn-out rechargeable
batteries must be recycled according to
Directive 2006/66/EC. Take the battery pack
and/or appliance to a nearby collection facility.
Please consult your local authorities regarding
suitable disposal of worn out power tools/battery
packs.
Dispose of the packaging in an
environmentally friendly manner.
Note the labelling on the packaging
and separate the packaging material
components for disposal if necessary. The pack-
aging material is labelled with abbreviations (a)
and numbers (b) with the following meanings:
1–7: plastics, 20–22: paper and cardboard,
80–98: composites.
Your local community or municipal
authorities can provide information
on how to dispose of the worn-out
product.

PAT 20-Li A1
■ 12 │ GB│IE│NI
Translation of the original Conformity Declaration
We, KOMPERNASS HANDELS GMBH, document officer: Mr Semi Uguzlu, BURGSTR. 21,
44867 BOCHUM, GERMANY, hereby declare that this product complies with the following
standards, normative documents and EC directives:
Machinery Directive
(2006/42/EC)
EC Low Voltage Directive
(2014/35/EU, charger only)
EMC (Electromagnetic Compatibility)
(2014/30/EU)
RoHS Directive
(2011/65/EU)*
* The manufacturer bears the full responsibility for compliance with this conformity declaration. The object of the
declaration described above complies with the requirements of the Directive 2011/65/EU of the European Parliament
and Council of 8 June 2011 on the limitations of use of certain dangerous substances in electrical and electronic
appliances.
Applied harmonised standards
EN 60745-1:2009+A11:2010
EN 60745-2-16:2010
EN 55014-1:2017
EN 55014-2:2015
EN 60335-1:2012+A13:2017
EN 60335-2-29:2004 + A2:2010
EN 62233:2008
EN 61000-3-2:2014
EN 61000-3-3:2013
EN 50581:2012
Type designation of machine: Cordless stapler PAT 20-Li A1
Year of manufacture: 09–2020
Serial number: IAN 346166_2004
Bochum, 09/09/2020
Semi Uguzlu
- Quality Manager -
We reserve the right to make technical changes in the context of further product development.

PAT 20-Li A1 GB│IE│NI │ 13 ■
Ordering a replacement battery
If you want to order a replacement battery for your appliance, you can do so easily via the
Internet on www.kompernass.com or by telephone.
Due to limited stocks, this item may sell out in a relatively short time.
NOTE
► Online ordering of replacement parts might not be possible in some countries. In this is the case,
please contact the Service hotline.
Telephone ordering
Service Great Britain Tel.: [phone]
Service Ireland Tel.: [phone]
(0,08 EUR/Min., peak · 0,06 EUR/Min., off peak)
To ensure fast processing of your order, have the article number of your appliance to hand (e.g.
IAN346166) in case of questions. The article number can be found on the type plate or the title page of
these instructions.

PAT 20-Li A1
■ 14 │ GB│IE│NI

PAT 20-Li A1 NL│BE │ 15 ■
Inhoud
Inleiding..............................................................16
Gebruik in overeenstemming metbestemming.............................................16
Onderdelen .......................................................................16
Inhoud van het pakket ...............................................................16
Technische gegevens ................................................................16
Algemene veiligheidsvoorschriften voor elektrische gereedschappen...........17
1. Veiligheid op de werkplek ..........................................................18
2. Elektrische veiligheid ..............................................................18
3. Veiligheid van personen............................................................18
4. Gebruik en behandeling van hetelektrische gereedschap .................................19
5. Gebruik en behandeling van hetaccugereedschap ......................................19
6. Service .........................................................................20
Apparaatspecifieke veiligheidsvoorschriften voor tackers ....................................20
Veiligheidsvoorschriften voor opladers...................................................20
Vóór de ingebruikname.................................................21
Accupack opladen (zie afb. A) ........................................................21
Accupack in het apparaat plaatsen/uit het apparaat nemen .................................21
Toestand van de accu controleren ......................................................21
Magazijnschacht laden ..............................................................21
Slagkracht instellen..................................................................22
Ingebruikname ........................................................22
Inschakelen........................................................................22
LED-werklampje inschakelen...........................................................22
Problemen oplossen .................................................................22
Onderhoud en reiniging.................................................22
Garantie van Kompernaß Handels GmbH ..................................23
Service ...............................................................24
Importeur ............................................................24
Afvoeren.............................................................24
Vertaling van de oorspronkelijke conformiteitsverklaring ....................25
Vervangende accu bestellen .............................................26
Telefonische bestelling ...............................................................26

PAT 20-Li A1
■ 16 │ NL│BE
ACCU-SPIJKERPISTOOL
PAT 20-Li A1
Inleiding
Hartelijk gefeliciteerd met de aankoop van uw
nieuwe product. U hebt hiermee gekozen voor een
hoogwaardig product. De gebruiksaanwijzing
maakt deel uit van dit product. Deze bevat belang-
rijke aanwijzingen voor veiligheid, gebruik en af-
voer. Lees alle bedienings- en veiligheidsvoor-
schriften voordat u het product in gebruik neemt.
Gebruik het product uitsluitend op de voorgeschre-
ven wijze en voor de aangegeven doeleinden.
Geef alle documenten mee als u het product over-
draagt aan een derde.
Gebruik in overeenstemming
metbestemming
Het apparaat is geschikt voor huishoudelijk gebruik
voor het nieten van karton, isolatiemateriaal, leer,
stof (textiel- of natuurlijke vezels) en vergelijkbare
materialen op hardhout, zacht hout, spaanplaat of
triplexachtig materiaal. Het gebruik is uitsluitend
toegestaan in droge ruimten. Elk ander gebruik of
modificatie van het apparaat geldt als oneigenlijk,
niet-toegelaten gebruik en brengt aanzienlijke
risico's op ongelukken met zich mee. De fabrikant
aanvaardt geen enkele aansprakelijkheid voor
schade die voortvloeit uit oneigenlijk, niet-toegela-
ten gebruik.
Niet bestemd voor commercieel, bedrijfsmatig
gebruik.
Onderdelen
Ontspanner
Knop voor LED-werklampje
Knop voor ontgrendeling van het accupack
Accupack*
Accu-display-LED
Toets accutoestand
Magazijnschuif
Ontgrendeling
Magazijnschacht
Schaalverdeling
Vulpeilweergave (nietjes met fijne draad)
Tackerneus
Kopplaat
LED-werklampje
Slagkrachtregelaar
Snellader*
Rode laadindicator
Groene laadindicator
Inhoud van het pakket
1 accu-spijkerpistool
500 nietjes 20 mm
500 spijkers 20 mm
1 draagtas
1 gebruiksaanwijzing
Technische gegevens
Accu-spijkerpistool PAT 20-Li A1
Nominale spanning 20 V (gelijkstroom)
Werksnelheid max. 30 slagen/min
Capaciteit magazijn-
schacht 50 stuks
Accu PAP 20 A1*
Type LITHIUM-ION
Nominale spanning 20 V (gelijkstroom)
Capaciteit 2,0 Ah
Cellen 5
