Parkside 331133 1907 User manual

Cordless Screwdriver PSSA 4 B2
Akku-Stabschrauber
Originalbetriebsanleitung
Cordless Screwdriver
Translation of the original instructions
Επαναφορτιζόμενο κατσαβίδι
Μετάφραση των αυθεντικών οδηγιών λειτουργίας
IAN 331133_1907

Before reading, unfold the page containing the illustrations and familiarise yourself with all functions
of the device.
Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τη σελίδα με τις εικόνες και εξοικειωθείτε με όλες τις λειτουργίες
της συσκευής.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit
allen Funktionen des Gerätes vertraut.
GB / IE / NI /CY Translation of the original instructions Page XX
GR /CY Μετάφραση των αυθεντικών οδηγιών λειτουργίας Σελίδα XX
DE / AT / CH Originalbetriebsanleitung Seite XX
4
16
30

1
1
2
2
2
3
13
12
5
6
6
11
4
4
12
7
9
10 8
814
15
16
3
5

GB NIIE CY
4
Contents
Introduction .................................4
Intended use................................4
General description......................5
Function description.......................... 5
Extent of the delivery ........................ 5
Overview........................................ 5
Technical data.............................. 6
Safety information ....................... 6
Symbols.......................................... 6
General safety instructions for
power tools ..................................... 7
Correct handling of the
battery charger.............................. 10
Charging process .......................11
Charging the battery ...................... 11
Initial Operation.........................11
Switching ON and OFF.................. 11
Checking the charge status of the
rechargeable battery...................... 12
Set the direction of rotation ............. 12
Inserting/replacing bits................... 12
Handle setting ............................... 12
Use as a torch ............................... 12
Interchangeable attachments ........... 12
Cleaning/Maintenance ...............13
Cleaning....................................... 13
Maintenance ................................. 13
Storage...................................... 13
Disposal and the environment....13
Spare parts/Accessories.............14
Guarantee .................................14
Repair Service............................15
Service-Center............................15
Importer .................................... 15
Introduction
Congratulations on the purchase of your
new device. With it, you have chosen a
high quality product. During production,
this equipment has been checked for qual-
ity and subjected to a nal inspection. The
functionality of your equipment is therefore
guaranteed.
The operating instructions constitute
part of this product. They contain
important information on safety, use
and disposal.
Before using the product, familiarise
yourself with all of the operating
and safety instructions. Use the
product only as described and for
the applications specied. Keep this
manual safely and in the event that
the product is passed on, hand over
all documents to the third party.
Intended use
The device is intended for drilling screws in
and out in wood, metal or plastic and for
light drilling operations. The device is not
suitable for commercial use. Commercial
use will invalidate the guarantee.
Any other use not specically mentioned
in this manual can lead to damage to the
unit and may present a serious hazard to
the user.
The manufacturer will not be held respon-
sible for damage or injuries caused by use
outside that stipulated by the manual or by
improper handling.
Translation of the original EC
declaration of conformity...........43

GB NIIE CY
5
General description
The illustration of the prin-
cipal functioning parts can
be found on the front foldout
pages.
Function description
The cordless screwdriver rotates in a clock-
wise and counter-clockwise direction.
Furthermore, the device can be used as a
torch.
Please read the following descriptions for
the function of the various controlling parts
of the unit.
Extent of the delivery
Carefully unpack the appliance and check
that it is complete.
Dispose of the packaging material cor-
rectly.
- Cordless screwdriver
- Charger
- 26 bits
- 1 Bit holder
-Case
- Instruction Manual
26 bits:
Slot No.
No.
No.
No.
No.
No.
No.
Cross
Cross
Tor x
Hexagonal
SL
25mm 3 • 4 •5 •6 •7
50mm 5
PZ
25mm PZ0 • 2x PZ1 • 2x PZ2 • PZ3
PZ2
PH0 • 2x PH1 • 2x PH2 • PH3
T10 • T15 • T20 • T25
H3 • H4 • H5
50mm
PH
25mm
T
25mm
H
25mm
Overview
1 Bit adapter
2 Release key for handle setting
3 Torch (not visible)
4 Battery Indicator
5 On/off switch, torch
6 Handle
7 On/Off switch
8 Direction switch
9 LED work light
10 Charger
11 Charging cable USB plug
12 Charging cable connector
13 Charging socket
14 Bits
15 Bit holder
16 Covering cap

GB NIIE CY
6
Technical data
Cordless screwdriver...... PSSA 4 B2
Motor voltage Umax ............4 V ; 1.5 Ah
Rated speed (n0).......................200 min-1
Torque ................................ max. 5Nm
Weight (without charger) .............0.45 kg
Sound pressure level (LpA)........ 53.2 dB(A)
................................................ K= 3 dB
Sound power level (LWA) ......... 64.2 dB(A)
................................................ K= 3 dB
Vibration (ah) while
tightening a screw .< 2.5 m/s2, K= 1.5 m/s2
Battery (Li-Ion)
Battery cells...................................... 1
Nominal voltage........................ 4 V
Capacity.................................. 1.5 Ah
Charging time ..................approx. 1 h*
* only in conjunction with
the supplied charger.
Charger ...............JLH100501700B1
Nominal consumption..................16 W
Voltage input .....100-240 V~, 50-60 Hz
Voltage Output ......................... 5 V
Output current ..................... 1700 mA
Protection class ............................. II
Protection category ...................... IPX0
The noise and vibration levels have been
calculated according to the norms stated in
the conformity statement.
The stated vibration emission value was
measured in accordance with a standard
testing procedure and may be used to com-
pare one power tool to another. The stated
vibration emission value may also be used
for a preliminary exposure assessment.
Warning: The vibration emission
value may differ during actual use
of the power tool from the stated
value depending on the manner in
which the power tool is used.Safety
precautions aimed at protecting the
user should be based on estimated
exposure under actual usage condi-
tions (all parts of the operating cy-
cle are to be considered, including,
for example, times during which the
power tool is turned off and times
when the tool is turned on but is
running idle).
Safety information
When using the device, please observe the
safety instructions.
Symbols
Symbols in the manual
Warning symbols with in-
formation on damage and
injury prevention.
Instruction symbols with information
on preventing damage.
Wear ear protection.
Help symbols with information on
improving tool handling.
Symbols on the unit
Before using for the rst time, care-
fully read through the user manual.
Li-Ion
Do not dispose of the device
with the battery installed in
household waste.

GB NIIE CY
7
away while operating a power
tool. Distractions can cause you to
lose control.
2) ELECTRICAL SAFETY
a) Power tool plugs must match
the outlet. Never modify the
plug in any way. Do not use
any adapter plugs with earthed
(grounded) power tools. Unmodi-
ed plugs and matching outlets will
reduce risk of electric shock.
b) Avoid body contact with
earthed or grounded surfaces,
such as pipes, radiators, ranges
and refrigerators. There is an
increased risk of electric shock if your
body is earthed or grounded.
c) Do not expose power tools to
rain or wet conditions. Water
entering a power tool will increase the
risk of electric shock.
d) Do not abuse the cord. Never
use the cord for carrying, pull-
ing or unplugging the power
tool. Keep cord away from
heat, oil, sharp edges or mov-
ing parts. Damaged or entangled
cords increase the risk of electric
shock.
e) When operating a power tool
outdoors, use an extension cord
suitable for outdoor use. Use of a
cord suitable for outdoor use reduces
the risk of electric shock.
f) If operating a power tool in a
damp location is unavoidable,
use a RCD (Residual Current
Device) protected supply with
a rated leakage current of not
more than 30 mA. Use of an RCD
reduces the risk of electric shock.
Symbols on the charger
Attention!
Read the manual.
The charger is for indoor use only.
Protection class II
Electric devices do not belong with
domestic waste.
General safety instructions
for power tools
WARNING! Read all safety
notices, instructions, illustra-
tions and technical data that
have been provided with this
power tool. Omissions in the
compliance with safety directions
and instructions can cause electrical
shock, re and/or severe injuries.
Retain all safety directions and in-
structions for future use.
The term “Power Tools” used in the safety
instructions refers to mains-operated power
tools (with power cord) and to battery-op-
erated power tools (without power cord).
1) WORK AREA SAFETY
a) Keep work area clean and well
lit. Cluttered or dark areas invite ac-
cidents.
b) Do not operate power tools in
explosive atmospheres, such as
in the presence of ammable
Iiquids, gases or dust. Power tools
create sparks which may ignite the
dust or fumes.
c) Keep children and bystanders

GB NIIE CY
8
3) PERSONAL SAFETY
a) Stay alert, watch what you are
doing and use common sense
when operating a power tool.
Do not use a power tool while
you are tired or under the inu-
ence of drugs, alcohol or medi-
cation. A moment of inattention white
operating power tools may result in
serious personal injury.
b) Use personal protective equip-
ment. Always wear eye protec-
tion. Protective equipment such as
dust mask, non-skid safety shoes, hard
hat, or hearing protection used for
appropriate conditions will reduce per-
sonal injuries.
c) Prevent unintentional starting.
Ensure the switch is in the off-
position before connecting to
power source and/or battery
pack, picking up or carrying
the tool. Carrying power tools with
your nger on the switch or energising
power tools that have the switch on
invites accidents.
d) Remove any adjusting key or
wrench before turning the pow-
er tool on. A wrench or a key left at-
tached to a rotating part of the power
tool may result in personal injury.
e) Do not overreach. Keep proper
footing and balance at all times.
This enables better control of the pow-
er tool in unexpected situations.
f) Dress properly. Do not wear
loose clothing or jewellery.
Keep your hair, clothing and
gloves away from moving
parts. Loose clothes, jewellery or long
hair can be caught in moving parts.
g) If dust extraction and collection
devices can be installed, make
sure that these are connected
and used correctly. Use of dust
collection can reduce dust-related haz-
ards.
h) Do not allow yourself to be
lulled into a false sense of se-
curity and do not disregard the
safety rules for power tools,
even if you are familiar with the
power tool after using it many
times. Careless action can lead to
serious injuries within a fraction of a
second.
4) POWER TOOL USE AND CARE
a) Do not force the power tool. Use
the correct power tool for your
application. The correct power tool
will do the job better and safer at the
rate for which it was designed.
b) Do not use the power tool if the
switch does not turn it on and
off. Any power tool that cannot be
controlled with the switch is dangerous
and must be repaired.
c) Remove the plug from the wall
socket and/or remove the re-
chargeable battery before you
change the device’s settings,
change accessory parts or put
away the power tool. Such pre-
ventive safety measures reduce the risk
of starting the power tool accidentaIly.
d) Store idle power tools out of the
reach of children and do not al-
low persons unfamiliar with the
power tool or these instructions
to operate the power tool. Power
tools are dangerous in the hands of
untrained users.
e) Look after the power tool and
application tool carefully. If dam-
aged, have the power tool repaired

GB NIIE CY
9
before use. Many accidents are caused
by poorly maintained power tools.
f) Keep cutting tools sharp and
clean. Properly maintained cutting
tools with sharp cutting edges are less
Iikely to bind and are easier to control.
g) Use the power tool, accessories
and tool bits etc. in accordance
with these instructions, taking
into account the working condi-
tions and the work to be per-
formed. Use of the power tool for op-
erations different from those intended
could result in a hazardous situation.
h) Keep handles and grip surfaces
dry, clean and free from oil and
grease. Slippery handles and grip
surfaces do not permit safe operation
and control over the power tool in un-
expected situations.
5) CAREFUL HANDLING AND USE
OF BATTERY DEVICES
a) Charge the batteries only in
chargers that are recommended
by the manufacturer. Risk of re if a
charger that is suitable for a specic type
of battery is used with other batteries.
b) In the power tools, use only the
batteries designed for the pur-
pose. The use of other batteries may
result in injuries and risk of re.
c) Keep the unused battery away
from paper clips, coins, keys,
nails, screws and other small
metal objects, which could
cause bridging of the contacts.
A short circuit between the battery con-
tacts may cause burns or re.
d) If used incorrectly, liquid may
leak from the battery. Avoid
contact with this. In the event of
accidental contact, rinse off with
water. If the liquid gets into
eyes, seek medical assistance.
Leaking battery uid may cause skin
irritations or burns.
e) Do not use damaged or altered
batteries. Damaged or altered batter-
ies can be unpredictable and lead to
re, explosion or risk of injury.
f) Do not expose batteries to re
or elevated temperatures. Fire or
temperatures over 130oC can cause
an explosion.
g) Follow all instructions for charg-
ing and never charge the bat-
tery or the battery-powered
tool outside the temperature
range stated in the operating
instructions. Incorrect charging or
charging outside the permitted tem-
perature range may destroy the battery
and increase the risk of re.
6) SERVICE
a) Have your power tool serviced
by a qualied repair person us-
ing only identical replacement
parts. This will ensure that the safety
of the power tool is maintained.
b) Never repair damaged batter-
ies. All battery repairs should be car-
ried out by the manufacturer or author-
ised customer service centres only.
7) SPECIFIC SAFETY INSTRUCTIONS
FOR POWER SCREWDRIVERS:
a) Hold the appliance by the in-
sulated handle grips when
performing work in which the
screw may come into contact
with hidden wiring or its own

GB NIIE CY
10
power cord. If the screw were to
come into contact with a live electrical
cable, metal parts of the appliance
could also become live and cause an
electric shock.
8) SPECIAL SAFETY DIRECTIONS
FOR BATTERY-OPERATED TOOLS
a) Do not subject the battery to
strong sunlight over long pe-
riods and do not leave it on a
heater. Heat damages the battery
and there is a risk of explosion.
b) Allow a hot battery to cool be-
fore charging.
c) Do not open up the battery and
avoid mechanical damage to
the battery. Risk of short circuit and
fumes may be emitted that irritate the
respiratory tract. Ensure fresh air and
seek medical assistance in the event of
discomfort.
Correct handling of the
battery charger
a) This appliance can be used
by children aged from 8
years and above and per-
sons with reduced physical,
sensory or mental capa-
bilities or lack of experience
and knowledge if they have
been given supervision or
instruction concerning use of
the appliance in a safe way
and understand the hazards
involved. Children shall not
play with the appliance.
Cleaning and user mainte-
nance shall not be made by
children without supervision.
b) Do not use the charger to
charge non-rechargeable bat-
teries.
c) Before each use, check
the charger, cable and
plug and have them
repaired by qualied
professionals and only
with original parts.
Do not use a defective
charger and do not
open it up yourself. This
ensures that the safety of the
device is maintained.
d) Connect the charger
only to a socket with an
earth. Ensure that the
mains voltage matches
the specications on the
charger rating plate.
Risk of electric shock.
e) Disconnect the charger
from the mains before
closing or opening con-
nection to the battery /
power tool / device. This
ensures that the battery and
charger are not damaged.
f) Keep the charger clean
and away from wet
and rain. Do not use
the charger outdoors.
Dirt and the entry of water
increase the risk of electric
shock.
g) Operate the charger
only with the appropri-
ate original batteries.
Charging other batteries may
result in injuries and risk of
re.
h) Avoid mechanical dam-
age to the charger. This
can result in internal short
circuits.

GB NIIE CY
11
i) Do not operate the
charger on a combusti-
ble surface (e.g. paper,
textiles). Risk of re due to
heating during charging.
j) In order to minimise the
risk of electric shock,
pull the charger plug
out of the socket prior
to cleaning it.
k) If the power cable
for this equipment is
damaged, it must be
replaced by the manu-
facturer, a customer ser-
vice agent of the same
or a similarly qualied
person in order to pre-
vent hazards.
Charging process
Do not expose the battery to
extreme conditions such as
heat and impact. There is a
risk of injury from leaking
electrolyte solution! In case
of contact, rinse with water
or neutraliser and consult a
doctor if contact has occurred
with eyes etc.
Charge the battery only in
dry areas.
There is a risk of injury from
electric shock.
• The device may only be powered with
SELV (Safety Extra Low Voltage) as
marked on the device.
• Before initial use, charge the battery
installed in the equipment.
• To charge the Li-ion battery integrated
in the appliance, use only the
JLH100501700B1 battery charger
supplied.
• In all cases, observe the applicable
safety information as well as the regu-
lations and directions for environmental
protection.
• Defects resulting from improper han-
dling are not subject to the guarantee.
Charging the battery
1. Connect the charging cable connector
(12) with the charging socket (13) of
the device.
Insert the USB plug ( 11) of the
charging cable into the charger ( 10)
2. Plug the charger ( 10) into an elec-
trical outlet.
3. The battery indicator (4) lights up:
red => Start of charging
red and yellow =>
Battery appr. half charged
red-yellow-green =>
Battery fully charged.
4. After the charging process, disconnect
the charger ( 10) from the mains
supply.
Initial Operation
Wearing hearing protection reduces
the risk of hearing damage.
Switching ON and OFF
1. Press the on/off switch (7) to start
the device. The LED work light (9)
lights up during operation.
2. To turn it off, release the on/off
switch (7).

GB NIIE CY
12
Overload protection: The safety cut-off of
the device switches off in case of overload.
Release the On/Off switch, the device can
be switched on again after a few seconds.
Checking the charge status
of the rechargeable battery
The battery indicator ( 4) signalises the
state of charge of the battery.
• Press the On/Off switch, the state of
charge of the battery is displayed by
turning on the 3 coloured LED lights:
red-yellow-green => Battery fully
charged
red and yellow =>
Battery appr. half charged
red => Battery is empty, please charge.
Set the direction of
rotation
You can select the direction of rotation with
the direction switch (clockwise and anti-
clockwise direction) and secure the device
against accidental start up.
1. Wait for the device to shut-down.
2. Clockwise direction:
Press direction switch (8) to the
right.
3. Anticlockwise direction:
Press direction switch (8) to the
left.
4. Switch lock: Bring direction switch to
neutral position.
Direction switch may only be acti-
vated at a standstill to prevent dam-
age to the transmission.
Inserting/replacing bits
Prior to commencing any work
on the device, bring the direction
switch ( 8) to the neutral position
in order to prevent an accidental
start up.
1. Insert the desired bit (14) or bit holder
(15) into the bit adapter (1).
2. To remove the bit or bit holder pull the
bit or bit holder out of the bit adapter.
Handle setting
Prior to commencing any work on
the device, bring the direction switch
(8) to the neutral position in
order
to prevent an accidental start up.
The device can be locked in two hand
settings:
- Pistol grip position
- Rod position
Press the release key PRESS (2) and
turn the handle (6) of the device by
180°. It locks into place audibly.
Use as a torch
1. Press the on/off switch (5) on the un-
derside of the handle (6). The torch
lights up.
2. To switch off, press the on/off switch (5)
again.
Interchangeable
attachments
You can remove the cap (16) in order to
use compatible interchangeable attach-
ments for Series PAS 4 B2/B3 cordless
screwdrivers.

GB NIIE CY
13
Grip one of the two recesses on the cap
and remove the cap.
Please consult the instruction manual sup-
plied with the exchange attachments for
assembly and disassembly of the exchange
attachments.
Cleaning/Maintenance
Leave any work not covered in this
manual to our Service Centre. Only
use original parts. There is a risk of
injury!
Cleaning
Clean and service the device regularly as
follows. This guarantees a long life for your
unit:
Do not jet water onto the
appliance and do not clean
it under owing water. This
would result in the danger of
an electric shock and the ap-
pliance could be damaged.
• Keep the ventilation slits, motor housing
and handles on the equipment clean. To
do this, use a damp cloth or brush.
Never use cleaning agents or solvents,
which can cause irreparable damage to
the unit.
Maintenance
The device is maintenance free.
Storage
• Keep the device in the carry case sup-
plied, dry and out of reach of children.
• Store the battery only in a partially
charged state. The state of charge should
be 40 – 60 % over a longer storage pe-
riod (1-2 LEDs are on).
• Store the device between 10° C and
25° C. During storage, avoid extreme
cold or heat so the battery does not lose
power.
• During a longer storage period, check
the state of charge of the battery and
recharge if necessary roughly every
3months.
Disposal and the
environment
Be environmentally friendly. Return the tool,
accessories and packaging to a recycling
centre when you have nished with them.
Electrical machines do not belong
with domestic waste.
Li-Ion
Do not dispose of the device
with the battery installed in
household waste, re (risk of
explosion) or water. Damaged
batteries may damage the envi-
ronment and your health if toxic
fumes or liquids leak out.
• Dispose of the equipment with the
battery discharged. Do not open the
equipment or the battery.
• Dispose of the equipment in accord-
ance with the local regulations. Take
the equipment to a collection point,
where it will be recycled in an environ-
mentally friendly manner. For informa-
tion about this, ask your local waste
management company or our service
centre.
• Defective units returned to us will be
disposed of for free.

GB NIIE CY
14
Spare parts/Accessories
Spare parts and accessories
can be obtained at
www.grizzly-service.eu
If you have issues ordering, please use the
contact form. If you have any other ques-
tions, contact the service centre
(see “Service-Center” Page 15).
26 Bits.................................. 91104080
Bit holder .............................. 91104081
Charger EU........................... 80001038
Charger UK........................... 80001039
Guarantee
Dear Customer,
This equipment is provided with a 3-year
guarantee from the date of purchase.
In case of defects, you have statutory rights
against the seller of the product. These
statutory rights are not restricted by our
guarantee presented below.
Terms of Guarantee
The term of the guarantee begins on the
date of purchase. Please retain the original
receipt. This document is required as proof
of purchase.
If a material or manufacturing defect
occurs within three years of the date of
purchase of this product, we will repair or
replace – at our choice – the product for
you free of charge. This guarantee requires
the defective equipment and proof of pur-
chase to be presented within the three-year
period with a brief written description of
what constitutes the defect and when it oc-
curred.
If the defect is covered by our guarantee,
you will receive either the repaired product
or a new product. No new guarantee pe-
riod begins on repair or replacement of the
product.
Guarantee Period and Statutory
Claims for Defects
The guarantee period is not extended by
the guarantee service. This also applies for
replaced or repaired parts. Any damages
and defects already present at the time of
purchase must be reported immediately af-
ter unpacking. Repairs arising after expiry
of the guarantee period are chargeable.
Guarantee Cover
The equipment has been carefully pro-
duced in accordance with strict quality
guidelines and conscientiously checked
prior to delivery.
The guarantee applies for all material and
manufacturing defects. This guarantee
does not extend to cover product parts that
are subject to normal wear and may there-
fore be considered as wearing parts (e.g.
bits, charger) or to cover damage to break-
able parts (e.g. switches, batteries).
This guarantee shall be invalid if the prod-
uct has been damaged, used incorrectly or
not maintained. Precise adherence to all of
the instructions specied in the operating
manual is required for proper use of the
product. Intended uses and actions against
which the operating manual advises or
warns must be categorically avoided.
The product is designed only for private
and not commercial use. The guarantee
will be invalidated in case of misuse or
improper handling, use of force, or inter-
ventions not undertaken by our authorised
service branch.

GB NIIE CY
15
Processing in Case of Guarantee
To ensure quick handling of you issue,
please follow the following directions:
• Please have the receipt and identica-
tion number (IAN 331133_1907)
ready as proof of purchase for all en-
quiries.
• Please nd the item number on the rat-
ing plate.
• Should functional errors or other de-
fects occur, please initially contact the
service department specied below by
telephone or by e-mail. You will then
receive further information on the pro-
cessing of your complaint.
• After consultation with our customer
service, a product recorded as defec-
tive can be sent postage paid to the
service address communicated to you,
with the proof of purchase (receipt)
and specication of what constitutes
the defect and when it occurred. In or-
der to avoid acceptance problems and
additional costs, please be sure to use
only the address communicated to you.
Ensure that the consignment is not sent
carriage forward or by bulky goods,
express or other special freight. Please
send the equipment inc. all accessories
supplied at the time of purchase and
ensure adequate, safe transport pack-
aging.
Repair Service
For a charge, repairs not covered by the
guarantee can be carried out by our ser-
vice branch, which will be happy to issue
a cost estimate for you.
We can handle only equipment that has
been sent with adequate packaging and
postage.
Attention: Please send your equipment to
our service branch in clean condition and
with an indication of the defect.
Equipment sent carriage forward or by
bulky goods, express or other special
freight will not be accepted.
We will dispose of your defective devices
free of charge when you send them to us.
Service-Center
GB Service Great Britain
Tel.: [phone]
E-Mail: [email protected]
IAN 331133_1907
IE
NI
Service Ireland
Northern Ireland
Tel.: [phone]
(0,08 EUR/Min., (peak))
(0,06 EUR/Min., (off peak))
E-Mail: [email protected]
IAN 331133_1907
CY Service Cyprus
Tel.: [phone]
E-Mail: [email protected]
IAN 331133_1907
Importer
Please note that the following address is
not a service address. Please initially con-
tact the service centre specied above.
Grizzly Tools GmbH & Co. KG
Stockstädter Straße 20
63762 Großostheim
Germany
www.grizzly-service.eu

16
GR CY
Περιεχόμενα

................................................16
....................................16
................................17
Περιγραφή λειτουργίας ......................17
Παραδοτέα υλικά ...............................17
Επισκόπηση ......................................17
...................................18
.........................18
Σύμβολα και εικονοσύμβολα .............18
Γενικές υποδείξεις ασφαλείας
για ηλεκτρικά εργαλεία ......................19
Σωστή μεταχείριση της συσκευής
φόρτισης συσσωρευτή ......................23
 ................................................24
Φόρτιση συσσωρευτή .......................24
.....................................24
Ενεργοποίηση και απενεργοποίηση .24
Έλεγχος κατάστασης φόρτισης του
συσσωρευτή......................................25
Ρύθμιση κατεύθυνσης περιστροφής .25
Τοποθέτηση/Αλλαγή μυτών ...............25
Ρύθμιση λαβής ..................................25
Χρήση ως φακός ...............................26
Προσαρτήματα αντικατάστασης ........26
 .....................26
Καθαρισμός .......................................26
συντήρηση ........................................26
 ........................................26

.....................................27
 .....................27
 ...............................................28
.................................29
Service-Center .....................................29
 ..........................................29
εισαγωγή
Συγχαρητήρια για την αγορά της νέας συ-
σκευής σας. Προτιμήσατε να αγοράσετε
ένα προϊόν ανώτερης ποιότητας.
Η ποιότητα αυτής της συσκευής ελέγχθη-
κε κατά τη διάρκεια της παραγωγής, αλλά
και σε τελικό έλεγχο. Με τον τρόπο αυτό
εξασφαλίστηκε η λειτουργικότητα της συ-
σκευής σας.
Οι οδηγίες χρήσης αποτελούν
αναπόσπαστο τμήμα αυτού του
προϊόντος. Περιέχουν σημαντικές
υποδείξεις για την ασφάλεια, τη
χρήση και διάθεση της συσκευής.
Πριν τη χρήση του προϊόντος να
εξοικειωθείτε με όλες τις οδηγίες
χειρισμούς και τις υποδείξεις ασφα-
λείας. Να χρησιμοποιείτε το προϊόν
μόνο όπως περιγράφεται και μόνο
για τον αναφερόμενο σκοπό.
Να φυλάξετε καλά τις οδηγίες και
να τις παραδώσετε σε τρίτους μαζί
με το προϊόν.
Σκοπός χρήσης
Η συσκευή προορίζεται για το βίδωμα και
το λύσιμο βιδών σε ξύλο, μέταλλο ή πλα-
στικό και για ελαφριές εργασίες διάτρησης.
Αυτή η συσκευή δεν είναι κατάλληλη για
επαγγελματική χρήση. Σε περίπτωση
επαγγελματικής χρήσης παύει να ισχύει η
εγγύηση.
Οποιαδήποτε άλλη χρήση, η οποία δεν
εγκρίνεται ρητά μέσα από τις οδηγίες
αυτές, μπορεί να προκαλέσει ζημιές στη
συσκευή και να αποτελέσει σοβαρό κίνδυ-
νο για το χρήστη. Ο κατασκευαστής δεν
ευθύνεται για ζημιές που προκλήθηκαν
λόγω μη ενδεδειγμένης χρήσης ή λόγω
εσφαλμένου χειρισμού.

..............44

17
GR CY
Γενική περιγραφή
Την απεικόνιση των σημα-
ντικότερων εξαρτημάτων
λειτουργίας θα βρείτε στη
σελίδα-φάκελλο.
Περιγραφή λειτουργίας
Το επαναφορτιζόμενο κατσαβίδι διαθέτει
δεξιόστροφη και αριστερόστροφη κίνηση.
Επιπρόσθετα μπορεί η συσκευή να χρησι-
μοποιείται σαν λυχνία εργασίας.
Τη λειτουργία των εξαρτημάτων χειρισμού
θα την βρείτε στις ακόλουθες περιγραφές.
Παραδοτέα υλικά
Βγάλτε τη συσκευή από τη συσκευασία
και ελέγξτε, αν είναι πλήρης:
Διαθέστε τα υλικά συσκευασίας σύμφωνα
με τους κανονισμούς.
- Επαναφορτιζόμενο κατσαβίδι
- Φορτιστής
- 26 Μύτες
- 1 Συγκράτηση μυτών
- Βαλίτσα
- Οδηγιών χρήσης

Υποδοχή Αρ.
Αρ.
Αρ.
Αρ.
Αρ.
Αρ.
Αρ.
Σταυρός
Σταυρός
Torx
Εξάγωνο
SL
25mm 3 • 4 •5 •6 •7
50mm 5
PZ
25mm PZ0 • 2x PZ1 • 2x PZ2 • PZ3
PZ2
PH0 • 2x PH1 • 2x PH2 • PH3
T10 • T15 • T20 • T25
H3 • H4 • H5
50mm
PH
25mm
T
25mm
H
25mm
Επισκόπηση
1 Υποδοχή μυτών
2 Πλήκτρο απασφάλισης για την
ρύθμιση λαβής
3 Φακός (δεν απεικονίζεται)
4 Ένδειξη κατάστασης φόρτισης
5 Διακόπτης ενεργο-/απενεργο-
ποίησης, φακός
6 Λαβή
7 Διακόπτης ενεργο-/απενεργο-
ποίησης
8 Διακόπτης κατεύθυνσης
περιστροφής
9 Λυχνία εργασίας LED
10 Φορτιστής
11 Καλώδιο φόρτισης με βύσμα
USB
12 Βύσμα καλωδίου φόρτισης
13 Υποδοχή φόρτισης
14 Μύτες
15 Συγκράτηση μυτών
16 Πώμα επικάλυψης

18
GR CY
Τεχνικά στοιχεία
Κατσαβιδι μπαταριας .... PSSA 4 B2
Τάση κινητήρα Umax ............4V ; 1,5 Ah
Αριθμός στροφών ρελαντί (n0) .... 200 min-1
Ροπή στρέψης ......................... μέγ. 5 Nm
Βάρος ((χωρίς Φορτιστής) .............0,45 kg
Στάθμη ηχητικής πίεσης (LpA) ...53,2 dB(A)
......................................................K= 3 dB
Επιτρεπόμενη στάθμη θορύβου
(LwA) ..........................64,2 dB(A), K= 3 dB
Δονήσεις (ah)
κατά το βίδωμα .... < 2,5 m/s2, K= 1,5 m/s2
Μονάδα μπαταρίας (Li-Ion)
Κυψελοειδείς μπαταρίες .......................1
Ονομαστική τάση ......................... 4 V
Χωρητικότητα ..............................1,5 Ah
Διάρκεια φόρτισης ................ περίπ. 1 h*
* μόνο σε συνδυασμό με την απεσταλμένη
συσκευή φόρτισης.
Φορτιστής ..........JLH100501700B1
Απόδοση .......................................... 16 W
Τάση εισόδου/
Input....................... 100-240 V~, 50-60 Hz
Τάση εξόδου/
Output ............................................. 5 V
Ρεύμα εξόδου .............................1700 mA
  ............................. II
  ............................. IPX0
H αφερόμενη τιμή μετάδοσης δόνησης
μετρήθηκε βάσει τυποποιημένης μεθόδου
δοκιμής και μπορεί να χρησιμοποιηθεί για
τη σύγκριση μίας ηλεκτρικής συσκευής με
μία άλλη.
Η αναφερόμενη τιμή μετάδοσης δόνησης
μπορεί επίσης να χρησιμοποιηθεί και για
αρχική εκτίμηση της έκθεσης.

Η τιμή μετάδοσης της δόνησης
μπορεί να διαφέρει κατά την πραγ-
ματική χρήση της ηλεκτρικής συ-
σκευής από την αναφερόμενη τιμή,
ανάλογα με τον τρόπο χρήσης της.
Πρέπει να οριοσθούν μέτρα
ασφαλεάις για την προστασία του
χειριστή βασιζόμενα σε εκτίμηση
της έκθεσης κατά τη διάρκεια των
πραγματικών συνθηκών χρήσης
(εδώ να ληφθούν υπόψη τα πο-
σοστά του κύκλου λειτουργίας, για
παράδειγμα οι χρόνοι κατά τους
οποίους είναι απενεργοποιημένη
η συσκευή και οι χρόνοι κατά τους
οποίους είναι μεν ενεργοποιημένη
η συσκευή αλλά λειτουργεί χωρίς
φορτίο).
Υποδείξεις ασφάλειας
Kατά τη χρήση της μηχανής να ακολουθεί-
τε τις υποδείξεις ασφαλείας.
Σύμβολα και εικονοσύμβολα

Διαβάστε τις οδηγίες χρήσης της
μηχανής και ακολουθήστε τις.
Li-Ion
   
 -  
.

Προσοχή!
Πριν τη φόρτιση να μελετήσετε τις
Οδηγίες χρήσης.
Ο φορτιστής προορίζεται μόνο για
φόρτιση σε εσωτερικούς χώρους.
  II

19
GR CY

α) 
 Σε
όχι τακτικούς ή όχι καλά φωτισμένους
χώρους εργασίας δημιουργούνται ατυ-
χήματα.
β) 


 Τα ηλεκτρικά
εργαλεία παράγουν σπινθήρες που
μπορούν να αναφλέξουν τη σκόνη και
τους ατμούς.
γ) 

 Εάν δεν
είστε καλά συγκεντρωμένοι, δεν απο-
κλείεται να χάσετε τον έλεγχο επί της
συσκευής.

α) -

-
-

-
 Όταν δεν έχουν αλλαχτεί τα
βύσματα και όταν χρησιμοποιείτε κα-
τάλληλες πρίζες, μειώνεται ο κίνδυνος
ηλεκτροπληξίας.
β) -



Υπάρχει ιδιαίτερος κίνδυνος ηλεκτρο-
πληξίας, όταν το΄΄ωμα σας είναι γειω-
μένο.
γ) 
 Η διείσδυση
νερού σε ηλεκτρική συσκευή αυξάνει
τον κίνδυνο ηλεκτροπληξίας.
   
 -  
.

 


Σύμβολο υποχρέωσης με στοιχεία
για την πρόληψη ζημιών.
Φοράτε προστασία για την ακοή.
Σύμβολο υπόδειξης με πληροφο-
ρίες για τον καλύτερο χειρισμό της
συσκευής.
Γενικές υποδείξεις ασφαλείας
για ηλεκτρικά εργαλεία



-
-
 Παραλείψεις στην τήρηση
των υποδείξεων ασφαλείας και των
οδηγιών μπορούν να οδηγήσουν
σε ηλεκτροπληξία, πυρκαγιά και/ή
βαρείς τραυματισμούς.
-


Η έννοια „ηλεκτρικά εργαλεία», που χρη-
σιμοποιείται στις υποδείξεις ασφαλείας,
αναφέρεται σε ηλεκτρικά εργαλεία που
λειτουργούνται με το ηλεκτρικό δίκτυο (με
καλώδιο ρεύματος) και σε ηλεκτρικά εργα-
λεία που λειτουργούνται με συσσωρευτή
(δίχως καλώδιο ρεύματος).

20
GR CY
δ) -




. Να προστατεύετε το
καλώδιο από ψηλές θερμοκρασίες,
λάδι, αιχμηρές άκρες και κινούμενα
τμήματα της συσκευής. Τα ελαττωμα-
τικά ή μπερδεμένα καλώδια αυξάνουν
τον κίνδυνο ηλεκτροπληξίας.
ε) 
-

 Η
χρήση μίας μπαλαντέζας κατάλληλης
για το ύπαιθρο μειώνει τον κίνδυνο
ηλεκτροπληξίας.
ζ) 





Η χρήση
ενός διακόπτη ασφαλείας RCD
μειώνει τον κίνδυνο ηλεκτροπληξίας.
 
α) -
-

-

-
 Μόνο
μία στιγμή απροσεξίας κατά τη χρήση
του ηλεκτρικού εργαλείου μπορεί να
προκαλέσει σοβαρούς τραυματισμούς.
β) -
-
. Η χρήση των μέσων
ατομικής προστασίας όπως αντιολι-
σθητικά υποδήματα, προστατευτικό
κράνος και ωτοπροστασία, μειώνει τον
κίνδυνο τραυματισμών.
γ) 

-



Εάν κατά την μεταφορά του ηλεκτρικού
αλυσοπρίονου έχετε το χέρι σας στον
διακόπτη ή η συσκευή είναι ενεργοποιη-
μένη όταν τη συνδέσετε με την παροχή
ρεύματος, δεν αποκλείονται ατυχήματα.
δ) 
-
.
Ένα εργαλείο ρύθμισης ή κλειδί που
βρίσκεται στο περιστρεφόμενο τμήμα
της συσκευής, μπορεί να οδηγήσει σε
τραυματισμούς.
ε) 


 Έτσι
μπορείτε να ελέγχετε το ηλεκτρικό
εργαλείο ακόμη και σε απρόοπτες πε-
ριστάσεις.
ζ) 
 Μη φοράτε
φαρδιά ρούχα ή κοσμήματα. Να κρα-
τάτε τα μαλλιά, τα ρούχα και τα γάντια
μακριά από κινούμενα εξαρτήματα.
Τα φαρδιά ρούχα, τα κοσμήματα ή τα
μακριά μαλλιά θα μπορούσαν να πια-
στούν από τα κινούμενα εξαρτήματα.
 -


-

 

-
