Parkside KH 3001 SOLDERING PENCIL Reference manual

5 GB
Table of Content
Before reading, unfold the page containing the illustrations
and familiarise yourself with all functions of the device.
The following icons/symbols are used in this instruction manual:
Read instruction manual! V~ Voltage
Observe caution and safety notes! Wear protective gloves
Beware of electrical shock! Wear safety goggles
WWatt (performance) Wear particle mask
Introduction
For your safety ................................................................ Page 7
Proper use ...................................................................... Page 7
Included items / supplied accessories ............................. Page 8
Technical information ...................................................... Page 8
Manual_UK_Inhalt.indd 5 14.11.2005 9:27:15 Uhr

6 GB
Table of Content
Safety
Important specific safety advice ..................................... Page 8
Operation .......................................................................... Page 10
Maintenance and care ................................................ Page 11
Disposal ............................................................................ Page 11
Information
Service ............................................................................ Page 12
Declaration of conformity ................................................. Page 12
Warranty ........................................................................... Page 13
Manual_UK_Inhalt.indd 6 14.11.2005 9:27:15 Uhr

7 GB
Soldering pencil PFLK 30
For soldering electronic components and
circuit boards
 Introduction
 For your safety
Please read carefully through the following infor-
mation concerning safety and proper use. Before
reading, fold out the page with the illustrations and
make yourself familiar with all the functions of
the equipment. Please read the operating instruc-
tions below and the accompanying safety
advice  carefully. Use the equipment only as
described and for the indicated purposes. By doing
this you will be able to work in complete safety and
produce better results. Be careful to keep these
advice notes and if necessary pass them on to a
third party.
 Proper use
The device is intended for soldering electronic
components and circuit boards. Any other use or
modification to the device shall be considered as
improper use and could give rise to considerable
dangers. Not suitable for commercial use.
Introduction
Manual_UK_Inhalt.indd 7 14.11.2005 9:27:16 Uhr

8 GB
 Included items /
supplied accessories
Check that all the items and accessories
are present immediately after unpacking:
1 Soldering pencil
1 Electronics solder, 10 grams
1 Soldering tip accessory
1 Operating instructions
 Technical information
Electricity supply: 230 V ~
Frequency: 50 Hz
Power consumption: 30 W
max. soldering tip temperature: approx. 300° C
 Safety
Important specific
safety advice
To avoid danger to life from
electric shock:
· Do not operate the device if the mains lead or
mains plug is damaged.
 Caution! A damaged mains lead presents a
serious danger to life from electric shock.
· The mains voltage at the mains socket must
match that shown on the rating plate on the
device. Devices marked with 230 V can also be
operated at 220 V. Never use a plug adapter in
the socket that could possibly earth the device.
· Have repairs carried out only by an electrician
Introduction/Safety
Manual_UK_Inhalt.indd 8 14.11.2005 9:27:16 Uhr

9 GB
or the relevant service centre.
· Do not operate the device if it is damp and do
not use it in a damp environment.
· If you use the device outdoors, always connect
it through a residual current device with a
maximum trip current of 30 mA. If using an ex-
tension lead, always use one that is approved
for outdoor use.
· Always keep the mains lead out of the operat-
ing area and run it away from the rear of the
device.
To avoid the danger of injury:
 Danger of burns! Do not touch the heated
soldering tip. You could suffer burn injuries.
· Before carrying out any work on the device
itself, for example, changing the soldering tip,
always pull the plug out of the mains socket
and allow the device to cool.
· Always wear protective glasses
when using the device. In
addition, it is recommended that you wear protec-
tive gloves, a face mask and a protective apron.
· Before use, always check the device, mains
lead and plug for any damage. If any parts are
damaged, have them fixed or replaced at a
specialist repair centre only.
· Ensure that no vapours that may be hazardous
to health can accumulate when working with
the device for long periods. Always provide
adequate ventilation of your working area.
· Switch on the device each time before you
bring it into contact with the materials to be
soldered.
Using the device safely:
· Before heating the device, check that the
soldering tip is firmly seated - the clamping
Safety
Manual_UK_Inhalt.indd 9 14.11.2005 9:27:17 Uhr

10 GB
screw must be fully tightened.
· When removing the soldering tip make sure
that the soldering pencil is switched off and do
not use too much force. Slide a new soldering
tip fully in so that it hits the stop.
· Do not heat up the soldering pencil without a
tip in place.
· After use let the soldering pencil cool down in
air only. Under no circumstances quench the
tip in water!
· Place the soldering pencil in the stand during
any pauses in your work.
· Danger of fire! Place the soldering pencil
down only in the special stand or on a fire-
resistant support pad.
· If danger arises, pull the mains plug immedi-
ately out of the mains socket.
· Never use the device for a purpose for which it
was not intended.
· Handle the device carefully and treat it with
respect. Always keep the device clean, dry and
free of oil or grease.
· Remain alert at all times! Watch what you are
doing and always proceed with caution. Do not
use the device if you cannot concentrate or
you are feeling unwell.
 Operation
Note the mains voltage. The mains voltage must
correspond with that shown on the sander rating
plate. Equipment labelled as 230 V may also be
used with 220 V.
 The soldering pencil PFLK 30, with its nominal
30 watt power rating, is ideal for soldering
electronic components and circuit boards.
Safety/Operation
Manual_UK_Inhalt.indd 10 14.11.2005 9:27:17 Uhr

11 GB
 The nominal soldering tip temperature is about
320° C. For best results use electronics solder
1.0 (10 g included with the soldering pencil) or
1.5 mm dia. 60 % Sn. We recommend solder-
ing paste (not soldering grease or soldering
fluid) as a flux.
 The design of the soldering pencil makes it
especially suitable for use where access is
difficult or for fine soldering work. The inter-
changeable tips increase the versatility of the
soldering pencil.
 Maintenance and care
 Attention: Always make sure that the mains
plug is out of the socket before doing any work
on the random orbital sander.
1) Clean the sander frequently; for best results,
do this immediately after you have finished
using it.
2) Do not use sharp objects for cleaning the
random orbital sander. Do not allow any liquids
to enter the random orbital sander. Use a soft
cloth to clean the housing – under no circum-
stances use petrol, solvents or cleaning agents
that attack plastic.
 Disposal
The packaging is wholly composed of environmen-
tally-friendly materials that can be disposed of at
a local recycling centre. Please contact your local
council office to find out about disposal facilities for
your worn-out electrical tools.
Operation/Maintenance and care/Disposal
Manual_UK_Inhalt.indd 11 14.11.2005 9:27:17 Uhr

12 GB
 Information
 Service
Please refer to the Warranty chapter for information
regarding your national service point.
 Declaration of conformity
We, Kompernaß GmbH, Burgstr. 21,
D-44867 Bochum, Germany, declare that this
product complies with the following EU directives:
EU Low Voltage Directive (73/23/EEC)
Electromagnetic compatibility (89/336/EEC)
Device type/Type:
Soldering pencil PFLK 30
Bochum, 31.03.2005
Hans Kompernaß
- Managing Director -
Information
Manual_UK_Inhalt.indd 12 14.11.2005 9:27:21 Uhr

13 GB
 Warranty
 This appliance is guaranteed for 3 years from
the date of purchase.
 It has been carefully produced and meti-
culously checked before delivery. Please
keep your receipt as proof of purchase.
Contact your service centre by telephone in
case of questions pertaining to the warranty.
Your goods can be transmitted free of cost
only in this manner. This warranty applies
only to the initial purchaser and is non-
transferable.
 The warranty covers only material or manu-
facturing faults, not normal wear or damage to
fragile parts such as switches or rechargeable
batteries.
 The appliance is intended solely for private, not
commercial, use.
 If this product has been subjected to improper
or inappropriate handling, abuse, or interven-
tions not carried out by one of our authorised
sales and service outlets, the warranty will be
considered void. This warranty does not affect
your statutory rights.
Warranty
Manual_UK_Inhalt.indd 13 14.11.2005 9:27:21 Uhr

14 GB
GB
Kompernass Service United Kingdom
Alpine House,
Premier Business Park
Long Street, Walsall
West Midlands, WS2 9DY
Tel.: [phone]
Fax: [phone]
e-mail: [email protected]
IRL
Kompernass Service Ireland
41 Harbour View
Howth, Co. Dublin
Tel [phone]
Fax: [phone]
e-mail: [email protected]
