Parrot Uncle AC25GTR-000ZA User manual

Installation & Operating Instructions for the
Owner’s Installation ,Manual
WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER
AC25GTR-000ZA
AC25GTR-000ZA
BEFORE OPERATING THIS PRODUCT, READ, UNDERSTAND, AND FOLLOW THESE INSTRUCTIONS.
BE SURE TO SAVE THIS BOOKLET FOR FUTURE REFERENCE

Installation & Operating Instructions for the
Owner’s Installation ,Manual
WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER
AC25GTR-000ZA
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed,
following:
1. Read all instructions.
2. Do not touch hot surfaces. Use handles or knobs.
3. To protect against electrical shock, do not immerse cord, plugs, or any electrical parts
in water or other liquid.
4. Close supervision is necessary when any appliance is used by or near children.
5. Unplug from outlet when not in use and before cleaning. Allow to cool before putting on
6. Do not operate any appliance with a damaged cord or plug or after the appliance
malfunctions or has been damaged in any manner. Return appliance to the nearest
service facility for examination, repair, or adjustment.
7. The use of accessory attachments not recommended by the appliance manufacturer may
cause injuries.
8. Do not use outdoors.
9. Do not let cord hang over edge of table or counter, or touch hot surfaces.
including the
or taking off parts.
authorized
10. Do not place on or near a hot gas or electric burner, or in a heated oven.
11. Extreme caution must be used when moving an appliance containing hot oil or other hot
liquids.
12. To disconnect, , then remove plug from wall outlet.
13. Do not use appliance for other than intended use.
14.Use extreme caution when removing tray or disposing of hot grease.
metal scouring pads. Pieces can break off the pad and touch electrical
parts, creating a risk of electric shock.
"off "turn any control to
parts, creating
16. Oversize foods or metal utensils must not be inserted in a toaster-oven as they may
create a fire or risk of electric shock.
o not clean with15. D
2

Installation & Operating Instructions for the
Owner’s Installation ,Manual
WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER
AC25GTR-000ZA
17. A fire may occur if the toaster-oven is covered or touching flammable material, including
curtains, draperies, walls, and the like, when in operation. Do not store any item on top
18. Extreme caution should be exercised when using containers constructed of other than
oven when not in use.
20. Do not place any of the following materials in the oven: paper, cardboard, plastic, and
21. Do not cover crumb tray or any part of the oven with metal foil. This will cause
.
of the appliance when in operation.
metal or glass.
like.
overheating of the oven
23. Remove plug from outlet when the appliance is not in use, before putting on or taking
before cleaning. Allow to cool before handing.
24. Avoid contacting moving parts.
2
26. In the process of cooking, press “START/STOP” to stop the oven working.
. For household use only.
off parts, and
SAVE THESE INSTRUCTIONS
22. Caution-To ensure continued protection against risk of electric shock, connect to
properly grounded outlets only.( If the appliance is of the grounded type)
19.Do not store any materials, other than manufacturers recommended accessories, in this
5
TECHNICAL INFORMATION
SKU Rated Voltage Rated Consume
120 VAC 60Hz
AC25GTR-000 A
z1750W
~
3

Installation & Operating Instructions for the
Owner’s Installation ,Manual
WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER
AC25GTR-000ZA
b) Longer extension cords are available and may be used if care is exercised in their use.
c) If a longer extension cord is used:
1) The marked electrical rating of the cord set or extension cord should be at least as
great as the electrical rating of the appliance.
2) The cord should be arranged so that it will not drape over the countertop or tabletop
a) A short power-supply cord should be used to reduce the risk resulting from becoming
entangled in or tripping over a longer cord.
where it can be pulled on by children or tripped over unintentionally.
3-wire cord.
3) If the appliance is of the grounded type, the extension cord should be a grounding-type
BEFORE FIRST USE
1. Remove all accessories and shipping materials packed inside the oven.
2. Wash the rack and grill tray with warm soapy water. Wipe the inside of the oven with a
damp cloth or sponge. Wipe up the inside of the oven with paper towels before using it.
3. Place oven on a flat counter or other stable surface. DO NOT OPERATE ON THE
SAME CIRCUIT WITH ANOTHER APPLIANCE.
4. Make sure that crumb tray is properly installed before using it.
For the first time only, set the Temperature Knob to MAX, and set the function setting
and timer to roast and 15 minutes. This will burn off oils remaining in the oven.
NOTE: The oven may smoke during this process. This is normal for a new oven and
this phenomenon will not last more than 10-15 minutes.
SHORT CORD INSTRUCTION
4

Installation & Operating Instructions for the
Owner’s Installation ,Manual
WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER
AC25GTR-000ZA
NAME OF PARTS
1. Housing
2. Display Screen Cover
3. Handle Holder
4. Door Handle
5.Door Glass
6. Button
7. Knob
8. Foot
10. Grill Tray
11. Rack
12. Cooking Basket
1
2
3
4
5
67
8
11 12
9. Crumb Tray
9 10
A1: Fries
A2: Wings
AIR FRY-MENUS: A3: Nuggets
A4: Seafood
A5: Snacks
A6: Vegetables
CONTROL PANEL
5

Installation & Operating Instructions for the
Owner’s Installation ,Manual
WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER
AC25GTR-000ZA
HOW TO USE
CAUTION: THE OVEN SURFACES ARE HOT DURING AND AFTER USE
GENERAL INSTRUCTIONS
1.
2. The food must be placed on the grill tray to avoid the fire danger that caused by the
3.
accumulation of food chipping on the heating pipes.
Place the grill tray and rack at a position suitable for the height of the food to be cooked.
Make sure to use an ovenproof container in the oven. Do not use plastic or cardboard
containers in the oven.
Clean the heating pipe periodically.
Never use glass or ceramic pans or lids.
DO NOT let juices flow to the bottom of the oven. Use the crumb tray when cooking.
Set the temperature according to the recipe or as desired.
Securely shut the door and set the cooking time to begin operating the oven.
4.
5.
6.
7.
8.
When you use the rack, please put the convex upward.
9.
Please don’t unplug the power cord before the oven has finished its work. The fan will
delay its work for 1 minute.
10.
OPERATION:
1. When the oven is electrified, the buzzer will ring once. All the indicators are displayed
and after 1 second the default function is displayed.
2. When the oven is electrified, all the indicators are put out if nobody works it after
10 minutes. Press any button and the indicators will display.
3. Rotate the "Function" knob to select different operation modes, including -AIR FRY,
-TOAST,- BAKE,-BROIL, -ROAST, -PIZZA, -REHEAT, -WARM, -SLOW COOK,
-DEHYDRATE. Rotate the “Select” to choose time, temperature, the slice, colour
and the other default for AIR FRY.
4. Convection “ ” can be used with BAKE, BROIL, ROAST, PIZZA or REHEAT function.
Press “ ” to open the fan. This method of cooking permits heat to penetrate evenly.
Then the icon is displayed.
5. In the process of cooking, press the " START/STOP " button once to stop cooking.
6

Installation & Operating Instructions for the
Owner’s Installation ,Manual
WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER
AC25GTR-000ZA
Display AIR FRY Menu
A1
A2
A3
A4
A5
A6
Fries
Wings
Nuggets
Seafood
Snacks
Vegetables
1. Rotate the “FUNCTION” knob to select “AIR FRY”. The screen displays "A1".
2. Rotate the “Select” knob to select A1~A6. Press “TIME/TEMP” once, then the screen
will display the default time and default temperature (when you use the “A1”, please put
the chips into the cooking basket, and use the default time and default temperature).
3. If you choose A2~A6, press “START/STOP” to start preheating and “PREHEAT” icon
flashes. When the work is over, the buzzer will ring and the “COMPLETE” icon
flashes. If choose A1, you can skip step 3.
5. If you want to change the temperature, press “TIME/TEMP” once and rotate the “Select”.
If you want to change the time, press “TIME/TEMP” twice and rotate the “Select”.
4. Put the food into the oven and press “START/STOP” to start working, and the cooking
time will begin to count down.
6. Check food temperature before moving to ensure that proper internal temperatures
have been reached.
7. Always remove food with oven mitts. The food and oven are very hot.
TOAST FUNCTION:
1. Rotate the “FUNCTION” knob to select “TOAST”. The screen displays "4 slice".
2. Rotate the “Select” knob to select the 1~6 slice.
3. Press “TIME/TEMP” once and rotate the “Select”. Select the degree of the baking coloring.
4. Press “START/STOP” to start working, and the cooking time will begin to count down.
5. Check food temperatures before moving to ensure that proper internal temperatures
have been reached.
6. Always remove food with oven mitts. The food and oven are very hot.
AIR FRY FUNCTION:
7

Installation & Operating Instructions for the
Owner’s Installation ,Manual
WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER
AC25GTR-000ZA
2. Rotate the “Select” knob to select the temperature of you want to broil the food. The
temperature will flash on the screen.
BAKE FUNCTION:
1. Rotate the “FUNCTION” knob to select “BAKE”.
2. Rotate the “Select” knob to select the temperature you want to bake the food. The
temperature will flash on the screen.
3. Press “TIME/TEMP” once and rotate the “Select” knob. Select the length of time you
want to bake the food.
4. Press “START/STOP” to start working, and the cooking time will begin to count down.
5. Check food temperatures before moving to ensure that proper internal temperatures
have been reached.
6. Always remove food with oven mitts. The food and oven are very hot.
BROIL FUNCTION:
1. Rotate the “FUNCTION” knob to select “BROIL”.
4. Press “START/STOP” to start working, and the cooking time will begin to count down.
5. Check food temperatures before moving to ensure that proper internal temperatures
have been reached.
6. Always remove food with oven mitts. The food and oven are very hot.
ROAST FUNCTION:
1. Rotate the “FUNCTION” knob to select “ROAST”.
2. Rotate the “Select” knob to select the temperature you want to roast the food. The
temperature will flash on the screen.
3. Press “TIME/TEMP” once and rotate the “Select” knob. Select the length of time you
want to roast the food.
4. Press “START/STOP” to start working, and the cooking time will begin to count down.
5. Check food temperatures before moving to ensure that proper internal temperatures
have been reached.
6. Always remove food with oven mitts. The food and oven are very hot.
3. Press “TIME/TEMP” once and rotate the “Select” knob. Select the length of time you
want to bake the food.
8

Installation & Operating Instructions for the
Owner’s Installation ,Manual
WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER
AC25GTR-000ZA
4. Put the food into the oven and press “START/STOP” to start working, and the cooking
time will begin to count down.
2. Rotate the “Select” knob to select the temperature you want to reheat the food. The
temperature will flash on the screen.
5. Press “TIME/TEMP” once and rotate the “Select” knob to change the time and
temperature in the work.
PIZZA FUNCTION:
1. Rotate the “FUNCTION” knob to select “PIZZA”. The screen displays “9 inch”.
3. Press “START/STOP” to start preheating and “PREHEAT” icon flashes. When the work
is over, the buzzer will ring and the “COMPLETE” icon flashes.
6. Check food temperatures before moving to ensure that proper internal temperatures
have been reached.
7. Always remove food with oven mitts. The food and oven are very hot.
2. Rotate the “Select” knob to select the 6 inch, 9 inch or 12 inch.
REHEAT FUNCTION:
1. Rotate the “FUNCTION” knob to select “REHEAT”.
3. Press “TIME/TEMP” once and rotate the “Select” knob. Select the length of time you
want to reheat the food.
4. Press “START/STOP” to start working, and the cooking time will begin to count down.
5. Check food temperatures before moving to ensure that proper internal temperatures
have been reached.
6. Always remove food with oven mitts. The food and oven are very hot.
2. Rotate the "Select" knob to select the temperature level between 100°F~300°F at
which you want to keep the food warm. The temperature will flash on the screen.
1. Rotate the “FUNCTION” knob to select “WARM”.
3. Press “TIME/TEMP” once and rotate the “Select” knob. Select the length of time
(1min~4hours) you want to keep the food warm.
4. Press “START/STOP” to start working, and the cooking time will begin to count down.
5. Check food temperatures before moving to ensure that proper internal temperatures
have been reached.
6. Always remove food with oven mitts. The food and oven are very hot.
WARM FUNCTION:
9

Installation & Operating Instructions for the
Owner’s Installation ,Manual
WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER
AC25GTR-000ZA
2. Rotate the “Select” knob to select the temperature you want to cook the food. The
temperature will flash on the screen.
3. Press “TIME/TEMP” once and rotate the “Select” knob. Select the length of time you
want to cook the food.
4. Press “START/STOP” to start working, and the cooking time will begin to count down.
5. Check food temperatures before moving to ensure that proper internal temperatures
have been reached.
6. Always remove food with oven mitts. The food and oven are very hot.
SLOW COOK FUNCTION:
1. Rotate the “FUNCTION” knob to select “SLOW COOK”.
2. Rotate the “Select” knob to select the temperature you want to dehydrate the food.
The temperature will flash on the screen.
3. Press “TIME/TEMP” once and rotate the “Select” knob. Select the length of time you
want to dehydrate the food.
4. Press “START/STOP” to start working for desired length of time.
5. Check food temperatures before moving to ensure that proper internal temperatures
have been reached.
6. Always remove food with oven mitts. The food and oven are very hot.
DEHYDRATE FUNCTION:
1. Rotate the “FUNCTION” knob to select “DEHYDRATE”.
10

Installation & Operating Instructions for the
Owner’s Installation ,Manual
WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER
AC25GTR-000ZA
CAUTION : hot surface
Warning: Hot Surface!
Advertencia: ¡Superficie Caliente!
Avertissement: Surface Chaude!
CARE AND CLEANING
1. Before cleaning, unplug the toaster oven and allow it to cool completely.
2. Wash all attachments, including the rack and the grill tray, with mild soap and water.
3. Do not use abrasive cleansers, scrubbing brushes and chemical cleaner as this will
damage the non-stick coating of grill tray.
4. Using a wet cloth to wipe the inside of the oven.
5. Clean the door by using a wet cloth saturated with detergent or soap.
6. Never immerse the unit in water or other liquid.
7. Any other services should be performed by an authorized service representative.
11
