1.0 Internal 48V Power Supply Unit for SN2300
1.1 Instructions
See Getting Started Guide , chapter 8, “Line power module installation.”
2.0 Internal 40V Power Supply Unit for SN2400
2.1 Instructions
See Getting Started Guide , chapter 8, “Line power module installation.”
3.0 External 40V Power Supply Unit for
SN1200 and SN1400
3.1 Instructions
See Getting Started Guide , chapter 8, “Line power module installation.”
Item Part Number Description
PM-48V-Int SN-PM-48V-INT 48 VDC power module for ISDN and analog lines, internal mounting in an SN2300 with
IC-4BRV or IC-4FXS. For the IC-4BRV it is an option to power the ISDN phones. For the
IC-4FXS, it is required to power analog phones. Input 110–240 VAC; Output 48
VDC, 30W.
Item Part Number Description
PM-40V-Int SN-PM-40V-INT 40 VDC power module for ISDN and analog lines, internal mounting in an SN2400 with
IC-4BRV or IC-4FXS. For the IC-4BRV it is an option to power the ISDN phones. For the
IIC-4FXS, it is required to power analog phones. Input 110–240 VAC; Output 48
VDC, 30W.
Item Part Number Description
PM-BRI-Ext
(230V) SN-PM-BRI-EXT/EUR 40 VDC power line module for ISDN and analog power line; external mounting. For SN1200 and SN1400. Input 230 VAC; Output 40 VDC, EU/Swiss connector.
PM-BRI-Ext
(120V) SN-PM-BRI-EXT 40 VDC power line module for ISDN and analog power line; external mounting. For SN1200 and SN1400. Input 120 VAC; Output 40 VDC, US connector.

4 PMC Hardware Reference Note
4.0 Interface Cards
4.1 Instructions
In the SmartNode 1000 and 2000 Series VoIP Media Gateways Getting Started Guide , see the section “Interface
cards descriptions” in chapter 1. Also consult chapter 9 for the installation of the card.
Item Part Number Description
IC-E1V SN-ICE1V PMC interface card for mounting in the SN2300 or SN2400 expansion slots providing one
PRI E1 port to support 30 VoIP calls.
IC-T1V SN-ICT1V PMC interface card for mounting in the SN2300 or SN2400 expansion slots providing one
PRI T1 port to support 23 VoIP calls.
IC-4BRV SN-IC4BRV PMC interface card for mounting in SN2300 or SN2400 expansion slots providing four BRI/
S0 ISDN ports to support 8 VoIP calls.
Internal Line Power Module PM-48V-Int (SN2300), PM-40V-Int (SN2400), or external
power supply PM-BRI-Ext can be used as an option to power ISDN phones.
IC-4FXS SN-4FXS PMC interface card for mounting in SN2300 or SN2400 expansion slots providing four ana-
log phone ports and eight DSP channels.
Requires Internal Line Power Module PM-48V-Int (SN2300) or PM-40V-Int (SN2400).
IC-4BRV-8VRSN-IC4BRV-8VR PMC that is an 8-channel gateway interface card for ISDN BRI/S0 with hardware bypass
(emergency) relay. For use in the SN2000 series expansion slots.
IC-E1V-0 SN-ICE1V-0 PMC that is an E1 gateway interface card for ISDN PRI-circuit switching only. For use in
SN2000 series expansion slots. NT/TE configurable.
IC-E1V-15 SN-ICE1V-15 PMC that is a 15-channel gateway interface card with one ISDN PRI/S2m port. NT/TE con-
figurable. Supports these voice codecs (G.711, G.726, G.723, G.729ab). For use in SN2000
series expansion slots.
