Patton electronics Patton SmartNode 2400 Series User manual

Combining a real-time QoS IP router, Voice-Over-Packet Gateway,
and ToIP circuit switching, the SmartNode 2400 VoIP Media Gateway is ideal
for multi-service carrier access and corporate PSTN networking for up to 120 simultaneous calls.
Complete Service Transparency
Using ISoIP™ and ToIP™ technology, calls are connected
with voice, data, and supplementary services delivered
transparently end-to-end.
H.323v3 and H.323+ VoIP
Connect to any SmartNode or VoIP capable device with universal
call control signalling. Use advanced features including H.245
Fast Connect, Early Start, Annex M3, ECS support, and RAS.
T1/E1, BRI, & FXS Voice Interface Cards
Use any combination of voice interfaces for connection to
any telephone, switch, or service provider. Scale your
connections by simply adding new interfaces.
Up to 120 Simultaneous Calls
Supports up to 120 simultaneous calls from any combina-
tion of voice intefaces including T1/E1 PRI, BRI, and FXS.
SMARTNODE 2400 SERIES
he SmartNode 2400 VoIP Media Gateway provides a high density,
seamless link between the circuit-switched telephone network and
Voice-over-IP. Ideal for multi-service carrier and corporate PSTN
access, the SmartNode 2400 takes 120 calls from voice-to-packet.
With dual 10/100 Ethernet ports and four voice interface slots, the
SmartNode 2400 connects to any switch, PBX, or data network.
The SmartNode delivers VoIP that has the clarity of toll-quality voice. Multiple
user-defined G.711 and G.726 voice codecs are included, as well as G.723 and
G.729ab for low bandwidth voice. T.38 FoIP, fax bypass, and modem bypass
capabilities ensure that the SmartNode 2400 will seamlessly connect to all voice
and data services. QoS ensures optimal voice performance through traffic classifi-
cation and prioritization.
Patton’s exclusive Telephony-over-IP™ (ToIP™) programmable circuit switching
delivers service transparency and flexible PSTN integration. With ToIP any BRI,
T1/E1 PRI, or FXS port can connect to any telephone or media gateway port.
For more information, visit us at www.patton.com.
T
Modular VoIP Media Gateway
Patton SmartNode 2400
VoIP—ToIP
Compatible CODECs
Connect to any gateway with any one of our standard codecs
(including G.711 and G.726). For low bandwidth
requirements, use G.723.1 and G.729ab vocoders.
QoS Router with Dual 10/100 Ethernet
Connect to your LAN with high speed Ethernet and deliver
increased bandwidth and efficiency. Traffic classification
prioritizes data and ensures optimal voice quality.

7622 Rickenbacker Drive
Gaithersburg, MD 20879 USA
Phone [phone]
Fax [phone]
E-mail [email protected]
URL http://www.patton.com
07M2400-DS1
Model Information
Application—Shared-Switch Access
Meriedweg 7
CH-3172 Niederwangen
Phone [phone]
Fax [phone]
E-mail [email protected]
URL http://www.inalp.com
SN2400/0V/UI VoIP Media Gateway router with internal 100–240 VAC power supply SNSW-IAF-4 IP Advanced Feature Set (Q-SIG,QoS, IP Classification)
To take advantage of emerging technologies and the
changing regulatory environments, network service
providers are providing new services which can be inte-
grated within the enterprise to reduce costs and improve
service. Deployed as a trunk gateway, the SmartNode is
the seamless link between the PSTN and VoIP access.
Subscribers now access new carrier services without
incurring charges from the incumbent carrier.
In enterprise networks, the SmartNode integrates
telephony and IP data communications for best use of
bandwidth, improved office-to-office communication,
and reduced network costs.
Instead of installing a separate PBX in a remote office,
the SmartNode is able to provide transparent extension
of PBX phones. The extension can be managed centrally
and benefit from services such as calling groups, least
cost routing, and call forwarding.
Specifications
Data Connectivity
• 2 10/100Base-T Ethernet, RJ-45
Voice Signalling
• Euro ISDN EDSS-1/ETSI BRI/NET3
• ETS 300 012-1 (ITU-T I.430)
• ETS 300 402-1 (ITU-T Q.921)
• ETS 300 403-1/2 (ITU-T Q.931)
• ETS 300 102-1 (ITU-T Q.931)
• Q-SIG (PSS-1)
• ECMA-143
• ETSI and ISO/ECMA channel numbering
• SIP and MGCP
• H.323v3
• RAS, H.225, H.245
• Fast-connect, early H.245
• Gatekeeper autodiscovery
• Alias registration
• Overlap sending
• Empty capability set (call transfer, hold)
• H.323v1 call transfer, hold
• ECS support
• ISDN over IP (ISoIP)
• H.323 GW and GK compatible
• H.323 Annex M3
• ISDN/Q-SIG feature tunnelling
• ISDN speech, audio and data (Fax Gr 4, UDI
64, RDI 64)
• ISDN supplementary services
Voice Routing—Session Router™
• Local switching
• Interface huntgroups
• ISDN broadcast message routing
• Routing Criteria
• Interface
• Calling/called party number
• Time of day, day of week, date
• ISDN bearer capability
• Number manipulation functions
• Replace numbers
• Add/remove digits
• Multiple remote gateways
• PLAR
IP Routing
• IPv4 router
• RIPv1, v2 (RFC 1058 and 2453)
• Programmable static routes
• ICMP redirect (RFC 792)
• DHCP client/server
• Packet fragmentation
• Static Firewall
• NAT/PAT/NAPT (RFC 1631)
• Access control lists
IP Quality of Services
• WFQ/Fixed Rate/Priority Queuing/Flow-split
scheduler
• Combination of QoS schemes with config-
urable burst
• DiffServe/ToS set or queue per header bits
• Packet Policing discards excess traffic
• 802.1p VLAN tagging
• Traffic classification
Management
• Industry standard CLI
• Local console (RS-232, RJ-45) and remote
Telnet access
• TFTP configuration down- and upload
• TFTP firmware download
• SNMP v1 agent (MIB II and private MIB)
• Built-in diagnostic tools (trace, debug)
• Java™ Applet
• HPOV Integration with NNM
Operating Environment
• Operating temperature: 0–40ºC
• Operating humidity: 5–80% (non condensing)
System
• CPU Motorola MPC750 at 333 MHz
Memory 32MB SDRAM (160MB max.)/16 MB
Flash
• Power: 100–240 VAC (50/60 Hz)
• Power dissipation 30W (fully loaded)
Compliance
• EMC compliance: EN55022 and EN55024
• Safety compliance: EN 50950
• CE compliance
• FCC Part 15 Class A
