Patton electronics SmartNode 4520 Series User manual

SmartNode 4520 & 4110 Series
VoIP Gateway Routers
User Manual
Important
This is a Class A device and is intended for use in a light industrial environment. It is
not intended nor approved for use in an industrial or residential environment.
Sales Office: [phone]
Technical Support: [phone]
E-mail: [e-mail]
WWW: www.patton.com
Part Number: 07MD4524-GS, Rev. J
Revised: October 8, 2015

Patton Electronics Company, Inc.
7622 Rickenbacker Drive
Gaithersburg, MD 20879 USA
tel: [phone]
fax: [phone]
support: [phone]
web: www.patton.com
e-mail: [e-mail]
Trademark Statement
The terms SmartWare and SmartView are trademarks of Patton Electronics Company.
All other trademarks presented in this document are the property of their respective
owners.
Copyright © 2015, Patton Electronics Company. All rights reserved.
The information in this document is subject to change without notice. Patton Elec-
tronics assumes no liability for errors that may appear in this document.
Warranty Information
The software described in this document is furnished under a license and may be used
or copied only in accordance with the terms of such license.
Patton Electronics warrants all SmartNode router components to be free from defects,
and will—at our option—repair or replace the product should it fail within one year
from the first date of the shipment.
This warranty is limited to defects in workmanship or materials, and does not cover
customer damage, abuse or unauthorized modification. If the product fails to perform
as warranted, your sole recourse shall be repair or replacement as described above.
Under no condition shall Patton Electronics be liable for any damages incurred by the
use of this product. These damages include, but are not limited to, the following: lost
profits, lost savings and incidental or consequential damages arising from the use of or
inability to use this product. Patton Electronics specifically disclaims all other warran-
ties, expressed or implied, and the installation or use of this product shall be deemed
an acceptance of these terms by the user.

3
Table of Contents
Table of Contents ...................................................................................................................................................3
About this guide .....................................................................................................................................................6
Audience................................................................................................................................................................. 6
Structure................................................................................................................................................................. 6
Precautions ............................................................................................................................................................. 7
Safety when working with electricity .................................................................................................................7
Preventing electrostatic discharge damage .........................................................................................................8
General observations .........................................................................................................................................9
Typographical conventions used in this document.................................................................................................. 9
General conventions .........................................................................................................................................9
1General information .......................................................................................................................................... 10
SmartNode Series VoIP routers overview...............................................................................................................11
SmartNode 4520 Series router ........................................................................................................................12
Ports descriptions ......................................................................................................................................14
Reset button behavior ...............................................................................................................................14
SmartNode 4110 Series router ........................................................................................................................16
Ports descriptions ......................................................................................................................................18
Reset button behavior ...............................................................................................................................18
2Applications overview ........................................................................................................................................ 20
Introduction..........................................................................................................................................................21
Applications for SmartNode 4110 Series ...............................................................................................................21
SIP and H.323 terminal and PSTN gateways ..................................................................................................21
Application—Analog line extension over IP ....................................................................................................22
Application—ITSP dial-in access ....................................................................................................................22
Application—Private line automatic ringdown (PLAR) ..................................................................................23
Application—Enterprise campus BRI to FXS telephony extension ..................................................................23
Application—PBX toll bypass gateway ............................................................................................................24
Applications for SmartNode 4520 Series ...............................................................................................................25
Application—SOHO off-premise extension ....................................................................................................25
Application—Single-phone PSTN and VoIP access ........................................................................................26
3Hardware installation......................................................................................................................................... 27
Planning the installation ........................................................................................................................................28
Installation checklist .......................................................................................................................................29
Site log ............................................................................................................................................................30
Network information ......................................................................................................................................30
Network Diagram .....................................................................................................................................30
IP related information .....................................................................................................................................30
Software tools .................................................................................................................................................30
Power source ...................................................................................................................................................30

4
SmartNode 4520 & 4110 Series User Manual Table of Contents
Location and mounting requirements .............................................................................................................31
Installing the gateway router..................................................................................................................................31
Mounting the gateway router ..........................................................................................................................31
Connecting cables ...........................................................................................................................................31
Installing an interface cable on the router’s FXS and FXO interface ports .................................................32
Installing the Ethernet cable ......................................................................................................................34
Connecting to external power source .........................................................................................................36
4Getting started with the SmartNode................................................................................................................... 38
Introduction..........................................................................................................................................................39
1. Configure IP address .........................................................................................................................................40
Power connection and default configuration ...................................................................................................40
Connect with the serial interface .....................................................................................................................40
Login ..............................................................................................................................................................41
Changing the IP address .................................................................................................................................41
2. Connect the SmartNode to the network............................................................................................................41
3. Load configuration ............................................................................................................................................42
Bootloader.............................................................................................................................................................43
Start Bootloader ..............................................................................................................................................43
Start-up with factory configuration .................................................................................................................43
Load a new application image (SmartWare) via TFTP ....................................................................................44
Load a new application image (SmartWare) via the serial link .........................................................................46
Additional information..........................................................................................................................................46
5LEDs status and monitoring .............................................................................................................................. 47
Status LEDs...........................................................................................................................................................48
6Contacting Patton for assistance......................................................................................................................... 51
Introduction..........................................................................................................................................................52
Contact information..............................................................................................................................................52
Warranty Service and Returned Merchandise Authorizations (RMAs)...................................................................52
Warranty coverage ..........................................................................................................................................52
Out-of-warranty service .............................................................................................................................52
Returns for credit ......................................................................................................................................52
Return for credit policy .............................................................................................................................53
RMA numbers ................................................................................................................................................53
Shipping instructions ................................................................................................................................53
ACompliance ...................................................................................................................................................... 54
Compliance ...........................................................................................................................................................55
EMC Compliance: ..........................................................................................................................................55
Safety Compliance: .........................................................................................................................................55
PSTN Regulatory Compliance: .......................................................................................................................55
CE Declaration of Conformity ..............................................................................................................................55
Authorized European Representative .....................................................................................................................55
Radio and TV Interference (FCC Part 15) ............................................................................................................56

5
SmartNode 4520 & 4110 Series User Manual Table of Contents
FCC Part 68 (ACTA) Statement (FXO Ports).......................................................................................................56
Industry Canada Notice (FXO Ports) ....................................................................................................................56
BSpecifications .................................................................................................................................................... 58
DSP.......................................................................................................................................................................59
Voice connectivity .................................................................................................................................................59
Connectivity..........................................................................................................................................................59
Voice processing (signalling dependent) ................................................................................................................59
Fax and modem support........................................................................................................................................59
Voice signalling .....................................................................................................................................................60
Voice routing—session router................................................................................................................................60
IP services..............................................................................................................................................................60
Management .........................................................................................................................................................61
Operating environment .........................................................................................................................................61
Operating temperature ....................................................................................................................................61
Operating humidity ........................................................................................................................................61
System...................................................................................................................................................................61
Dimensions ...........................................................................................................................................................61
Weight and power dissipation ...............................................................................................................................61
Power supply .........................................................................................................................................................62
AC version ......................................................................................................................................................62
DC version .....................................................................................................................................................62
Identification of the SmartNode devices via SNMP...............................................................................................62
CCabling ............................................................................................................................................................. 64
Introduction..........................................................................................................................................................65
Serial console.........................................................................................................................................................65
Start the SmartNode Discovery Tool.....................................................................................................................66
Ethernet 10Base-T and 100Base-T ........................................................................................................................66
Analog FXS ...........................................................................................................................................................69
Analog FXO ..........................................................................................................................................................70
DPort pin-outs .................................................................................................................................................... 71
Introduction..........................................................................................................................................................72
Console port..........................................................................................................................................................72
Ethernet 10Base-T and 100Base-T port ................................................................................................................72
FXS port................................................................................................................................................................73
FXO port ..............................................................................................................................................................73
ESmartNode 4110 Series factory configuration .................................................................................................... 74
Introduction..........................................................................................................................................................75
FSmartNode 4520 Series factory configuration .................................................................................................... 76
Introduction..........................................................................................................................................................77
GInstallation checklist ......................................................................................................................................... 78
Introduction..........................................................................................................................................................79

6
About this guide
This guide describes the SmartNode 4110 and 4520 Series hardware, installation and basic configuration. For
detailed software configuration information refer to the SmartWare Software Configuration Guide and the avail-
able Configuration Notes.
Audience
This guide is intended for the following users:
•Operators
•Installers
•Maintenance technicians
Structure
This guide contains the following chapters and appendices:
•Chapter 1 on page 10 provides information about router features and capabilities
•Chapter 2 on page 20 contains an overview describing router operation and applications
•Chapter 3 on page 27 provides quick start hardware installation procedures
•Chapter 4 on page 38 describes getting started with the SmartNode router
•Chapter 5 on page 47 contains definitions for the LED status indicators
•Chapter 6 on page 51 contains information on contacting Patton technical support for assistance
•Appendix B on page 58 contains specifications for the routers
•Appendix C on page 64 provides cable recommendations
•Appendix D on page 71 describes the router’s ports and pin-outs
•Appendix E on page 74 lists the factory configuration settings for SmartNode 4110 Series devices
•Appendix F on page 76 lists the factory configuration settings for SmartNode 4520 Series devices
•Appendix G on page 78 lists the tasks for installing a SmartNode 4520 or 4110 Series router
For best results, read the contents of this guide before you install the router.

7
SmartNode 4520 & 4110 Series User Manual About this guide
Precautions
Notes and cautions, which have the following meanings, are used throughout this guide to help you become
aware of potential Router problems. War nings relate to personal injury issues, and Cautions refer to potential
property damage.
CAUTION
The shock hazard symbol and CAUTION heading indicate a
potential electric shock hazard. Strictly follow the instructions to
avoid property damage caused by electric shock.
CAUTION
The alert symbol and CAUTION heading indicate a potential haz-
ard. Strictly follow the instructions to avoid property damage.
Note Calls attention to important information.
WARNING
The shock hazard symbol and WARNING heading indicate a
potential electric shock hazard. Strictly follow the warning
instructions to avoid injury caused by electric shock.
WARNING
The alert symbol and WARNING heading indicate a potential
safety hazard. Strictly follow the warning instructions to avoid
personal injury.
Safety when working with electricity
WARNING
The SmartNode contains no user serviceable parts. The equip-
ment shall be returned to Patton Electronics for repairs, or
repaired by qualified service personnel.
WARNING
Mains Voltage: Do not open the case when the power cord is
connected. For systems without a power switch, line voltages
are present within the power supply when the power cord is
connected. The mains outlet that is utilized to power the Smart-
Node router shall be within 10 feet (3 meters) of the device,
shall be easily accessible, and protected by a circuit breaker.
WARNING
For AC powered units, ensure that the power cable used meets
all applicable standards for the country in which it is to be
installed, and that it is connected to a wall outlet which has
earth ground.

WARNING
For units with an external power adapter, the adapter shall be a
listed Limited Power Source.
WARNING
Hazardous network voltages are present in WAN ports regard-
less of whether power to the SmartNode is ON or OFF. To avoid
electric shock, use caution when near WAN ports. When
detaching the cables, detach the end away from the Smart-
Node first.
WARNING
Before opening the chassis, disconnect the telephone network
cables to avoid contact with telephone line voltages. When
detaching the cables, detach the end away from the Smart-
Node first.
WARNING
Do not work on the system or connect or disconnect cables
during periods of lightning activity.
In accordance with the requirements of council directive 2002/96/
EC on Waste of Electrical and Electronic Equipment (WEEE),
ensure that at end-of-life you separate this product from other
waste and scrap and deliver to the WEEE collection system in
your country for recycling.
8
SmartNode 4520 & 4110 Series User Manual About this guide
Preventing electrostatic discharge damage
When starting to install interface cards place the interface card on its shielded plastic bag if you lay it on your bench.
CAUTION
Electrostatic Discharge (ESD) can damage equipment and
impair electrical circuitry. It occurs when electronic printed circuit
cards are improperly handled and can result in complete or inter-
mittent failures. Do the following to prevent ESD:
•Always follow ESD prevention procedures when removing and
replacing cards.
•Wear an ESD-preventive wrist strap, ensuring that it makes good
skin contact. Connect the clip to an unpainted surface of the chas-
sis frame to safely channel unwanted ESD voltages to ground.
•To properly guard against ESD damage and shocks, the wrist strap
and cord must operate effectively. If no wrist strap is available,
ground yourself by touching the metal part of the chassis.

9
SmartNode 4520 & 4110 Series User Manual About this guide
General observations
•Clean the case with a soft slightly moist anti-static cloth
•Place the unit on a flat surface and ensure free air circulation
•Avoid exposing the unit to direct sunlight and other heat sources
•Protect the unit from moisture, vapors, and aggressive liquids
Typographical conventions used in this document
This section describes the typographical conventions and terms used in this guide.
General conventions
The procedures described in this manual use the following text conventions:
Table 1. General conventions
Convention Meaning
Garamond blue type Indicates a cross-reference hyperlink that points to a figure, graphic, table, or sec-
tion heading. Clicking on the hyperlink jumps you to the reference. When you
have finished reviewing the reference, click on the Go to Previous View
button in the Adobe® Acrobat® Reader toolbar to return to your starting point.
Futura bold type Commands and keywords are in boldface font.
Futura bold-italic type Parts of commands, which are related to elements already named by the user,
are in boldface italic font.
Italicized Futura type Variables for which you supply values are in italic font
Futura type Indicates the names of fields or windows.
Garamond bold type Indicates the names of command buttons that execute an action.
< > Angle brackets indicate function and keyboard keys, such as <SHIFT>, <CTRL>,
<C>, and so on.
[ ] Elements in square brackets are optional.
{a | b | c} Alternative but required keywords are grouped in braces ({ }) and are separated
by vertical bars ( | )
blue screen Information you enter is in blue screen font.
screen Terminal sessions and information the system displays are in screen font.
node The leading IP address or nodename of a SmartNode is substituted with node in
boldface italic font.
SN The leading SN on a command line represents the nodename of the SmartNode
#An hash sign at the beginning of a line indicates a comment line.

10
Chapter 1 General information
Chapter contents
SmartNode Series VoIP routers overview .........................................................................................................11
SmartNode 4520 Series router ....................................................................................................................12
Ports descriptions ....................................................................................................................................14
Reset button behavior ............................................................................................................................14
SmartNode 4110 Series router ....................................................................................................................16
Ports descriptions ....................................................................................................................................18
Reset button behavior ............................................................................................................................18

SmartNode Series VoIP routers overview 11
SmartNode 4520 & 4110 Series User Manual 1• General information
SmartNode Series VoIP routers overview
The SmartNode 4520 and 4110 Series VoIP Gateway Routers (see figure 1) combine IP routing, VPN/Secu-
rity, and Quality of Service for up to 8 transparent voice and FAX calls over any IP or PSTN network. Leverage
low-cost IP services with packet-voice for complete branch office voice and data connectivity.
Figure 1. SmartNode Router (SmartNode 4524 shown)
The SmartNode 4520 Series Gateway Routers, equipped with two 10/100Base-T Ethernet ports provide;
voice over IP (VoIP) and Internet telephony plus Internet access routing, VPN and firewall functions, and
extensive Quality of Service (QoS) functions.
The SmartNode 4110 Series Media Gateways, equipped with a single 10/100Base-T Ethernet port that provide
VoIP an d Interne t telephony.
The SmartNode VoIP Gateways and Gateway-Routers perform the following major functions:
•Voice over IP and local switching via a combination of 2 to 8 analog phone ports (FXS) and 2 to 4 analog line
ports (FXO).
•Standard compliant VoIP conversion in accordance with SIP and H.323 protocols.
•Internet access and IP Routing (4520 Series only) with IP Quality of Service (QoS) support for mixed voice
and data traffic.
Section “SmartNode 4520 Series router” on page 12 provides more information on the SmartNode 4520
Series. Section “SmartNode 4110 Series router” on page 16 describes the SmartNode 4110 Series.

SmartNode Series VoIP routers overview 12
SmartNode 4520 & 4110 Series User Manual 1• General information
SmartNode 4520 Series router
The SmartNode 4520 Series are compact VoIP Gateway Routers that support two to eight VoIP calls and vari-
ous combinations of FXS and FXO ports (see figure 2).
10/100 Ethernet
0/30/2 0/1 0/0
VoicePorts
FXS
Figure 2. Examples of SN4520 Series rear panels
The following base models (each equipped with two 10/100Base-T Ethernet ports) are available:
•SmartNode 4522 (2 VoIP calls)
•SmartNode 4524 (4 VoIP calls)
•SmartNode 4526 (6 VoIP calls)
•SmartNode 4528 (8 VoIP calls)

SmartNode Series VoIP routers overview 13
SmartNode 4520 & 4110 Series User Manual 1• General information
The port combinations are indicated in the extension of the model code. The products the following model
code conventions apply:
•JS stands for FXS ports
•JO stands for FXO ports
•UI stands for integrated universal input power supply (see figure 3)
•EUI stands for external universal input power supply (see figure 3)
For example, the model code SN4526/4JS2JO/EUI describes a SmartNode configured as follows:
•4 FXS ports
•2 FXO ports
•External power supply
Note For a complete listing of available models, refer to the SmartNode VoIP page
at http://www.patton.com/voip/.
Figure 3. SmartNode 4520 Series power input connectors

SmartNode Series VoIP routers overview 14
SmartNode 4520 & 4110 Series User Manual 1• General information
Ports descriptions
The SmartNode 4520 Series rear panel ports are described in table 2.
Table 2. Rear panel ports
Port Location Description
10/100 Ethernet
ETH 0/0 & ETH 0/1
Rear panel RJ-45 connectors (see figure 16 on page 32) that connect the router to an
Ethernet device (e.g., a cable or DSL modem, LAN hub or switch).
Analog voice port,
FXS
Rear panel FXS RJ-11(6 position, 4 wire) connectors (see figure 16 on page 32) that
connect the router with an analog terminal (a telephone, for example)
FXO port. EuroPOTS support (ETSI EG201 188). FXS on-hook voltage is
48V for each FXS port.
Analog voice port,
FXO
Rear panel FXO RJ-11(6 position, 4 wire) connectors (see figure 16 on page 32) that
connect the router with an analog line (FXS port). EuroPOTS support
(ETSI EG201 188).
Power Rear panel The gateway is available in a DC or AC power input version (see
figure 3), labeled as follows:
•AC version (Internal power supply): 100–240 VAC, 50/60 Hz, 200 mA
•DC version: 12 VDC, 1.25 A
Console Front
panel
Used for service and maintenance, the Console port (see figure 4 on
page 15), an RS-232 RJ-45 connector, connects the router to a serial terminal
such as a PC or ASCII terminal (also called a dumb terminal).
Reset button behavior
For those SmartNode devices that have a Reset button on the rear panel, its behavior is as follows:
•To restart the unit with the current startup configuration—Press for less than 1 second and release the Reset
button. The SmartNode will restart with the current startup configuration.
•To restart the unit with factory default configuration—Press the Reset button for 5 seconds until the Power
LED starts blinking. The unit will restart with factory default configuration.
•To restart the unit in bootloader mode (to be used only by trained SmartNode technicians)—Start with the
unit powered off. Press and hold the Reset button while applying power to the unit. Release the Reset button
when the Power LED starts blinking so the unit will enter bootloader mode.

SmartNode Series VoIP routers overview 15
SmartNode 4520 & 4110 Series User Manual 1• General information
Figure 4. SmartNode 4520 Series front panels
Note For LED descriptions, refer to chapter 5, “LEDs status and monitoring” on
page 47.

SmartNode Series VoIP routers overview 16
SmartNode 4520 & 4110 Series User Manual 1• General information
SmartNode 4110 Series router
The SmartNode 4110 Series are compact VoIP Gateways that support two to eight VoIP calls and various com-
binations of FXS and FXO ports (see figure 5).
0/3 0/2 0/10/0
Voice Ports
FXS
,1.25A
Figure 5. Examples of SN4110 Series rear panels

SmartNode Series VoIP routers overview 17
SmartNode 4520 & 4110 Series User Manual 1• General information
The following base models (each equipped with one 10/100Base-T Ethernet port) are available:
•SmartNode 4112 (2 VoIP calls)
•SmartNode 4114 (4 VoIP calls)
•SmartNode 4116 (6 VoIP calls)
•SmartNode 4118 (8 VoIP calls)
•SmartNode 4112 and 4112S (2 VoIP calls)
The port combinations are indicated in the extension of the model code. The products the following model
code conventions apply:
•JS stands for FXS ports
•JO stands for FXO ports
•UI stands for integrated universal input power supply (see figure 6)
•EUI stands for external universal input power supply (see figure 6)
For example, the model code SN4116/4JS2JO/EUI describes a SmartNode configured as follows:
•4 FXS ports
•2 FXO ports
•External power supply
Note For a complete listing of available models, refer to the SmartNode VoIP page
at http://www.patton.com/voip/.
Figure 6. SmartNode 4110 Series power input connectors

SmartNode Series VoIP routers overview 18
SmartNode 4520 & 4110 Series User Manual 1• General information
Ports descriptions
The SmartNode 4110 Series rear panel ports are described in table 3.
Table 3. Rear panel ports
Port Location Description
10/100 Ethernet
ETH 0/0
Rear panel RJ-45 connector (see figure 5 on page 16) that connects the router to an
Ethernet device (a cable or DSL modem, LAN hub or switch, for exam-
ple).
Analog voice port,
FXS
Rear panel FXS RJ-11(6 position, 4 wire) connectors (see figure 16 on page 32) that
connect the router with an analog terminal (a telephone, for example)
FXO port. EuroPOTS support (ETSI EG201 188).
Analog voice port,
FXO
Rear panel FXO RJ-11(6 position, 4 wire) connectors (see figure 16 on page 32) that
connect the router with an analog line (FXS port). EuroPOTS support
(ETSI EG201 188).
Power Rear panel The gateway is available in a DC or AC power input version (see
figure 6), labeled as follows:
•AC version (Internal power supply): 100–240 VAC, 50/60 Hz, 200 mA
•DC version: 12 VDC, 1.25 A
Console Front
panel
Used for service and maintenance, the Console port (see figure 7 on
page 19), an RS-232 RJ-45 connector, connects the router to a serial terminal
such as a PC or ASCII terminal (also called a dumb terminal).
Reset button behavior
For those SmartNode devices that have a Reset button on the rear panel, its behavior is as follows:
•To restart the unit with the current startup configuration—Press for less than 1 second and release the Reset
button. The SmartNode will restart with the current startup configuration.
•To restart the unit with factory default configuration—Press the Reset button for 5 seconds until the Power
LED starts blinking. The unit will restart with factory default configuration.
•To restart the unit in bootloader mode (to be used only by trained SmartNode technicians)—Start with the
unit powered off. Press and hold the Reset button while applying power to the unit. Release the Reset button
when the Power LED starts blinking so the unit will enter bootloader mode.
Note SN4112S does not have a console port. See “Start the
SmartNode Discovery Tool” on page 66

s
SmartNode Series VoIP routers overview 19
SmartNode 4520 & 4110 Series User Manual 1• General information
Figure 7. SmartNode 4110 Series front panels
Note For LED descriptions, refer to chapter 5, “LEDs status and monitoring” on
page 47.
