Pawleys Island Roman Arc Cypress Hammock Stand User manual

Roman Arc Cypress
Hammock Stand
INSTRUCTIONS
Made in the USA NOTE: TWO PERSON ASSEMBLY SUGGESTED
Quantity per hardware pack (1 per box, 2 packs needed for full assembly)
(5) HEX NUTS
(8) FLAT WASHER (2) CARRIAGE BOLT
HARDWARE PACK
• CENTER BEAM (WITH FOUR COUNTERSUNK HOLES)
• FOOT BEAM (SHORTEST BEAM)
• END BEAM (WITH ROMAN ARC BRASS TAG)
The hammock stand is shipped in two boxes. Stand parts and
hardware pack contents listed below are per box. Stand parts and
hardware packs from both boxes are required for assembly.
STAND PARTS
• RATCHET OR PLIERS (not included)
• SCREW DRIVER (not included)
• 1 (9/16”) DEEP WELL SOCKET TOOL (included in each hardware kit)
SUGGESTED TOOLS
• Lightly sand once a year and add a coat of boiled
linseed oil to keep the cypress wood in good condition.
CARE INSTRUCTIONS
(2) HEX BOLTS
(3) PLASTIC CAPS TO COVER BOLT ENDS
(1) EYE BOLT

Congratulations on purchasing this Roman Arc Cypress Hammock Stand.
QUESTIONS REGARDING THIS PRODUCT? Call our customer service team,
800.643.3522.
ASSEMBLY
STEP 2. Position the assembly upright. To attach the feet, align the holes
in each foot with the holes in the center beams. The slant on the base of
the foot should angle the foot in towards the center of the stand. Insert
(4) carriage bolts, (4) at washers, and (4) hex nuts like shown in the dia-
gram. Tighten all bolts.
NOTE. Recommended use of the three
rubber/plastic caps provided, to cover the
exposed ends of the eye bolt and hex bolts
EYE BOLT
HEX NUT
HEX NUT
HEX NUT
FLAT WASHER
FLAT WASHER
FLAT
WASHER
CARRIAGE
BOLT
FLAT
WASHER
FLAT
WASHER
#6091 / 0217
HEX
BOLT
Make sure
counter bores
are facing out
STEP 1. Insert (2) eye bolts, (4) flat washers (two on each side), and
(2) hex nuts into the top of the end section of beams. Loosely attach
center beams to each end beam using (4) hex bolts, (8) flat washers,
and (4) hex nuts like shown in the diagram.
NOTE: Do not tighten anything until all bolts are installed in step 2.
NOTE: Hex Bolts and Eye Bolts require a
washer on each end. Carriage Bolts use a
washer only on the nut end.
