Sunjoy D-CM092PST-1A User manual

ProductionNumber:XXXXXXXXMadeInChina1/4
ASSEMBLY INTRUCTIONS
ITEM#：D-CM092PST-1A




























Warning
Some parts may contain sharp edges. When assembling and using this product, basic safety precautions should
always be followed to reduce the risk of personal injury and damage to the product. Please read all instructions
before assembly and use.
Check all bolts for tightness before use, and periodically check and tighten bolts as necessary.
Important: For technical assistance on assembly or replacement parts, please call Sunjoy Industries at 1(866) 578-6569
from 8:00AM EST to 8:00 PM PST. You may email to [e-mail] or visit
www.sunjoyonline.com to place your order or fax your parts replacement order form (which is included in the
packaging) together with your purchase receipt to 1 [phone] for assistance.





ProductionNumber:XXXXXXXXMadeInChina2/4
PARTS LIST
Label Description QTY
A Table Top 1
B Table Leg 4
C1 Left Arm 3
C2 Right Arm 3
D1 Backboard 1 2
D2 Backboard 2 1
E1 Seat Board 1 2
E2 Seat Board 2 1
F Seat Cushion 4
G Back Cushion 4
HARDWARE PACK
Label Description QTY
AA Bolt M6x15 24
BB Bolt M6x20 4
CC Bolt M6x35 7
DD Flat Washer M6 25
EE Wrench M6 1


ASSEMBLY STEPS-Coffee Table



















Fig.1: Insert the Table Leg (B) into Table
Top (A) and tighten with Bolt (BB) and
Flat Washer (DD).

ProductionNumber:XXXXXXXXMadeInChina3/4
ASSEMBLY STEPS-Single Chair
















ASSEMBLY STEPS-Loveseat




























Fig.2: Attach Seat Board 1 (E1) to Right Arm (C2)
using Bolt (AA) and Flat Washer (DD). Do not
tighten. Repeat this to Left Arm (C1).
Fig.3: Attach Backboard 1 (D1) to Seat Board 1 (E1)
using Bolt (CC) and Flat Washer (DD). Do not
tighten now.
Fig.4: Attach Backboard 1 (D1) to
RightArm (C2) using Bolt (AA) and Flat
Washer (DD). Repeat this to Left Arm (C1).
Tighten all bolts.
Fig.5: Attach Seat Board 2 (E2) to Right Arm
(C2) using Bolt (AA) and Flat Washer (DD).
Do not tighten. Repeat this to Left Arm (C1).
Fig.6: Attach Back Board 2 (D2) to Seat
Board 2 (E2) using Bolt (CC) and Flat
Washer (DD). Do not tighten now.
Fig.7: Attach Backboard (D2) to Right Arm
(C2) using Bolt (AA) and Flat Washer (DD).
Repeat for Left Arm (C1). Tighten all bolts.
F
G After assembling, put all
Seat Cushion (F) and
Back Cushion (G) on the
seat for using.
F
G

ProductionNumber:XXXXXXXXMadeInChina4/4
Care & Maintenance:
Before using, clean the product completely with a soft dry towel.
When not in use, wipe free of any dirt or loose objects, wash with a mild solution of soap and water; rinse
thoroughly and dry completely. Do not use strong detergent or abrasive cleaners.
Steel components of garden accessories and furniture are treated with rust inhibiting paint. However, due to the
nature of steel, surface oxidation (rusting) will occur if this protective coating is scratched.
To minimize this condition, it is recommended that care be taken when assembling and handling the product, in
order to prevent the paint from being scratched.
Limited Warranty: The item is warranted to be free from defects in material or workmanship for a period of twelve
(12) months. However, we do not reimburse for transportation or delivery costs, nor compensate the individual or any
outside party for assembling or disassembling the product. This limited warranty is extended to the original purchaser
and applies to defects in materials and workmanship of your item, provided the item is maintained with care and used
only for personal residential purposes.
Exclusions
Items used for commercial, contract, or other non-residential purposes, or items damaged due to acts of nature,
vandalism, misuse, or improper assembly are not covered. Corrosion or rusting of hardware is not covered. Proof of
purchase (dated register receipt) is required for warranty claims. Warranty is to the original purchaser and is
non-transferable. Any replacement of warranted items will be in the original style and color or a similar style and color
if the original is unavailable or has been discontinued. As some states do not allow exclusions or limitations on an
implied warranty, the above exclusions and limitations may not apply. This warranty gives you specific rights, and you
may also have other rights, which vary from state to state.
