PCB Piezotronics 132A31/004AW User manual

Model 132A31/004AW
Micro ICP® pressure sensor, 140 mV/psi, pigtail conn. (for high frequency
Installation and Operating Manual
For assistance with the operation of this product,
contact PCB Piezotronics, Inc.
Toll-free: 800-828-8840
24-hour SensorLine: 716-684-0001
Fax: [phone]
E-mail: [email protected]
Web: www.pcb.com

The information contained in this document supersedes all similar information that
may be found elsewhere in this manual.
Total Customer Satisfaction –PCB
Piezotronics guarantees Total Customer
Satisfaction. If, at any time, for any
reason, you are not completely satisfied
with any PCB product, PCB will repair,
replace, or exchange it at no charge.
You may also choose to have your
purchase price refunded in lieu of the
repair, replacement, or exchange of the
product.
Service –Due to the sophisticated
nature of the sensors and associated
instrumentation provided by PCB
Piezotronics, user servicing or repair is
not recommended and, if attempted,
may void the factory warranty. Routine
maintenance, such as the cleaning of
electrical connectors, housings, and
mounting surfaces with solutions and
techniques that will not harm the
physical material of construction, is
acceptable. Caution should be observed
to insure that liquids are not permitted to
migrate into devices that are not
hermetically sealed. Such devices
should only be wiped with a dampened
cloth and never submerged or have
liquids poured upon them.
Repair –In the event that equipment
becomes damaged or ceases to
operate, arrangements should be made
to return the equipment to PCB
Piezotronics for repair. User servicing or
repair is not recommended and, if
attempted, may void the factory
warranty.
Calibration –Routine calibration of
sensors and associated instrumentation
is recommended as this helps build
confidence in measurement accuracy
and acquired data. Equipment
calibration cycles are typically
established by the users own quality
regimen. When in doubt about a
calibration cycle, a good “rule of thumb”
is to recalibrate on an annual basis. It is
also good practice to recalibrate after
exposure to any severe temperature
extreme, shock, load, or other
environmental influence, or prior to any
critical test.
PCB Piezotronics maintains an ISO-
9001 certified metrology laboratory and
offers calibration services, which are
accredited by A2LA to ISO/IEC 17025,
with full traceability to SI through
N.I.S.T. In addition to the normally
supplied calibration, special testing is
also available, such as: sensitivity at
elevated or cryogenic temperatures,
phase response, extended high or low
frequency response, extended range,
leak testing, hydrostatic pressure
testing, and others. For information on
standard recalibration services or
special testing, contact your local PCB
Piezotronics distributor, sales
representative, or factory customer
service representative.
Returning Equipment –Following
these procedures will insure that your
returned materials are handled in the
most expedient manner. Before
Warranty, Service, Repair, and
Return Policies and Instructions

returning any equipment to PCB
Piezotronics, contact your local
distributor, sales representative, or
factory customer service representative
to obtain a Return Warranty, Service,
Repair, and Return Policies and
Instructions Materials Authorization
(RMA) Number. This RMA number
should be clearly marked on the outside
of all package(s) and on the packing
list(s) accompanying the shipment. A
detailed account of the nature of the
problem(s) being experienced with the
equipment should also be included
inside the package(s) containing any
returned materials.
A Purchase Order, included with the
returned materials, will expedite the
turn-around of serviced equipment. It is
recommended to include authorization
on the Purchase Order for PCB to
proceed with any repairs, as long as
they do not exceed 50% of the
replacement cost of the returned
item(s). PCB will provide a price
quotation or replacement
recommendation for any item whose
repair costs would exceed 50% of
replacement cost, or any item that is not
economically feasible to repair. For
routine calibration services, the
Purchase Order should include
authorization to proceed and return at
current pricing, which can be obtained
from a factory customer service
representative.
Warranty –All equipment and repair
services provided by PCB Piezotronics,
Inc. are covered by a limited warranty
against defective material and
workmanship for a period of one year
from date of original purchase. Contact
PCB for a complete statement of our
warranty. Expendable items, such as
batteries and mounting hardware, are
not covered by warranty. Mechanical
damage to equipment due to improper
use is not covered by warranty.
Electronic circuitry failure caused by the
introduction of unregulated or improper
excitation power or electrostatic
discharge is not covered by warranty.
Contact Information –International
customers should direct all inquiries to
their local distributor or sales office. A
complete list of distributors and offices
can be found at www.pcb.com.
Customers within the United States may
contact their local sales representative
or a factory customer service
representative. A complete list of sales
representatives can be found at
www.pcb.com. Toll-free telephone
numbers for a factory customer service
representative, in the division
responsible for this product, can be
found on the title page at the front of this
manual. Our ship to address and
general contact numbers are:
PCB Piezotronics, Inc.
3425 Walden Ave.
Depew, NY14043 USA
Toll-free: [phone]
24-hour SensorLineSM: [phone]
Website: www.pcb.com
E-mail: [email protected]

PCB工业监视和测量设备 - 中国RoHS2公布表
PCB Industrial Monitoring and Measuring Equipment - China RoHS 2 Disclosure Table
部件名称
有害物质
铅(Pb)
汞
(Hg)
镉
(Cd)
六价铬(Cr(VI))
多溴联苯 (PBB)
多溴二苯醚(PBDE)
住房
O
O
O
O
O
O
PCB板
X
O
O
O
O
O
电气连接器
O
O
O
O
O
O
压电晶体
X
O
O
O
O
O
环氧
O
O
O
O
O
O
铁氟龙
O
O
O
O
O
O
电子
O
O
O
O
O
O
厚膜基板
O
O
X
O
O
O
电线
O
O
O
O
O
O
电缆
X
O
O
O
O
O
塑料
O
O
O
O
O
O
焊接
X
O
O
O
O
O
铜合金/黄铜
X
O
O
O
O
O
本表格依据 SJ/T 11364 的规定编制。
O：表示该有害物质在该部件所有均质材料中的含量均在 GB/T 26572 规定的限量要求以下。
X：表示该有害物质至少在该部件的某一均质材料中的含量超出 GB/T 26572 规定的限量要求。
铅是欧洲RoHS指令2011/65/ EU附件三和附件四目前由于允许的豁免。
CHINA RoHS COMPLIANCE

DOCUMENT NUMBER: 21354
DOCUMENT REVISION: C
ECN: 45605
Component Name
Hazardous Substances
Lead
(Pb)
Mercury
(Hg)
Cadmium
(Cd)
Chromium VI
Compounds
(Cr(VI))
Polybrominated
Biphenyls
(PBB)
Polybrominated
Diphenyl
Ethers (PBDE)
Housing
O
O
O
O
O
O
PCB Board
X
O
O
O
O
O
Electrical
Connectors
O
O
O
O
O
O
Piezoelectric
Crystals
X
O
O
O
O
O
Epoxy
O
O
O
O
O
O
Teflon
O
O
O
O
O
O
Electronics
O
O
O
O
O
O
Thick Film
Substrate
O
O
X
O
O
O
Wires
O
O
O
O
O
O
Cables
X
O
O
O
O
O
Plastic
O
O
O
O
O
O
Solder
X
O
O
O
O
O
Copper Alloy/Brass
X
O
O
O
O
O
This table is prepared in accordance with the provisions of SJ/T 11364.
O: Indicates that said hazardous substance contained in all of the homogeneous materials for this part is below the limit
requirement of GB/T 26572.
X: Indicates that said hazardous substance contained in at least one of the homogeneous materials for this part is above
the limit requirement of GB/T 26572.
Lead is present due to allowed exemption in Annex III or Annex IV of the European RoHS Directive 2011/65/EU.

ICP

is a registered trademark of PCB Piezotronics, Inc. Drawing Number: 21094
Revision: A
ECO #: 35764
OPERATION MANUAL FOR MICROSENSORS
132 Series
1
1.0 INTRODUCTION
132 Series Microsensors are small, piezoelectric
pressure sensors featuring extremely fast response for
measurement of short wavelength pressure pulses.
The short time constant of some models filters off the
longer duration portion of pressure pulses, allowing
differentiation of consecutive pressure pulses.
132 Series Microsensors contain integrated ICP

circuit amplifiers which operate as source followers
and provide very high-frequency response. These
micro-integrated circuit amplifiers convert the high-
impedance voltage from the crystals into low-
impedance voltage of less than 100 ohms.
Output from the microsensors may be coupled
directly into oscilloscopes, recorders and A to D
converters. Power to operate the IC amplifier and the
output signal are conducted over a single conductor,
two-wire cable with the ground serving as signal
return. Special low-noise cables are not required.
The calibrated mV/psi output of these microsensors is
not attenuated nor is noise appreciably increased by
the cable.
2.0 DESCRIPTION
132 Series Microsensors feature small diameter
pressure-sensing surfaces incorporating very small (<
1 mm) piezoelectric sensing elements. The small size
of the sensing elements imparts extremely fast
response time to the microsensors.
The charge generated by deflection of the
piezoelectric element when subjected to shock
pressures creates a voltage on the input capacitance at
the gate of the microsensor ICP

amplifier. The
amplifier, in conjunction with the source element,
transforms the input into a low-impedance output
signal of equal amplitude. The DC bias that exists on
the signal lead is removed from the output signal by a
coupling capacitor in the power supply. Resistors in
the internal ICP

amplifiers of the microsensors set
the internal discharge time constant, which
determines the low-frequency response of the
microsensors. (Refer to General Guide to ICP

Instrumentation, G-0001, for complete details.)
Below are the available configurations for the 132
Series Microsensors.
Model 132A31 Time-of-Arrival
ICP



Microsensor
Model 132A32
Model 060A28
Clamp Nut
¼” Hex
¼-28 Thread
(supplied)
2-ft Twisted Pair
Cable Terminating into
Model 070B09 Solder
Connector Adaptor
(supplied)
Terminating into
#10-32 Coaxial
Connector

ICP

is a registered trademark of PCB Piezotronics, Inc. Drawing Number: 21094
Revision: A
ECO #: 35764
OPERATION MANUAL FOR MICROSENSORS
132 Series
2
Model 132A35
Model 132A36
Model 132A37
3.0 INSTALLATION
Refer to the installation drawing for details. If the
microsensors are to be subjected to pressures beyond
their specified range, be sure to use backing nuts to
prevent the sensors from backing out of their
mounting ports. (Thread adaptors are available from
PCB to facilitate mounting.)
Connect the microsensors to an ICP

power supply.
Use standard two-conductor cable between the sensor
and the ICP

power unit.
Next, connect the power unit to a readout device, e.g.,
oscilloscope, recorder or high-speed A to D
converter.
4.0 OPERATION
Switch the ICP

power unit on and observe reading of
bias-monitoring voltmeter on front panel of power
unit.
If indicator is in green section of indicator panel, the
IC amplifier is providing proper bias (normally +11
VDC), cable connections are normal and the system
is ready to operate.
If the needle moves to the red area of the fault
monitor meter, output is zero and a short is indicated.
The short could be located in the amplifier cable
connectors or in the power unit.
If the pointer moves into the yellow area of the fault
monitor meter, an open circuit is indicated with full
power supply voltage. An open circuit could be the
result of a faulty amplifier, an open cable or open
connectors.
Allow the sensor to thermally stabilize for about one
minute. A signal drift may occur when the output
cable is connected to the readout instrument.
The drift occurs during charging of the coupling
capacitor in the power unit. The signal will stabilize
in several minutes.
Model 060A28
Clamp Nut
¼” Hex
¼-28 Thread
(supplied)
2-ft Twisted Pair
Cable Terminating into
Model 070B09 Solder
Connector Adaptor
(supplied)
2-ft Twisted Pair
Cable Terminating
into Pigtail
#10-32
Coaxial
Connector
O-Rings
(2 supplied)
O-Rings
(2 supplied)

ICP

is a registered trademark of PCB Piezotronics, Inc. Drawing Number: 21094
Revision: A
ECO #: 35764
OPERATION MANUAL FOR MICROSENSORS
132 Series
3
4.1 OPERATION BEYOND RANGE
SPECIFICATION
Because 132 Series Microsensors can be installed
using RTV-like potting materials to hold them in
place, maximum pressure specifications are given to
prevent the sensors from being extruded from the
mounting holes. Static or slow dynamic
overpressures are more apt to cause a problem than a
short dynamic shock pulse. Use of backing nuts will
minimize the possibility of a problem.
The microsensors are capable of responding to
dynamic overpressures up to ten times the specified
range. The output will be “clipped” (look flat-topped
on the readout) after about 10 volts.
The initial rise of the output will be accurate up to the
point of clipping. This can allow for an accurate
time-of-arrival measurement, even though the peak
pressure cannot be measured.
5.0 CALIBRATION
A shock tube is used to calibrate the microsensors.
6.0 MAINTENANCE AND REPAIR
Except for repair of wires, the microsensors are not
field-repairable. In case of serious malfunction,
contact the PCB at [phone].
It is well to observe the following precautions in
using the microsensors:
1. Do not exceed specified pressure levels without
proper mounting.
2. Do not subject microsensors to temperatures
exceeding 174 °F (79 °C).
3. Do not apply voltage to sensors without current-
limiting diodes or other current protection. (PCB
ICP

power supplies feature proper voltage and
current protection.)
4. Do not apply more than 20 mA of current to the
microsensors.

Model Number
132A31 ICP® PRESSURE SENSOR Revision: R
ECN #: 44634
Performance ENGLISH SI
Measurement Range 50 psi 345 kPa
Sensitivity(± 30 %) 140 mV/psi 20.3 mV/kPa
Maximum Pressure(Dynamic) 800 psi 5516 kPa
Resolution 0.001 psi 0.007 kPa
Resonant Frequency ≥1000 kHz ≥1000 kHz
Rise Time(Incident) ≤3 µ sec ≤3 µ sec [1]
Rise Time(Reflected) ≤0.5 µ sec ≤0.5 µ sec [2]
Low Frequency Response(-5 %) 11,000 Hz 11,000 Hz
Environmental
Temperature Range(Operating) 0 to +175 °F -18 to +79 °C
Electrical
Output Polarity(Positive Pressure) Positive Positive
Discharge Time Constant(at room temp) ≥.000045 sec ≥.000045 sec
Excitation Voltage 20 to 30 VDC 20 to 30 VDC
Constant Current Excitation 2 to 20 mA 2 to 20 mA
Output Impedance ≤100 Ohm ≤100 Ohm
Output Bias Voltage 8 to 14 VDC 8 to 14 VDC
Physical
Sensing Element Ceramic Ceramic
Housing Material Stainless Steel Stainless Steel
Sealing Epoxy Epoxy
Electrical Connector Integral Twisted Pair Integral Twisted Pair
Weight(without clamp nut) 0.018 oz 0.52 gm [3]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
ICP®is a registered trademark of PCB Group, Inc.
M- Metric Mount
N- Negative Output Polarity
W- Water Resistant Cable
NOTES:
[1]Rise time in air at Mach 1
[2]Rise time at 20mA
[3]Weight including cable.
SUPPLIED ACCESSORIES:
Model 060A28 Clamp Nut, 1/4-28 x 1/4" Hex (1)
Model 070B09 Solder adaptor (1)
3425 Walden Avenue, Depew, NY 14043
Phone: [phone]
Fax: [phone]
E-Mail: [email protected]
OPTIONAL VERSIONS
Optional versions have identical specifications and accessories as listed for the standard model
except where noted below. More than one option may be used.
Entered: JM Engineer: MJK Sales: RWM Approved: APB Spec Number:
Date: 10/6/2015 Date: 10/6/2015 Date: 10/6/2015 Date: 10/6/2015 132-1310-80

1
1
2
2
A A
B B
CODE
IDENT. NO.
52681
DWG. NO.
SCALE: SHEET
DRAWN CHECKED ENGINEER
TITLE
UNLESS OTHERWISE SPECIFIED TOLERANCES ARE:
DIMENSIONS IN MILLIMETERS
[ IN BRACKETS ]
XX ±0.13
ANGLES 2 DEGREES
3425 WALDEN AVE. DEPEW, NY 14043
[phone] E-MAIL: [e-mail]
DIMENSIONS IN INCHES
DECIMALS XX ±.01
ANGLES 2 DEGREES
FILLETS AND RADII
.003 - .005
DECIMALS X ± 0.3
FILLETS AND RADII
0.07 - 0.13
INSTALLATION DRAWING
6574
1 OF 13X
MODEL 132A31
MICRO SENSOR
XXX ±.005
BB 1/13/16 ECB 1/13/16 MJK 1/13/16
6574
PCB Piezotronics Inc. claims proprietary rights in
the information disclosed hereon. Neither it nor any
reproduction thereof will be disclosed to others
without the written consent of PCB Piezotronics Inc.
REVISIONS
REV DESCRIPTION DIN
D ADDED WIRE NOTE 44937
MODEL 070B09
SOLDER CONNECTOR ADAPTOR
(SUPPLIED)
.30 [7.6]
.125 [3.18]
MODEL 132A31
MICRO SENSOR
RED - SIG/PWR
BLACK - GROUND
(SUPPLIED
.300 [7.62]
.20 [5.1]
.27 [6.9]
1/4-28 UNF - 2A
MODEL 060A28
CLAMP NUT
.25[6.4] HEX
(SUPPLIED)
SIG/PWR
GROUND
MOUNTING HOLE PREPARATION:
Ø.1285 [3.250] THRU
Ø.203 [5.20] .220
1/4-28 UNF - 2B .150
WIRE: #36 AWG
TWISTED PAIR 2.00 FEET (.6 METERS) LONG
RED: SIG/PWR
BLACK: GROUND
6.) ALLOW RTV TO FULLY CURE
5.) REMOVE EXCESSIVE RTV FROM MICRO SENSOR AND MOUNTING HOLE SURFACES
4.) WHILE APPLYING FINGER PRESSURE TO THE BOTTOM OF THE MICRO SENSOR, UNTIGHTEN CLAMP NUT
UNTIL DATUM A AND B ARE FLUSH WITH EACH OTHER
3.) INSERT MICRO SENSOR INTO BOTTOM OF MOUNTING HOLE
2.) HAND TIGHTEN CLAMP NUT INTO MOUNTING HOLE
1.) LIGHTLY COAT THE INSIDE DIAMETER OF MOUNTING HOLE, OUTSIDE DIAMETER OF MICRO SENSOR
(MODEL 132A31), AND CLAMP NUT (MODEL 060A28) WITH RTV
B
A
