PCchips M787CLR User manual

Mainboard User’s Manual
This publication, including all photographs, illustrations and
software, is protected under international copyright laws, with all
rights reserved. Neither this manual, nor any of the material
contained herein, may be reproduced without the express written
consent of the manufacturer.
The information in this document is subject to change without
notice. The manufacturer makes no representations or warranties
with respect to the contents hereof and specifically disclaims any
implied warranties of merchantability or fitness for any particular
purpose. Further, the manufacturer reserves the right to revise this
publication and to make changes from time to time in the content
hereof without obligation of the manufacturer to notify any person
of such revision or changes.
Trademarks
I M, VGA, and PS/2 are registered trademarks of International
usiness Machines.
Intel, Pentium/II/III, MMX, and Celeron are registered trademarks
of Intel Corporation.
Microsoft, MS-DOS and Windows 95/98/NT/2000 are registered
trademarks of Microsoft Corporation.
PC-cillin and ChipAwayVirus are trademarks of Trend Micro Inc.
Award is a trademark of Award Software Inc.
A3D is a registered trademark of Aureal Inc.
SuperVoice is a registered trademark of Pacific Image
Communications Inc.
MediaRing Talk is a registered trademark of MediaRing Inc.
3Deep is a registered trademark of E-Color Inc.
Other names used in this publication may be trademarks and are
acknowledged.
Copyright © 2001
All Rights Reserved
M787 Series, V1.1
V133X/M y 2001

Mainboard User’s Manual
II

Mainboard User’s Manual
Table of Contents
Trademarks..............................................................................I
Chapter 1: Introduction...................................................................1
Key Features...........................................................................2
Package Contents....................................................................5
Static Electricity Precautions..................................................6
Pre-Installation Inspection......................................................6
Chapter 2: Mainboard Installation..................................................7
Mainboard Components..........................................................8
I/O Ports..................................................................................8
Install Memory.......................................................................9
Setting Jumper Switches.......................................................10
Install the Mainboard............................................................12
Optional Extension rackets.................................................13
Install Other Devices............................................................13
Expansion Slots....................................................................15
Chapter 3: IOS Setup Utility......................................................17
Introduction..........................................................................17
Running the Setup Utility.....................................................18
Standard CMOS Features Page.............................................19
Advanced IOS Features Page.............................................20
Advanced Chipset Features Page..........................................22
Integrated Peripherals Page...................................................24
Power Management Setup Page............................................27
PnP/PCI Configurations Page...............................................29
Hardware Monitor Page........................................................31
Frequency/Voltage Control Page..........................................32
Load estPerf. Defaults........................................................32
Load Optimized Defaults......................................................33
Set Password.........................................................................33
Save & Exit Setup.................................................................33
Exit Without Saving..............................................................33
Chapter 4: Software & Applications.............................................35
Introduction..........................................................................35
Installing Support Software..................................................35
Auto-installing under Windows 98.......................................37
III

Mainboard User’s Manual
IV

1: Introduction
Chapter 1
Introduction
This mainboard has onboard VIA Samuel2 1Gig Pro processor
with front-side bus speeds of 133MHz.
This mainboard uses the VIA VT133 chipset, and integrates a 3D
Gr phics Acceler tor and Ultr DMA 33/66/100 (VT82C686
chip only) function. The mainboard has a built-in AC97 Codec,
provides an AMR (Audio Modem Riser) slot to support Audio and
Modem application, and has a built-in 10B seT/100B seTX
Network Interf ce. In addition, the mainboard has an extended set
of ATX I/O Ports including PS/2 keyboard and mouse ports, two
US ports, a parallel port, a VGA port, a serial port, a game port
and audio ports. An extra US header gives you the option of
connecting two more US ports.
This mainboard has all the features you need to develop a powerful
multimedia workstation. The board is Micro ATX size and has a
power connector for an ATX power supply.
1

Mainboard User’s Manual
Key Features
The key features of this mainboard include:
1Giga Pro Processor
uilt-in VIA C3 Samuel2 1Giga Pro CPU
Supports up to 133MHz Front-Side us
Memory Support
Two DIMM slots for 168-pin SDRAM memory modules
Support for 100/133 MHz memory bus
Maximum installed memory is 2 x 512M = 1G
Expansion Slots
One AMR slot for a special audio/modem riser card
Three 32-bit PCI slots for PCI 2.2-compliant bus interface.
One 8/16-bit ISA slot.
Onboard IDE c annels
Primary and Secondary PCI IDE channels
Support for PIO modes, us Mastering and Ultra DMA
33/66/100 (optional VT82C686 ) modes
Power Supply and Power Management
ATX power supply connector
ACPI and previous PMU support, suspend switch
Supports Wake on LAN and Wake on Alarm
Built-in Grap ics System
Onboard 64-bit 2D/3D graphic engine and Video
Accelerator with advanced DVD video
2 to 8 M frame buffer use system memory
Supports high resolutions up to 1600x1200
2

1: Introduction
AC97 Codec
Compliant AC97 2.1 specification
Supports 18-bit ADC (Analog Digital Converter) and DAC
(Digital Analog Converter) as well as 18-bit stereo full-
duplex codec
Built-in Et ernet LAN
10B seT/100B seTX Ethernet LAN
LAN controller integrates Fast Ethernet MAC and PHY
compliant with IEEE802.3u 100 ASE-TX, 10 ASE-T and
ANSI X3.263 TP-PMD standards
Compliant with ACPI 1.0 and the Network Device Class
Power Management 1.0
High Performance provided by 100Mbps clock generator
and data recovery circuit for 100Mbps receiver
Onboard I/O Ports
Provides PC99 Color Connectors for easy peripheral device
connections
Floppy disk drive connector with 1Mb/s transfer rate
One serial ports with 16550-compatible fast UART
One parallel port with ECP and EPP support
Two US ports, and optional two US ports module
Two PS/2 ports for keyboard and mouse
One infrared port connector for optional module
Hardware Monitoring
uilt-in hardware monitoring for CPU & System
temperatures, fan speeds and mainboard voltages
Onboard Flas ROM
Automatic board configuration support Plug and Play of
peripheral devices and expansion cards
uilt-in virus protection using Trend’s ChipAw yVirus
provides boot process virus protection.
3

Mainboard User’s Manual
Bundled Software
PC-Cillin2000 provides automatic virus protection under
Windows 95/98/NT/2000
SuperVoice is data, fax and voice communication software
Medi Ring T lk provides PC to PC or PC to Phone
internet phone communication
3Deep delivers the precise imagery and displays accurate
color in your monitor
WinDVD2000 is a DVD playback application (optional)
Dimensions
Micro ATX form factor (24.4cm x 19cm)
4

1: Introduction
Package Contents
Attention: This mainboard series includes two different models.
They are M787CLR (LAN Ready) and M787CR (without LAN).
Please contact your local supplier for your purchase model.
Each model will support different specification, list as below:
Model Specification
M787CLR Onboard LAN chip (U800) and LAN (RJ45)
connector
M787CR ---
Your mainboard package ships with the following items:
The mainboard
This User’s Guide
1 UDMA/66 IDE cable
1 Floppy disk drive cable
Support software on CD-ROM disk
Optional Accessories
You can purchase the following optional accessories for this
mainboard.
Extended US module
AMR Fax/Modem card
5

Mainboard User’s Manual
Static Electricity Precautions
Components on this mainboard can be damaged by static
electricity. Take the following precautions when unpacking the
mainboard and installing it in a system.
1. Keep the mainboard and other components in their original
static-proof packaging until you are ready to install them.
2. During installation, wear a grounded wrist strap if possible. If
you don’t have a wrist strap, discharge static electricity by
touching the bare metal of the system chassis.
3. Handle the mainboard carefully by the edges. Avoid touching
the components unless it is absolutely necessary. During
installation put the mainboard on top of the static-protection
packaging it came in with the component side facing up.
Pre-Installation Inspection
1. Inspect the mainboard for damage to the components and
connectors on the board.
2. If you suspect that the mainboard has been damaged, do not
connect power to the system. Contact your mainboard vendor
and report the damage.
6

2: Mainboard Installation
Chapter 2
Mainboard Installation
To install this mainboard in a system, follow the procedures in this
chapter:
Identify the mainboard components
Install a CPU
Install one or more system memory modules
Verify that any jumpers or switches are set correctly
Install the mainboard in a system chassis (case)
Connect any extension brackets or cables to the mainboard
connector headers
Install any other devices and make the appropriate connections to
the mainboard connector headers.
Note:
1. efore installing this mainboard, make sure the jumper J AT1
is set to Normal setting. See this chapter for information on
locating J AT1 and the setting options.
2. Never connect power to the system during installation. Doing
so may damage the mainboard.
7

Mainboard User’s Manual
Mainboard Components
Use the diagram below to identify the major components on the
mainboard.
Note: Any jumpers on your mainboard that do not appear in
this illustration are for testing only.
I/O Ports
The illustration below shows a side view of the built-in I/O ports
on the mainboard.
8

DIMM2
DIMM1
2: Mainboard Installation
Install Memory
The mainboard has two DIMM sockets for system memory
modules. You must install at least one memory module in order to
use the mainboard.
For this mainboard, you must use 168-pin, 3.3V unbuffered PC100
or PC133 SDRAM memory modules. You can install any size
memory module from 32 M to 512 M , so the maximum
memory size is 2 x 512 M = 1 G .
The edge connectors on the memory modules have cut outs, which
coincide with spacers in the DIMM sockets so that memory
modules can only be installed in the correct orientation.
To install a module, push the retaining latches at either end of the
socket outwards. Position the memory module correctly and insert
it into the DIMM socket. Press the module down into the socket so
that the retaining latches rotate up and secure the module in place
by fitting into notches on the edge of the module.
9

1
Mainboard User’s Manual
Setting umper Switches
Jumpers are sets of pins which can be connected together with
jumper caps. The jumper caps change the way the mainboard
operates by changing the electronic circuits on the mainboard. If a
jumper cap connects two pins, we say the pins are SHORT. If a
jumper cap is removed from two pins, the pins are OPEN.
Jumper JBAT1: Clear CMOS Memory
Use this jumper to clear the contents of the CMOS memory. You
may need to clear the CMOS memory if the settings in the Setup
Utility are incorrect and prevent your mainboard from operating.
To clear the CMOS memory, disconnect all the power cables from
the mainboard and then move the jumper cap into the CLEAR
setting for a few seconds.
Function Jumper Setting
Normal Operation Short Pins 1-2
Clear CMOS Memory Short Pins 2-3
Jumper J2: Codec Selector
Use this jumper to select the onboard audio codec or Audio
Modem Riser (AMR) slot.
Function Jumper Setting
Primary codec onboard Short Pins 1-2
Primary Codec on AMR slot Short Pins 2-3
10
JP800
JP96
1
JBAT1
1
JP95
1
JMIC1
J2
1

2: Mainboard Installation
Jumper JP95: BIOS Write Protect Selector
Use this jumper to make the IOS read-only.
Function Jumper Setting
Enable read only) Short Pins 1-2
Disable Short Pins 2-3
Jumper JP96: Keyboard Power On Selector
If you enable the keyboard power on feature, you can use hot keys
on your keyboard as a power on/off switch for the system.
Note: The system must provide 1A on the +5VSB (+5V Standby)
signal before using the Keyboard ower On function.
Function Jumper Setting
Disable Keyboard Power On Short Pins 1-2
Enable Keyboard Power On Short Pins 2-3
Jumper JP800: Enable/Disable Onboard LAN
The mainboard has a built-in 10 aseT/100 aseTX network
adapter. If you plan on using an alternative network adapter, you
must use this 3-pin jumper to disable the onboard network adapter.
Function Jumper Setting
Disable Onboard LAN Short Pins 1-2
Enable Onboard LAN Short Pins 2-3
Jumper JMIC1: Microp one Type Selector
Use this jumper to select the microphone type that passive one or
the active one input audio to the sound system.
Function Jumper Setting
Passive Microphone Short Pins 1-2
Active Microphone Open Pins 1-2
11

JFAN2
Mainboard User’s Manual
Install the Mainboard
Install the mainboard in a system chassis (case). The board is a
micro ATX size mainboard with a twin-tier of I/O ports. Ensure
that your case has an I/O cover plate that matches the ports on this
mainboard.
Install the mainboard in a case. Follow the instructions provided by
the case manufacturer using the hardware and internal mounting
points on the chassis.
Connect the power connector from the power supply to the ATX
connector on the mainboard.
If there is a cooling fan installed in the system chassis, connect the
cable from the cooling fan to the JFAN2 fan power connector on
the mainboard.
If there are a microphone-in jack and/or a speaker-out jack on the
front pannel, connect the cables from the microphone-in and
speaker-out jacks to the PANEL2 header on the mainboard. Then
set the jumper JMIC1 to open setting.
Connect the case switches and indicator LEDs to the PANEL1
switch and LED connector header. See the illustration below for a
guide to the header
pin assignments.
12
PANEL1
ATX
22
21
Power LED
Pins 2-4-6
peaker
Pins 1-3-5-7
HDD LED
Pins 15-16
2
1
Reset witch
Pins 17-18
Power Button
Pins 21-22
uspend LED
Pins 19-20
PANEL2
LineOut
-L 1
-R 5
LineOut
2 MICIN
4 GND
6 MICP

2: Mainboard Installation
Optional Extension Brackets
For this mainboard, you can also obtain a US module extension
bracket. Install them by following the steps below.
Extended USB Module
This module bracket has two US ports for more US devices
(US port 3-4).
1. Locate the US 1 header on the mainboard.
2. Plug the bracket cable onto the header.
3. In the system chassis, remove a slot cover from one of the
expansion slots and install the extension bracket in the
opening. Use the screw that held the slot cover in place to
secure the extension bracket to the chassis.
Install Other Devices
Install and connect any other devices in the system following the
steps below.
13
1
1
IDE1
IDE2
U B1 Header
VCC
NC
UV-
UV+
GND
GND
UV+
UV-
NC
VCC
FDD1
1

Mainboard User’s Manual
Floppy Disk Drive
The mainboard ships with a floppy disk drive cable that can
support one or two drives. Drives can be 3.5” or 5.25” wide, with
capacities of 360K, 720K, 1.2M , 1.44M , or 2.88M .
Install your drives and connect power from the system power
supply. Use the cable provided to connect the drives to the floppy
disk drive header FDD1.
IDE Devices
IDE devices include hard disk drives, high-density diskette drives,
and CD-ROM or DVD-ROM drives, among others.
The mainboard ships with an IDE cable that can support one or
two IDE devices. If you connect two devices to a single cable, you
must configure one of the drives as Master and one of the drives as
Slave. The documentation of the IDE device will tell you how to
configure the device as a Master or Slave device. The Master
device connects to the end of the cable.
Install the device(s) and connect power from the system power
supply. Use the cable provided to connect the device(s) to the
Primary IDE channel connector IDE1 on the mainboard.
If you want to install more IDE devices, you can purchase a second
IDE cable and connect one or two devices to the Secondary IDE
channel connector IDE2 on the mainboard. If you have two
devices on the cable, one must be Master and one must be Slave.
Internal Sound Connections
If you have installed a CD-ROM drive or DVD-ROM drive, you
can connect the drive audio cable to the onboard sound system.
On the mainboard, locate the two 4-pin connectors CDIN1 and
CDIN2. There are two kinds of connector because different brands
of CD-ROM drive have different kinds of audio cable connectors.
Connect the cable to the appropriate connector.
14
CDIN1
CDIN2

2: Mainboard Installation
Infrared Port
You can connect an infrared port to the mainboard. You can
purchase this option from third-party vendors.
1. Locate the infrared port IR header on the mainboard.
2. If you are adding an infrared port, connect the ribbon cable
from the port to the header and then secure the port to an
appropriate place in your system chassis.
Expansion Slots
This mainboard has three 32-bit PCI expansion slots, one AMR
slot and one 8/16-bit ISA slot.
Follow the steps below to install a PCI/AMR/ISA expansion card.
1. Locate the AMR, PCI or ISA slots on the mainboard.
2. Remove the slot cover for this slot from the system chassis.
3. Insert the expansion card edge connector into the slot and press
it firmly down into it so that it is fully inserted.
4. Secure the expansion card bracket to the system chassis using
the screw that held the slot cover in place.
15
AMR1
I A1
PCI2
PCI4
PCI3 PCI1
PCI3
J1-IR Header
VCC 1
NC 2
IRRX 3
GND 4
IRTX 5

Mainboard User’s Manual
AMR Slot
The AMR (Audio Modem Riser) slot is an industry standard slot
that allows for the installation of a special audio/modem riser card.
Different territories have different regulations regarding the
specifications of a modem card. You can purchase an AMR card
that is approved in your area and install it directly into the AMR
slot.
Wake On Modem (WOM)
You can configure your system so that it powers down by software
and can be resumed by alarms. If you have installed a fax/modem
card, connect the fax/modem to the Wake On Modem header
WOM1. You can then use the setup utility to program your
computer to resume from a power saving mode whenever there is
an incoming call to the fax/modem.
Wake On LAN (WOL)
If you have installed a LAN adapter expansion card, connect the
card to the Wake On LAN connector WOL1. This allows
incoming traffic to resume the system from a software power
down. You need to enable this feature in the system setup utility.
16
WOM1
Header
WOL1
Header
