Peak Performance PKC0BM Instruction Manual

T
M
150 Watt Cup
Power Inverter
Model No.: PKC0BM
Owner’s Manual
and Warranty Information
15
Read these instructions completely before using this product.
Retain this Owner’s Manual for future reference.

INTRODUCTION
This 150 Watt Cup Power Inverter can be used to operate personal electronic devices and portable
office equipment with a combined, continuous power requirement of 150 watts maximum.
When using the Power Inverter in a vehicle, check the vehicle owner’s manual for maximum power• rating and recommended output.
Only connect the Power Inverter to a vehicle when the vehicle is parked. Do not connect the• power plug while driving the vehicle.
Read and understand this Owner’s Manual before using the Power Inverter.• Install and operate the Power Inverter only as described in this Owner’s Manual.•
FEATURES
Compact cup design for safer use, transport and storage• LED operation indicators• In-line replaceable fuse• Connects to a 12-volt cigarette lighter/accessory socket• Two North American Standard 110/120-volt AC receptacles• Two USB power outlets• Self-closing lid•
15
1
10
2
3
4
5
6
8
9
7
Legend
Self-Closing Lid1. North American Standard 110/120-volt AC Receptacles (2)2. USB Power Outlets (2)3. Red LED Fault Indicator Light4. ON/OFF Switch5. Blue Power Indicator LED6. Cooling Vents7. In-Line 15-Amp Fuse8. 12-volt DC Power Plug9. Fan10.

OPERATION
The Power Inverter converts 12-volt DC (direct current) input voltage to 110/120-volt, 60 Hz AC
(alternating current) power.
The Inverter produces a “modified sine wave.” The modified sine wave is suitable for most AC
powered appliances and personal electronic devices.
The following devices may not work with a modified sine wave:
Photocopiers, laser printers, magneto-optical hard drives• Some laptops• Metal halide arc (MHI) lights• Some fluorescent lights with electronic ballasts• Power tools that use solid-state power• Fans and power tools that use variable speed controls• Some new furnaces and pellet stoves with microprocessor control• Digital radios and clocks• Sewing machines with speed/microprocessor control• Electronics that modulate radio frequency signals on the AC line• X-10 home automation systems• Oxygen concentrators and other medical equipment•
Most battery chargers can be connected to the AC receptacle. Battery chargers that use separate
transformers or chargers that plug into the AC receptacle to supply a low-voltage DC-to-AC output
should work. However, battery chargers for small nickel-cadmium batteries can be damaged if plugged
into the Inverter.
The following appliances or devices could be damaged if plugged into the Inverter:
Small battery operated appliances that can be plugged directly into the AC receptacle such as• flashlights, cordless razors and toothbrushes
Certain battery chargers for cordless tool battery packs. These chargers can be identified by a• warning label stating dangerous voltages are present at the battery terminals.
Monitor the temperature of the battery charger for about 10 minutes. If the battery
charger becomes abnormally warm, disconnect it from the Power Inverter immediately.
If you are unsure about powering any appliance or device with the Inverter, contact the manufacturer
or consult the owner’s manual of the device.
Power Source
The 12-volt cigarette lighter/accessory socket must provide between 10.5 and 15 volts DC and must
be able to provide sufficient current (in amperes) to operate the device.
Do not exceed the maximum input voltage of 15 volts DC. The Inverter could be
damaged.
Positioning of Power Inverter
Allow at least one inch (25 mm) of clearance around the Inverter to allow for airflow. Always use the
Inverter where there is adequate ventilation. Do not block cooling vents or the fan.
FIRE HAZARDS
• Do not place the Inverter near flammable materials or in any location that may accumulate
flammable fumes or gases.
Do not expose the Inverter to extreme heat or flames. The surrounding air temperature• should be between 50° and 86°F (10° and 30°C). Do not place the Inverter on or near a
heating vent or any equipment which is generating heat above room temperature. Do not
place the Power Inverter in direct sunlight.
ELECTROCUTION HAZARD
Do not operate the Power Inverter if it is wet. Do not allow water, moisture or other liquids to
come in contact with the Power Inverter, the device being operated or the power source.
Connecting to 12-volt Cigarette Lighter/Accessory Socket
Do not use with positive ground electrical systems. Connecting the Inverter to a
positive ground electrical system will damage the Inverter. Only use the Power Inverter on
negative ground electrical systems. If in doubt, check with your vehicle dealer or consult the
vehicle’s owner’s manual.
To connect the Power Inverter:
Make sure the ON/OFF switch is in the OFF (O) position and all devices are disconnected from1. the Power Inverter.

Plug the power plug into the 12-volt cigarette lighter/accessory socket.2. Rotate the power plug to make good contact with the socket.3. The blue power indicator LED will light continuously, indicating that the Inverter is connected to a4. power supply.
Connecting a Load to the Power Inverter
The Power Inverter is capable of delivering up to 150 watts of power output. Do not
exceed 150 continuous watts when the Inverter is connected to the 12-volt cigarette lighter/
accessory socket. The Inverter could be damaged.
If the Power Inverter does not work, verify that the 12-volt cigarette lighter/accessory
socket is powered. The ignition switch may have to be turned on to power the socket.
Do not operate high wattage appliances or equipment that will produce heat, such
as hair dryers, irons, heaters and toasters, with this Inverter.
The manufacturer provides a label with power consumption information in watts or amps for their
product. If the item’s power consumption is not indicated in watts, but in amps AC, multiply the amp
AC value by 120 (AC volts) to determine the wattage.
When you turn on an appliance or device, it will require twice the rated wattage
of the appliance or device to start. This is known as the“starting load” or“peak load.” To
determine the starting load or peak load, multiply the rated wattage by two. If this exceeds the
peak surge output of the Inverter, do not operate the appliance or device with the Inverter.
The Power Inverter can operate a resistive load device or an inductive load device.
Operating a resistive load device is the easiest for the Inverter. However, the Inverter will not operate
larger resistive load devices.
TVs and stereos are inductive load devices (devices with a coil or transformer). They may require
more current to operate than a resistive load device of the same wattage rating. The Inverter will not
operate larger inductive load devices.
Operating the 110/120-volt AC Receptacle
Switch the inverter ON/OFF switch to the ON (1. I) position. The ON/OFF switch will illuminate,
indicating the Inverter is functioning.
Plug the device into the 110/120-volt AC receptacle.2. Switch the device on.3. Monitor the temperature of the device for the first 10 minutes of operation to
determine its temperature. If the temperature of the device becomes excessively hot, it is an
indication that the device should not be used with this Inverter.
When shutting down, first turn the power of the appliance or device off.4. Remove the power plug from the Inverter’s 110/120-volt AC receptacle.5. Switch the ON/OFF switch to the OFF (O) position.6. Disconnect the Power Inverter from the 12-volt cigarette lighter/accessory socket.7. Always disconnect the Power Inverter from the 12-volt cigarette lighter/accessory
socket when the Power Inverter is not in use.
Operating the USB Power Outlet
The USB power outlets do not support data communication. The outlets have a
maximum of 5 volts/500mA DC power each to an external USB-powered device.
The USB power outlets are unswitched outlets. Whenever the Inverter is connected
to a power source, there will be power to the USB outlets.
Connect the USB-powered device into the USB power outlet.1. Switch the device on.2. When shutting down, first turn the power of the device off.3. Disconnect the USB-powered device from the USB power outlet.4. Disconnect the Power Inverter from the 12-volt cigarette lighter/accessory socket.5. Always disconnect the Power Inverter from the 12-volt cigarette lighter/accessory
socket when the Power Inverter is not in use.

Protective Features
Low-Voltage Shutoff (Red LED will light) – The Inverter will automatically shut down in case of low
voltage (prevents the battery from total discharge). The Inverter will automatically reset itself and start
back up if the voltage increases.
Overload Protection (Red LED will light) –The Inverter will automatically shut down if the
continuous current draw exceeds the maximum rating. The Inverter will automatically reset itself and
start back up if the current draw decreases below the maximum rating.
To manually reset the Inverter:
Turn off the device and unplug it from the Inverter.1. Turn the ON/OFF switch on the Inverter to the OFF (O) position.2. Turn the ON/OFF switch to the ON (3. I) position.The red LED light should not be lit.
Verify the wattage of the device(s) before plugging back into the Inverter.4.
High-Temperature Safety Shutoff (Red LED will light) - If the unit’s temperature exceeds 149°F
(65°C), it will switch off automatically and the red LED fault light will come on. After unplugging the
Inverter and letting it cool down for about 15 minutes, the Inverter can be used again.
Common Problems
Buzzing in audio systems - Some inexpensive stereo systems will emit a buzzing sound from their
speakers when operating from the Inverter. This is because the power supply in the device does not
adequately filter the modified sine wave produced by the Inverter.
Television interference -The Inverter is shielded and filtered to minimize interference with TV
signals. In some cases, especially with weakTV signals, some interference may be visible. Try the
following corrective measures:
Position the Inverter as far away as possible from the television, the antenna and the antenna• cable.
Adjust the orientation of the Inverter, the antenna cable and the TV power cable to minimize• interference.
Use high-quality, shielded antenna cable.•
CARE AND MAINTENANCE
Storage
Store and use this Power Inverter in a cool, dry area and keep it away from direct sunlight, heat,
excessive humidity and dampness.
Cleaning
Do not clean or wipe the Power Inverter with solvents or chemical materials. If necessary, remove dirt
or stains using a soft cloth dampened with a mild detergent solution.
Fuse Replacement
Turn off the Inverter and disconnect any devices from the Inverter.1. Unplug the Inverter from the power source.2. Pull the fuse straight out of the holder.3. Replace with a new 15-amp spade-type fuse.4.

SPECIFICATIONS
1. DC Input Voltage 10.5-15V
2. AC Output Voltage 105-125V
3. AC Receptacle Two 110/120V AC North American
Standard Receptacles
4. Maximum Continuous Power 150W
5. USB Output DC Two 5V/500mA
6. Efficiency ≥85%
7. No Load Current Consumption ≤500mA
8. High Input Voltage Limit 15 ± 0.3V (red LED is on)
9. Short Circuit and Reverse Polarity Protection 1 x 15A spade fuse
10. Signal Format/Output Modulated sine wave 60Hz ± 2Hz
11. Working Temperature 50°F to 86°F (10°C to 30°C)
12. Storage Temperature -4°F to 185°F (-20°C to 85°C)
13. Storage Air Humidity 10%-90%
TROUBLESHOOTING
Problem Situation Action
Low output
voltage Inverter is overloaded Do not exceed maximum load rating for the Inverter.
Input voltage is below
10.5 volts Increase input voltage above 10.5 volts to maintain regulation.
No power
output 12-volt cigarette lighter/ accessory socket needs
ignition to be on
Turn ignition to ACC position.
Battery voltage below
10 volts Recharge or replace battery.
Equipment being
operated draws too
much power
Reduce load; DO NOT exceed maximum rating for the
Inverter.
Inverter in thermal
shutdown condition Allow Inverter to cool down. Ensure there is adequate ventilation around the Inverter. Ensure that load is no more
than its maximum rating for continuous operation.
AC output is shorted Check condition of power plug and 12-volt cigarette lighter/
accessory socket. Clean or replace as necessary.
Fuse is blown Check fuse and replace as necessary.
