SMA SB 4200TL HC User manual

SUNNY BOY 4200TL HC / SB 5000TL HC
PV Inverter
Installation Guide Version 1.1 SBTLHCMS-IEN080411
IME-SB42-50-TLHC

SMA Technologie AG Table of Contents
Installation Guide SBTLHCMS-IEN080411 Page 3
Table of Contents
1 Explanation of the Symbols Used . . . . . . . . . . . . 5
2 Foreword. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2. 1 Target Group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2. 2 Appropriate Usage. . . . . . . . . . . . . . . . . . . . . . . . . 8
2. 3 Validity of the Documentation . . . . . . . . . . . . . . . . . 8
3 Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . 9
4 overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4. 1 Unit Description . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4. 2 External dimensions . . . . . . . . . . . . . . . . . . . . . . . 12
5 Installation Requirements. . . . . . . . . . . . . . . . . . 13
5. 1 Installation Site Requirements . . . . . . . . . . . . . . . . . 13
5. 2 PV Generator Requirements . . . . . . . . . . . . . . . . . . 15
5. 3 Low-voltage Grid (AC) . . . . . . . . . . . . . . . . . . . . . 16
5.3. 1 Line Losses. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
6 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
6. 1 Mounting the Unit. . . . . . . . . . . . . . . . . . . . . . . . . 21
6. 2 Electrical Installation . . . . . . . . . . . . . . . . . . . . . . . 22
6.2. 1 Connecting the AC Output . . . . . . . . . . . . . . . . . . . . . . . . . . .24
6.2. 2 PV String (DC) Connection . . . . . . . . . . . . . . . . . . . . . . . . . . .26
6. 3 Startup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
7 Opening and Closing the Sunny Boy . . . . . . . . 31
7. 1 Opening the Sunny Boy . . . . . . . . . . . . . . . . . . . . 31
7. 2 Closing the Sunny Boy . . . . . . . . . . . . . . . . . . . . . 32
8 Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . 33
8. 1 PV generator connection data . . . . . . . . . . . . . . . . 33
8. 2 Grid connection data . . . . . . . . . . . . . . . . . . . . . . 34

Table of Contents SMA Technologie AG
Page 4 SBTLHCMS-IEN080411 Installation Guide
8. 3 General Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
8. 4 Operating parameters . . . . . . . . . . . . . . . . . . . . . 38
8.4. 1 Explanation of the Operating Parameters . . . . . . . . . . . . . . . . .38
8.4. 2 Parameter settings for Germany. . . . . . . . . . . . . . . . . . . . . . . .41
8.4. 3 Country-specific Parameter Settings . . . . . . . . . . . . . . . . . . . . .43
8.4. 4 Non-modifiable Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . .43
9 Inspection of the Electronic Solar Switch . . . . . . 45
10 Replacing the Varistors . . . . . . . . . . . . . . . . . . . 47
11 Rating for a Line Circuit Breaker . . . . . . . . . . . . 51
12 The Communications Interface . . . . . . . . . . . . . . 53
12. 1 Connection RS232, RS485, Radio Piggy-Back. . . . . 54
12.1. 1 Jumper Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
12. 2 Powerline Connection . . . . . . . . . . . . . . . . . . . . . . 56
13 Contact. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

SMA Technologie AG Explanation of the Symbols Used
Installation Guide SBTLHCMS-IEN080411 Page5
1 Explanation of the Symbols Used
To ensure optimum use of this document, note the following explanation of the symbols
used.
This symbol indicates an example.
This symbol indicates a notice which, if ignored, will make the procedure or oper-
ation more difficult.
This symbol indicates a fact which, if not observed, could result in damage
to components or represent a danger to persons. Read these passages es-
pecially carefully.

Explanation of the Symbols Used SMA Technologie AG
Page 6 SBTLHCMS-IEN080411 Installation Guide

SMA Technologie AG Foreword
Installation Guide SBTLHCMS-IEN080411 Page7
2 Foreword
For detailed information on troubleshooting and on how to use the Sunny Boy and the
various communications options, please see the operating instructions.
"Sunny Design" helps you design the system and check string size taking the relevant
inverter into consideration. Further information on Sunny Design is available at
www.SMA.de.
If you require further information, please call the SMA Service Line on the following
number:
(0561) 95 22 - 499
2. 1 Target Group
This installation manual is intended solely for qualified personnel. Its aim is to help install
and set up SMA inverters type “SB 4200TL HC Multi-String“ or “Sunny Boy SB 5000TL
HC Multi-String“ quickly and correctly.
The Sunny Boy inverters are equipped with the "SMA grid guard". This is a type
of automatic disconnection device. It ensures that the Sunny Boy complies with the
VDEW (Verband der Elektrizitätswirtschaft – German Electricity Industry Associa-
tion) regulations for the connection and parallel operation of electrical power units
to the low-voltage grid of the electricity supply company and with DIN VDE 0126-
1-1, which forms a part of these regulations.
Notice!
The Sunny Boy may only be installed by qualified personnel. The installer
must be approved by the local energy supplier. Read this "installation
guide" carefully. All prescribed safety regulations, the technical connec-
tion requirements of the local energy supplier and all applicable provi-
sions must be adhered to.

Foreword SMA Technologie AG
Page 8 SBTLHCMS-IEN080411 Installation Guide
2. 2 Appropriate Usage
The Sunny Boy is designed for operation in grid-connected PV systems. Any other use
of the leads to loss of the right to all warranty claims and may lead to a fault in the
device. This includes, among other things, the operation at voltage sources without any
current limit. When in doubt, contact SMA.
Plant Design
The Sunny Boy may only be operated with PV-generators (Modules and according ca-
bles) with protection class II.
It is mandatory to ensure that all components will operate within the specified operating
range. The free design tool "Sunny Design" (www.SMA.de/SunnyDesign) will help you
with this.
The manufacturer of the modules should have approved the modules for operation with
this Sunny Boy. It is furthermore advisable to implement all measures for maintaining the
module performance (see also Application Note 2 "Module Technology" in the down-
load area of www.SMA.de).
2. 3 Validity of the Documentation
The Sunny Boy SB 4200TL HC Multi-String and Sunny Boy SB 5000TL HC Multi-String
are identical except for the technical data. The devices are referred to as Sunny Boy in
case the information applies for both models. The full device name is used in case of
device specific information.

SMA Technologie AG Safety Instructions
Installation Guide SBTLHCMS-IEN080411 Page9
3 Safety Instructions
Caution! Overvoltage!
Check the system design using the "Sunny Design" design tool
(www.SMA.de) or by calling the SMA Service Line. Overvoltage damages
the Sunny Boy and results in the exclusion of all warranty claims!
Warning! High voltages!
Work on the Sunny Boy with the cover removed must be carried out by a
qualified electrician. High voltages are present in the device. Before work-
ing on the Sunny Boy with the cover removed, the AC and DC voltages
must be disconnected from the Sunny Boy and the capacitors must be dis-
charged.
The Sunny Boy must be disconnected from the mains grid and precautions
must be taken to prevent the grid being inadvertently reconnected. In ad-
dition, the connections to the PV generator must be disconnected.
After isolating the AC and DC voltage, you must wait approx. 30 minutes
for the capacitors in the Sunny Boy to discharge. Only then is it safe to
open the unit by removing the cover. You must also make sure that no
voltage is present in the device.
Caution! Electrostatic charge!
When working on the Sunny Boy and handling the components, remem-
ber to observe all ESD safety regulations. Electronic components are vul-
nerable in terms of electrostatic charge. Discharge any electrostatic
charge by touching the grounded enclosure before handling any electron-
ic component.
Notice! Entry of water and dirt!
Once the handle of the Electronic Solar Switch has been pulled out, the
Sunny Boy provides protection degree IP21. The Sunny Boy is then no
longer protected against water and contamination with dirt!
Grounding the PV generator
Pay attention to local regulations for the grounding of the modules and the PV-
generator. SMA reccomends to electrically bond the module frames, the racks
and all metal surfaces and ground these in order to have optimal protection of the
system and personnel.
