DSEE050 Installation Instructions
These instructions are intended as a quick guide only. For complete instructions and
specifications, refer to DSE publication 057-300 DSEE050 Operator Manual available
from www.deepseaelectronics.com.
NOTE: Cables / wires must be installed as indicated to prevent liquid (water)
entering the device. Part number of suitable connectors / blanking plugs are given
overleaf and detailed in DSE publication 057-300 DSEE050 Operator Manual
available from www.deepseaelectronics.com.
CONFIGURATION
NOTE: DSEE050 is supplied with Factory (Default) Settings to suit most
J1939 compatible engine ECUs. Due to the configurable nature of the device this
is subject to change as required by the supplier. Contact supplier or consult the
device configuration source for full details of the configured instrumentation.
NOTE: For details of module configuration, refer to DSE Publication: 057-299
DSEE050 Configuration Suite PC Software Manual.
For configuration of the device, a PC USB to CAN Interface is required. Detailed below.
The device driver is supplied with the interface and is further available at the website
listed in the table below.
Manufacturer
Part Number
Description
PEAK-System Technik GmbH
https://www.peak-system.com/
IPEH-002021
PCAN-USB
IPEH-002022
PCAN-USB Opto-Isolated
Deep Sea Electronics Ltd.
Tel: [phone]
[e-mail]
Web: www.deepseaelectronics.com
Deep Sea Electronics Inc.
Tel: [phone]
Fax: [phone]
[e-mail]
Web: www.deepseaelectronics.com
053-242 ISSUE 1

DIMENSIONS
Description
Specification
Overall Dimensions (Height x Width x Depth)
112.5 mm x 115.0 mm x 49.0 mm
(4.43 ” x 4.53 ” x 1.93 ”)
Mounting Type
Fascia Mount
Overall Weight
<1 kg
(2.2 lb)
Panel Cut-Out diameter
82 mm
(3.23 ”)
Panel Cut-Out Flat Side Dimension
76.0 mm
(2.99 “)
Fascia Tightening Torque to prevent distortion
of the sealing gasket and subsequent seal
failure / mechanical damage to the controller.
8 Nm Maximum
(5.9 ft. lb Maximum)
CONNECTORS, HARNESSES AND SPARE PARTS
Description
DSE Part
Manufacturer Part
Manufacturer
DSEE050 Connector A
007-850
DT16-18SA-K004
TE / Deutsch
Connector Pin Crimp
(0.5 mm2 to 1.0 mm2)
N/A
0462-201-16
TE
Connector Pin Crimp
(2 mm2)
0462-209-16
TE
DSEE050 Connector
Harness Kit
016-176
N/A
DSE
DSEE050 Connector
Configuration Harness.
016-177
N/A
DSE
Pin Blank Inserts (Seals
unused connector pins)
N/A
114017
TE
Belden 9841 (CAN Cable)
016-030
9841
Belden
PCAN-USB PC
Configuration Interface
N/A
IPEH-002021 or
IPEH-002022
PEAK-System
Technik GmbH
Rear Case Ring Nut
020-1058-01
N/A
DSE
