peerless-AV KL546-TOSHIBA02 Guide

ISSUED: 03-27-12 SHEET #:125-9290-4 03-11-14
Visit the Peerless Web Site at www.peerless-av.com For customer care call 1-800-865-2112 or 708-865-8870.
1 of 5
Installation and Assembly:
Indoor Digital Signage/Kiosk Enclosure - Landscape
Model: KL546-TOSHIBA02
Maximum Load Capacity:
75 lb (28 kg)

ISSUED: 03-27-12 SHEET #:125-9290-4 03-11-14
Visit the Peerless Web Site at www.peerless-av.com For customer care call 1-800-865-2112 or 708-865-8870.
2 of 5
B
E
H
D
G
C
F
I
A
Parts List
Part #Description Qty
Akiosk 1 201-1027
BM5 x 12mm 4 520-1027
CM5 x 25mm 4 520-9543
DM6 x 12mm 4 520-1128
EM6 x 25mm 4 520-1208
FM8 x 12mm 4 520-9571
GM8 x 25mm 4 520-1031
HM5/M6/M8 washer 4 580-1398
Ispacer 4 540-1059
Jkey (not shown) 3 565-0049A

ISSUED: 03-27-12 SHEET #:125-9290-4 03-11-14
Visit the Peerless Web Site at www.peerless-av.com For customer care call 1-800-865-2112 or 708-865-8870.
3 of 5
Open the top cover of kiosk (A). The adapter
plate inside kiosk (A) can be adjusted vertically
buy loosening the knobs shown in detail 1.
Remove adapter brackets from kiosk (A) as
shown.
TOP COVER
1
DETAIL 1
KNOB
2
Attach adapter brackets to back of display using four screws (B,C,D,E,F or G) and washer (H). Spacer (I) may be
used between the adapter bracket and display to provide additions space. as shown in detail 2.
NOTE: Some displays may have offset hole patterns. When using offset hole patterns make sure that adapter
brackets are centered on back of display.
3
Attaching Adapter Brackets to Display
300 mm
MAX VESA-600 mm
MIN VESA-200 mm
400 mm
BACK VIEW
DISPLAY
B,C,D,E,F,or G
H
DETAIL 2
200 mm
Adapter Brackets
Display

ISSUED: 03-27-12 SHEET #:125-9290-4 03-11-14
Visit the Peerless Web Site at www.peerless-av.com For customer care call 1-800-865-2112 or 708-865-8870.
4 of 5
Reattach adapter brackets with display onto
channels in the kiosk. Adapter brackets and display
can be adjusted horizontally.
CHANNEL
TOP COVER
4

ISSUED: 03-27-12 SHEET #:125-9290-4 03-11-14
Visit the Peerless Web Site at www.peerless-av.com For customer care call 1-800-865-2112 or 708-865-8870.
5 of 5
IN OUT
TILT BACKWARD TILT RIGHT TILT LEFT
TILT FORWARD
Use legend below to determine position of display.
NOTE: Each knob can be adjusted independently for ne tuning adjustments.
5
Turn knob CLOCKWISE to tighten
Turn knob COUNTER-CLOCKWISE to loosen
Adapter Assembly Adjustment
